3M™ Digital Projector DX70i
With the 3M Digital Projector DX70i utilizing the DarkChip3 DLP Technology your projected image
will take on a whole new level of WOW! The 3M DX70i Digital Projector delivers exceptionally
bright, crisp images, vibrant color and brightness uniformity.
• XGA (1024 x 768) resolution
• 4200 lumens*
• Lightweight at only 8 lbs.
• Digital Keystone Correction
• 2 RGB inputs, 1 RGB output
• 4:3 native aspect ratio; 16:9 supported
• DVI-D input
• Network control
• 30"-350" image range
• 3-Year standard warranty included
• High usage warranty upgrade available
Features
[Audio-in 1 Port]
[Audio-in 3 Port]
[DVI-D Input]
[S-Video Port]
[VGA-in 1 Port]
[Video Port]
[RJ45]
[USB Port]
[VGA Out Port][VGA-in 2 Port/
SCART
[Audio-in 2 Port][Audio Out Port]
[RS-232]
[Power Inlet]
3M DX70i Projector
78-9236-7706-2

Image Size 4:3
eProjection Distance
Minimum (m) Maximum (m)
64" (1.6)
96" (2.4)
160" (4.1)
240" (6.1)
320" (8.1)
480" (12.2)
Screen Siz
(Diagonal)
40" (1.0)
60" (1.5)
100" (2.5)
150" (3.8)
200" (5.1)
300" (7.6)
77" (2.0)
115" (2.9)
192" (4.9)
288" (7.3)
384" (9.8)
576" (14.6)
Image Size 16:9
Projection Distance
Minimum (m) Maximum (m)
70" (1.8)
105" (2.7)
174" (4.4)
261" (6.6)
348" (8.8)
522" (13.3)
84" (2.1)
125" (3.2)
209" (5.3)
314" (8.0)
418" (10.6)
627" (15.9)
Note: These sizes are +10
percent. This is due to variations
in the manufacture of the lens. If
you are close to one of the end-
points you should verify with your
unit that the image is the proper
size at the proper distance.
© 3M 2011. A ll rights reserved. Please recycle. v01.11
3M Mobile
Interactive Solutions
Building A147-5N-01
6801 River Place Blvd.
Austin, TX 78726-9000
USA
3M Canada
PO Box 5757
London,
Ontario, Canada
NGA 4T1
3M Mexico, S.A. de C.V.
Apartado Postal 14-139
Mexico, D.F. 07070
Mexico
Important Notice
All statements, technical information, and recommendations related to 3M’s products are based on
information believed to be reliable, but the accuracy or completeness is not guaranteed. Before using
this product, you must evaluate it and determine if it is suitable for your intended application. You assume
all risks and liability associated with such use. Any statements related to the product which are not con-
tained in 3M’s current publications, or any contrary statements contained on your purchase order shall
have no force or effect unless expressly agreed upon, in writing, by an authorized officer of 3M.
Warranty; Limited Remedy; Limited Liability
This product will be free from defects in material and manufacture for a period of 3 years or 2500 hours
from the date of purchase. 3M MAKES NO OTHER WARRANTIES or CONDITIONS INCLUDING, BUT NOT
LIMITED TO, ANY IMPLIED WARRANTY OR CONDITION OF MERCHANTABILITY OR FITNESS FOR A PAR-
TICULAR PURPOSE. If this product is defective within the warranty period stated above, your exclusive
remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of the
3M product. Except where prohibited by law, 3M will not be liable for any indirect, special, incidental or
consequential loss or damage arising from this 3M product, regardless of the legal theory asserted.
3M, and the 3M logo are trademarks of 3M Company. Used under license in Canada. All other trade names
referenced are the service marks, trademarks, or registered trademarks of their respective companies.
