3idee hp-32f User manual

www.3idee.eu
hp-32f VESA adapter
Assembly instructions
The 3idee VESA adapter is compatible with the following product
from hp (hp.com) compatible:
32f
With the VESA adapter, you can conveniently attach your HP brand monitor to a
monitor arm with a VESA hole pattern (75 x 75mm). Use the included screws and
nuts.
If you want to mount your VESA adapter directly to the wall, use suitable screws
and dowels (not included).

2
Assembly instructions
Important Safeguards
Please read these instructions carefully and keep them for future reference.
If you pass the product on to third parties, these instructions should also
always be given. Failure to follow these instructions may result in injury or
damage to people and the product, for which we cannot accept any liability.
IMPORTANT - KEEP FOR FUTURE REFERENCE.
- Use of this product should always be in accordance with the specified safety instructions.
- Do not exceed the maximum weight of the compatible monitor models or serious injury or property
damage may result.
- Observe the maximum ambient temperature of 35°C when using the product.
- Do not mount the VESA adapter near a heat source or under direct sunlight as this may heat up the
adapter.
- Check whether your mounting point (e.g. monitor arm) can withstand the weight of the monitor with
VESA adapter.
- The product is designed exclusively for mounting with a hole pattern of 75x75 mm.
- After installing the VESA adapter, the position of the monitor must be readjusted to ensure proper
ergonomics.
⚠ CAUTION
Make sure that the device is switched off and disconnected from the power supply before
installation to avoid possible injury or damage.
1. Before First Use
Check the product carefully for possible transport damage and for the absence of accessories, such as
screws, which should be included in the scope of delivery.
⚠ CAUTION
Make sure that packaging materials and small screws and parts contained therein are
inaccessible to children to minimize the risk of choking and other risks.
2. Maintenance and Cleaning
2.1 Maintenance
- It is recommended to check every three months that all screws are still tight. Also, regularly check the
condition of all components of the product.
- Store the product in a cool and safe place, ideally at a maximum storage temperature of 40°C. For
additional safety, keep the product away from children and preferably in its original packaging.
- Avoid any vibrations and shocks so as not to affect the life and functionality of the product.
2.2 Cleaning

3Assembly instructions
- No corrosive or hot cleaning agents should be used to clean the product. Likewise, wire brushes, metal
or other sharp materials are unsuitable for cleaning and should not be used.
- For gentle and effective cleaning, the use of a soft, damp cloth is recommended.
3. Waste Disposal
For the disposal of this product we recommend to contact the responsible local authorities or disposal
services. They can provide you with detailed information on available disposal options and recycling
centers in your area.
4. Manufacturer Information
3idee Technologies S.à r.l.
5 Um Lenster Bierg
L-6125 Junglinster
Luxembourg
5. Help and Feedback
If you need help with your article, we are here for you. We also appreciate any feedback.
https://help.3idee.eu/en/contact

4
Assembly instructions
Scope of Delivery Accessories
4x M4x14 Phillips head screw
(SP5)
4x M4 Locknut (SP5)2x M3x8 Phillips head screw
(SP5)

5Assembly instructions
Horizontal / Vertical Alignment
Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This
limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information,
as the load limit of the adapter can quickly be exceeded if not installed properly.
We are continuously working on developing monitors and adapters that are also suitable for vertical
orientation.
However, monitors are designed for horizontal alignment by default.
Horizontal
Mounting: YES
Vertical
Mounting: NO

6
Assembly instructions
Assembly Instruction
Step 1
Place your screen in a safe, soft place so that your screen does not get damaged.
Remove the base of the monitor.
Step 2
Figure 1
Loosen the two screws on the bottom of the white clip. Then
you can pull it off the monitor. (Figure 1)
Step 3
Figure 2
The preparation is complete, now you can attach the 3idee
Vesa adapter to your monitor arm / wall. Use the provided
screws and nuts . (Figure 2)

7Assembly instructions
Step 4
Figure 3
For this step, it is best to have a second person help you.
Now take your monitor and carefully insert it into the mount
(Figure 3). Hold the monitor firmly while it is not yet
fixed to the mount with the 2 screws.
The screw holes in the Vesa adapter should now be aligned
with the threads in the metal part of the monitor.
Step 5
Figure 4
Now screw the 2 small screws from below into the Vesa
adapter until they are flush and tight with the monitor.
(Figure 4)
