3D3 CLASSIC A1111 User manual

UNIVERSAL 3D TV EYEWEAR
user manual
CLASSIC A1111 •A1112

3D3 Universal 3D TV Eyewear is
designed to function with TVs
using Active Shutter technology.
Compatibility can be checked by
visiting 3d3.co.uk/compatibility.
TV Compatibility
Function button
& indicator light
3D signal receiver
•
•
•
Charging port

prepare f r installati n
nEnsure that only the TV you wish to use with the
3D3 Eyewear is switched on.
nSet the TV to 3D mode (refer to the TV operating
instructions).
nStand less than 1 metre from the TV.
installati n
nWith the 3D eyewear switched off, press and hold the
function button for five seconds. The indicator light
will flash until the 3D signal is detected and then
extinguish. You should now be viewing 3D images.
nIf the 3D signal has not been detected, check that
there is nothing blocking the signal from the TV to
the eyewear and repeat the process.
charging
nWhen the battery is low, the blue indicator light will
flash for approximately five seconds when switching
on. Connect the supplied cable to the charging port
and the other end to any suitable USB charger or port
on a TV, laptop or desktop computer. The indicator
light will illuminate red until fully charged and then
extinguish.

perati n
nPower On - Press and release the function button,
the indicator light will illuminate blue for
approximately five seconds and then extinguish.
nPower Off - Press and hold the function button for
approximately three seconds until the blue indicator
flashes three times and then extinguishes.
n3D Mode witch (optional on IR TV only) -
Some 3D TVs allow the 3D image to be reversed or
inverted. While watching 3D images, press the
function button once. Press the function button
again to return to the previous state.
n3D Mode witch (RF Bluetooth TV only) -
While watching 3D images, double-click the function
button to switch to the mode most suited to your TV.
Mode 1 - the blue indicator light illuminates
continuously for five seconds
Mode 2 - the blue indicator light illuminates in a
series of five double-flashes one second apart for
five seconds.

safety precauti ns
nEnsure appropriate adult supervision at all times
when children are using 3D Eyewear.
nSit an appropriate distance from the TV to minimise
eye strain.
nUsing 3D Eyewear for extended periods of time may
result in symptoms such as headaches, fatigue or
dizziness. Take regular breaks if you experience any
adverse effects.
nSeek professional medical advice if you experience
any adverse effects that do not subside after
stopping 3D viewing.
nEnsure that children are asked whether they feel
any adverse effects during and after 3D viewing.
n3D viewing is not recommended for people in poor
physical or mental condition, under the influence of
alcohol or feeling nauseous.

safety precauti ns
n3D TV is an immersive experience and can startle
viewers. You should consider this if pregnant,
elderly, epileptic or if suffering from any serious
physical condition.
nBe aware of ob ects around the viewing position to
avoid damage or in ury. 3D viewing can alter the
perception of distance.
nOnly use the 3D Eyewear for their intended purpose.
n3D Eyewear should not be exposed to direct
sunlight, heat, fire or water.
nDo not bend, drop or apply force to any part of the
3D Eyewear.
nClean the 3D Eyewear with a soft, dry cloth. Do not
use cleaning fluid, spray, chemicals, solvents,
surfactants or lubricants.

disp sal
The 3D Eyewear contains a lithium-ion
polymer rechargeable battery which
should be removed before disposal.
Please discard according to local
regulations. Used electrical and
electronic products should not be
mixed with general waste. Please dispose of this product
only in designated national waste electronic schemes.
battery rem val
nRemove the nosepiece and the two screws located
near the hinges.
nSeparate the inner frame from the outer frame.
nPull off the battery located on the right hand side,
cut off the two wires and insulate them with tape.
recycling
3D Eyewear may be returned to your supplier who will
offer responsible recycling.

www.3D3.c .uk
rechargeable
