3MillID S-Gang Keypad Reader User manual

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comImages shown in this document are for illustrative purposes only. The features, colours, style and appearance may change without notice.Product FeaturesDesigned to embrace cutting-edge RFID technologies in a stylish and innovative package, this advanced access control reader offers a refreshing breakthrough in the access security marketplace. Shaped in a sleek single-gang style design, with an RGB LED illuminated keypad, offering ‘prox-and-pin’ security, the reader may be fixed directly onto a US electrical backbox.This powerfully secure and innovative reader has a beautifully clean aesthetic, and a bright RGB LED that can be applied to many applications such as colour coded access levels, migration status or mood lighting.The reader housing is moulded using tough polycarbonate plastic, and includes a shadow-line backplate, a subtle and simple mechanical design feature that makes the reader, when fixed, appear to float against the wall.•125KHzProximity•13.56MHzSmart Contactless•Bluetooth LE•Black textured moulding•Slim profile•RGB LED•Fully encapsulated electronics•RGB illuminated keypad•Wide range of output formats•5 year limited warranty•Read range up to 10cm (4 inches)MANUAL3MS-GangKeypad
style or technology - now you can have both

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.com3millID acknowledges all copyrights and registered trademarks used by third parties. No affiliation is implied, or should be inferred, to the use of any tradename or reference to copyright material.Any reference to copyright material or registered trademarks within this document is used purely to depict or identify such material for the purpose of comment, description or comparison, and to assist in the evaluation of products or services described herein.No part of this publication may be reproduced or translated into other languages or transmitted into a language used by data processing machines without the express written consent of 3millID.E&OEWe do our best to provide accurate and reliable information at the time of publication, but due to continuous developments we cannot be held responsible for clerical errors, omissions or outdated information, and we reserve the right to amend, alter or withdraw such information, without notice.Images shown in this document are for illustrative purposes only. The features, colours, style and appearance may change without notice.EQUIPMENT*******These devices comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.These devices contains: FCC ID: TCZ-10103751G1UTJ-AV90These RFID proximity readers comply with the essential requirements and relevant provisions of:EU Directive 2014/53/EC.Together with information provided by suppliers and subcontractors, these devices comply with the requirements and relevant provisions of:EU Directive 2011/65/EC.This symbol on the product or on its packaging indicates that the product must not be disposed of with normal household waste. Instead, it is your responsibility to dispose of your waste equipment by arranging to return it to a designated collection point for the recycling of waste electrical and electronic equipment. By separating and recycling your waste equipment at the time of disposal you will help to conserve natural resources and ensure that the equipment is recycled in a manner that protects human health and the environment.EU Directive 2012/19/ECSECTIONTITLE PAGE1.Parts List 32.Specification 33.Installation Guide 44.Keypad (programming guide)52CONTENTSMANUAL3MS-GangKeypad
style or technology - now you can have both

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.com1 xreader MODULE1 xreader BACKPLATE1 x3 x 10mm black cross-head securing screw10cmup to+ -6635C5yrs1.parts list2.specificationperformance level for access controlThis product complies with the following UL294 Access Control Performance Levels:Destructive AttackLevel ILine SecurityLevel IEnduranceLevel IVStandby PowerLevel ISee the UL Listed access control unit controller installation instructions for reader compatibility.UL Ref. Number??????environmentalOperating Temperature-35°C to +66°C (-31°F to + 151°F)Humidity85 ±5% at 30 ±2°C (86 ±3°F)Ingress ProtectionIP65 (not evaluated by UL)PositioningSuitable for INDOOR and OUTDOOR use.electricalPower supplyPower is to be provided by a UL294 Listed, low-voltageClass 2 power limited supply or control panel, capableof 4 hours standby.Voltage+10Vdc to +16VdcCurrent135mA typicalData VoltageRest >4Vdc / Active <1VdcData OutputWiegand, Clock & Data, Custom OutputsIndication1 RGB LED + RGB illuminated keypadSounderIntegral speakerdimensions120mm x 76mm x 21mm(4.7 x 3.0 x 0.8 inches)polymeric materialsPotting compoundUL R/C (QMFZ2)MouldingsUL746CwiringWiring methods shall be in accordance with theNational Electrical Code (ANSI/NFPA70), localcodes, and the authorities having jurisdiction.Recommended cableBELDEN 953x (or equivalent UL listed) - WiegandBELDEN 9502 (or equivalent UL listed) - RS485All cable and wiring must be Listed and suitable for use.Cable lengthCable length must not exceed 30 metres maximum(98.5 feet) for ULMinimum permissible wire sizenot less than 26 AWG (0.24mm²)connectionsScrew terminal(All readers in this series use this terminal connection) 1-0VSupply voltage ground 2-+VdcSupply voltage (+10Vdc to +16Vdc) 3-DATA1/CLKWiegand or Clock/Data output 4-DATA0/DATWiegand or Clock/Data output 5-GREENGreen LED control input 6-REDRed LED control input 7-BuzzerBuzzer control input 8-TMPR/CPTamper or Card Present output 9-RS485-RS485 Bus10-RS485+RS485 Bus
120mm4.7 inches
21mm0.8 inch76mm3.0 inches6809#47*5123MANUAL3MS-GangKeypad3

