3D Systems Touch User manual

Touch™ and Touch X™
Haptic Device
User Guide
30-0433 Rev. A

TABLE OF CONTENTS
1 INTRODUCTION 1
1.1 Copyright 1
1.2 FCC Notice 1
1.3 Compliance 1
1.4 Warranty 2
1.5 Limitation of Liability 2
2 GETTING STARTED 3
2.1 Overview 3
2.2 About This Guide 3
2.3 What Comes With Your Device 3
2.4 The 3D Systems Touch Haptic Device 4
2.5 System Requirements 4
2.6 Customer Support 4
3 USING THE HAPTIC DEVICE 5
3.1 Overview 5
3.2 Working in 3D Space 5
3.3 Proper Handling and Positioning of the Haptic Device 5
3.3.1-Handling the Haptic Device 5
3.3.2-Positioning the 3D Systems Haptic Device 7
3.4 Physical Limits of the Device 7
4 INSTALLING THE 3D SYSTEMS HAPTIC DEVICE 9
4.1 Overview 9
4.2 Important Information for Existing Users Upgrading to 3D Systems Touch™ or Touch X™ 9
4.2.1-Uninstall the Previous Version of the Device Driver 9
4.3 Connecting the 3D Systems Touch Device 9
4.4 Installing the Touch Device Drivers 11
4.5 Run 3D Systems Touch Smart Setup 12
5 APPENDIX A: SPECIFICATIONS AND REQUIREMENTS 13
6 APPENDIX B: ALTERNATE CONFIGURATIONS 15
7 APPENDIX C: OPTIONAL SETUP STEPS 16
8 APPENDIX D: TROUBLESHOOTING 18
9 APPENDIX E: TOUCH RE-PACKAGING INSTRUCTIONS 20

3D Systems, Inc.
130-0433 Rev. A
1 INTRODUCTION
1.1 Copyright
©2018 3D Systems, Inc. All rights reserved. The content of this manual is furnished for informational use only, is
subject to change without notice, and should not be construed as a commitment by 3D Systems, Inc. This document
is copyrighted and contains proprietary information that is property of 3D Systems, Inc. The 3D Systems Touch, 3D
Systems TouchX, 3D Systems OpenHaptics, Phantom, Geomagic, Phantom Desktop, Phantom Omni, Touch 3D Stylus,
Geomagic OpenHaptics, Sensable, 3D Systems, and 3D Systems logo are registered trademarks of 3D Systems. Use
of the 3dsystems.com website constitutes acceptance of its Terms of Condition and Privacy Policy. Any similarity of
likeness of the names, places, and/or events in this publication to those of any individual, living or dead, place, event,
or that of any group or association is purely coincidental and unintentional.
1.2 FCC Notice
Touch
This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at their expense.
TouchX
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
1.3 Compliance
Touch
This equipment conforms with EN 61326-1:2013, IEC 61000-3-2:2014, IEC 61000-3-3:2013, and EN 60950-1:2006
(Second Edition) +A11:2009 +A1:2010 +A12:2011 +A2:2013 and meets the requirements of the applicable EU
Directives.
TouchX
This section is not applicable for the TouchX as it is a Class B device.

