IAP2300C Series
Industrial Wireless Client
Quick Installation Guide
3onedata Co., Ltd.
Address: 3/B, Zone 1, Baiwangxin High Technology
Industrial Park, Xili, Nanshan District, Shenzhen
Website: www.3onedata.com
Tel: [phone]
Fax: [phone]
【Package Checklist】
Please check the integrity of package and accessories while
first using the wireless client.
1.
Wireless Client
2.
DIN-Rail mounting attachment
3.
2.4G/5G dual-band antenna ×2
4.
Wall-mounting panel x 2
Note: 2E single-frequency device antenna (standard), and
2E2E dual-frequency device antenna (optional).
5.
Warranty card
6.
Certificate
If any of these items are damaged or lost, please contact our
company or dealers, we will solve it ASAP.
【Product Overview】
The products of this series are DIN-Rail/wall mounting
industrial wireless client. For convenience, the products of this
series adopt the following number on the left in this guide,
please affirm the number of your product.
Model I. IAP2300C-2E-2T-1D-P12_36 (2 2.4G/5G dual-band
antenna interfaces + 2 100M LAN + 1 RS-
232/485/422 serial port, 12~36VDC power input).
Model II. IAP2300C-2E2E-2T-1D-P12_36 (4 2.4G/5G dual-
band antenna interfaces + 2 100M LAN + 1 RS-
232/485/422 serial port, 12~36VDC power input).
Model III. IAP2300C-2E-5T-1D-P12_36 (2 2.4G/5G dual-band
antenna interfaces + 1 100M WAN + 4 100M LAN + 1
RS-232/485 serial port, 12~36VDC power input).
Model IV. IAP2300C-2E2E-5T-1D-P12_36 (4 2.4G/5G dual-
band antenna interfaces + 1 100M WAN + 4 100M
LAN + 1 RS-232/485 serial port, 12~36VDC power
input).
【Panel Design】
Model I
Model II

-2 / 6 -
1. Wall-mounting location hole
2. DIN-Rail mounting kit
3. RESET button
4. Terminal blocks for power supply input
5. RS-232/485/422 serial port
6. 10/100Base-T(X) 100M LAN port (LAN1-LAN2)
7. Device indicators, from left to right in turn they are:
Serial port indicator (SERIAL)
LAN port indicator (LAN2-LAN1)
Wireless bridge indicator (WLAN)
Running status indicator (RUN)
8. 2.4G/5G dual-band antenna interface (WIFI1-WIFI2)
Model III
Model IV 1. Wall-mounting location hole
2. DIN-Rail mounting kit
3. RESET button
4. Terminal blocks for power supply input
5. RS-232 serial port
6. RS-485 serial port
7. 10/100Base-T(X) 100M WAN port (WAN)
8. 10/100Base-T(X) 100M LAN port (LAN1-LAN4)
9. Device indicators, from left to right in turn they are:
SERIAL indicator (SERIAL)
WAN port indicator (WAN)
LAN port indicator (LAN4-LAN1)

-3 / 6 -
Signal strength indicator (RSSI)
Wireless network indicator (WLAN)
Running status indicator (RUN)
10. Grounding screw
11. 2.4G/5G dual-band antenna interface (WIFI1-WIFI2)
【Mounting Dimension】
Unit: mm
Model I, Model II
Model III, Model IV
Notice Before Mounting:
Don't place or install the device in area near water or
moist, keep the relative humidity of the device
surrounding between 5%~95% without condensation.
Before power on, first confirm the supported power
supply specification to avoid over-voltage damaging the
device.
The device surface temperature is high after running;
please don't directly contact to avoid scalding.
【DIN-Rail Mounting】
The product adopts 35mm standard DIN-Rail mounting which
is suitable for most industrial scenes, mounting steps as
follows:
Check whether the DIN-Rail mounting kit that
comes with the device is installed firmly.
Insert the bottom of DIN-Rail mounting kit (one side
with spring support) into DIN-Rail, and then insert
the top into DIN-Rail.
Tips:
Insert a little to the bottom, lift upward and then insert to
the top.
Check and confirm the product is firmly installed on
DIN-Rail, then mounting ends.
【Disassembling DIN-Rail】
Power off the device.
After lifting the device upward slightly, first shift out
the top of DIN-Rail mounting kit, and then shift out
the bottom of DIN-Rail, disassembling ends.
【Wall-mounted Device Mounting】
Adopt M3 screw to install the left/right mounting
board on the device side board.

