4B IE-NODE Series User manual

www.go4b.com
IE-NODE
INDUSTRIAL ETHERNET NODE 1
8 CONTACT/NTC TEMPERATURE INPUTS &
2 PULSED/4-20 mA INPUTS
COMMUNICATION PROTOCOLS -
PROFINET, ETHERNET/IP & MODBUS TCP/IP
INSTALLATION INSTRUCTIONS
OPERATION MANUAL
Part No.’s - ETH-NODE1V46CAI, ETH-NODE1V4CAI
Hardware Version R4 - Software Version 4.1.X - Ethernet 00.02.XX

Exposed buckets and
moving parts will cause
severe injury or death.
Lockout power before
removing cover or
inspection door.
DANGER
Moving parts can
crush and cut.
Lockout power before
removing guard or
servicing.
Do NOT operate with
guard removed
WARNING

1. CUSTOMER SAFETY RESPONSIBILITIES Page 4 - 5
2. PRODUCT OVERVIEW Page 6
3. SPECIFICATIONS Page 6
4. APPROVALS Page 7
5. DIMENSIONS Page 8
6. INSTALLATION Page 8
7. SENSOR PLACEMENT DIAGRAMS Page 9
8. ELECTRICAL CONNECTION Page 10
9. WIRING DIAGRAMS Page 12 - 16
9.1 Supply Voltage Wiring (120 to 240 VAC) Page 12
9.2 Supply Voltage Wiring (24 VDC) Page 12
9.3 Wiring Block Diagram for Elevator & Conveyor Page 13
9.4 Standard System Sensor Wiring Diagram A Page 14
9.5 Standard System Sensor Wiring Diagram B Page 15
9.6 Individual Bearing Sensor Wiring Diagrams Page 16
9.7 Individual Belt Alignment Sensor Wiring Diagrams Page 16
9.8 Individual Speed Sensor Wiring Diagrams Page 17
10. IE-NODE OPERATION Page 18 - 20
10.1 Startup Operation Page 18
10.2 Rotary Switch (SW1) Page 18
10.3 DIP Switches (SW2) Page 19
10.4 PLC Protocol Selection Page 19
10.5 Temperature Unit Page 19
10.6 Terminal A#1 Setup Page 19
10.7 Terminal A#2 Setup Page 19
10.8 Bootloader Selection Page 19
10.9 RTU Node ID Source Page 19
10.10 Internal Temperature Sensor Page 20
11. COMMUNICATIONS OPTIONS Page 20
12. EXPANSION BOARDS Page 20
13. IE-NODE NETWORK CONFIGURATOR SOFTWARE Page 21-24
14. TROUBLESHOOTING GUIDE Page 25
15. TESTING AND MAINTENANCE Page 25
16. PRODUCT WARRANTY Page 27
TABLE OF CONTENTS

PAGE 4
Dear 4B Customer:
Congratulations on your purchase. 4B appreciates your business and is pleased you have chosen our
products to meet your needs.
Please read in its entirety and understand the literature accompanying the product before you place the
product into service. Please read the safety precautions carefully before operating the product. With each
product you purchase from 4B, there are some basic but important safety considerations you must follow
to be sure your purchase is permitted to perform its design function and operate properly and safely, giving
you many years of reliable service. Please read and understand the Customer Safety Responsibilities
listed below. Failure to follow this safety directive and the Operation Manuals and other material furnished
or referenced, may result in serious injury or death.
SAFETY NOTICE TO OUR CUSTOMERS
A. In order to maximize e󰀩ciency and safety, selecting the right equipment for each operation is vital.
The proper installation of the equipment, and regular maintenance and inspection is equally important
in continuing the proper operation and safety of the product. The proper installation and maintenance
of all our products is the responsibility of the user unless you have asked 4B to perform these tasks.
B. All installation and wiring must be in accordance with Local and National Electrical Codes and
other standards applicable to your industry. The installation of the wiring should be undertaken by
an experienced and qualied professional electrician. Failure to correctly wire any product and/or
machinery can result in the product or machine failing to operate as intended, and can defeat its design
function.
C. Periodic inspection by a qualied person will help assure your 4B product is performing properly. 4B
recommends a documented inspection at least annually and more frequently under high use conditions.
D. Please see the last page of this manual for all warranty information regarding this product.
CUSTOMER SAFETY RESPONSIBILITIES
1. READ ALL LITERATURE PROVIDED WITH YOUR PRODUCT
Please read all user, instruction and safety manuals to ensure that you understand your product operation
and are able to safely and e󰀨ectively use this product.
2. YOU BEST UNDERSTAND YOUR NEEDS
Every customer and operation is unique, and only you best know the specic needs and capabilities of
your operation. Please go to www.go4b.com or call the 24-hour hotline at [phone] for assistance
with any questions about the performance of products purchased from 4B. 4B is happy to discuss product
performance with you at any time.
1. CUSTOMER SAFETY RESPONSIBILITIES

