Secure, reliable
108 Mbps PoE wireless
connectivity in a
cost-e ective access
point with advanced
enterprise-class
eatures and dual
radios
DATA SHEET
OVERVIEW
The 3Com®Wireless 8760 Dual-Radio 11a/b/g PoE Access Point is a
Power over Ethernet (PoE) wireless solution for enterprises of all sizes.
This fully-featured dual-radio access point functions simultaneously
with an IEEE 802.11b/g and an IEEE 802.11a radio and provides ultra-
fast speeds of up to 108 Mbps. Advanced security features such as Wi-Fi
Protected Access (WPA/ WPA2), Wired Equivalent Privacy (WEP) and
Open System are included. This access point also provides multiple SSID
support and VPN passthrough along with VLAN support.
KEY BENEFITS
ENABLING WIRELESS FREEDOM
Take advantage of the freedom of high-speed networking without wires
with the Wi-Fi CERTIFIED 3Com Wireless 8760 Dual-Radio 11a/b/g PoE
Access Point. Wireless LANs (WLANS) are an attractive solution for
cost-effectively and securely extending mobile access to wired network
resources or creating full-featured networks in small and medium
businesses, remote sites, or temporary locations. Each access point (AP)
supports up to 64 wireless users per radio for a total of 128 users, leaving
plenty of room for growth.
PROVIDES PoE DEPLOYMENT FLE IBILITY
PoE support makes it easier than ever to overcome installation problems
by eliminating the need for an AC power plug at each AP. The 3Com
Baseline Switch 2426-PWR Plus or the Switch 4400/4500/5500 PWR or
other IEEE 802.3af-compliant PoE products supply both power and data
to the access points through Category 5 or 6 Ethernet cable, providing
flexible installation options in hard-to-wire locations. For convenience
a PoE adapter is supplied with the unit.
3Com®Wireless 8760 Dual-Radio 11a/b/g PoE Access Point
3Com Wireless 8760 Dual-Ra io 11a/b/g PoE Access Point

3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
2
KEY BENEFITS
(CONTINUED)
SECURES AND PROTECTS WIRELESS COMMUNICATIONS
This new access point delivers enterprise-class security to businesses
of all sizes. To shield wireless communications at the source, WPA and
WPA2 encryption provide the latest, toughest standards-based security;
WEP encryption is also supported. For additional protection, the
access point supports IEEE 802.1X and MAC address access control,
authentication and authorization through backend RADIUS servers.
PROVIDES FLE IBLE SECURITY AND ACCESS CONTROL
Configure and store up to four SSIDs with different security profiles
for groups of users. IEEE 802.1Q-compliant VLAN support works with
the multiple SSID feature to control access to network resources and
segment user traffic.
SOLVES COMPLE CONNECTIVITY PROBLEMS
The Wireless Distribution System bridging feature solves complex
wireless connectivity problems. The access point supports both point-
to-point and point-to-multipoint WDS links as well as repeater mode
for flexible network deployment.
OFFERS INVESTMENT PROTECTION
No reason to replace APs as the network grows. Unique 3Com stand-
alone-to-managed conversion method allows the 3Com 8760 AP to be
used in stand-alone mode, or easily converted to be managed by the
3Com Gigabit Unified Wireless PoE Switch and 3Com WX-series
wireless controllers and switch.
DELIVERS ENTERPRISE-CLASS FEATURES
3Com delivers superior business value by offering enterprise-class
solutions without the complexity. 3Com also backs each product with
global sales, service and support along with technology, financial and
operational strength.
FLE IBLE HIGH-SPEED CONNECTIVITY
Dual-radio support Supports and offers 802.11a and 802.11b/g radios.
High-speed access 802.11a and 802.11b/g standard supports speeds up to 108 Mbps.
Wi-Fi a/b/g CERTIFIED Helps ensure interoperability with Wi-Fi CERTIFIED products from other
vendors.
ROBUST SECURITY FEATURES
Encryption: WPA/WPA2, AES, TKIP Toughest industry-standard algorithms help keep wireless transmissions
and WEP private.
Multiple security profiles Store up to eight different security settings; up to four security profiles
per radio.
Multiple SSID support with SSIDs can be bridged together or isolated.
SSID isolation
Access control Screens device MAC addresses to ensure that only trusted clients gain
access to the WLA .
802.1Q VLA support Groups users according to data or traffic requirements to segment traffic
flow based on business priorities.
RADIUS server MAC-based and Centralizes wireless security through existing network RADIUS servers.
802.1X AAA support
FEATURES AND BENEFITS

