3SIXT Fusion Studio User manual

USER GUIDE
FUSION STUDIO TRUE
WIRELESS EARBUDS
3S-1191

IMPORTANT SAFETY INFORMATION
• Read all instructions and warnings before using the 3SIXT
Fusion Studio True Wireless Earbuds. Improper use of this
product may result in product damage, excessive heat, toxic
fumes, fire or explosion, for which damages you (“Purchaser”)
and not 3SIXT (“Manufacturer”) are responsible.
• Do not store the accessory in a high-temperature
environment, including heat caused by intense sunlight or
other forms of heat (heaters etc.).
• Do not place any parts of the device in fire or other extremely
hot environments.
• Do not disassemble or modify the accessory in any manner.
• Do not attempt to power this device using any other method
than as instructed explicitly in this user guide.
• Use caution and follow applicable laws regarding mobile
phones and the 3SIXT Fusion Studio True Wireless Earbuds
use, if using the device for phone calls while driving.
• Be aware of your surrounds while using your 3SIXT Fusion
Studio True Wireless Earbuds, not doing so could lead to
damage to property, others of yourself.
• Do not use the 3SIXT Fusion Studio True Wireless Earbuds at
high volume for an extended period. Use your earbuds at a
comfortable, moderate volume level to avoid potential hearing
damage. Turn the volume down on your device before placing
the earbuds into your ears, then turn the volume up gradually
until you reach a comfortable listening level.
• This accessory is intended for adults, not minors or pets.
3SIXT Fusion Studio True Wireless Earbuds contain a
lithium-ion battery and may be hazardous if swallowed. If
ingested, seek immediate medical attention by calling your
relevant emergency service.
• Do not submerge or expose the earbuds to water.

3
Welcome
Thank you for purchasing the
3SIXT Fusion Studio True Wireless
Earbuds. The 3SIXT Fusion Studio
True Wireless Earbuds come full of
great features, and this guide will
allow you understanding around
how to operate them safely.
For more information and support,
visit www.3sixtgear.com

4
PACKAGE CONTENTS
2 X TWS Earbuds
USB-A to Micro USB cable
– Black
Wireless Induction Charging
Case
3 X Pairs Assorted Sized
Earbuds
User Guide

5
THE BASICS
Buttons, Ports & Lights
1. Charging Case
2. TWS Earbud
3. Charging Port
4. Wireless Induction Charging
Base
5. Built-in Mic
6. LED Light Indicators
7. LED Ring Indicator
8. Left Power On/Off/Pair
/Skip/Pause/Voice Assistant
9. Right Power On/Off/Pair
/Skip/Voice Assistant
1
5 9
3 4
3
82
7
6

6
Turning on the device
1. Remove the 3SIXT Fusion Studio
True Wireless Earbuds from the
charging case (1).
2. Push and hold down the on/off
buttons (8 & 9) simultaneously
for 2 seconds.
3. An audio confirmation via the
earbuds will play when the 3SIXT
Fusion Studio True Wireless Earbuds
are turned on.
Turning off the device
1. Push and hold down the on/
off buttons (8 & 9) for 4 seconds
simultaneously on your 3SIXT Fusion
Studio True Wireless Earbuds.
OPERATION INSTRUCTIONS
8
8
9
9
2 x sec
4 x sec

7
New Device Pairing
1. If not already paired to a device,
the 3SIXT Fusion Studio True
Wireless Earbuds automatically set
themselves into pairing mode.
2. Within your device’s Bluetooth
settings, enable Bluetooth and look
for the device name, ‘3S-1191‘.
3. If prompted to enter a code use,
‘0000’ and accept the 3SIXT Fusion
Studio True Wireless Earbuds/device
access approval notification.
4. In the event of a successful pairing,
an audio confirmation via the
earbuds will play.
OPERATION INSTRUCTIONS
3S-1191
0000

8
Additional Device Pairing
The 3SIXT Fusion Studio True Wireless Earbuds can pair with up to
8 devices.
1. Turn on the 3SIXT Fusion Studio
True Wireless Earbuds by pushing
and holding down the on/off
buttons (8 & 9) simultaneously for
2 seconds.
2. Ensure that the initially paired
device is off or out of range of the
3SIXT Fusion Studio True Wireless
Earbuds.
3. If no connection is detected,
the 3SIXT Fusion Studio True
Wireless Earbuds automatically set
themselves into pairing mode.
OPERATION INSTRUCTIONS
8 9
off on
device 2device 1
2 x sec