PAGE 5
3. SELECT A QUALIFIED AND COMPETENT INSTALLER
Correct installation of the product is important for safety and performance. If you have not asked 4B to
perform the installation of the unit on your behalf, it is critical for the safety of your operation and those
who may perform work on your operation that you select a qualied and competent electrical installer to
undertake the installation. The product must be installed properly to perform its designed functions. The
installer should be qualied, trained, and competent to perform the installation in accordance with local
and national electrical codes, all relevant regulations, as well as any of your own standards and preventive
maintenance requirements, and other product installation information supplied with the product. You
should be prepared to provide the installer with all necessary installation information to assist in the
installation.
4. ESTABLISH AND FOLLOW A REGULAR MAINTENANCE AND INSPECTION SCHEDULE FOR
YOUR 4B PRODUCTS
You should develop a proper maintenance and inspection program to conrm that your system is in good
working order at all times. You will be in the best position to determine the appropriate frequency for
inspection. Many di󰀨erent factors known to the user will assist you in deciding the frequency of inspection.
These factors may include but are not limited to weather conditions; construction work at the facility; hours
of operation; animal or insect infestation; and the real-world experience of knowing how your employees
perform their jobs. The personnel or person you select to install, operate, maintain, inspect or perform
any work whatsoever, should be trained and qualied to perform these important functions. Complete
and accurate records of the maintenance and inspection process should be created and retained by you
at all times.
5. RETAIN AND REFER TO THE OPERATION MANUAL FOR 4B’S SUGGESTED MAINTENANCE
AND INSPECTION RECOMMENDATIONS
As all operations are di󰀨erent, please understand that your specic operation may require additional
adjustments in the maintenance and inspection process essential to permit the monitoring device to
perform its intended function. Retain the Operation Manual and other important maintenance and service
documents provided by 4B and have them readily available for people servicing your 4B equipment.
Should you have any questions, please call go to www.go4b.com or call the 24-hour hotline at +1-309-
698-5611.
6. SERVICE REQUEST
If you have questions or comments about the operation of your unit or require the unit to be serviced
please contact the 4B location who supplied the product or send your request go to www.go4b.com or call
the 24-hour hotline at [phone]. Please have available product part numbers, serial numbers,
and approximate date of installation. In order to assist you, after the product has been placed into service,
complete the online product registration section which is accessed via our website www.go4b.com.