-4 / 6 -
On the wall of device mounting, place the device on
the wall for reference or refer to the mounting
dimension to mark two screw positions.
Nail M3 screws on the wall and keep 2mm
interspace reserved.
Hang the device on two screws and slide downward,
then tighten the screw to enhance stability,
mounting ends.
【Device Disassembling】
Power off the device.
Unscrew the screw on the wall about 2mm.
Lift the device upward slightly; take out the device,
disassembling ends.
Notice before power on:
Power ON operation: First insert the power supply
terminal block into the device power supply interface,
then plug the power supply plug contact and power on.
Power OFF operation: First, remove the power plug, then
remove the wiring section of terminal block. Please pay
attention to the above operation sequence.
【Power Supply Connection】
Model I, Model II
The Model I and Model II device of this
series provide 3-pin 5.08mm pitch
terminal blocks and supports 1 DC
power supply input which supports anti-reverse connection.
Pin definitions are shown in the left figure, V+ and V- are the
positive and negative poles of power input, and is the case
grounding. Voltage range: 12~36VDC.
Model III, Model IV
This Model III and Model IV device of
this series provide 2*5PIN 3.81mm
pitch terminal blocks, power supply
occupies the left 4 pins. Support 1 DC
power supply input with anti-reverse
connection protection. The pins are defined as shown in the
figure on the left. V+ and V- are the positive and negative poles
of power input, and any set of V+ and V- can be used for power
input. Voltage range: 12~36VDC.
【Serial Port Connection】
Model I, Model II
The Model I and Model II device of this
series provide 1 RS-232/485/422 3IN1
serial port, and the interface type is DB9
male. The pin definition as follows:
PIN
1
2
3
4
5
RS-232
—
RXD
TXD
—
GND
RS-485
— —
D+
D-
GND
RS-485/422
RX-
RX+
TX+
TX-
GND
PIN
6
7
8
9
IO (Reserved)
DO+
DO-
DI+
DI-
Model III, Model IV
Model III and IV of this series of
device provide 1 RS-232/485 2-in-1
serial port. The interface type is
2*5PIN 3.81mm pitch terminal, and
the serial port occupies 6 pins on the
right. The pin definition as follows:
PIN
1
2
3
4
5
Definition
V+
V-
D-
D+
GND
Description 12~36VDC
power input
RS-485 serial port
PIN
6
7
8
9
10
Definition
V+
V-
TXD
RXD
GND
Description 12~36VDC
power input
RS-232 serial port
【RESET Button Setting】
This series device provide 1 RESET button, press
the button for 1-3s then release it, then the 2T device
can enable debugging WLAN temporarily, and the 5T device
can be rebooted automatically; press the button for 5s then
release it to restore factory defaults. The SSID of debugging
WLAN, that is, the Wi-Fi name is ADMIN-XXXXXX(X is the last
six digits of the MAC address of the device), which is
password-free, and is mainly used to temporarily access the
device through the wireless network for debugging. After the
device restarts or reconfigures the wireless, the device will
automatically turn off the debugging WLAN.
【Antenna Connection】
Model I and model III of this series of device are equipped with
two antennas as standard, and the antenna specifications are
as follows:
Type P/N Gain
(dBi)
Count
(pcs)
2.4/5.8G Dual frequency
antenna
3005040132 2 2
【Checking LED Indicator】
The series of devices provide LED indicators to monitor its
operating status, which has simplified the overall

