3Disc FireID User manual

User Manual
RFID Reader for FireCR Dental
The RFID reader supports Direct Connection Mode for a single FireCR Dental
reader with a single computer and Network Sharing Mode for multiple FireCR
Dental readers with multiple computers. This manual describes Network Sharing
Mode using .
Doc No. : TM-501-EN
Rev 0.1.4 Oct. 2013
Part No. : CR-FPM-54-001-EN
3DISC RFID Reader are trademarks of 3D Imaging & Simulations Corp, South Korea, and its
affiliates. All other trademarks are held by their respective owners and are used in an editorial
fashion with no intention of infringement. The data in this publication are for illustration purposes
only and do not necessarily represent standards or specifications, which must be met by 3D
Imaging & Simulations Corp. All information contained herein is intended for guidance
purposes only, and characteristics of the products and services described in this publication can
be changed at any time without notice. Products and services may not be available in your local
area. Please contact your local sales representative for availability information. 3D Imaging &
Simulations Corp. strives to provide as accurate information as possible, but shall not be
responsible for any typographical error.
© Copyright 2013 3D Imaging & Simulations Corp, all rights reserved, printed, and published
in South Korea by 3D Imaging & Simulations Corp.

User Manual
FireID TM-501-EN
2
Contact
815, Tamnip-Dong, Yuseong-Gu,
Daejeon, Korea
Tel : [phone]
Fax : [phone]
Website : www.3DISCimaging.com
E-mail : [e-mail]
3DISC Americas
22560 Glenn Dr, Suite 116
Sterling, VA 20164 USA
Tel : [phone]
E-mail : [e-mail]
3DISC Europe
Gydevang, 39-41, 3450 Alleroed, Denmark
Tel : [phone]
E-mail : [e-mail]

User Manual
FireID TM-501-EN
3
The device complies with Part 15 of the FCC Rules. Operation is subject to the condition
that this device does not cause harmful interference.
NOTE : This equipment has been tested and found to comply with the limits for a Class B Digital
Device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction, may cause harmful interference to radio communication. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

User Manual
FireID TM-501-EN
4
Warnings and Used Symbols
To ensure the safety of patients, staff and other persons, any changes to software and hardware
delivered by 3D Imaging & Simulations Corp. may only be made with prior written permission
from 3D Imaging & Simulations Corp.
Please read the respective manuals of the connected software, such as acquisition and diagnostic
software, before starting to use the FireCR Dental system.
The following symbols will be used throughout this manual:
D
ANGER
Damage to the reader can occur if it is used incorrectly.
If unauthorized changes have been made to the delivered system
and accessories, the warranty by 3D Imaging & Simulations
Corp. becomes void. 3D Imaging & Simulations Corp. will not
accept any responsibility or liability for the improper functioning of
the product in such a case.
W
ARNING
The functionality of the system can be limited in the case of
incorrect use. These directions require special attention.
N
OTE
Notes represent information that is important to know, but which do
not affect the functionality of the system.
D
ANGER
This equipment is indoor use only and all the communication
wirings are limited to inside of the building.

User Manual
FireID TM-501-EN
5
General Safety Guidelines
All the safety and operating instructions should be read carefully before this device is operated.
This device has been designed and tested to meet strict safety requirements applicable to medical
equipment, and has been supplied in a safe condition. To ensure personnel and patient safety,
the device shall be operated and serviced in compliance with all procedures, warnings and
precautions during all phases of operation and service of this device. Failure to comply to with
safety guidelines may result in injury to service personnel, operator, or patient. 3D Imaging &
Simulations Corp. assumes no liability for failure to comply.
If this device is not used as specified, the protection provided by the device could be impaired.
This device must be used in a normal condition only.
Installation, service and operation of this device should only be undertaken by qualified trained
personnel. The operator should study instructions and precautions carefully before starting to
use the device listed here and throughout the manual.
There are no user serviceable parts inside this device. The device should only be opened and
serviced by qualified service personnel. Failure to heed this warning may result in injury to
service personnel or damage to equipment, and void any and all warranties. If there is a service
problem, please contact 3D Imaging & Simulations Corp. or an authorized dealer.
•Do not spill liquids on the device, and never operate the device in a wet environment.
•Keep the device from radiators and heat sources.
•Use the device only with accessories supplied with this device.
•This device contains static sensitive components. Proper static handling procedures and
equipment must be used when servicing this device.
If any of the following conditions occur, unplug the device from the electrical outlet and contact
authorized service personnel.
•The USB cable is damaged.
•The device has been exposed to water.
•The device has been dropped or damaged.
•The device does not operate correctly when the operating instructions are followed.