2. PRODUCT OVERVIEW
The Industrial Ethernet Node 1 (IE-NODE) is a remote sensor monitoring device designed to work alongside
a PLC or other control systems. The unit has 10 total sensor inputs - 8 shared contact or NTC temperature
inputs, and 2 congurable pulse or 4-20 mA (current loop) inputs.
However, the IE-NODE can be expanded up to 16 sensor inputs with the installation of an optional expansion
board. The board provides space for 6 additional NTC/Contact or 4-20 mA inputs.
The IE-NODE operates by reading its sensor inputs and sending processed data when requested by another
system (e.g. PLC). The unit is equipped with an RJ45 Ethernet socket and supports PROFINET, EtherNet/
IP and Modbus TCP/IP protocols for easy integration with Siemens, Allen-Bradley Rockwell, Modicon and
other PLC’s or automation devices.
The IE-NODE can be used with the following 4B sensors:
Temperature (Bearing & Surface) -
• ADB Series (NTC Type)
• Milli-Temp Series (4-20 mA)
Belt Alignment -
• Touchswitch (Contact)
Speed Switch -
• Milli-Speed Switch (4-20 mA)
• M800 Elite Speed Switch (Pulse)
• P300 Proximity Sensor (4 Wire Version - Pulse)
• P800 Proximity Sensor (4 Wire Version - Pulse)
WARNING
• Rotating machinery can cause serious injury or death
• Always lockout and tagout the machine prior to installation
PAGE 6
3. SPECIFICATIONS
Supply Voltage - 120 to 240 VAC (ETH-NODE1V46CAI)
24 VDC (ETH-NODE1V4CAI)
Power Dissipation - 12 Watts Maximum
Sensor Supply - 24 VDC @ 800 mA (Across Fuse 1 - Fuse 4)
Power Terminals - 14 AWG / 2.5 mm2
Signal Terminals - 16 AWG / 2.5 mm2
Communication Protocols - PROFINET, EtherNet/IP and Modbus TCP/IP
Height - 9.7 in. (248 mm)
Width - 7.4 in. (188 mm)
Depth - 5.2 in. (133 mm)
Fixing Centers - 8.75 x 4 in. (223 x 102 mm)
Cable Entry - 2 Holes - 25mm Diameter
Weight - 2.5 lbs / 1.1 kg
Protection - IP66

PAGE 7
4. APPROVALS
ETH-NODE1V46CAI Approvals Information
CSA
Class II, Division 2, Groups F and G T130°C
Tamb: -20°C to +50°C
ATEX
Baseefa11ATEX 0033X
Ex II 3D Ex tc IIIC T125°Dc IP66
TAMB -20°C to +45°C
IECEx
IECEx BAS11.0018X
Ex tc IIIC T125°Dc IP66
TAMB -20°C to +45°C
ETH-NODE1V4CAI Approvals Information
CSA
Class II, Division 2, Groups F and G T130°C
Tamb: -20°C to +50°C
ATEX
Baseefa04ATEX0131X
Ex II 2D Ex tb IIIC T125° Db IP66
TAMB -20°C to +50°C
IECEx
IECEx BAS05.0026X
Ex tb IIIC T125° Db IP66
TAMB -20°C to +50°C
SPECIAL CONDITIONS OF USE
• The equipment shall be suitably earth bonded via the PCB mounted earth terminal inside the
equipment enclosure.
• Warning: The equipment is a potential static hazard, clean only with a damp cloth.
• Do not allow dust layers to build up on the equipment.

5. DIMENSIONS
PAGE 8
6. INSTALLATION
The IE-NODE should be installed in an area with network Ethernet access.
ENCLOSURE INSTALLATION -
1. Use the correct cable, glands and sealing arrangement in accordance with all installation codes.
2. Where other certied components are used as part of the assembly or installation procedure, the
user must take in to account any limitations which might be listed on the relevant certicates.
3. The box is supplied with 2 x 25mm diameter pre drilled holes in the bottom face. All unused entry
apertures must be sealed using component certied stopping plugs. The end user must install
component or apparatus certied stopping plugs and cable glands/conduit in strict accordance with
the manufacturer’s instructions. Depending on the installation goegraphy, it may be needed to
connect conduit to the control unit enclosure. In this use a CSA and/or UL certied Class II conduit
hub (for example, a Myers™ hub) with a suitable bonding (grounding) connection that is rated for the
installation environment.
4. The enclosure must not be modied in any way, as this will invalidate the certication.
5. All wiring must be carried out in accordance with relevant codes of practice and / or instructions.
6. The voltage, current and maximum power dissipation on the units label must not be exceeded.
7. The wiring installation must extend to within 1 mm of the metal face of the terminal.
8. All leads must be insulated for the appropriate voltage.
9. Not more than one or multiple strand cable is to be connected to any terminal unless multiple
conductors have previously been joined in a suitable manner (e.g. boot lace ferrule) such that they
present a single connection point to the terminal.
10.The sensor terminals use a screwless push in spring design, a small at-head or straight screwdriver
can be used to gently push in the tab to terminate the sensor wires.
SENSOR INSTALLATION -
Follow the installation instructions for each sensor as provided in each individual product manual.