3D Systems, Inc.
230-0433 Rev. A
1.4 Warranty
No warranties of any kind are created or extended by this publication. 3D Systems warrants that the Touch and
TouchX haptic device will be free from defects in materials and workmanship, during the applicable warranty period,
when used under the normal conditions described in the documentation provided to you, including the respective
User Guide. 3D Systems will promptly repair or replace the Touch or TouchX, if required, to make it free of defects
during the warranty period. This warranty excludes repairs required during the warranty period because of abnormal
use or conditions (such as riots, oods, misuse, neglect or improper service by anyone except 3D Systems or its
authorized service provider). The warranty period for the Touch and TouchX is twelve (12) months and shall start the
date your device is purchased. For consumers who are covered by consumer protection laws or regulations in their
country of purchase or, if different, their country of residence, the benets conferred by our standard warranty are in
addition to, and operate concurrently with, all rights and remedies conveyed by such consumer protection laws and
regulations, including but not limited to these additional rights.
THIS WARRANTY IS THE ONLY WARRANTY PROVIDED FOR THE TOUCH AND TOUCHX DEVICES. TO THE MAXIMUM
EXTENT PERMITTED BY LAW, 3D SYSTEMS EXPRESSLY DISCLAIMS ALL OTHER WARRANTIES FOR THE TOUCH DEVICE
AND EACH OF ITS COMPONENTS, WHETHER THOSE WARRANTIES ARE EXPRESS, IMPLIED OR STATUTORY, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR INTENDED OR PARTICULAR PURPOSES.
1.5 Limitation of Liability
3D SYSTEMS WILL NOT BE RESPONSIBLE FOR CONSEQUENTIAL, EXEMPLARY OR INCIDENTAL DAMAGES (SUCH AS
LOSS OF PROFIT OR EMPLOYEE’S TIME) REGARDLESS OF THE REASON. IN NO EVENT SHALL THE LIABILITY AND/OR
OBLIGATIONS OF 3D SYSTEMS ARISING OUT OF THE PURCHASE, LEASE, LICENSE AND/OR USE OF THE EQUIPMENT BY
YOU OR OTHERS EXCEED THE PURCHASE PRICE OF THE TOUCH OR TOUCHX DEVICE.

3D Systems, Inc.
330-0433 Rev. A
2 GETTING STARTED
2.1 Overview
Congratulations on your purchase of the 3D Systems Touch haptic device!
This guide covers information about the 3D Systems Touch haptic device. The information contained in this manual
was current at the time of publication. Visit https://softwaresupport.3dsystems.com for the latest information.
This chapter describes the following:
• About this guide
• What comes with your device
• The 3D Systems Touch haptic device features
• System requirements
2.2 About This Guide
The 3D Systems Touch Device Guide describes the process of installing the required device drivers for your new 3D
Systems haptic device and connecting the hardware device to your computer. You will also nd information on how to
use the device and other information about the device.
For the most current device information please visit the Geomagic website at https://softwaresupport.3dsystems.
com.
We’ve worked extensively to ensure that the 3D Systems haptic device and device drivers install and work smoothly. If
you experience any problems during the installation or use of your device, please contact Customer Support.
2.3 What Comes With Your Device
The following documentation and other materials are provided to assist you in learning about your haptic device:
The 3D Systems Haptic Device: The haptic device uses high-delity force feedback to make it possible to touch and
manipulate virtual objects.
The Quick Start Guide: A quick start to attaching the haptic device, installing the drivers and using the device. For
detailed information, see the 3D Systems Touch and Touch X User Guide.
The User Guide: This guide (available online at https://softwaresupport.3dsystems.com), describes the process of
connecting the haptic device as well as how to work with the device including proper handling, troubleshooting, and
device specications. It also includes the process of installing the device drivers.
USB Type A to Type B Cable: This cable is used to connect the haptic device to the USB 2.0 or 3.0 port on the
computer.
Universal Power Supply: The power supply can be used on any standard circuit, using the supplied power cord.
Power Cord: The power cord connects the Universal Power Supply to the wall outlet.
Wrist Rest (TouchX Only): The wrist rest comes with the TouchX device and provides wirst support when using the
device