User Manual
FireID TM-501-EN
6
Table of contents
Chapter 1. Introduction.................................................................... 7
Chapter 2. Unpacking...................................................................... 8
Inspection for Damage ..................................................................... 8
Identify the Components................................................................... 8
Chapter 3. Setting Up.................................................................... 10
Connection..................................................................................... 10
PC Driver Installation on the PC......................................................11
Computer Requirements ................................................................ 13
Recommended Requirement.................................................... 13
Minimum Requirement ............................................................. 13
Installation of Acquisition and Diagnostic Software ........................ 13
Chapter 4. Operation..................................................................... 14
System Specifications .................................................................... 14
Operation Conditions...................................................................... 14
Operating Instructions .................................................................... 15
Chapter 5. Symbols....................................................................... 16
Manufacturer’s Declaration............................................................ 18
- Electromagnetic Emission........................................................... 18
Manufacturer’s Declaration - Electromagnetic Immunity................ 18
G u i d a n c e a n d M a n u f a c t u r e r ’ s D e c l a r a t i o n –
Electromagnetic Immunity.......................................................................... 20
Chapter 6. Warranty and Repair Service....................................... 22
Standard Warranty ......................................................................... 22
Repair Service................................................................................ 22
Out of Warranty Repair Service...................................................... 22
Shipping ......................................................................................... 23
Chapter 7. Technical Assistance.................................................... 23

User Manual
FireID TM-501-EN
7
Chapter 1. Introduction
Dear Customer
Thank you for choosing the RFID Reader to complement your 3DISC Imaging FireCR Dental
Reader.
The advanced technology of the RFID Reader provides quick and accurate registration of data
relevant to each individual patient. By pre-registering the unique tag code and imaging plate on
the , the scanned image, imaging plate size information and the serial number of the imaging
plate are automatically assigned to the individual patient file.
Please read and follow the instructions given in this ‘User Manual’ carefully prior to using the
RFID Reader and keep this manual within reach for future reference.
The purpose of this manual is to direct you through the main functions and interfaces of the RFID
Reader. You will be guided through the procedures of ‘Unpacking’, ‘Setting Up’ and ‘Operating’
the . You can also learn about ‘Symbols’, ‘Warranty and Repair Service’and ‘Technical Assistance’.
It is important to observe all safety information to prevent potential personal injury or material
damage.

User Manual
FireID TM-501-EN
8
Chapter 2. Unpacking
Inspection for Damage
is shipped in a custom designed container to protect the from external shock. Before
unpacking the product, inspect the shipping container for damage. In case the container is
damaged, notify the shipper immediately.
Identify the Components
Open the shipping container and identify each of these components.
Part No. Item
CR-FP-51-001 FireID
CR-FPA-02-004 Mini USB 2.0 Interface Cable (5 pin)
CR-FPM-54-001-EN User Manual
Figure 1. Mini USB 2.0 Interface Cable (5pin)
Figure 2. Top view of

User Manual
FireID TM-501-EN
9
W
ARNING
Improper disposal of this product may result in environmental
contamination. When disposing of this equipment, contact 3D
Imaging & Simulations Corp.’s representative or related
government agencies. Do not dispose of any part of this
equipment without consulting a 3D Imaging & Simulations Corp.
representative first.
3D Imaging & Simulations Corp. does not assume any
responsibility for damage resulting from disposal of this equipment
without consulting 3D imaging & Simulations Corp.
W
ARNING
Use only devices meeting the requirements of IEC60950-1 or
IEC60601-1 when connecting to the FireID via the USB port.
W
ARNING
If the FireID needs to be returned to manufacturer or one of its
representatives, the reader must be repacked in the original
container with all accessories.