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comRemove module securement screw. Lever bottom edge of reader module away from the backplate, and lift up.Fix reader BACKPLATE to a plain surface finish, using suitable screw fixings having a diameter no greater than 4mm (0.15 inch).If printed full scale, you may use the drawing below as a fixing template.MEASURE and CHECK DIMENSIONS before use.NOTE:Mounting this reader on (or near) metal may impair the read range of the unit.3.installation guideFasten the reader module, ensuring the top-edge fixings engage correctly with therecesses at the top of the backplate. Swing the bottom edge of the module downand forward until you feel the unit ‘snap’ shut.Secure the module to the backplate using the M3x10mm screw supplied.If required, you may opt to use a security screw to the sizes shown here.Following installation, it is recommended the access control system and controlunits are subjected to a maintenance and operational test procedure.TEST COMPLETE SYSTEM AT LEAST ONCE A YEAR
i12i31
Once the backplate is secured, make wire connections to the reader, in accordance with the screw terminal connections shown on Page 3 of this document and your control panel requirements. Ensure the cable does not impair or prevent the reader module being secured.
i23
83.3mm (US)3.3 inches
60.3mm (UK/EU)2.4 inches
53.0mm2.1 inches
53.0mm2.1 inches
15mm0.6 inch
centrelineBACKPLATEFixing holes - 4mm maximum diameter.MANUAL3MS-GangKeypad4

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.com‘MIFARE’, ‘MIFARE Classic’ and ‘MIFARE DESFire EV1’ are trademarks of NXP B.V.MANUAL3MS-GangKeypad5- entering programming mode- set PIN mode (output)- set audible tone on key press- set audible tone on card- set proximity reading- set LED colour configuration- set site code embedding- set LED quiescent colour66777888LOG ONPIN MODEKEY TONECARD TONEPROX READRX00 LEDSITE CODERX00 COLOUR*00*01*02*03*04*05*06*07 pageKEYPAD SECTIONTITLEDESCRIPTION- set reader to read HID®- set reader to read EM- set reader to read CASI- set reader to read AWID- set reader to read KANTECH- set reader to read FARPOINTE- set reader to read MIFARE®- set reader to read ENDIAN- set reader to read DESFire®RX00 HIDRX00 EMRX00 CASIRX00 AWIDRX00 KANTECHRX00 FARPOINTERX80 MIFARERX80 ENDIANRX90 DESFIRE*10*11*12*13*14*15*20*21*30- set engineer’s PIN code- exit configuration mode1212SET PINLOG OFF*98*99999101010111111The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad6
*010#*011#*012#*013#*014#*015#*016#*017#*018#*019#..................................................example*00nnnn#LOG-ONPIN CODES
*00
entering ‘PROGRAMMING MODE’exampleBefore you can configure the reader you MUST enter programming mode by using this command. You must enter the correct four-digit security PIN for the reader.The factory default PIN = 1234This programming command allows you to configure how the reader handles keypad data. The reader is capable of keypad data output in a number of industry-standard formats. The following modes are supported:*010#*011#*012#*013#*014#*015#*016#*017#*018#*019#DISABLED (NO keypad output)HID 4-bit WIEGAND (factory default)Dorado 8-bit WIEGAND (compatible with INDALA)Mercury 8-bit WEIGAND burst1 digit CLOCK and DATADorado 8-bit burst8 digit CLOCK and DATA (buffered)26-bit WIEGAND (buffered)32-bit WIEGAND (buffered)34-bit WIEGAND (buffered)To set the reader to buffer keystrokes and output them in the industry-standard 26-bit WIEGAND format, you should enter: *017# once the reader has been placed into programming mode.To place a FACTORY-DEFAULT reader into programming mode, you must enter: *001234# After entering programming mode, the reader will time out after approximately 30 seconds if no keys are pressed for that duration. Any changes you may have made to values or settings will be lost.To change the log-on PIN code, see:Section *98 on Page 12 of this document.NOTE:To exit PROGRAMMING MODE see:Section *99 on Page 12 of this document.You must correctly exit this mode to save any changes to values or settings you may have made.NOTE:
6809#47*5123The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
PIN modePIN CODES
*01
set PIN mode (output)*01n#
6809#47*5123