7. SENSOR PLACEMENT DIAGRAMS
1
2
2
33
4
1
2
2
3
3
SPEED MONITORING
Qty 1 - One sensor located on either
side of the tail or boot shaft.
BEARING TEMPERATURE
Qty. 4 - One sensor for the bearings
at each end of the drive and tail or
head and boot shafts.
BELT MISALIGNMENT
Qty. 4 - Sensors work in pairs, one
for each side of the belt on the drive
and tail or head and boot sections.
TAIL PULLEY MISALIGNMENT
(Enclosed Belt Conveyor)
Qty. 2 - One sensor located on each
side of the housing on the conveyor
tail section.
1
2
3
4
TYPICAL SENSOR PLACEMENT
FOR BUCKET ELEVATORS &
ENCLOSED BELT CONVEYORS
PAGE 9

WARNING
The Control Unit is susceptible to static voltage, static handling precautions should be taken. Connection
of a clean ground to terminal 23 is essential for optimum performance.
Since the enclosure is a static hazard, it should only be cleaned with a damp cloth.
8. ELECTRICAL CONNECTION
All wiring must be in accordance with local and national electrical codes and should be undertaken by an
experienced and qualied electrician. All equipment should be properly grounded prior to operation.
Additional wire used during the installation must have a temperature rating of 158°F (70°C) or above, and
be at least 24 AWG. 4B recommends using shielded cable to reduce electromagnetic interference (EMI)
to maintain signal integrity. Never run sensor cables in the same conduit as three phase motor cables.
If required, use dust/liquid tight exible metal conduit with approved ttings to protect the sensor cables.
Use rigid metal conduit to protect the cables from the sensors to the control unit. If installing with a conduit
systems, it can channel water due to ingress and condensation directly to sensors and sensor connections
which over time will adversely a󰀨ect the performance of the system. As such, the installation of low point
conduit drains is recommended for all sensors.
All electrical connections are shown in image 1.
FUSE RATINGS -
In order to maintain the product certication, all fuses MUST be replaced with equivalent fuses at the same
rating. Failure to do so will invalidate the certication and any warranties which may exist.
Model ETH-NODE1V46CAI
• F1 - F4 and F6 2 Amp.
• F5 200 mA.
Model ETH-NODE1V4CAI
• F1 - F4 AND F5 200 mA
SENSOR INPUTS -
NOTE
Recommended cable type is Belden 5508FE with 10 conductors each 22 AWG, shielded. Alternatively
SY 10 x 0.25mm^2 can be used.
PAGE 10
TERMINAL SENSOR MINIMUM MAXIMUM
T#1 - T#8 Temperature (NTC) -40 °F (-40 °C) 230 °F (110 °C)
T#1 - T#8 Belt Alignment (Contact) 0 Volts 24 Volts
A#1 - A#2 Speed (Pulse) 20 PPM 5,000 PPM
A#1 - A#2 Speed/Temperature (4-20 mA) 0 mA 20 mA
PPM = Pulses Per Minute