User Manual
FireID TM-501-EN
10
Chapter 3. Setting Up
Connection
The interfaces with the computer via the enclosed USB 2.0 Interface Cable.
1. Locate the USB 2.0 Interface Cable inside the shipping container.
2. Connect the cable to the ’s mini USB2.0 port, located on the rear of the .
3. Connect the other end of the cable to the USB2.0 port on the computer.
Figure 3. Mini USB connector on the rear of
W
ARNING
Unsuitable Installation Sites
Locations with excessive humidity or dust
Locations subject to high temperature
Locations subject to shaking or vibration
Locations exposed to considerable electrical or magnetic
noise, or other forms of electromagnetic energy
Locations with poor heat radiation

User Manual
FireID TM-501-EN
11
PC Driver Installation on the PC
The Windows driver for will be located and installed automatically if the PC is connected to the
internet. If internet is not available or the driver installation did not complete normally (see Figure
4), the driver for the will need to be installed manually with the driver file provided.
Figure 4. Driver is not installed normally

User Manual
FireID TM-501-EN
12
When the driver is installed correctly, a USB Serial Converter is added under Universal Serial
Bus Controller category and a new USB Serial Port is displayed under Ports category.
Figure 5. Driver is installed correctly.

User Manual
FireID TM-501-EN
13
Computer Requirements
Recommended Requirement
Operation System Microsoft Windows 7 or Windows 8 (32 bit or 64 bit)
CPU Core Duo / Core2 Processor
Memory RAM 4GB or more
Hard Disk 300GB Free Hard Disk Space
Network 100Mbps Ethernet for Network Sharing Mode
USB 2.0 HighSpeed
Minimum Requirement
Operation System Microsoft Windows 7 (32 bit or 64 bit)
CPU Core Duo / Core2 Processor
Memory RAM 2GB or more
Hard Disk 80GB Free Hard Disk Space
Network 100Mbps Ethernet for Network Sharing Mode
USB 2.0 HighSpeed
Installation of Acquisition and Diagnostic Software
Refer to the Acquisition and Diagnostic Software manual.

User Manual
FireID TM-501-EN
14
Chapter 4. Operation
System Specifications
Dimension 27 x 60 x 96 (H x L x W)
Weight 90g
Frequency 13.56MHz
Protocol ISO 15693
Interface Mini USB B
Power Supply USB Power
* Specifications subject to change without notice.
** Specific results may vary since operating conditions fluctuate.
Operation Conditions
Indoor use only
Operating Temperature 15°C ~ 30°C (59°F ~ 86°F)
Temperature Gradient 0.5°C / Min
Relative Humidity 15% ~ 95% (non-condensing)
Storage Temperature - 10°C ~ 50°C (14°F ~ 122°F)
Storage Humidity 15% ~ 95% (non-condensing)
Storage Atmospheric Pressure 500 ~ 1,060 hPa
Transportation Temperature - 10°C ~ 50°C (14°F ~ 122°F)
Transportation Humidity 15% ~ 95% (non-condensing)
Transportation Atmospheric Pressure 500 ~ 1,060 hPa
Pollution Degree 2
Ingress of Liquids IPX0
Equipment Maintenance No user maintenance is required and no user
service is allowed. Please contact technical
support if there is a problem.
Cleaning Wipe the outside of the reader to remove dust,
using a soft and dry cloth.

User Manual
FireID TM-501-EN
15
Operating Instructions
Before an imaging plate is scanned from a FireCR Dental reader that is connected to a router
through an Ethernet cable, the imaging plate should be tagged on the in order to identify the
target PC. If the imaging plate is not tagged on the , the scanner will not begin to scan. The
imaging plate must be tagged. When a tagged imaging plate is scanned from a FireCR Dental
reader, the target PC will receive the scanned image, imaging plate size information and the serial
number of the imaging plate.
If the PC is connected to a new FireCR Dental reader or a new PC is added to an existing FireCR
Dental reader, the PC will download the calibration data from the FireCR Dental reader
automatically.
Figure 6. Typical configuration of Network Sharing Mode
Operating procedure:
1. Tag the image plate on the of the target PC by briefly touching the imaging plate onto
the topside of the .
2. Put a protective cover on the imaging plate and insert both into a hygienic bag.
3. After exposing the plate, remove hygienic bag and protective cover and dispose of them.
4. Put the imaging plate on the tray of the FireCR Dental reader and push the tray in to
scan.
5. The scanned image is transferred to the target PC along with the serial number of the
imaging plate.
D
ANGER
This equipment is indoor use only and all the communication
wirings are limited to inside of the building.

User Manual
FireID TM-501-EN
16
Chapter 5. Symbols
Symbol Description
W
ARNING
Do not pull out the USB cable during tag information reading.