3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
3
INSTALLATION AND MANAGEMENT CONVENIENCE
WDS bridge and repeater Multiple APs can function as bridges supporting point-to-point or multi-
configuration point modes; repeater mode extends wireless coverage.
PoE support Expands installation options by eliminating the need for power adapters
and AC outlets for APs.
Access Point Discovery program Automatically discovers AP devices to simplify configuration and management
(PCs with Windows based operating systems only).
S MP support Enables the AP to be centrally managed by popular standards-based
network management applications such as S MP v1, v2c and v3.
Syslog support Enables the AP to be centrally monitored by sending data to the network
Syslog server.
Web browser-based administration Familiar browser interface lets you configure and manage APs from
anywhere on the network.
Investment protection Use the AP as a stand alone unit, convert to managed functionality for
use with the 3Com Unified Wireless Switch, and then when needed,
convert to support 3Com WX-series wireless controllers and switch.
FEATURES AND BENEFITS (CONTINUED)
PoE Support
Choose from several power options to
match your installation nee s. First, the
PoE access point can be powere with
the supplie PoE injector.
The access point can also be powere
using an 802.3af-compliant PoE switch.
The switch provi es both ata an power
through the Ethernet cable.
Non-PoE switch
3CRWX120695AWireless LAN Switch WX1200 3CRWX120695AWirelessLANSwitchWX1200
EthernetData
EthernetData
and Power
3Com®Wireless8760 Dual-Radio
11a/b/gPoEAccessPoint
TOACCESSPOINT
TOHUB/SWITCH
Data and power
Ethernet
3Com Baseline
Switch 2426-PWR Plus
3Com
®Wireless8760Dual-Radio
11a/b/gPoEAccessPoint
Data and power Data only
Fast Ethernet switch
3Com Power over Ethernet
Multiport Midspan Solution
3Com
®Wireless8760Dual-Radio
11a/b/gPoEAccessPoint
The Mi span solution istributes power
to the PoE access point over existing
switch connections, seamlessly
exten ing network connectivity into
har -to-wire locations.

3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
4
WPA2clients
SSID1=WPA2
LegacyWEP clients
SSID2=WEP
3Com
®Wireless8760Dual-Radio
11a/b/gPoEAccessPoint
SuperStack3
WPA2 clients
LegacyWEP clients
SSID1
SSID1=VLAN1
SSID2= VLAN2
VLAN1
VLAN1
VLAN2
SSID1SSID2
SSID2
3ComSwitch4400PWR
Wireddesktops
VLAN2
Wired desktops
3Com
®Wireless8760Dual-Radio
11a/b/gPoEAccessPoint
Multiple SSID Support
Multiple SSID support enables many flexible configurations,
inclu ing supporting multiple client security schemes
simultaneously–no nee to umb own the wireless
network to support a few legacy WEP evices.
Multiple SSID and VLAN Support
With the 3Com Wireless 8760 Dual-Ra io 11a/b/g PoE Access Point,
a single Ethernet link supports multiple VLAN traffic tunnels.

3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
5
Wireddesktops
Wireddesktops
WDS
3Com®
OfficeConnect®
Switch 8
3Com
OfficeConnect
Switch 8
3ComWireless
8760Dual-Radio
11a/b/gPoE
AccessPoint
inPTPmode
3ComWireless
8760Dual-Radio
11a/b/gPoE
AccessPoint
inPTPmode
Wireddesktops
3Com
OfficeConnect
Switch8
3ComWireless
8760Dual-Radio
11a/b/gPoE
AccessPoint
inPTMPmode
Wireddesktops
3Com
OfficeConnect
Switch8
3ComWireless
8760Dual-Radio
11a/b/gPoE
AccessPoint
inPTMPmode
WDS
WDS
Wireddesktops
3Com®
OfficeConnect®
Switch83ComWireless
8760Dual-Radio
11a/b/gPoE
AccessPoint
inPTMPmode
Point-to-Point WDS Link
The 3Com Wireless 8760 Dual-Ra io 11a/b/g PoE Access
Point connects wire LANs with a wireless WDS link. The
APs act as wireless bri ges, forwar ing traffic between
LANs.
Point-to-Multipoint WDS Link
The 3Com Wireless 8760 Dual-Ra io 11a/b/g PoE Access Point
can function as a wireless bri ge in either point-to-point (PTP) or
point-to-multipoint (PTMP) mo es for installation flexibility.

