3M SCP715 Manual

Super Close Projection System
SCP715/SCP740/SCP717
Operator’s Guide
Important Note
Before using this product, please read the “Product Safety Guide”
and related manuals to ensure the proper use of this product. After
reading them, store them in a safe place for future reference.
www.3m.com/meetings
Super Close Projection System
Operator’s Guide
© 3M 2008. All Rights Reserved
78-6971-1396-3

© 3M 2008. All Rights Reserved.
Contact 3M
In the event of missing and/or damaged equipment, or technical questions, the following
information can help in the completion of the installation.
Customer Service – 1-800-328-1371 (US)
SCP 700 Series Warranty Statements
Limited Warranty
• The 3M SCP700 Series projector (the “3M Product”) is warranted is warranted to be
free from defects in material or manufacture for a period of three (3) years from the
date of purchase or 4,000 hours of usage, whichever occurs rst.
• All other accessories of the 3M Product (those in the applicable modular congura-
tions), excluding the projector lamps, but including the wall mounts, ceiling mounts,
digital annotation sensors, and input/output devices are warranted to be free from de-
fects in material or manufacture for a period of one (1) year from the date of purchase.
• The lamp component of the 3M Product is warranted to be free from defects in mate-
rial and manufacture for a period of for a period of ninety (90) days after the date of
purchase of the 3M Product or 180 hours of lamp usage, whichever occurs rst. This
warranty is for parts only and in the case of an approved warranty claim for a lamp,
your exclusive remedy will be for a replacement product shipped to your location.
• Optional product upgrades and/or accessories that are not sold as part of any modular
conguration are subject to individual warranties.
THE WARRANTIES STATED ABOVE ARE EXCLUSIVE AND ARE MADE IN PLACE OF
ANY AND ALL WARRANTIES, EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS,
INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, OR ANY INDUSTRY PRACTICE OR CUSTOM OR TRADE
USAGE.
In the event the 3M Product fails to conform to the above stated warranties within the
applicable warranty period, your exclusive remedy shall be, at 3M’s option, to replace or
repair the 3M Product or to refund the purchase price of the 3M Product. All replaced parts
or products become property of 3M. If the product is repaired, 3M will repair the defective
part(s) with a new or used part(s). If the 3M Product is replaced, 3M will replace the 3M
Product with the same or equivalent model and with a new or refurbished 3M Product. In
the case of an approved warranty claim, the replacement 3M Product will carry only the re-
maining term of the original 3M Product’s warranty period as stated above. . For warranty
service, you must provide proof of the date of the orginal purchase else the manufacturing
code date will be used to establish the start date of the warranty. The following are exclu-
sions to the above listed warranty:

© 3M 2008. All Rights Reserved. iii
3M™ Super Close Projection System Table of Contents
a. This warranty does not cover 3M Product that is modied or damaged through im-
proper storage, misuse, abuse, accident, vandalism, improper installation, neglect,
improper shipping, damage caused by acts of war, disasters such as re, ood, and
lightning, improper electrical current, software problems, interaction with non-3M prod-
ucts, or service other than by an 3M Authorized Service Provider, neglect or mishan-
dling by any person. Normal wear and tear is not covered under warranty.
b. 3M Product is designed to operate in the typical indoor environment. This warranty
does not cover 3M Product used outside of the following circumstances:
o 100V-240V AC, 50/60 Hz
o 16° to 29° C (60° to 85° F)
o 10-80% RH (without condensation)
o 0-1828m (0-6000 feet) above sea level
c. The Air Intake and Exhaust Vent must be clear of obstructions, including any potential
blockage or obstructions caused from a ceiling or other mount. Inadequate air ventila-
tion will cause the 3M Product to malfunction or will cause damage to the 3M Product
which will void the warranty.
d. This warranty does not cover any additional costs including, but not limited to, those
associated with removal, cleaning or installation of the 3M Product, adjustments,
(mechanical or electronic) made to the 3M Product or replacing customer replaceable
parts like lamps and air lters.
e. This warranty covers only normal use of the product. 24-hour-per-day or other exces-
sive continual use causes strain and is not considered normal use.
f. This warranty does not cover consumables (e.g., fuses), other than lamps and only as
set forth below.
g. This warranty is not transferable.
h. 3M is not responsible for warranty service should the 3M label or logo or the rating
label or serial number be removed unless otherwise stated in writing for the purposed
of private labeling for partnership requirements.
i. This warranty does not cover postage, insurance, or shipping costs incurred in pre-
senting your 3M Product for warranty service. Said costs are the customer’s respon-
sibility. If a claimed defect cannot be identied or reproduced in service, the customer
may be held responsible for cost incurred. Should your warranty upgrade include a
“change out” service and the claimed defect cannot be identied or reproduced by the
technician, the customer will be responsible for call out costs.
FAILURE TO FOLLOW THE INSTRUCTIONS CONTAINED IN THE APPROPRIATE 3M
PRODUCT MANUAL OR TO USE THE 3M PRODUCT IN ACCORDANCE WITH 3M’S IN-
TENDED USE STATEMENT, WILL VOID ALL WARRANTIES AND LIMITED REMEDIES.