User Manual
FireID TM-501-EN
17
Manufacturer
Warning, Consult Accompanying Documents
General mandatory action manual
General prohibition indication
User Manual Reference
Keep Dry
Fragile
Handle with care
This side up
Non-ionizing electromagnetic radiation
CE Mark

User Manual
FireID TM-501-EN
18
Manufacturer’s Declaration- Electromagnetic Emission
The RFID reader system is intended for use in the electromagnetic environment specified below.
The customer or the user of RFID reader system
should assure that it is used in such an
environment
Emission test Compliance Electromagnetic environment - guidance
RF emissions
CISPR 11 Group 1 Class B The RFID Reader uses RF energy only for its internal function. Therefore. Its RF emissions are
very low and are not likely to cause any
interference in nearby electronic equipment
Manufacturer’s Declaration - Electromagnetic Immunity
The system is intended for use in the electromagnetic environment specified below.
The
customer or the user of system should assure that it is used in such an environment
Immunity test
IEC 60601
Test level Compliance level
Electromagnetic
Environment -guidance
Conducted RF
IEC 61000-4-6 3 Vrms 150 kHz to 80 MHz 3 Vrms 150 kHz to 80 MHz Portable and mobile RF
communications equipment
should be used no closer to
any part of the FireCR Dental
system, including cables, than
the recommended separation
distance calculated from the
equation applicable to the
frequency of the transmitter.
Recommended separation
distance

User Manual
FireID TM-501-EN
19
Radiated RF
IEC 61000-4-3 3 V/m 80.0 MHz to 2.5 GHz 3 V/m 80.0 MHz to 2.5 GHz
Recommended separation
distance
Where Pis the maximum
output power rating of the
transmitter in watts (W)
according to the transmitter
manufacturer and dis the
recommended separation
distance in meters (m).
Field strengths from fixed RF
transmitters, as determined by
an electromagnetic site survey,
(a) Should be less than the
compliance level in each
frequency range (b).
Interference may occur in the
vicinity of
equipment marked with the
following symbol:
N
ote 1)
Uт is the A.C. main voltage prior to application of the test level.
Note 2) At 80 MHz and 800 MHz, the higher frequency range applies.
Note 3) These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which the
EUT is used exceeds the applicable RF compliance level above, the EUTshould be observed to verify normal
operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting
or relocating the EUT.
bOver the frequency range 150 kHz to 80 MHz, field strengths should be less than [V1] V / m.
Recommended Separation Distances Between Portable and Mobile RF Communications
Equipment and the system.

User Manual
FireID TM-501-EN
20
The
system is intended for use in an electromagnetic environment in which radiated RF
disturbances are controlled. The user of the system can help prevent electromagnetic
interference by maintaining a minimum distance between portable and mobile RF communicat
ions
equipment (transmitters) and the system as recommended below, according to the maximum
output power of the communications equipment.
Rated maximum output
power (W) of transmitter
Separation distance (m) according to frequency of transmitter
150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5
GHz
0.01 0.12 0.12 0.23
0.1 0.37 0.37 0.74
1 1.17 1.17 2.33
10 3.70 3.70 7.37
100 11.70 11.70 23.30
For transmitters rated at a maximum output power not listed above, the recommended separation
distance (d) in meters (m) can be estimated using the equation applicable to the frequency of the
transmitter, where P is the maximum output power rating of the transmitter in watts (W) according
to the transmitter manufacturer.
N
ote
1:
At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
Note 2:
These guidelines may not apply in all situations. Electromagnetic propagation is affected
by absorption and reflection from structures, objects, and people.
Immunity and Compliance Level
Immunity test IEC 60601 Test Level Actual Immunity Level Compliance Level
Conducted RF
IEC 61000-4-6 3 Vrms, 150 kHz to 80 MHz 3 Vrms, 150 kHz to 80 MHz 3 Vrms, 150 kHz to 80 MHz
Radiated RF
IEC 61000-4-3 3 V/m, 80 MHz to 2.5 GHz 3 V/m, 80 MHz to 2.5 GHz 3 V/m, 80 MHz to 2.5 GHz
Guidance and Manufacturer’s Declaration
Electromagnetic Immunity
The system is intended for use in the electromagnetic environment specified below.
The customer
or the user of system should assure that it is used in such an environment
Immunity test
IEC 60601
Test level Compliance level
Electromagnetic
environment
-
guidance
Conducted RF
IEC 61000-4-6 3 Vrms 150 kHz to 80MHz 3 Vrms 150 kHz to 80 MHz system must only be used in a
shielded location with the minimum RF
shielding effectiveness and, each cable
should have the minimum RF shielding
effectiveness.