Information in this section is relevant
to the 3Com Wireless 8760 Dual-Radio
11a/b/g PoE Access Point when used
in stand-alone mode. When used in
managed mode with a wireless switch
or controller, see that switch or
controller’s documentation for details.
MINIMUM SYSTEM
REQUIREMENTS
Computer with an Ethernet 10BASE-T,
10/100, or 10/100/1000 interface
configured for Internet communication
Operating system that supports an
Ethernet connection with an IP stack
(Installation CD Discovery Application
requires Windows XP, 2000 or Vista)
MEDIA INTERFACES
R -45, IEEE 802.11a, 802.11b, 802.11g
One 10BASE-T/100BASE-TX IEEE
802.3af-compatible PoE port with
auto-negotiation
DATA RATES
802.11a: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11b,g: 54, 48, 36, 24, 18, 12, 11, 9,
6, 5.5, 2, 1 Mbps
802.11a/g turbo mode: 108, 96, 72 Mbps
FREQUENCY BAND
802.11a: 5 GHz; 802.11b/g: 2.4 GHz
USERS SUPPORTED
Up to 128 wireless users, with
maximum of 64 users each on
802.11b/g and 802.11a radios
OPERATING RANGE
802.11a: up to 50 meters (164 feet)
transmit and receive
802.11b/g: up to 100 meters (328 feet)
transmit and receive
Unobstructed range maximum: 457
meters (1,499 feet)
OPERATING CHANNELS:
Channel availability depends on local
country regulations. Wireless LAN
system administrator must choose
correct country of operation.
Channels are then automatically
configured to comply with specified
country regulations.
MODULATION TECHNIQUE
DSSS (Direct Sequence Spread
Spectrum)
OFDM (Orthogonal Frequency
Division Multiplexing)
MEDIA ACCESS PROTOCOL
CSMA/CA
POWER CONSUMPTION
7.2 watts of PoE power with both
radios active
SPECIFICATIONS
3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
6
Wireddesktops
Wirelessclients
3Com®
OfficeConnect®
Switch8
3ComWireless
8760Dual-Radio11a/b/g
PoEAccessPoint
inRepeatermode
3ComWireless
8760Dual-Radio
11a/b/gPoE
AccessPoint
inrepeatermode
Wireless Repeater mode
The 3Com Wireless 8760 Dual-Ra io 11a/b/g PoE Access
Point can also exten the range of WLANs by acting as a
wireless repeater, forwar ing traffic between associate
wireless workstations an another AP connecte to the
wire LAN.

3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
7
TRANSMIT POWER SETTINGS
Based on the regulatory domain set by
the system administrator, not to
exceed the following:
802.11a
6 Mbps: +18 dBm
9 Mbps: +18 dBm
12 Mbps: +18 dBm
18 Mbps: +18 dBm
24 Mbps: +18 dBm
36 Mbps: +18 dBm
48 Mbps: +16 dBm
54 Mbps: +16 dBm
802.11b/g
1–11 Mbps: +18 dBm
12 Mbps: +18 dBm
18 Mbps: +18 dBm
24 Mbps: +18 dBm
36 Mbps: +18 dBm
48 Mbps: +16 dBm
54 Mbps: +16 dBm
RECEIVE SENSITIVITY
802.11a
6 Mbps: -87 dBm
9 Mbps: -86 dBm
12 Mbps: -84 dBm
18 Mbps: -82 dBm
24 Mbps: -79 dBm
36 Mbps: -75 dBm
48 Mbps: -72 dBm
54 Mbps: -71 dBm
802.11b/g
1 Mbps: -95 dBm
2 Mbps: -92 dBm
5.5 Mbps: -91dBm
6 Mbps: -89 dBm
9 Mbps: -88 dBm
11 Mbps: -88 dBm
12 Mbps: -86 dBm
18 Mbps: -84 dBm
24 Mbps: -81 dBm
36 Mbps: -77 dBm
48 Mbps: -73 dBm
54 Mbps: -72 dBm
STANDARDS CONFORMANCE
IEEE 802.11a, 802.11b, 802.11g,
802.11i, 802.3, 802.3af, 802.1X; WEP,
AES, WPA, WPA2, WMM and Wi-Fi
CERTIFIED
ANTENNA
2 removable 2dB gain antennas with
R-SMA connector
SECURITY
WPA2 AES and TKIP encryption;
64/128/152-bit WEP encryption;
802.1X with EAP-TLS, EAP-TTLS and
PEAP; WPA-PSK authentication; MAC
address authentication and filtering;
802.1Q VLAN; multiple SSID; RADIUS
client authentication, authorization
and accounting
NETWORKING PROTOCOLS
TCP/IP, Bridging Protocol, DHCP,
HTTP, HTTPS, SSH, Telnet
PERFORMANCE
Dynamic rate shifting
Packet bursting
Clear channel connect
802.11a/b/g SuperG mode
MANAGEMENT
SNMP v1, v2c and v3 support
Remote management with Web
browser over SSL or HTTPS; command
line interface over SSH v2 or Telnet
LEDS
Power, 10/100 Mbps, 802.11b/g
activity, or 11g activity
DIMENSIONS AND WEIGHT
Height: 15.9 cm (6.25 in)
Width: 21.91 cm (8.625 in)
Depth: 4.13 cm (1.625 in)
Weight: 544.31 g (1.2 lb)
REGULATORY/AGENCY
APPROVALS
Sa ety
UL/CSA 60950-1
EN/IEC 60950-1
NOM-019- SCFI
EMC/EMI
FCC 15 Subpart C
IC RSS-210
EN 300 328
EN 301 893
EN 301 489-1, -17
EN 60601
ENVIRONMENTAL RANGES
Operating temperature: -10 to 40°C
(14 to 122°F)
Storage temperature: -40 to 70°C
(-40 to 158°F)
Humidity: 10 to 95% non-condensing
PACKAGE CONTENTS
3Com Wireless 8760 Dual-Radio
11a/b/g PoE Access Point
2 external dual-band 2.4/5.15GHz
antennas with R-SMA connectors
Mounting hardware
PoE injector (3CN PSE)
1.6 m CAT 5 cable
Quick Installation Guide
Support and Safety sheet
Warranty sheet
Product range sheet
CD with Discovery application and
documentation
WARRANTY AND OTHER SERVICES
Three-year hardware warranty.
Advanced hardware replacement and
90 days free technical support. Refer
to www.3com.com/warranty for details.
SPECIFICATIONS
(CONTINUED)