iv © 3M 2008. All Rights Reserved.
Table of Contents 3M™ Super Close Projection System
EXCEPT AS SPECIFICALLY STATED IN THE APPLICABLE 3M PRODUCT MANUAL, 3M
SHALL NOT BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUEN-
TIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, LOSS OF PROFITS, REVENUE
OR BUSINESS) RESULTING FROM, OR IN ANY WAY RELATED TO PERFORMANCE,
USE OR INABILITY TO USE ANY OF THE 3M PRODUCT. This limitation applies regard-
less of the legal theory upon which damages are sought.
For warranty support, please call or write your local 3M ofce or a 3M Authorized Service
Provider to obtain an RMA # (Return Material Authorization Number) before returning the
product. If you are inside the Continental United States of America, please contact 3M
Customer Service at 800-328-1371 or email [email protected].
What 3M Will Do To Correct Problems:
•If your 3M Product requires service, 3M will ask you to bring or send the 3M Product,
securely packaged in its original container or equivalent, along with proof of the date of
original purchase, to your 3M Service Dealer or 3M Service Center.
• 3M will, at its option, repair or replace the defective unit without charge for parts or
labor. Return of the 3M Product will be at 3M’s expense.
• When warranty service involves the exchange of the 3M Product or of a part, the item
replaced becomes 3M property.
• The exchanged 3M Product or part may be new or previously refurbished to the 3M
standard of quality, and at 3M’s option, the replacement may be another model of like
kind and quality.
• 3M’s liability for replacement of the warranted 3M Product or part will not exceed the
original retail selling price of the 3M Product. Exchange or replacement products or
parts assume the remaining warranty period of the product covered by this limited
warranty. However, each replacement lamp carries the limited 90-day warranty stated
above.

© 3M 2008. All Rights Reserved. v
3M™ Super Close Projection System Table of Contents
The 3M logo, and 3M are trademarks of the 3M Company.
Important Notice
All statements, technical information, and recommendations related to 3M’s products are
based on information believed to be reliable, but the accuracy or completeness is not
guaranteed. Before using this product or implementation, you must evaluate them and de-
termine if they are suitable for your intended application or situation. You assume all risks
and liability associated with such use or implementation. Any statements related to the
product which are not contained in 3M’s current publications, or any contrary statements
contained on your purchase order shall have no force or effect unless expressly agreed
upon, in writing, by an authorized ofcer of 3M.
All rights reserved. No part of this book covered by the copyrights hereon may be repro-
duced or copied in any form or by any means-graphic, electronic, or mechanical, including
photocopying, taping or information storage and retrieval systems-without written permis-
sion of 3M Projection Systems Department.