PAGE 11
WARNING
The unit should ONLY be powered with either a main supply (ETH-NODE1V46CAI model) OR a
24 VDC (ETH-NODE1V4CAI) NOT BOTH (see specications).
Image 1 -
Control Board - No Internal Power Supply
FIELD WIRING
CONNECTIONS
01 - 0 VDC
02 - T#1 Temp/Belt Align
03 - T#2 Temp/Belt Align
04 - +24 VDC (Fuse F1)
05 - 0 VDC
06 - T#3 Temp/Belt Align
07 - T#4 Temp/Belt Align
08 - +24 VDC (Fuse F2)
09 - 0 VDC
10 - T#5 Temp/Belt Align
11 - T#6 Temp/Belt Align
12 - +24 VDC (Fuse F3)
13 - 0 VDC
14 - T#7 Temp/Belt Align
15 - T#8 Temp/Belt Align
16 - +24 VDC (Fuse F4)
17 - 0 VDC
18 - A#1 Speed/Analog
19 - A#2 Speed/Analog
20 - +24 VDC (Fuse F4)
Power Supply
Location
(If Installed)
POWER CONNECTIONS
21 - VAC Neutral Connection
22 - 120 to 240 VAC Connection
23 - 0 VDC & Ground Connection
24 - (+) 24 VDC Connection
DIP Switches (SW2)
Rotary Switch (SW1)
HB (Heart Beat) - Green LED
Power - Red LED
RJ45 Ethernet

PAGE 12
9. WIRING DIAGRAMS
9.1 SUPPLY VOLTAGE WIRING (120 TO 240 VAC)
21 22 23 24
No
Connection
N L
Ground
Fuse
2 A
9.2 SUPPLY VOLTAGE WIRING (24 VDC)
21 22 23 24
No
Connection
+
-
Ground
24 VDC
Fuse
2 A

PAGE 13
NOTE
• Left and right are determined when facing the direction the bucket elevator discharges.
9.3 WIRING BLOCK DIAGRAM FOR BUCKET ELEVATOR & BELT CONVEYOR -
HEAD / DRIVE
BOOT / TAIL
Hot Bearing
Sensor
Hot Bearing
Sensor
Hot Bearing
Sensor
Hot Bearing
Sensor
Alignment
Top Right
Alignment
Top Left
Alignment
Bottom Left
Alignment
Bottom Right
Speed
Sensor
INDUSTRIAL
IE-NODE
Junction
Box
Junction
Box
RJ45 Connection
Modbus TCP/IP
Ethernet/IP or
PROFINET
Switch & Fused
Supply
BELDEN 5508FE
BELDEN 5508FE
Ethernet
Denotes shielded
cable. Shield to
be grounded at
one end only.
TOP LEFT TOP RIGHT
BOTTOM LEFT BOTTOM RIGHT

PAGE 14
Alignment
Top (Head)
Blue
X
X
RIGHT
Orange
Black
White
Red
Green
Blue
X
X
LEFT
Orange
Black
White
Red
Green
Alignment
Bottom (Tail)
Blue
X
X
RIGHT
Orange
Black
White
Red
Green
Blue
X
X
LEFT
Orange
Black
White
Red
Green
Black
Brown
Black
Brown
Black
Brown
Black
Brown
Bearing
Bottom (Tail)
Bearing
Top (Head)
RIGHT
LEFT
RIGHT
LEFT
White
Blue
Brown
Black
Speed
9.4 STANDARD SENSOR WIRING DIAGRAM A:
- NTC SENSORS (BEARING TEMP), TOUCHSWITCHES (ALIGNMENT) & P800 (SPEED)
01 0 VDC
02 T#1
03 T#2
04 +24 VDC (Fuse F1)
05 0 VDC
06 T#3
07 T#4
08 +24 VDC (Fuse F2)
09 0 VDC
10 T#5
11 T#6
12 +24 VDC (Fuse F3)
13 0 VDC
14 T#7
15 T#8
16 +24 VDC (Fuse F4)
17 0 VDC
18 A#1
19 A#2
20 +24 VDC (Fuse F4)