3D Systems, Inc.
430-0433 Rev. A
2.4 The 3D Systems Haptic Device
The 3D Systems haptic device enhances productivity and eciency by enabling the most intuitive human/computer
interaction possible, the ability to solve problems by touch. The haptic device employs high delity force feedback that
senses motion in 6 degrees of freedom providing the best, most realistic 3D touch sensation for any application. You
can feel the point of the stylus in all axes, and track its orientation (pitch, roll and yaw). The haptic device’s portable
design, compact footprint, and an USB interface ensures quick installation and ease-of-use.
General Features
• Dexterous Serial manipulator design
• Six degree-of-freedom positional sensing
• Portable design and compact footprint for workplace exibility
• Compact workspace for ease-of-use
• Multi-function indicator light
Touch Features
• Textured paint on plastic stylus to assist with grip
• Two switches on the stylus for ease of use and end-user customization
TouchX Features
• Wrist-rest to maximize user comfort
• One switch on the stylus for ease of use and end-user customization
• Comfortable molded-rubber stylus to provide secure grip
2.5 System Requirements
The haptic device requires certain hardware and software components to be able to function properly. This section
describes the minimum requirements for operating the haptic device.
NOTE: Visit https://softwaresupport.3dsystems.com to get the latest and most complete system requirements for the
applications you will be using with your haptic device. Please refer to the support page for specications of legacy
versions of the haptic device hardware.
• Intel i5/i7 5th generation, or equivalent CPU
• Win 7 64-bit, Win 8.1 64-bit, Win 10 64-bit
• Minimum 256 MB VRAM graphics card (Make sure you have the latest drivers)
• 4 GB of RAM and 512 MB of installation disk space
• Minimum display resolution of 1280 x 800
• USB 2.0 / 3.0 compatible port or USB hub
2.6 Customer Support
WARNING: DO NOT OPEN THE DEVICE. Attempting to open or repair the device by anyone other than a certied
authorized service center voids the manufacturer warranty and hardware maintenance contract. There are no
serviceable components in the haptic device or power supply. Return to 3D Systems for servicing.
If you encounter any diculties within your warranty period, you can obtain Technical Support through the three
channels listed below. If you are out of warranty and do not have active maintenance, Technical Support is limited. If
you purchased your 3D Systems haptic device from a distributor, please contact them rst.
Visit the support section at https://softwaresupport.3dsystems.com
E-mail: [email protected]
Customer Support can also be reached via telephone: [phone]

3D Systems, Inc.
530-0433 Rev. A
3 USING THE HAPTIC DEVICE
3.1 Overview
This chapter introduces you to working with the haptic device and the physical limits of the device’s range of motion.
It is important to understand these limitations so that you do not inadvertently damage the device by forcing it past
its designed limits.
3.2 Working in 3D Space
We have become so accustomed to using a mouse to move around a computer monitor that we don’t think twice
as we move our hand around a desk to move the cursor on the computer screen. But there was a time not long ago
when this seemingly simple task was not second nature; some even found it challenging and were often frustrated
as they learned. If you are new to working in 3D digital space and haptics, working with the haptic device may take
a little getting used to. Understanding where objects are in 3D space may take some practice before you are able to
move and manipulate objects with ease and certainty. Be patient with yourself.
3.3 Proper Handling and Positioning of the Haptic Device
3.3.1-Handling the Haptic Device
Lifting the device (Touch): To properly lift the device grasp the base of the unit on both sides and lift as shown in
the image below. DO NOT lift by grasping the stylus or arm. The stylus is detachable by design. Lifting the unit by the
stylus or arm could result in severe damage to the device.
Lifting the device (TouchX): To properly lift the device use one hand to grasp the back of the device, and the other
to grasp the base portion, as shown in the image below. DO NOT lift by grasping the stylus or arm. The stylus is
detachable by design. Lifting the unit by the stylus or arm could result in severe damage to the device.
Touch Touch X
Lifting the stylus out of the inkwell (Touch): Grasp the end of the stylus and lift UP, to disengage, and then OUT as
show below in the image on the left. Do NOT attempt to pull the stylus straight out as shown on the right.
Be sure to lift the stylus in a two step motion.

3D Systems, Inc.
630-0433 Rev. A
Calibrating the device (Touch): The haptic device may need to be re-calibrated from time to time, particularly if it
has lost power. To calibrate the device, place the stylus in the inkwell and start your haptically enabled application.
The indicator light in the inkwell of the haptic device will be lit a steady blue when the device is properly calibrated.
Alternatively, you can use the Touch Diagnostic Utility (Start>All Programs>3D Systems>Touch Device Drivers).
Touch Calibration
NOTE: For additional calibration instructions, please refer to the RUN 3D SYSTEMS TOUCH SMART SETUP section
Storing the stylus: After the device is calibrated, the stylus may be eft resting on the desk or kept in the inkwell
(Touch only). Keep in mind that storing the stylus in the inkwell increases the risk that the device will be knocked over
or that the stylus will be damaged.
Touch Touch X
Protecting the device from damage: It is best to place the unit rmly on the desktop and away from edges to
reduce the risk of damage to the device from a direct, unintentional elbow hit. The stylus is particularly vulnerable to
sustaining damage when it is in the inkwell.
To reduce the risk of damage, keep the device out of harms way. Pay extra attention if the stylus is stored in the inkwell.
Reassembling the detachable stylus: The Touch stylus is detachable by design. Reassemble it by aligning the blade
on the shaft with the slot in the stylus and inserting it till it snaps in place as shown in the image below.
Align the blade and shaft to reassemble the Touch stylus.