9
4. Within your additional device’s
Bluetooth settings enable Bluetooth
and look for the device name,
‘3S-1191‘.
5. If prompted to enter a code use,
‘0000’ and accept the 3SIXT Fusion
Studio True Wireless Earbuds/device
access approval notification.
6. In the event of a successful pairing,
an audio confirmation via the
earbuds will play.
Note: Randomised device pairing, can occur when turning on the 3SIXT
Fusion Studio True Wireless Earbuds in the proximity of several paired
devices. The 3SIXT Fusion Studio True Wireless Earbuds will randomly
try to prioritise a single device. Ensure all devices you do not wish to
pair, have the Bluetooth setting in the off position or are out of range.
OPERATION INSTRUCTIONS
3S-1191
0000

10
Skipping Track Forward
1. While on and playing music with
your 3SIXT Fusion Studio True
Wireless Earbuds, double press
either on/off buttons (8 or 9) to skip
forward.
Pausing
1. While on and playing music with
your 3SIXT Fusion Studio True
Wireless Earbuds, press either on/off
buttons (8 or 9) once to pause play.
2. To resume playing music press
either on/off buttons (8 or 9) once
to play.
Device Smart Assistant
1. While turned on press either on/
off buttons (8 or 9) for 2 seconds
to initiate your smart device voice
assistant through your 3SIXT Fusion
Studio True Wireless Earbuds.
OPERATION INSTRUCTIONS
press twice to skip
press once to pause
press once to play
8 9
2 x sec

11
OPERATION INSTRUCTIONS
Apply Selected Earbuds
The 3SIXT Fusion Studio True Wireless Earbuds come with 3 pairs of
silicone earbud tips in different sizes to fit depending on the size of
your inner ear. Applying is easy.
1. Select the silicone earbud tips to
match your inner ear best.
2. Line up one of the silicone earbud
tips and the 3SIXT Fusion Studio
True Wireless Earbuds. Push the
silicone earbud tip into place until
the silicone bud is just past the lip
of the 3SIXT Fusion Studio True
Wireless Earbuds.
3. Repeat on the other earbud.
Note: Store the extra pairs away in a safe place, so you can use them if
you ever misplace your chosen set.
SML MED LRG

12
3SIXT Fusion Studio True Wireless Earbud LED’s
Each Earbud has an LED Ring
Pairing Status
Blue/White LED flashing Pairing mode
Connecting Status
Blue LED flashing (every 7 sec) Connecting mode
Turning Off Status
White LED flashes once then turns off
Earbuds Charging Status
White LED solid when inserted into charging case and charging
3SIXT Fusion Charging Case
When the earbuds are inserted magnets guide them into place and
automatically trigger charging
Charging Case Status
LED light flashing x 1 1% - 25% battery
LED light flashing x 2 25% - 50% battery
LED light flashing x 3 50% - 75% battery
LED light flashing x 4 75% - 100% battery
LED light solid Battery Charged 100%
LED INDICATORS
LED Ring
4 x LED Lights

13
CHARGING METHODS
1. The Charge Case uses wireless
technology (4). All you need to do
is place the charge case on any
wireless charge pad for charging to
commence immediately. Ensure the
earbuds are inserted into the case.
2. The Charge Case has a Micro USB
input (3) for standard cable charging.
Use a USB-A to Micro USB cable
(included) by plugging the Micro USB
connector into the charge case and
the USB-A Connector into any wall
charger, car charger or computer
to charge immediately. Ensure the
earbuds are inserted into the case.

14
Power input Micro USB 5V 1.0A | Wireless 5W
Ingress Rating IPX4 Splash Proof (Earbuds only)
Battery Charge Case: Polymer Lithium 3.7v/500mAh
Earbuds: 50mAh
Wireless Protocol BT v5.0
Distance Up to 10m
Audio Output 5mW
Unit 10 mm x 2
Playback Time Play: 2-3 hours | Talk: 2 hours
Standby Time 50 hours
Charge Time
Charge Case: 1-2 hours
Earbuds: 45-60 mins
*The earbuds and charging case battery
can be recharged more than 500 times;
after that time the battery will only charge
around 70% of initial capacity.
Earbuds charging in
Charge Case
3-4 times
(4th time only 60-70% battery charge)
Frequency Range 20Hz-20KHz
DistortionTHD ~1%
Operating
Temperature -10°C - 55°C / Humidity: 0% -85%
Storage
Temperature -20°C - 60° C / Humidity: 0% -90%
Microphone /
Speaker Built-In
Dimensions Charge Case: 105 x 47 x 30 mm
Weight 2 X Earbuds: 15.6g | Charge Case: 33g
Total: 48.6g
TECH SPECS

