6Questions? Call 888-888-7985
ASSEMBLY DRAWING
STEP 2- Assembly the handle bars into
STEP 1- Attach the console
masts to the base frame
A). Insert the left console mast (without a wire
attached inside) into the base frame. Attach
the left console mast with four M8X15mm
bolts using Allen wrench.
(Do not tighten the bolts)
B). Put the lower console wire and grounded wire
inside and through the right console mast using
the wire attached inside the right console mast,
insert the right console mast into the base frame,
right secure the console mast with four
M8X15mm bolts using Allen wrench.
(Do not tighten the bolts)
STEP 3- Screw on the M8x40mm bolt on
handle bars & tighten it.
(A) Refer to the attached drawing, first to screw &
tight the bolts #1 on handle bars,
then, to screw & tight the bolts #2
STEP 4- Attach the console to the
console masts
A).Secure with 6 pcs of M8X15mm bolt on the
right console mast,using Allen wrench.Do
the same on left console mast
(Do not tighten the bolts)
(Caution: be carful when connect two console
wires. There are pins inside connector, the pins
MUST be straight, otherwise it will cause
problem. The most problem is that no power on
monitor, or show E1)
STEP 5- Assemble the protective cover
A). Assembly the protective cover to base
frame, secure with screw 4X10mm
using Allen wrench.
to the main body
ASSEMBLY INSTRUCTIONS
STEP 1 Assemble the Up-Right tubes
onto Base Frame. STEP 2 Assemble the handle bars into
the console.
STEP 3 Screw the M8x40mm bolts onto
the handle bars and tighten.
STEP 4
6
ASSEMBLY DRAWING
STEP 2- Assembly the handle bars into
STEP 1- Attach the console
masts to the base frame
A). Insert the left console mast (without a wire
attached inside) into the base frame. Attach
the left console mast with four M8X15mm
bolts using Allen wrench.
(Do not tighten the bolts)
B). Put the lower console wire and grounded wire
inside and through the right console mast using
the wire attached inside the right console mast,
insert the right console mast into the base frame,
right secure the console mast with four
M8X15mm bolts using Allen wrench.
(Do not tighten the bolts)
STEP 3- Screw on the M8x40mm bolt on
handle bars & tighten it.
(A) Refer to the attached drawing, first to screw &
tight the bolts #1 on handle bars,
then, to screw & tight the bolts #2
STEP 4- Attach the console to the
console masts
A).Secure with 6 pcs of M8X15mm bolt on the
right console mast,using Allen wrench.Do
the same on left console mast
(Do not tighten the bolts)
(Caution: be carful when connect two console
wires. There are pins inside connector, the pins
MUST be straight, otherwise it will cause
problem. The most problem is that no power on
monitor, or show E1)
STEP 5- Assemble the protective cover
A). Assembly the protective cover to base
frame, secure with screw 4X10mm
using Allen wrench.
to the main body
Assemble the Upper Console
onto the Up-Right tubes.
STEP 5 Assemble the side covers to the
main body.
(A) Assemble the left Up-Right tube onto the left side of the
Base Frame, use four M8X15mm bolts and the Allen wrench,
but do not tighten yet.
(B) There is a preinstalled guide cable inside the right side
Up-Right tube. Attach the lower Console Data Cable & Ground
Cable from the motor cavity area to the guide cable. Once
attached, nd the top portion of the guide cable at the top of
the Up-Right tube and pull the guide cable up through the tube
until the attached Console Data Cable & Ground Cable are
exposed. At this point, secure the cable for later use. Note:
make sure that you do not allow the cable set to slip back down
the Up-Right tube. Assemble the right Up-Right tube onto the
right side of the Base Frame. Use four M8X15mm bolts and the
Allen wrench, but do not tighten yet.
(A) Secure the handle bars onto the upper
console. Insert and tighten bolts as shown
in diagram #1 and #2.
(A) Assemble the side covers to base frame using
screw 4X10mm and the Allen wrench.
(A) Plug and connect the Console Cable and Ground Cable from the
right Up-Right tube to the cables from the Upper Console: Do not “force”
connection, make sure the pins line up evenly. Failure to do so may cause
the pins to bend which will prevent the treadmill from working properly. Refer
to attached drawing. Once the cables are attached to each other, place the
entire Upper Console onto the Up-Right tubes. (Make sure not to pinch Data
Cables between Upper Console and Up-Right tubes). Align the bolt holes
from both Up-Right tubes with the bolt holes from the Upper Console and
insert and tighten 6 pieces of M8X15mm bolt as shown. Again, make sure
that cables are not pinched between any parts of the treadmill.