-5 / 6 -
troubleshooting process. The function of each LED is
described in the table below:
LED
Indicate
Description
RUN
ON The device is powering on or the
device is abnormal.
Blinking
The device is running normally
OFF The device is powered off or the
device is abnormal.
WLAN(5T)
ON
Wireless network is enabled
Blinking
Wireless network is in an active
network status
OFF
Wireless network is running
abnormally or disabled
WLAN(2T)
RSSI(5T)
ON
The wireless terminal has
established bridge and the signal
is great
Blinking
0.5Hz blinking, the established
bridge signal is normal; 1Hz
blinking, and the established
bridge signal is weak
OFF
The wireless terminal has not
established bridge
WAN/
LAN1-
LAN4
ON
Ethernet port has established a
valid network connection
Blinking
Ethernet port is in an active
network status
OFF
Ethernet port has not
established valid network
connection
SERIAL
Blinking
Serial port is sending/receiving
data
OFF
No serial port connection or no
data transfer
【Logging in to WEB Interface】
This device supports WEB management and configuration.
Computer can access the device via Ethernet interface. The
way of logging in to device’s configuration interface via IE
browser is shown as below:
Configure the IP addresses of computer and the
device to the same network segment, and the
network between them can be mutually accessed
Enter device’s IP address in the address bar of the
computer browser.
Enter device’s username and password in the login
window as shown below.
Click “Login” button to login to the WEB interface of
the device.
Note:
The default IP address of the device is “192.168.1.254”.
The default user name and password of the device are
“admin”.
If the user name or password is lost, user can restore it to
factory settings via RESET button or management
software; all modified configurations will be cleared after
restoring to factory settings, so please backup
configuration file in advance.
Please refer to user manual for specific configuration
method of logging in to WEB interface and other
configurations about network management function.
【Specification】
Panel
Antenna 2.4G/5G dual-
band antenna
interfaces, RP-SMA-K(Female)
Wan
10/100Base-T(X) RJ45 interface
Lan
10/100Base-T(X) RJ45 interface
Serial Port RS-
232/485/422 serial port adopts
DB9 (Male);
RS-232/485 serial port adopt 2*5PIN
3.81mm pitch terminal blocks (serial
port occupies 6 pins)
Indicator
Running indicator, WLAN indicator,
RSSI indicator, WAN indicator, LAN
indicator, serial port indicator
Radio Frequency
Channel 802.11b/g/n: 2.412GHz~2.4835GHz
802.11a/n: 5.18GHz~5.825GHz
RF Power
Output
20dBm
Modulation
Scheme
DBPSK, DQPSK, CCK, OFDM, 16-
QAM, 64-QAM
Receiving Sensitivity
802.11b
-95dBm@1Mbps, -89dBm@11Mbps
802.11g
-90dBm@6Mbps, -74dBm@54Mbps
802.11a
-89dBm@6Mbps, -72dBm@54Mbps
802.11n
-85dBm@MCS0, -67dBm@MCS7
Transmitting Power
802.11b
23dBm@1Mbps, 20dBm@11Mbps
802.11g/a
23dBm@6Mbps, 20dBm@54Mbps
802.11n
23dBm@MCS0, 20dBm@MCS7
Power Supply
Input Power
Supply
12~36VDC, support anti-reverse
connection
Access
Terminal Block
Model I, Model II:
3-pin 5.08mm pitch terminal block;
Model III, Model IV:
2*5PIN 3.81mm pitch terminal blocks,
power supply occupies 4 pins
Power Consumption
Model I No-load at normal temperature:
2.0W@12VDC, 2.0W@36VDC
Full load at normal temperature:

-6 / 6 -
4.6W@12VDC, 4.8W@36VDC
Full load at high temperature:
4.7W@12VDC, 5.1W@36VDC
Model III No-load at normal temperature:
2.1W@12VDC, 2.5W@36VDC
Full load at normal temperature:
5.5W@12VDC, 5.7W@36VDC
Full load at high temperature:
5.5W@12VDC, 5.7W@36VDC
Working Environment
Working
Temperature
-40℃～75℃
Storage
Temperature
-40℃～85℃
Working
Humidity
5%～95% (no condensation)
Protection
Grade
IP30(metal shell)