© 3M 2008. All Rights Reserved. 1
3M™ Super Close Projection System Table of Contents
Table of Contents ......................................................................................... 1
Usage Notice................................................................................................ 2
Precautions...........................................................................................................2
Important Note......................................................................................................6
Introduction................................................................................................... 7
Product Features..................................................................................................7
Package Overview................................................................................................8
Product Overview .................................................................................................9
Main Unit........................................................................................................................9
Control Panel ...............................................................................................................10
Connection Ports ......................................................................................................... 11
Remote Control with Mouse Function..........................................................................12
Installation .................................................................................................. 13
Connecting the Projector....................................................................................13
Connect the Computer/Notebook ................................................................................13
Connect the Video .......................................................................................................14
Powering On/Off the Projector............................................................................15
Powering On the Projector...........................................................................................15
Powering Off the projector ...........................................................................................16
LED Indicator ...............................................................................................................16
Adjusting the Projected Image............................................................................17
Adjusting the Projector Image Height ..........................................................................17
Adjusting the Projector Focus ......................................................................................18
3M Super Close Projection System SCP715/SCP717 Adjusting Projected Image
Size ..............................................................................................................................18
3M Super Close Projection System SCP740 Adjusting Projected Image Size ............19
User Controls ............................................................................................. 20
Control Panel & Remote Control ........................................................................20
On-Screen Display Menus..................................................................................23
How to Operate ...........................................................................................................23
Menu Tree-1/2..............................................................................................................24
Menu Tree-2/2..............................................................................................................25
Information ...................................................................................................................26
Management-1/3..........................................................................................................27
Management-2/3..........................................................................................................29
Management-3/3..........................................................................................................31
Image-1/2.....................................................................................................................32
Image-2/2.....................................................................................................................35
LAN ..............................................................................................................................37
Security ........................................................................................................................41
Appendices................................................................................................. 43
Troubleshooting..................................................................................................43
Replacing the Lamp............................................................................................47
Compatibility Modes ...........................................................................................48
RS232 Protocol Function List.............................................................................49
Regulation & Safety notices ...............................................................................52

2 © 3M 2008. All Rights Reserved.
Usage Notice 3M™ Super Close Projection System
Precautions
Follow all warnings, precautions and maintenance as
recommended in this user’s guide to maximize the life of
your unit.
WARNING
• Do not look into the projector’s lens when the lamp is on. The
bright light may hurt your eyes.
• To reduce the risk of injury to the eyes, do not look directly into
the laser light on the remote control and do not point the laser
light into anyone eyes. This remote control is equipped with a
Class II laser that emits radiation.
• To reduce the risk of re or electric shock, do not expose this
product to rain or moisture.
• Please do not open or disassemble the product as this may
cause electric shock.
• When changing the lamp, please allow unit to cool down, and fol-
low all changing instructions.
• Position the power cord and data cable so that they can not be
tripped over.
• Do not remove any screws other than those specied in the lamp
replacement instructions.
• Disconnect power cord when the projector is not in use, during
lamp replacement and while cleaning.
• Switch power "OFF" and disconnect the plug from electrical outlet
before replacing the lamp. Grasp plug and pull to disconnect.
• Do not attempt to service the projector; other than the lamp car-
tridge there are no user serviceable parts inside the projector.

© 3M 2008. All Rights Reserved. 3
3M™ Super Close Projection System Usage Notice
WARNING
• Do not attempt to service the projector other than performing
routine lamp replacement. Service should only be performed by
a 3M authorized service provider. Aside from the projection lamp
assembly, there are no serviceable parts inside the unit.
• Contact a 3M authorized service provider for service.
•Do not modify this projector.
• Do not allow water or other liquids to enter the projector.
• Do not operate this projector in wet environments or outdoors.
• Do not use this projector around unsupervised children.
• Replace power cord if damaged.
• Contact a 3M authorized service provider if the projector be-
comes damaged.
•Connect this projector into a grounded outlet.
• Use a grounded extension cord with a rating at least equal to that
of the projector.
•Use only the 3M brand wall mounting hardware kit if wall mount-
ing is desired.
- Installation of 3M wall kit must only be performed by qualied
personnel.
- Adhere strictly to the proper installation procedure as outlined in
the installation instructions when installing the 3M wall kit.
• Always operate the unit on a at, sturdy, and horizontal surface.
• Before operating, please read owner's manual. Do not remove
screws except lamp cover screws. Do not block venting open-
ings.

4 © 3M 2008. All Rights Reserved.
Usage Notice 3M™ Super Close Projection System
WARNING
• Lamp replacement caution. Before removing the screws, discon-
nect the power cable. Hot surface inside. Allow 1 hour to cool
before replacing the lamp. Handle with care. Risk of explosion.
See Owner's Manual.
• Unplug the projector from the electrical outlet and allow the lamp
to cool for 60 minutes before replacing the lamp.
•Wait at least 30 minutes for the lamp assembly to cool before
replacing.
• Always handle the fragile lamp module with care.
• In the event of a lamp rupture, call a 3M authorized service pro-
vider for repair. Ruptured lamp is not user serviceable.
• Ventilate the area where the lamp rupture occurred. The lamp
operates at high pressure and temperature.
• Replace the lamp module when the lamp replacement message
appears.
• Never replace the lamp module with a previously used lamp
module.
•Hg: Lamp contains mercury. Don't throw in trash. Dispose ac-
cording to local, state, or federal laws. See www.lamprecycle.org
or call 1-800-328-1371.
• Wash your hands thoroughly if contact with ruptured lamp debris
has taken place.
• Ventilate the area where the lamp rupture occurs. The lamp oper-
ates at high temperature.