Optical
Resolution
Native: XGA (1024 x 768)
Maximum: UXGA (1600 x 1200)
Imager Set
Single 0.7" XGA DarkChips 3™
DLP® Technology by Texas Instruments
Aspect Ratio
4:3 native and 16:9 supported
Colors
16.7 million (24 bit)
Contrast Ratio
2300:1
Brightness
4200 lumens (maximum rating)
Projection Lens
F2.4-2.6 (f=28-33.6mm)
Throw Ratio (Distance: Image Width)
2.0:1 - 2.4:1
Screen size (range)
30-350 inches diagonal
Zoom/Focus
Manual
Zoom Ratio
1.2:1
Lamp
Osram 280W (normal mode), 250W (whisper mode)
Lamp Life
2000 hours (normal mode)
Up to 3000 hours (whisper mode)
Size
Dimensions (W x H x D)
13.2 x 3.9 x 9.8 in. (335 x 100 x 250mm)
Weight
8 lbs (3.6kg)
Warranties
For details see www.3m.com/meetings/warranties
Projector
3 years or 2500 hours
Lamp
90 days or 180 hours with remainder of 1 year prorated
Ultra Value Warranty Enhancement (optional)
Includes 1 free lamp, free loaner while unit is
being repaired and expedited service.
Not available outside U.S.
High Usage Warranty Upgrade (optional)
Covers unlimited hours of usage during 3 year term.
Note: Standard Warranty covers 2500 hours of usage
during 3 year term.
System Specifications
Video Compatibility
NTSC, NTSC 4.43, PAL (B, D, G, H, I, M, N), SECAM (B,
D, G, K, Kl, L)
SDTV/HDTV
525i(480i), 576p(480p), 750p(720p@60Hz),
1125i(1080i@60Hz)
Computer Resolution
640x480 (VGA), 800x600 (SVGA), 1024x768
(XGA), 1280x1024* (SXGA), 1400x1050* (SXGA+),
1600x1200* (UXGA), 832x624 (MAC 16") *resolution
digitally compressed.
Digital Keystone Correction
Vertical & Horizontal ±15 degrees
Audio Output
2x2 Watt
Noise Level
Normal 32dB; Whisper 30dB
Horizontal/Vertical Scan
15-91kHz/ 50-85Hz
Power Consumption
385W (Normal Mode); 320W (Whisper Mode)
Power Supply
Universal: 100-120V/220-240V, 50/60Hz
Regulatory Approvals
UL, cUL, FCC Part 15 -Class B, CE, EN60950-1, WEEE
Operating Temperature
41°- 95°F (5°- 35°C)/0-2500 Ft.
Temperature Altitude
41°- 86°F (5°- 30°C)/2500-5000 Ft.
41°- 77°F (5°- 25°C)/5000-10,000 Ft.
Storage Temperature
-4°- 140°F (-20°- 60°C)
Maximum Humidity
80% RH with no condensation
800.328.1371 | www.3m.com/meetings
Specifications subject to change without notice.
Hg—LAMP CONTAINS MERCURY. Manage in accordance with disposal laws. See www.lamprecycle.
org or call 1-800-328-1371(USA), 1-800-364-3577 (Canada). For product disposal see www.eiae.org
(USA) or www.epsc.ca (Canada).
Technical Support
• 24/7 Technical Support by calling 800.328.1371
Connections
Computer
VGA-1 - In 15 Pin HD-sub analog computer input
VGA-2 - In/SCART 15 Pin HD-sub analog computer input
VGA-Out 15 Pin HD-sub analog computer input
DVI-D 29 Pin DVI-D digital computer input
USB USB Type B - mouse emulation
RS-232 3 Pin Mini-Din control port
RJ45 Wired LAN for control via web
Video
S-Video 4 Pin Mini-Din - S-Video input
RCA-composite Composite video input
Component Shared with VGA2
Audio
Audio In 1,2,3 3.5mm stereo mini jack - PC and Video
audio input
Audio Out* 3.5mm stereo mini jack - audio output
*Audio output is shared with computer and video inputs
Accessories Included
Lens cap
Power cords (US, UK, Europe)
Remote control with 2 AAA batteries
Multi-language Operator's Guide CD
VGA/RGB cable
S-Video cable
USB cable
Free unlimited software downloads and updates available on
our website at www.3m.com/meetings
Optional Accessories
Lamp replacement kit (WDX70i) 78-6969-9994-1
Universal ceiling mount 78-6969-9874-5
Ultra Value Enhanced Warranty
(WDX70i) U.S. only 78-9998-3418-3
High Usage Warranty
(HUWDX70i) U.S. only 78-9998-3419-1