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad7
KEY TONEPIN CODES
*02
set AUDIBLE TONE on KEY PRESSCARD TONEPIN CODES
*03
set AUDIBLE TONE on CARDPROX READPIN CODES
*04
set PROXIMITY READING*020#*021#..........*02n#example*030#*031#..........*03n#example*040#*041#..........*04n#example
The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
DISABLE(NO audio tone) (factory default)ENABLE(audible tone on PIN entry)To ENABLE the buzzer, enter: *021# once the reader has been placed into programming mode.During the entry of a buffered PIN you have the option of making the reader issue a confirmation beep or an error (triple-beep) on entering the PIN.
6809#47*5123
During the entry of a buffered PIN you have the option of making the reader issue a confirmation beep or an error (triple-beep) on presenting a CARD.To ENABLE audio tone, enter: *031# once the reader has been placed into programming mode.DISABLE(NO audio tone) (factory default)ENABLE(audible tone on presenting a card)
6809#47*5123
This programming command allows you to disable transmission of the proximity card data from the reader.The reader will still beep to indicate that it has read the card.To DISABLE transmission of the card data, enter: *040# once the reader has been placed into programming mode.DISABLE(data will NOT be sent)ENABLE(data WILL be sent) (factory default)
6809#47*5123

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad8
*05n#example*050#*051#*052#*053#*054#.........................*06nnnnn#example*07n#example*070#*071#*072#*073#*074#*075#*076#*077#........................................RX00 LEDPIN CODES
*05
set LED COLOUR CONFIGURATIONSITE CODEPIN CODES
*06
set SITE CODE EMBEDDINGRX00 COLOURPIN CODES
*07
set LED QUIESCENT COLOURTo set RX Demo enter: *051# once the reader has been placed into programming mode.The LED may be configured to the following modes:
6809#47*5123The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
RX standard LED configurationRX DemoRX buzzerRX AWE (excluded from documentation)RX MPS (excluded from documentation)This option allows the SITE CODE number to be combined with the card number read from the card and sent as the complete card info’ message. The unit accepts site codes from 0 to 65535 - however the maximum valid value depends on the output format.To embed SITE CODE ‘123’ enter: *0600123# once the reader has been placed into programming mode.
6809#47*5123
The LED may be configured to the following standard colours.To set the LED to TURQUOISE enter: *076# once the reader has been placed into programming mode.
6809#47*5123
BlueMagentaYellowOrangeRedWhiteTurquoiseOFF (LED disabled when in idle mode)

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad9
*10n#example*100#*101#*102#...............*11n#example*110#*111#*112#*113#*114#.........................*12n#example*120#*121#*122#*123#*124#.........................RX00 HIDPIN CODES
*10
set reader to read ‘HID®’RX00 EMPIN CODES
*11
set reader to read ‘EM’RX00 CASIPIN CODES
*12
set reader to read ‘CASI’
The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
To set WIEGAND Pass Through enter: *101# once the reader has been placed into programming mode.Configure reader to read ‘HID®’ proximity cards.
6809#47*5123
DISABLE functionWIEGAND Pass ThroughClock and DataTo set 26-bit WIEGAND enter: *111# once the reader has been placed into programming mode.Configure reader to read ‘EM’ proximity cards.
6809#47*5123
DISABLE function26-bit WIEGAND34-bit WIEGAND42-bit WIEGANDClock and DataTo set 4001 40-bit WIEGAND enter: *121# once the reader has been placed into programming mode.Configure reader to read ‘CASI’ proximity cards.
6809#47*5123
DISABLE function4001 40-bit WIEGAND4002 40-bit WIEGANDExtended 4001 40-bit WIEGANDExtended 4002 40-bit WIEGAND