© 3M 2008. All Rights Reserved. 5
3M™ Super Close Projection System Usage Notice
WARNING
• Use only battery type AA.
- Orient the batteries plus (+) and (-) terminals of the batteries ac-
cording to the markings found on the remote control.
- Do not leave the battery in the remote for an extended period of
time.
- Do not heat, disassemble, short, recharge, or expose to re or
high temperature.
- Do not carry batteries loose in your pocket or purse.
- Avoid eye and skin contact in the event that battery would leak.
- Do not mix used and new batteries.
• Dispose of exhausted batteries in accordance with applicable
federal, state and local regulations.
•Avoid looking directly into projector lens while the lamp is on.
•Keep the battery and battery cover away from children and pets.
• Changes or modications not expressly approved by the manu-
facturer could void the user's authority, which is granted by the
Federal Communications Commission to operate this computer.
Do:
Turn off the product before cleaning.
Use a soft cloth moistened with mild detergent to clean the
display housing.
Disconnect the power plug from AC outlet if the product is not
being used for a long period of time.
Don’t:
Block the slots and openings on the unit provided for ventilation.
Use abrasive cleaners, waxes or solvents to clean the unit.
Use under the following conditions:
- In extremely hot, cold or humid environments.
- In areas susceptible to excessive dust and dirt.
- Near any appliance that generates a strong magnetic eld.
- In direct sunlight.

6 © 3M 2008. All Rights Reserved.
Usage Notice 3M™ Super Close Projection System
Important Note
1. This product will detect the life of the lamp itself. Please be
sure to change the lamp when it shows warning messages.
2. Reset the “Lamp Counter Reset” function from the On
Screen Display “Management” menu after replacing the
lamp module (refer to page 28).
3. When switching the projector off, please allow the projector
to complete its cooling cycle before disconnecting the power.
4. Turn on the projector rst and then the signal sources.
5. When the lamp reaches the end of its life, it will burn out
and may make a loud popping sound. If this happens, the
projector will not turn back on until the lamp module has
been replaced. To replace the lamp, follow the procedures
listed under “Replacing the Lamp”. (see page 47)

© 3M 2008. All Rights Reserved. 7
3M™ Super Close Projection System Introduction
Product Features
3M Super Close Projection System SCP715/SCP717
are XGA single chip 0.7” DLP®projectors and 3M Super
Close Projection System SCP740 is a WXGA single chip
0.65” DLP® projector. Outstanding features include:
SCP715/SCP717 - True XGA, 1024 x 768 addressable
pixels
SCP740 - True WXGA, 1280 x 800 addressable pixels
Texas Instruments Single chip DLP®Technology
NTSC/NTSC4.43/PAL/PAL-M/PAL-N/SECAM and HDTV
compatible (480i/p, 576i/p, 720p, 1080i/p)
Multi-Auto functions: Auto detection, Automatic saving of
user adjustments
Full function IR remote control with mouse function
User friendly multilingual on screen menu
Advanced digital keystone correction and high quality full
screen image re-scaling
User friendly control panel
Two built-in speakers with 2 Watt amplier
Multiple for Audio inputs
Computer Compatibility: UXGA, SXGA+, SXGA
compression and SVGA, VGA re-sizing
Mac compatible
DVI support (HDCP compliant)
Support Network function (LAN/RS232)

8 © 3M 2008. All Rights Reserved.
Introduction 3M™ Super Close Projection System
US AC Power Cord
VGA Cable
Wireless Remote
Controller
Projector
Package Overview
This projector comes with all the items shown below.
Check to make sure your unit is complete. Contact your
dealer immediately if anything is missing.
Documents :

Operator’s Guide

Quick Start Card

Product Safety Guide

WEEE Card
2 x AA Batteries
UK AC Power Cord
EUR AC Power Cord 3.5mm Audio Cable
USB Cable

© 3M 2008. All Rights Reserved. 9
3M™ Super Close Projection System Introduction
1. Control Panel
2. Focus Ring
3. Projection Lens
4. Elevator Button
5. Elevator Foot
6. Power Socket
7. Connection Ports
8. IR Receivers
Main Unit
Product Overview
1
2
3
5
8
7
6
4