15
LIABILITY NOTICE
LIABILITY NOTICE
We reserve the right to printing errors and changes to product,
packaging or product documentation.
• See our terms of the warranty. These are available in their
current form by the importer of record in each region where
the item is sold.
DISPOSAL
Parts of this unit contain materials that are recyclable. Certain
waste companies specialise in recycling these parts. Dispose
of the components in compliance with all applicable regions
regulations. Contact your local waste management authority for
more detailed information about recycling this product.
DISPOSAL (Applicable for EU countries)
This symbol on the product, or in the operating
instructions, or on the packaging indicates that the
product must not be included as general household
waste.
According to the European WEEE directive, electrical and
electronic equipment must not be disposed of with consumers
waste. Its components must be recycled or disposed separately
of general household waste. Otherwise, contaminative and
hazardous substances can pollute the environment and adversely
aect human health.
As a consumer, you are commied by law to dispose of electrical
and electronic devices to the producer, the dealer, or public
collecting points at the end of the devices lifetime. This kind of
waste separation, application, and recycling of materials help with
conserving natural resources critical to environmental protection.
WEEE No: 82898622
EU DECLARATION OF CONFORMITY
With the CE sign, 3SIXT, an imported brand of Wentronic
GmbH ensures, that the product is conformed to the
basic European standards and directives.

16
WARRANTY
AUSTRALIA & NEW ZEALAND TWO YEAR WARRANTY
3SIXT will replace the faulty product at no cost to the consumer. The warranty
does not extend to any consequential damages or costs that may be incurred
and is valid for TWO YEARS from date of purchase. The consumer must return
the faulty product to the retail store it was purchased from together with
proof of purchase. The benefits to the consumer under this warranty are in
addition to other rights and remedies of the consumer under Australian and
New Zealand laws in relation to the goods to which the warranty relates. Our
goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for major failure
and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not amount to a major failure.
The warranty is provided by: Cellnet Limited (in Australia): 59-61 Qantas Drive,
Eagle Farm, Queensland 4009. Ph: 1300 CELLNET (1300 235 563). Email: info@
cellnet.com.au. Cellnet Limited (in New Zealand): 10a Orbit Drive, Rosedale,
Auckland 0632. Ph: 0800 CELLNET (0800 235 563), Email: [e-mail]
For more detailed warranty information, please visit:
www.3sixtgear.com/warranty-policy
EUROPE WARRANTY
This warranty is by Wentronic GmbH. Wentronic GmbH oer the manufacturer’s
warranty in addition to the legal guarantee of this 3SIXT product. This warranty
applies to products in the following countries: Germany, France, Ireland, Italy,
Luxembourg, Austria, Switzerland, or United Kingdom. The warranty does not
extend to any consequential damages or costs that may be incurred. Defects
and damages resulting from misuse, wear parts and consumables are excluded
from the warranty. Damage which is not caused to the product itself, is also
not covered under the warranty. Claims due to the neglect of duties, misuse on
manipulations and claims for reimbursement of expenses are excluded against us
or our agents under the warranty; This also applies to claims for compensation
of consequential damages. The restrictions, mentioned above, do not apply to
statutory rights of the consumer of a purchase of consumer goods or claims
of damages resulting from injury to life, body or health, intentionally or by
gross negligence, or under the Product Liability Act (ProdHaG Germany). The
warranty is void for improper use of the product. The warranty does not extend
the guarantee period or initiate a new guarantee. The statutory guarantee rights
are not aected by this warranty but are available fully unchanged to the buyer
in addition. The warranty is provided by: Wentronic GmbH: Pillmannstraße
12, 38112 Braunschweig, Hotline: [phone] (0.14€ per minute within
Germany. Max 0.42€ per minute from mobiles), Email: o[email protected],
Web: www.wentronic.de
For more detailed warranty information, please visit:
www.3sixtgear.com/warranty-policy-eu

EN
DE
FR
ES
IT
EU PRODUCT SUPPORT
3SIXT PRODUCT SUPPORT
For more information, visit www.3sixtgear.com/support
3SIXT PRODUKT-SUPPORT
Bie besuchen Sie www.3sixtgear.com/support
ASSISTANCE PRODUIT 3SIXT
Veuillez consulter www.3sixtgear.com/support
ASISTENCIA TÉCNICA DEL PRODUCTO 3SIXT
Visite www.3sixtgear.com/support
ASSISTENZA TECNICA 3SIXT
Si prega di visitare www.3sixtgear.com/support
Copyright © 2018.
3SIXT and its logo are trademarks of Cellnet Group Limited
in Australia & New Zealand. All Rights Reserved.
CELLNET GROUP LIMITED
59-61 Qantas Drive, Eagle Farm, QLD 4009 Australia.
MADE IN CHINA.
3SIXTgear.com

For more information, visit
www.3sixtgear.com
or visit www.3sixtgear.com/support
3SIXTgear
3S-1191