3D Systems, Inc.
730-0433 Rev. A
3.3.2-Positioning the 3D Systems Haptic Device
The correct placement of the device will vary from one user to another. You may want to experiment to nd a
placement that feels right for you.
• The device should be positioned so that you are comfortable when working with it.
• You should not feel any strain on your wrist or forearm when working with the device.
• If you are left-handed, you may nd it easier to work with the haptic device placed to the left of the keyboard.
• Remember to take breaks often to stretch your hands, wrists, and elbows.
3.4 Physical Limits of the Device
The haptic device has six degrees of motion provided by six axis points. All the degrees of motion have physical limits.
When you reach one of these limits you will feel a sudden stop; this is the mechanical stop designed into the device.
Forcing the device past any of these stops risks damaging the device. Take some time to become more familiar with
the physical limits of the haptic device before using the device by moving the device through its full range of motion
at each axis point.
1. First make sure the device is not active; the inkwell should not be lit. If the inkwell is lit, close any haptic applications
you have open.
2. Grasp the stylus as you would a pen, with the free end of the stylus (the eraser end of a pencil) pointing toward you
and the point of the stylus (the end connected to the arm) pointing toward the unit. Using the following illustration
as a guide, gently move the stylus in all directions to feel each mechanical stop. Now, you will perform macro
movements. That is, you will move the device at the “body,” “shoulder,” and “elbow” of the haptic device.
Encoder articulation: Macro movements. Showing movement of the haptic device arm and the body.
Touch Touch X

3D Systems, Inc.
830-0433 Rev. A
3. Perform macro movements, as follows:
a. Start with large-but gentle-movements. See the Figure above. Beginning at the top, move the arm of the device
left/right. The body, sometimes referred to as the turret, of the haptic device will pivot until it reaches a physical
limit. Again, do not try to force the device past any of the mechanical stops.
b. Next, move the stylus up/down. The primary movement will happen in the shoulder of the haptic device.
c. Next move it in/out with the primary movement happening in the elbow. When you reach a physical limit, you’ll
feel one of the
device’s mechanical stops. Don’t force the device past any of these stops.
4. Next, perform micro movements further down the haptic device, moving the device at the stylus:
a. Holding the stylus with one hand rotate left/right at the top of the yoke.
b. Next pivot it up/down at the bottom of the yoke where it joins the stylus.
c. Finally, gently twist the stylus back/forth.
Gimbal articulation: Micro movements. Showing movement of the haptic device stylus.
Touch Touch X
You should now have an understanding of the range of motion of the haptic device at each axis point and where its
limits are.
WARNING: ALWAYS WORK WITH THE CONNECTED END OF THE STYLUS POINTING AWAY FROM YOU. NEVER ROTATE THE
STYLUS WITH THE POINT FACING YOU.

3D Systems, Inc.
930-0433 Rev. A
4 INSTALLING THE 3D SYSTEMS HAPTIC DEVICE
4.1 Overview
This chapter describes, step by step, how to install the haptic device and drivers:
• Install the Touch Device Driver software to allow your computer to communicate with the haptic device.
• Connect the haptic device to your power source and computer.
4.2 Important Information for Existing Users Upgrading to 3D Systems Touch™ or
Touch X™
If you are an existing user with a haptic device and want to upgrade, before you run the Touch Setup (on the next
page), you must follow these procedures prior to setup.
4.2.1-Uninstall the Previous Version of the Device Driver
Before installing the new Touch Device Driver, you MUST rst uninstall any previous versions of the Phantom Device
Driver (PDD) that you have installed on your system.
1. From the Control Panel, click Programs and Features.
2. Locate, select and uninstall the 3D Systems Touch Device Drivers.
3. Delete all les in the following location: C:\Users\Public\Documents\3DSystems\
4. Reboot the computer prior to performing the following steps.
4.3 Connecting the 3D Systems Touch Device
In this section you will setup the haptic device and plug in all of the cables. The following steps detail the
recommended connection process (Connection Setup below).
NOTE: Exact appearance of your equipment may vary from that shown in the gures.
1. Remove the haptic device from the packaging, as shown in the following image. Position the haptic device in
your workspace, using both hands to grasp the covers and base of the device. See PROPER HANDLING AND
POSITIONING OF THE HAPTIC DEVICE section for instructions on how to handle the device to reduce the risk of
damage.
Touch Extraction Touch X Extraction

3D Systems, Inc.
10 30-0433 Rev. A
2. Connect the supplied USB cable to both the device and the host computer.
Touch USB Connection Setup TouchX USB Connection Setup
3. Plug the power cord into an available outlet (for 110V the outlet must be rated for at least 2 Amps, for 220V: 1 Amp).
Next, plug the power connector into the connector (Power) on the back of haptic device. Hook up the Power Supply
(use only the supplied power supply with the haptic device). Plug the power cord into the power supply. The blue
inkwell LED should quickly blink twice to indicate proper performance.
Touch Power Cord Connection TouchX Power Cord Connection

3D Systems, Inc.
11 30-0433 Rev. A
4.4 Installing the Touch Device Drivers
1. Download the Touch Device Driver from the 3D Systems website. Go to www.3Dsystems.com/haptics-devices/touch/
documents, locate Touch Device Driver, and select Downloads.
NOTE: As with most other software packages, you must have administrator privileges on the machine in order to
install system software.
2. If the installation wizard does not start, you will need to manually start the installation. Using Windows Explorer,
locate and double-click the Touch Device Driver Installer .exe le.
3. Follow the Install Wizard to start the installation of the Touch Device Driver.
4. In the Select components to install, be sure the check box, “Desktop Shortcuts” is selected. This will create desktop
shortcuts for the Touch Smart Setup Application. If you do not install the Desktop Shortcuts, you will need to go to
Start>All Programs>3D Systems>Touch Smart Setup to run the Touch Smart Setup Application.
NOTE: Selecting the Optional Desktop Shortcuts checkbox will install the optional Touch Setup application, outlined in
the RUN 3D SYSTEMS TOUCH SMART SETUP section.
5. Reboot your machine upon completion of this process. The device and drivers will not work properly until this has
been completed.

3D Systems, Inc.
12 30-0433 Rev. A
4.5 Run 3D Systems Touch Smart Setup
1. Select the Touch Smart Setup desktop icon to open the Touch Smart Setup application. Wait for the Smart Setup
application to scan for connected devices. If no device is detected, ensure that your touch device is properly
connected to your computer.
2. Follow the calibration instructions as they are displayed in the application.
Touch Calibration Touch X Calibration
3. Perform the steps presented in the Device View section of the Smart Setup. Move the stylus in all directions while
taking note of the visual representation in the application. Select the Sphere Simulation checkbox and perform the
steps presented in this section of the Smart Setup. Attempt to touch the sphere with virtual stylus tip. Take note of
the feel of the haptic feedback device in this process and verify that the feedback feels correct.
4. Select the Hollow Cube Simulation Test checkbox and perform the steps presented in this section of the Smart
Setup. Attempt move the stylus tip into the cube, then gently pull it back out. Take note of the feel of the haptic
feedback device in this process and verify that the feedback feels correct.
5. When these tests have been completed, select Save Conguration to complete the Touch Smart Setup.

3D Systems, Inc.
13 30-0433 Rev. A
5 APPENDIX A: SPECIFICATIONS AND REQUIREMENTS
Device Specications (Touch)
NOTE: Product specications are subject to change without notice.
Force Feedback Workspace ~ 6.4 W x 4.8 H x 2.8 D in > 160 W x 120 H x 70 d mm
Footprint (physical area the base of the
device occupies on a surface) ~ 6 5/8 W x 8 D in ~ 168 W x 203 D mm
Weight (device only) 3 lbs 15 oz ~1.42 kg
Range of Motion Hand movement pivoting at wrist
Nominal Position Resolution > 450 dpi ~0.055 mm
Backdrive Friction < 1 oz < 0.26 N
Maximum Exertable Force (at nominal
orthogonal arms position) .75 lbf 3.3 N
Continuous Exertable Force (24 hrs) > 0.2 lbf > .88 N
Stiness
X axis > 7.3 lbs./in
Y axis > 13.4 lbs./in
Z axis > 5.9 lbs./in
X axis > 1.26 N/ mm
Y axis > 2.31 N/mm
Z axis > 1.02 N/mm
Inertia (apparent mass at tip) ~ 0.101 lbm ~ 45 g
Force Feedback X, Y, Z
Position Sensing X, Y, Z (digital encoders)
Stylus gimbal Pitch, roll, yaw (± 5% linearity potentiometers)
Interface USB 2.0
OpenHaptics® SDK compatibility? Yes
Device Specications (Touch X)
Force Feedback Workspace ~ 6.4 W x 4.8 H x 4.8 D in > 160 W x 120 H x 120 d mm
Footprint (physical area the base of the
device occupies on a surface) ~ 5 5/8 W x 7 1/4 D in ~ 143 W x 184 D mm
Weight (device only) 7.1805 lbs ~3.257 kg
Range of Motion Hand movement pivoting at wrist
Nominal Position Resolution > 1100 dpi ~0.023 mm
Backdrive Friction < 0.23 oz < 0.06 N
Maximum Exertable Force (at nominal
orthogonal arms position) 1.8 lbf 7.9 N
Continuous Exertable Force (24 hrs) > 0.4 lbf > 1.75 N
Stiness
X axis > 10.8 lbs./in
Y axis > 13.6 lbs./in
Z axis > 8.6 lbs./in
X axis > 1.86 N/ mm
Y axis > 2.35 N/mm
Z axis > 1.48 N/mm
Inertia (apparent mass at tip) ~ 0.077 lbm ~ 35 g
Force Feedback X, Y, Z
Position Sensing (Base X,Y,Z) X, Y, Z (digital encoders)
Position Sensing (Stylus Gimbal) Pitch, roll, yaw (Magnetic absolute position sensor, 14-bit precision.)
Interface USB 2.0
OpenHaptics® SDK compatibility? Yes

3D Systems, Inc.
14 30-0433 Rev. A
System Requirements
Operating System 64-bit Windows 7, 8.1, and 10
Processor Intel i5 / i7, 5th Generation or greater CPU, Minimum 2.5 GHz
frequency
RAM 4 GB
Graphics Card Minimum 256 MB VRAM (Install the latest drivers)
Disk Space 512 MB
Display Resolution 1280 x 800 (Minimum)
Interface USB 2.0 / 3.0 port or USB Hub that supports USB 2.0/ 3.0. (Use only
USB A to B cable provided by 3D Systems).
OpenHaptics ® SDK Compatibility Yes
* Please visit the Support and Resources section of our website for more information: (https://
softwaresupport.3dsystems.com).

3D Systems, Inc.
15 30-0433 Rev. A
6 APPENDIX B: ALTERNATE CONFIGURATIONS
Dual Unit Conguration
The haptic device may be congured in a dual unit setup. In this scenario, two units are connected upon beginning
the Smart Setup application.
1. With two devices connected, select the Touch Smart Setup desktop icon to open the Touch Smart Setup application.
2. When prompted, select both the Right and Left devices from the list.
3. Insert the stylus for both devices into each inkwell for calibration.
NOTE: Please refer to the Run 3D Systems Touch Smart Setup section for detailed calibration steps.
4. Perform the Sphere Simulation and Hollow Cube tests on each device to verify proper performance.
5. Select Save Conguration to complete the dual unit conguration process.

3D Systems, Inc.
16 30-0433 Rev. A
7 APPENDIX C: ADVANCED SETUP STEPS
Run 3D Systems Touch Setup (Optional)
If you have already congured the device using smart setup, please skip this step. Touch Setup and Diagnostic
tools are for advanced users.
NOTE: The following statement is only applicable for LAN devices.
In this section you will identify your 3D Systems haptic device and pair it with your host PC. This process only needs to
be executed once. There is a safety key exchange during the pairing process. The safety key will be saved to host PC
hard drive and the NV-Ram of the 3D Systems Touch after the pairing process is properly done.
NOTE: For existing users, see the following section before proceeding: IMPORTANT INFORMATION FOR USERS
UPGRADING TO 3D SYSTEMS TOUCH OR TOUCH X.
1. Double-click the 3D Systems Touch Setup icon on your desktop, or if you chose not to install desktop shortcuts click
Start>All Programs>3D Systems>3D Systems Touch>3D Systems Touch Setup.
Make sure that the correct 3D Systems Touch Model (Touch or TouchX) is selected on the Hardware tab. From the
Host Name drop-down list on the Hardware Tab, do the following:
a. Match the name of the device or the serial number on the bottom of the device with a device in the list.
2. After you have identied your device you will need to lock or “Pair” it with your host PC. NOTE: This step is applicable
to LAN Devices only.
a. Press the Pair button on the back of your 3D Systems Touch device. The device and your computer are now
paired together.
NOTE: You will only need to Pair the device again if you move the device to a different computer. If you run out of
time, a timeout error will appear. In this case repeat steps 4 and 5 again.
3. Click OK to apply the pairing and exit the Setup dialog.
The 3D Systems Touch Setup Window