10 © 3M 2008. All Rights Reserved.
Introduction 3M™ Super Close Projection System
Control Panel
1. Four Directional Select Keys
2. Keystone +/-
3. Enter
4. Menu (On/Off)
5. Source Select
6. Re-Sync
7. Power/Standby
8. Power/Standby LED
9. Lamp Indicator LED
10. Temp Indicator LED
1 2 4 6
235 7 9
8 10

© 3M 2008. All Rights Reserved. 11
3M™ Super Close Projection System Introduction
Connection Ports
1. Power Socket
2. 5V-Relay Connector (Output: 5VDC, 2A )
3. RS232 Connector
4. Audio Input Connector (for S-Video or Composite)
5. Audio Output Connector
6. Audio Input Connector (for DVI-D or RGB1-In or RGB2-In)
7. KensingtonTM Lock Port
8. Networking Connector RJ45
9. USB Connector (connect to PC for Remote Mouse function)
10. Composite Video Input Connector
11. S-Video Input Connector
12. Monitor Loop-through Output Connector
13. RGB2-In Connector (PC Analog Signal/HD/Component
Video Input)
14. RGB1-In SCART Connector (PC Analog Signal/SCART
RGB/HD/Component Video Input)
15. DVI-D Input Connector (PC Digital/HDTV/HDCP Input)
1 2 3 4 5 6 7
8 9 10 11 12 13 14 15

12 © 3M 2008. All Rights Reserved.
Introduction 3M™ Super Close Projection System
Remote Control with Mouse Function
1. Power
2. Mute
3. Timer
4. Display Format
5. Mouse
6. Mouse Right Click
7. Page Up
8. Page Down
9. Four Directional Select
Keys
10. Re-Sync
11. Enter
12. S-Video Source
13. Composite Video
Source
14. DVI Source
15. Source Lock
16. Blank
17. Freeze
18. Display Mode
19. Mouse Left Click
20. Zoom In
21. Zoom Out
22. Clear
23. Menu
24. VGA1 Source
25. VGA2 Source
26. Number Buttons
1
2
3
4
5
6
7
8
9
11
12
13
1415
16
17
18
19
20
21
22
24
25
26
23
10

© 3M 2008. All Rights Reserved. 13
3M™ Super Close Projection System Installation
Connecting the Projector
1....................................................................................................Power Cord
2....................................................................................... Audio Output Cable
3..............................................................Network Cable (optional accessory)
4.....................................................................................................USB Cable
5................................................................ RS232 Cable (optional accessory)
6.....................................................................................................VGA Cable
7.......................................................... DVI to DVI Cable (optional accessory)
8.........................................................Audio Input Cable (optional accessory)
Connect the Computer/Notebook
1
4
3
5
8
67
2
VGA DVI
RS232
USB
5V Relay Output
Audio Output
(For Active Speakers)

14 © 3M 2008. All Rights Reserved.
Installation 3M™ Super Close Projection System
Connect the Video
1....................................................................................................Power Cord
2....................................................................................... Audio Output Cable
3................................................Composite Video Cable (optional accessory)
4............................................................. S-Video Cable (optional accessory)
5.........................................................Audio Input Cable (optional accessory)
6...................VGA to 3 RCA Component/HDTV Adapter (optional accessory)
7................................RCA Component Cable for YPbPr (optional accessory)
8.....................................................................................................VGA Cable
9....................................................HDMI to DVI Adapter (optional accessory)
10................................................................HDMI Cable (optional accessory)
S-Video Output
Video Output
Audio Output
(For Active Speakers)
DVD Player, Set-top Box,
HDTV receiver
5V Relay Output
1
3
5
5
4
6
8
9
10
7
2

© 3M 2008. All Rights Reserved. 15
3M™ Super Close Projection System Installation
Powering On the Projector
1. Ensure that the power cord and signal cable are securely
connected. The Power LED will turn red.
2. Turn on the lamp by pressing “Power/Standby” button on the
control panel.And the Power LED will turn blue.
3. Turn on your source (computer, notebook, video player,
etc.). The projector should automatically detect your source
within “Management” menu; check that “Input Source” has
been set to “Auto Searching”.
To access the built-in test pattern, please press the “Blank”
button, then up arrow.
If you connect multiple sources at the same time, use the
“Source” button on the control panel or direct source key on
remote control to switch.
Powering On/Off the Projector
Power/Standby
• Turn on the
projector rst and
then the signal
sources.
Test Pattern
1
1