PAGE 15
Black
Brown
Black
Brown
Black
Brown
Black
Brown
Bearing
Bottom (Tail)
Bearing
Top (Head)
RIGHT
LEFT
RIGHT
LEFT
Blue
Black
Speed
9.5 STANDARD SENSOR WIRING DIAGRAM B:
- NTC SENSORS (BEARING TEMP), RUB BLOCKS (ALIGNMENT) & MILLI-SPEED (SPEED)
01 0 VDC
02 T#1
03 T#2
04 +24 VDC (Fuse F1)
05 0 VDC
06 T#3
07 T#4
08 +24 VDC (Fuse F2)
09 0 VDC
10 T#5
11 T#6
12 +24 VDC (Fuse F3)
13 0 VDC
14 T#7
15 T#8
16 +24 VDC (Fuse F4)
17 0 VDC
18 A#1
19 A#2
20 +24 VDC (Fuse F4)
Alignment
Top (Head)
Black
Brown
Black
Brown
Alignment
Bottom (Tail)
Black
Brown
Black
Brown
RIGHTLEFTRIGHTLEFT

PAGE 16
9.6 INDIVIDUAL BEARING SENSOR WIRING DIAGRAMS:
Black
Brown
0 VDC
T#
+24 VDC
NTC
Black
Brown
0 VDC
A#
+24 VDC
4-20 mA
9.7 INDIVIDUAL BELT ALIGNMENT SENSOR WIRING DIAGRAMS:
Blue
X
X
Orange
Black
White
Red
Green
Touchswitch
0 VDC
T#
+24 VDC
Black
Brown
0 VDC
T#
+24 VDC
NTC Rub Block
0 VDC
A#
+24 VDC
Black
Brown
4-20 mA Rub Block

PAGE 17
9.8 INDIVIDUAL SPEED SENSOR WIRING DIAGRAMS:
White
Blue
Brown
Black
Speed
0 VDC
A#
+24 VDC
P800
NOTE
The M800 Elite is an 8 wire switch. The diagram above illustrates the IE-NODE connection only, the
remaining wires are for the alarm and shutdown relays.
Brown
Blue
Pink
White
Speed
0 VDC
A#
+24 VDC
M800 Elite
Blue
Black
Speed
0 VDC
A#
+24 VDC
Milli-Speed (4-20 mA)
Brown
Black
White
Blue
Speed
0 VDC
A#
+24 VDC
P3003V34 (4-wire)

PAGE 18
10. IE-NODE OPERATION
The Industrial Ethernet Node is designed to sample data from several sensors and provide this data to
remote users or PLC’s on request. It is only a reporting system, and does not control any other system
or device.
10.1 STARTUP OPERATION -
After all sensor and power connections have been made, locate the POWER and HB (Heart Beat) LED’s
on the IE-NODE’s control board (See Image 1). When the unit is powered on, the red power LED should
be solid and the green HB LED should begin ashing.
The HB LED will behave in one of four ways -
HB LED DESCRIPTION
O󰀨 No internal communications, indicates an issue with the rmware or hardware.
On Normal operation, no external communications from a PLC or other device.
Flashing Normal operation, external communication detected from a PLC or other
device.
Fading Bootloader mode (allows for software updates)
10.2 ROTARY SWITCH (SW1) -
The rotary switch on the IE-NODE (Image 2) is used for setting the node slave ID when using one of the
optional expansion boards that support RS485. Refer to the expansion board manual for installation and
setup.
If SW1 Node ID functionality is not enabled, the default Modbus ID number is derived from the last 2 digits
of the product serial number. For example, if the last 2 digits of the serial number are ‘00’ then the ID
number becomes ‘100’ given that the ID number ranges from 1 to 100.
Image 2 -
Control Board
Rotary Switch (SW1)
POSITION NODE ID
0 100
1 1
2 2
3 3
4 4
5 5
6 6
7 7