3D Systems, Inc.
17 30-0433 Rev. A
Run 3D Systems Touch Diagnostic (Optional)
If you have already congured the device using smart setup, please skip this step. Touch Setup and Diagnostic
tools are for advanced users.
In this section you will run the 3D Systems Touch Diagnostic application to conrm that the device is properly
connected and installed.
1. Click the 3D Systems Touch Diagnostic icon on your desktop, or if you chose not to install desktop shortcuts click
Start>All Programs>3D Systems>Touch Diagnostic.
2. The 3D Systems Touch Diagnostic application will open and you will be in the Mode dialog.
3. Click the Next arrow in the bottom right of the dialog or click the Select tab to move on to the next step.
4. The Select tab initializes the 3D Systems Touch device and begins to run to the Servoloop. Click the Next arrow when
the six remaining test tabs appear in the dialog to move on to the Calibration stage.
5. You will have to place the stylus in the ink well to properly calibrate the device. The icon changes from red to green
when the calibration is complete.
6. Click Next to move on the next test.
7. The Read Encoder dialog displays the range of the devices read and gimbal encoders.
8. The Cycle Amps tab will cycle the device amps. When the results dialog states that the device ampliers are OK click
Next to move on to the next test.
9. The Test Forces dialog contains a slider for the Motor DAC values and a Celsius eld to estimate the heat of motors
using a determined force. When you are comfortable with the motor levels click Next to move on to the Box Test.
10. On the Box Test dialog, take the stylus and move it around the box in the dialog. You will notice a Force meter on
the right hand side that displays the force in Newtons. Click Next to move on to the Servoloop.
11. The nal diagnostic is the Servoloop. The Servoloop demonstrates statistics on the timing intervals of the servo
loop; these statistics are then written to this dialog (you can copy and send to support if needed). The device driver
requires by default that the haptic device forces be updated at a rate of 1000 times a second (1000 Hz).

3D Systems, Inc.
18 30-0433 Rev. A
8 APPENDIX D: TROUBLESHOOTING
This section provides tips for correcting some common problems encountered with the 3D Systems haptic device.
If after following these steps, you cannot resolve the problem, please contact Customer Support.
The haptic device light does not come on at all.
The light on the haptic device should be on if it is receiving power. Check that the power supply is plugged into a
working outlet. Then check that the connection between the power supply and the haptic device is made correctly.
NOTE: The inkwell LED should quickly blink twice upon powering up the device.
The LED states and their meaning.
The inkwell LED states for the device are as follows:
Touch LED States Touch X LED States
Fast blinking Blue for 2 seconds: Occurs once upon
powering up the device
Fast blinking Amber LED for 2 seconds: Occurs upon
powering up device
Dim Blue: Device is in standby mode, or connected to
power but not in use
Slow alternation between Green and Amber: Occurs
after the device powers up and before setup
Solid Blue: The application is running and the device is
in use
Slow blinking green: Indicates that the device requires
calibration
Slow blinking Blue: The device requires calibration Solid Amber: Device is calibrated and in standby
mode
-Solid Green: The application is running, the device
forces are on and the device is in use
-Fast blinking Amber LED for 2 secondss: USB has been
disconnected whole power is connected
When I start a demo I get an error.
This can happen if the device is not plugged in properly or is not congured properly. Execute the following steps,
checking at each point for proper operation:
• Verify power supply - Check to make sure the haptic device is plugged in properly. The light should align with a state listed above if
properly functioning.
• Verify USB port connection - Check that the USB cable plugged into the Touch device. Check that the other end is plugged into the
USB port on your computer.