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad10
RX00 AWIDPIN CODES
*13
set reader to read ‘AWID’RX00 KANTECHPIN CODES
*14
set reader to read ‘KANTECH’RX00 FARPOINTEPIN CODES
*15
set reader to read ‘FARPOINTE’*13n#example*130#*131#..........*14n#example*140#*141#*142#...............*15n#example*150#*151#..........
The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
To set ENABLE ‘AWID’ function, enter: *131# once the reader has been placed into programming mode.Configure reader to read ‘AWID’ proximity cards.
6809#47*5123
DISABLE functionENABLE functionTo set KANTECH 26-bit Wiegand enter: *141# once the reader has been placed into programming mode.Configure reader to read ‘KANTECH®’ proximity cards.
6809#47*5123
DISABLE function26-bit WIEGAND39-bit XSF WIEGANDTo enable Farpointe enter: *151# once the reader has been placed into programming mode.Configure reader to read ‘FARPOINTE®’ proximity cards.
6809#47*5123
DISABLE functionENABLE function

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad11
RX80 MIFAREPIN CODES
*20
set reader to read ‘MIFARE®’RX80 ENDIANPIN CODES
*21
set reader to read ‘ENDIAN’RX90 DESFirePIN CODES
*30
set reader to read ‘DESFire®’*20n#example*200#*201#*202#*203#*204#*205#..............................*21n#example*210#*211#..........*30n#example*300#*301#..........
The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
To set 26-bit Wiegand enter: *201# once the reader has been placed into programming mode.Configure reader to read ‘MIFARE®’ proximity cards.
6809#47*5123
DISABLE function26-bit WIEGAND32-bit WIEGAND34-bit WIEGANDClock and DataMIFARE® SETo set Little ENDIAN enter: *211# once the reader has been placed into programming mode.Configure reader to read ‘ENDIAN’ proximity cards.
6809#47*5123
Big ENDIANLittle ENDIANTo ENABLE function, enter: *301# once the reader has been placed into programming mode.Configure reader to read ‘DESFire®’ proximity cards.
6809#47*5123
DISABLE functionENABLE function

3millID 9249 S. Broadway Building #200 Suite 826 Highlands Ranch CO 80129
[phone][email protected]© 3millID100-02640-Awww.3millid.comMANUAL3MS-GangKeypad4.END of keypad programming guide12
set PINPIN CODES
*98
set engineer’s PIN codeLOG OFFPIN CODES
*99
EXIT CONFIGURATION MODEexample*98oooonnnn#oooonnnn..........example*99#
The following instructions give a step-by-step procedure for accessing the many features supported by this reader.4.keypad programming guide
Use this code to change the factory default PIN to your own 4 digit engineer’s PIN setting.The factory default PIN = 1234To set your new PIN to 6789 enter: *9812346789# once the reader has been placed into programming mode.After entering programming mode, the reader will time out after approximately 30 seconds if no keys are pressed for that duration. Any changes you may have made to values or settings will be lost.Remember to keep a record of your new PIN.NOTE:If you forget your PIN setting, you will need to contact your INSTALLER or SUPPLIER to obtain a RESET code.WARNING:
6809#47*5123
current PIN(4 digits) (factory default = 1234)engineer’s PIN setting(4 digits)Use this code to EXIT the CONFIGURATION MODE of the reader.Enter: *99# to exit CONFIGURATION MODE (and save any settings made).After entering programming mode, the reader will time out after approximately 30 seconds if no keys are pressed for that duration. Any changes you may have made to values or settings will be lost.You MUST use this code to ensure any changes to values or settings you may have made, are safely SAVED to the reader.NOTE:
