3M™ Digital Projector X30
The 3M Digital Projector X30 features 2,600 lumens of brightness and a 2000:1 contrast ratio for exceptional
picture quality. Backed by the 3M brand for superior performance and reliability, the X30 is easy to install and
transport at only 7.9 pounds. A new hybrid filter operates for up to 4,000 hours under normal conditions enabling
savings in maintenance costs over the lifetime of the projector. It is ideal for education users and business
environments where advanced picture clarity and ease of use is a must.
• 2600 lumens*
• 2000:1 contrast ratio
• Quick Start and Instant Off
• Auto vertical keystone
• Input source naming
• 16W Audio Out sound
• "My Button" personalized settings
• Whiteboard and Blackboard Modes
• Video noise reduction
• Vivid image daytime mode
• Easy change top lamp door
• Hybrid lter with longer maintenance intervals
Features
[Monitor out port] [Computer port][Computer 2 port]
Audio in 3 R/L
ports (red&white)
[ ] [Control port]
[USB port]
[Video port]
[S Video]
[Components]
[Audio in 1 & 2]
[Audio out R/L]

Note: These sizes are +10 percent. This is due to
variations in the manufacture of the lens. If you are close
to one of the endpoints you should verify with your unit
that the image is the proper size at the proper distance.
Image Size 16:9 Image Size 4:3
Projection Distance Projection Distance
Min. [inch (m)] Max. [inch (m)] Min. [inch (m)] Max. [inch (m)]
30" (0.8) 38" (1.0) 45" (1.1) 34" (0.9) 41" (1.0)
60" (1.5) 77" (1.9) 91" (2.3) 70" (1.8) 83" (2.1)
80" (2.0) 102" (2.6) 122" (3.1) 94" (2.4) 112" (2.8)
100" (2.5) 128" (3.3) 153" (3.9) 118" (3.0) 140" (3.6)
150" (3.8) 193" (4.9) 229" (5.8) 177" (4.5) 211" (5.3)
200" (5.1) 258" (6.6) 306" (7.8) 237" (6.0) 281" (7.1)
300" (7.6) 388" (9.9) 460" (11.7) 356" (9.0) 422" (10.7)
Screen Size
Diagonal [inch (m)]
© 3M 2011. A ll rights reserved. Please recycle. Printed in USA. v01.11
3M Projection
Systems
Building A147-5N-01
6801 River Place Blvd.
Austin, TX 78726-9000
USA
3M Canada
PO Box 5757
London,
Ontario, Canada
NGA 4T1
3M Mexico, S.A. de C.V.
Apartado Postal 14-139
Mexico, D.F. 07070
Mexico
Important Notice
All statements, technical information, and recommendations related to 3M’s products are based on
information believed to be reliable, but the accuracy or completeness is not guaranteed. Before using this
product, you must evaluate it and determine if it is suitable for your intended application. You assume all
risks and liability associated with such use. Any statements related to the product which are not contained
in 3M’s current publications, or any contrary statements contained on your purchase order shall have no
force or effect unless expressly agreed upon, in writing, by an authorized officer of 3M.
Warranty; Limited Remedy; Limited Liability
This product will be free from defects in material and manufacture for a period of 3 years or 2500
hours from the time of purchase. 3M MAKES NO OTHER WARRANTIES or CONDITIONS INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. If this product is defective within the warranty period stated above, your exclusive
remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of the
3M product. Except where prohibited by law, 3M will not be liable for any indirect, special, incidental
or consequential loss or damage arising from this 3M product, regardless of the legal theory asserted.
3M, and the 3M logo are trademarks of 3M Company. Used under license in Canada. All other trade
names referenced are the service marks, trademarks, or registered trademarks of their respective
companies.
Optical
Resolution
Native: True XGA (1024 x 768)
Maximum: UXGA (1600 x 1200)
Imager set
0.63", P-Si TFT Panel
Aspect Ratio
native 4:3, 16:9 and 14:9 letterbox
Colors
16.7 million true colors (24 bit)
Contrast Ratio
2000:1
Brightness
2600 lumens (normal mode) maximum rating
1750 lumens (eco mode)
Projection Lens
F1.7-1.9 (f=19-23mm)
Screen Size (range)
30-300 inches
Throw Ratio (distance:width)
1.5:1 - 1.8:1
Zoom/Focus
Manual
Zoom Ratio
1.2:1
Optional Lenses
NA
Lamp
UHP 210W (normal mode), 140W (eco mode)
Lamp Life*
Up to 3000 hours (normal mode)
Up to 6000 hours (eco mode)
*Lamp life may vary due to environment, conditions and
usage. Lamp decreases over time.
Warranties
Projector
3 years or 2500 hours
Lamp
1 year discounted
Ultra Value Enhanced Warranty (optional)
Includes 1 free lamp, free loaner while unit is
being repaired and expedited service.
Not available outside U.S.
System Specifications
Video Compatibility
NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, SECAM
SDTV/HDTV
480i, 480p, 525i, 525p, 625i, 576i, 720p@60Hz,
750p, 1080@60Hz, 1125i
Digital Keystone Correction
Vertical ±30 degrees
Mouse Emulation
USB
Audio
1 x 16 Watt
Startup Screen
Customizable
Noise Level
Normal 37dB; Whisper 30dB
Feature Set
Auto off, 4x digital magnification, image blank
Horizontal Scan
31.5 - 106 kHz
Vertical Scan
56 - 120 Hz
Power Consumption
330W
Power Supply
AC 110~120V /220~240V (50/60 Hz)
Regulatory Approvals
UL, cUL, FCC Part 15 Subpart B, Class B, EN60950-1,
CE
Operating Temperature
41°- 95°F (5°- 35°C)
Storage Temperature
-4°- 140°F (-20°- 60°C)
Altitude
Sea level to 6000 ft. (1,829m)
800.328.1371 | www.3m.com/meetings
Specifications subject to change without notice.
Hg—LAMP CONTAINS MERCURY. Manage in accordance with disposal laws. See www.lamprecycle.
org or call 1-800-328-1371(USA), 1-800-364-3577 (Canada). For product disposal see www.eiae.org
(USA) or www.epsc.ca (Canada).
Technical Support
• Free unlimited software downloads and updates
available on our website at www.3m.com/meetings
• Toll free 24/7 Technical Support by calling 800.328.1371
Connections
Computer
Computer IN 1,2 15 pin HD – sub-analog computer input
USB Type B - mouse emulation
Monitor Out 15 pin HD – sub-analog computer output
Control 9 pin D- sub-RS-232 control port
Video
Component 3xRCA (Y, Cb/Pb, Cr/Pr) – component video input
S-Video 4 pin Mini-Din S-Video input
Video RCA-composite video input
Audio
Audio in 1, 2 3.5mm stereo mini jack– PC audio input
Audio Out* 2xRCA (red, white) –audio output
Audio in 3, 2xRCA (red, white) –right and left channel
audio input
*Audio is shared with computer and video inputs
Size
Dimensions (W x H x D)
12.5 x 4.6 x 11.3 in. (317 x 118 x 288mm)
Weight
7.9 lbs (3.58kg)
Accessories Included
Power cords (US, UK, Europe)
Remote control without laser (with AA batteries)
VGA/RGB cable
Multi-Language Operator’s Guide CD
Lens cap
Optional Accessories
Ultra Value Enhanced Warranty
(X30) U.S. only 78-6972-0010-9
Lamp replacement kit 78-6972-0008-3
Universal ceiling mount 78-6969-9874-5
Soft rolling bag 78-6969-9716-8