PAGE 19
10.4 PLC PROTOCOL SELECTION -
The IE-NODE will always have Modbus TCP/IP enabled, but it can also communicate over PROFINET or
Ethernet/IP (selectable).
10.5 TEMPERATURE UNIT -
The IE-NODE output temperature readings can be set as degrees Celcius or Fahrenheit.
10.6 TERMINAL A#1 SETUP -
The A#1 channel can be set up to accept either a current loop input of up to 20 mA or a pulse (PNP)input
of up to 5000 PPM.
10.7 TERMINAL A#2 SETUP -
The A#2 channel can be set up to accept either a current loop input of up to 20 mA or a pulse (PNP) input
of up to 5000 PPM.
10.8 BOOTLOADER SELECTION -
This switch selects whether bootloading for software updates is permitted or not. The switch is set to OFF
from the factory.
10.9 RTU NODE ID SOURCE -
This switch enables the Node ID settings for RS485 Modbus RTU. If the rotary switch (O󰀨 - Left) is
chosen, the node address is set from the rotary switch (Section 9.2). If internal (On - Right) is chosen,
then the node address is set from the IE-NODE Network Congurator Software (Section 11).
10.3 DIP SWITCHES (SW2) -
The IE-NODE has a set of eight DIP switches to change settings (Image 3). Each switch setting is
described in the table below. If a switch setting is changed, the unit must be restarted for the change to
take e󰀨ect.
Image 3 -
Control Board
DIP Switches (SW2)
SWITCH DESCRIPTION OFF (LEFT) ON (RIGHT)
1 PLC Protocol Selection PROFINET EtherNet/IP
2 Temperature Unit °C °F
3Terminal A#1 Setup 4-20 mA Pulse - PNP
4Terminal A#2 Setup 4-20 mA Pulse - PNP
5 Bootloader Selection Allowed Disabled
6 HazardMon.com Setup Enabled Disabled
7Reserved - Not Used (No E󰀨ect) ---- ----
8 RTU Node ID Source Rotary Switch (SW1) Internal

PAGE 20
10.10 INTERNAL TEMPERATURE SENSOR -
In addition to the 10 sensor inputs, the IE-NODE is tted with an internal NTC temperature sensor. This
device is mounted to the IE-NODE PCB and will therefore provide the temperature of the electronics. If an
IE-NODE is mounted in the eld, it could be used to approximate the local ambient temperature, but will
report temperatures approximately 10°F (5°C) higher than local ambient. For a more accurate ambient
temperature reading, an ambient temperature sensor can be wired to one of the 10 sensor inputs.
The IE-NODE comes with a standard RJ45 Ethernet Socket. The unit is sent out from the factory with the
following IP address settings pre-set:
FACTORY SETTING VALUE
IPV4 Address 192.168.1.100
Subnet Mask 255.255.255.0
Default Gateway 192.168.1.1
Primary DNS Server 0.0.0.0
Secondary DNS Server 0.0.0.1
The IE-NODE supports PROFINET and EtherNet/IP communication protocols. The data allocation is
exactly the same for both the protocols and detailed information can be found in the IE-NODE Data
Format document.
The byte order within words is dependent on the selected protocol. For PROFINET it is Little-Endian and
for EtherNet/IP it is Big-Endian.
Modbus TCP is supported in addition to PROFINET and EtherNet/IP. The Modbus TCP information
contains equivalent information to the PROFINET and EtherNet/IP array type communications.
11. COMMUNICATIONS OPTIONS
12. EXPANSION BOARDS
Two expansion boards are available for the IE-NODE to expand total sensor inputs from 10 to 16.
1. The ETH-NODE-AUXI-6NTC expansion board allows for the support of up to 6
extra NTC temperature sensors or 6 contact sensors, or any combination of 6.
2. The ETH-NODE-AUXI-6AN expansion board allows for the support of up to 6 extra 4-20 mA (current
loop) sensors.
Both boards add the capability to allow for an RS485 Modbus RTU connection to be made to access all
onboard sensor information. Refer to the expansion board manual(s) for installation and setup.
Image 4 -
Expansion Board Installed