Visit www.3com.com for more information about 3Com secure converged network solutions.
3Com Corporation, Corporate Headquarters, 350 Campus Drive, Marlborough, MA 01752-3064
3Com is publicly traded on NASDAQ under the symbol COMS.
Copyright © 2007 3Com Corporation. All rights reserved. 3Com, the 3Com logo, OfficeConnect, and X ACK are registered trademarks, and Express is a service mark,
of 3Com Corporation. All other company and product names may be trademarks of their respective companies. Wireless speed and performance depend on number
of users, physical conditions, and other electronic devices in the area. While every effort is made to ensure the information given is accurate, 3Com does not accept
liability for any errors or mistakes which may arise. All specifications are subject to change without notice. 400991-006 10/07
PRODUCT DESCRIPTION MODEL N0 3COM SKU
3Com Wireless 8760 Dual-Radio
11a/b/g PoE Access Point WL-546 3CRWE876075
Managed Wireless LAN Access Point Antenna Options
3Com 6/8dBi Dual-Band Omni Antenna 3CWE591
3Com 3/4dBi Dual-Band Ceiling Mount Antenna 3CWE592
3Com 18/20dBi Dual-Band Panel Antenna 3CWE596
3Com 4/6dBi Dual-Band Hallway Antenna 3CWE597
3Com 8/10dBi Dual-Band Panel Antenna 3CWE598
Antenna Cables
3Com Ultra Low Loss 6 Foot Antenna Cable 3CWE580
3Com Ultra Low Loss 20-Foot Antenna Cable 3CWE581
3Com Ultra Low Loss 50-Foot Antenna Cable 3CWE582
3Com RSMA to SMA 6” Antenna Cable 3CWE586
3Com Wireless LAN-Related Products
3Com Unified Gigabit Wireless PoE Switch 24 3CRUS2475
3Com Baseline Switch 2924-PWR Plus 3CBLSG24PWR
3Com Baseline Switch 2426-PWR Plus 3C16491
3Com OfficeConnect®Managed Gigabit PoE Switch 3CDSG10PWR
3Com OfficeConnect Managed Switch 9 3CR16708-91
3Com Global Services
3Com Wireless LA Site Survey, etwork Health Check,
Installation Services and ExpressSM Maintenance www.3com.com/services_quote
3Com University Courses www.3com.com/3comu
For additional in ormation, please visit www.3com.com
ORDERING
INFORMATION
3COM® WIRELESS 8760 DUAL-RADIO 11A/B/G POE ACCESS POI T
