4-noks ZR-HMETER6-50-EM Operating and maintenance instructions

1/2
4-noks s.r.l.
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) –ITALY
Tel [phone] Fax [phone] [email protected] www.4-noks.com
4-noks s.r.l.
QUICK INSTALLATION MANUAL
ZR-HMETER6-50-EM / ZR-HMETER6-100-EM three-phase and single phase energy meter
GENERAL DEVICE CHARACTERISTICS
CARATTERISTICHE GENERALI
ZR-HMETER6 is ZigBee three-phase and single
phase energy meter with router capabilities. It
can monitor the real-time power of 6 different
single-phase or 2 three-phase loads.
ZR-HMETER6 è un energy meter dotato di radio
ZigBee con funzioni di ripetitore. Permette di
leggere 2 carichi trifase o 6 monofase
DEVICE ELECTRICAL CHARACTERISTICS
CARATTERISTICHE TECNICHE
Power supply:
Measures:
Max.phase curr:
Relay:
Protect.Class
CT
210-250 Vac; 50 Hz
Phase voltage and current, line
frequency, power factor,
active/reactive/apparent power,
active/reactive energy
ZR-HMETER3-50: 40A (50A peak)
ZR-HMETER3-100: 80A (100A peak)
10A 250V
IP30
ZR-HMETER3-50: Nom. Curr. 50A
ZR-HMETER3-100: Nom. Curr. 100A
Alimentazione:
Misure:
Corr.Max:
Relè:
Classe prot.:
TA
210-250 Vac; 50 Hz
Tensione e corrente di fase,
frequenza, fattore di potenza,
potenza att./reat. e apparente
energia attiva e reattiva
ZR-HMETER3-50: 40A (50A picco)
ZR-HMETER3-100: 80A (100A picco)
10A 250V
IP30
ZR-HMETER3-50: Corr. Nom. 50A
ZR-HMETER3-100: Corr. Nom. 100A
PIN-OUT / CONNESSIONI MORSETTI
THREE PHASE / TRIFASE SINGLE PHASE / MONOFASE
N
Neutral (Power Supply) / Neutro (alimentazione)
13
Do NOT wire / Non connesso
L1
Phase L1 (Power Supply) / Fase 1 (alimentazione)
14
Do NOT wire / Non connesso
L2
Phase L2 / Fase 2
15
Do NOT wire / Non connesso
L3
Phase L3 / Fase 3
16
Do NOT wire / Non connesso
S
Shield for extended CTs / Schermatura estensione TA
17
Do NOT wire / Non connesso
1
SIG+ (CT 1) / SIG+ (TA 1)
18
Do NOT wire / Non connesso
2
SIG- (CT 1) / SIG- (TA 1)
19
Do NOT wire / Non connesso
3
SIG+ (CT 2) / SIG+ (TA 2)
20
Do NOT wire / Non connesso
4
SIG- (CT 2) / SIG- (TA 2)
21
Do NOT wire / Non connesso
5
SIG+ (CT 3) / SIG+ (TA 3)
22
Do NOT wire / Non connesso
6
SIG- (CT 3) / SIG- (TA 3)
23
GND (Input 2)
7
SIG+ (CT 4) / SIG+ (TA 4)
24
IN (Input 2)
8
SIG- (CT 4) / SIG- (TA 4)
25
GND (Input 1)
9
SIG+ (CT 5) / SIG+ (TA 5)
26
IN (Input 1)
10
SIG- (CT 5) / SIG- (TA 5)
NO
Normally Open (Relay) / Normalmente aperto (relè)
11
SIG+ (CT 6) / SIG+ (TA 6)
AL
Signal (Relay) / Comune (relè)
12
SIG- (CT 6) / SIG- (TA 6)
NC
Do NOT wire

2/2
4-noks s.r.l.
Via per Sacile, 158 31018 Francenigo di Gaiarine (TV) –ITALY
Tel [phone] Fax [phone] [email protected] www.4-noks.com
4-noks s.r.l.
Esempio di installazione / Sample installation
DEVICE ADDRESSING
INDIRIZZAMENTO MODBUS
The device default address is 127 (0x80). To set a
new Modbus ID, write command 6521(0x1979) on
HoldingRegister[0] and desired address on
HoldingRegister[2], then trigger the action by
setting Coil Status CS[0] to 0xFF00.
The ZR-HMETER3P-EM can take IDs between 16 and 127.
To leave the device with its default address is
highly discouraged.
L’indirizzo ModBus di default è 127. Per impostare
un nuovo ID Modbus scrivere 6521(0x1979 nell’Holding
Register [0] e l’indirizzo desiderato nell’Holding
Register [2]. Poi confermare scrivendo su Coil
Status [0] 0xFF00. Sconsigliamo di lasciare 127 come
indirizzo mpermanente
ASSOCIATING THE DEVICE TO A COMPATIBLE NETWORK
ASSOCIAZIONE A UNA RETE
The annexing process is activated automatically by
the device if the node does not have network
parameters, this happens if the device is new or if
it has been voluntarily disassociated.
Network opening is performed by stimulating the
Gateway, by pressing the Gateway's push button or
sending the appropriate command password (for further
information, refer to the document relating to the
Gateway).
Il processo di attivazione è automatico
all’accensione o se il dispositivo è stato
disassociato. Per associarlo ad un Gateway aprire la
rete premendo il pulsante apposito sul gateway
stesso (fare riferimento al manuale del gateway per
dettagli ulteriori)
DISASSOCIATING THE DEVICE FROM THE NETWORK
DISASSOCIAZIONE DA UNA RETE
Press the external button for at least 6 seconds,
until “Generic Alarm” and “Communication” LEDs light
up steady. Device disassociation causes the loss of
network parameters, with the consequent exiting of
the device from the network it belongs to.
Tenere il tasto esterno premuto per 6 secondi fino a
che i LED “Generic Alarm” e “Communication”
rimangono sempre accesi. La disassociazione provaca
la perdita dei paramentri di rete e l’uscita dalla
stessa.
LED INTERFACE
Input 1 is operating
Input 2 is operating
ZigBee connection is active
Communication with the Gateway
Power
Generic alarm message
