4iiii Podiiiium User manual

Manual
User

1. Introduction
1.1 What’s in the box 1
2. Getting Started
2.1 Installation 2
2.2 Preparing for your ride 3
2.3 Charging and caring for your batteries 4
2.3.1 Non-drive-side powermeters 5
2.3.2 Drive-side powermeters for Shimano FC-R8000 and FC-R9100 6
2.4 Conguring your powermeter using the 4iiii App 7
2.4.1 Conguring as a dual-sided powermeter 8
2.4.2 Unlinking your dual-sided powermeter 9
2.4.3 Conguring in single-sided mode 10
3. Pairing
3.1. Pairing with ANT+ enabled displays 11
3.2. Pairing with Bluetooth® 13
TABLE OF CONTENTS

4. Performing a Zero Oset
4.1. Performing a zero oset via ANT+ 14
4.2. Performing a zero oset using your 4iiii App (Bluetooth®) 16
5. Advanced Features
5.1 Renaming your powermeter using the 4iiii App 18
5.2 Setting scale factor compensation values 19
5.3 Using third-party compatibility mode on Bluetooth® 20
6. Maintenance and Care 21
7. Troubleshooting 22
8. Specications 25
9. Safety Information 26
10.Warranty 27
11. Regulatory Compliance 30
12. Contact Information Back Cover
TABLE OF CONTENTS

Podiiiium
Crankset
included
with Ride
Ready
purchase
3m dual-ended 90 degree
micro-USB cable.
Extra dust cap and
dust-cap screw.
1INTRODUCTION
1.1 What’s in the Box?
Your Podiiiium
powermeter comes
complete with the
following:
1
Table of Contents

2.1 Installation
The steps and tools needed for installing a crankset on your bike will vary
depending on the model of your crankset. For your safety, follow the crankset
manufacturer’s instructions when installing the crankset to your bike. Consult your
local bike mechanic if you are not comfortable or able to follow the manufacturer’s
installation instructions.
Quick Tip: Accuracy of your powermeter is dependent on proper torque. Not following
proper installation procedure could aect the accuracy of your powermeter.
2GETTING STARTED
2
Table of Contents

2.2 Preparing for your ride
1. Wake your Podiiiium from shipping mode by plugging into a power source for at
least 5 seconds. Unplug the charging cord when charge is complete.
2. Your Podiiiium powermeter is equipped with an indicator LED.
During charging, the LED will turn red. Once the powermeter
is fully charged, the LED will turn green for a few minutes and
then turn o.
2GETTING STARTED
75-100%
LED displays green for
3 seconds (long ash)
25-50%
LED shows
1 long red ash
50-75%
LED blinks green
5 times (short ashes)
0-25%
LED shows
5 short red ashes
3. Once charged, wake-up Podiiiium by rotating the crank 3 or 4 times.
4. Pair with your power capable device.
5. Zero Podiiiium using your paired device. Unclip from
your pedals and position crankarms as shown.
Press “zero oset” or “calibrate” on your display.
LED ashes blue once to indicate successful zero oset. Left
Crank
Right
Crank
3
Table of Contents

2.3 Charging and caring for your batteries
Your powermeter uses a rechargeable lithium ion batteries. When the reported battery
life is 8%, you will have 4-5 hours of remaining usage.
Your dual-sided Podiiiium Pro PRECISION Powermeter comes with a micro-USB charge
cable that allows you to charge both sides at once.
Your power meter will take approximately 3-4 hours to fully charge.
Please note that the charge time may depend on the power source used.
NOTE: If the battery reaches 0% on one side, the other side of the dual system will
automatically operate as a single-sided powermeter; reported wattage from this side
will be doubled.
• Use a USB AC adapter with a voltage of 5.0V and with a current equal or greater
than 1.0A.
• Use the designated charge cable to charge the powermeter.
• Avoid contact of the charge cable and/ or powermeter with water while charging.
• Do not disassemble or modify the charge cable.
• Charge the device at the specied power supply voltage only.
• Lithium-ion batteries are recyclable. For information on disposal of used batteries,
contact your original dealer.
• If the battery has become completely depleted, charge it as soon as possible.
Leaving the battery in a depleted state can cause the battery to deteriorate.
2GETTING STARTED
4
Table of Contents

2GETTING STARTED
2.3.1 Non-drive-side powermeters
To charge your non-drive side powermeter, connect the 90-degree micro-USB
connector to the powermeter. Ensure cable is connected as per image below:
5
Table of Contents

2GETTING STARTED
2.3.2 Drive-side powermeters for Shimano Cranksets
To charge your drive side powermeter, slip the 90-degree micro-USB connector
between the crank-arm and chain-rings. Ensure cable is connected as per image below:
6
Table of Contents

2GETTING STARTED
2.4 Conguring your powermeter using the 4iiii App
When your Podiiiium was shipped from the factory, the drive side and non-drive side
powermeters were linked together such that they operate as a dual-sided powermeter.
Your powermeter can also operate as two independent single-sided powermeters. If
you want to operate your Podiiiium powermeter as a single-sided powermeter using
only one crank arm, follow the instructions in Section 2.4.2
Additional information and settings on your Podiiiium can be accessed through the
4iiii app on iOS and Android devices using Bluetooth®.
To congure your Podiiiium powermeter in single-sided mode, follow the instructions
in Section 2.4.3
To congure your Podiiiium powermeter in dual-sided mode, follow the instructions in
Section 2.4.1
Quick Tips:
Pairing is the connection between your powermeter and display units
such as a bike computer, watch, or smartphone. Linking is the connection between the
drive and non-drive side powermeters.
Connect your powermeter to the 4iiii App once a month to check for the latest rmware
update. If your rmware requires updating, you will be prompted to upgrade.
Your battery percentage for you drive-side and non-drive-side powermeter can be
viewed by connecting to the 4iiii App.
7
Table of Contents

2GETTING STARTED
2.4.1 Conguring as a dual-sided powermeter
If you have unlinked your Podiiiium, you will need to re-link in order to use it as a
dual-sided powermeter:
1. Spin the crank arms four times to wake your powermeter
2. Open the 4iiii app on your smartphone
3. Tap on the menu and select PRECISION Conguration
4. Select your powermeter from the list
5. Select Dual Sided when prompted
6. Select your other powermeter to link
7. On the next screen, wait up to one minute for the left borders of the information
panes to turn green
Quick Tip: If the left borders of the information panes are red, the powermeter is not
paired to the app, see Section 7.4
8
Table of Contents

2GETTING STARTED
2.4.2 Unlinking your dual-sided powermeter
To unlink your dual-sided powermeter so
that it becomes two separate single-sided
powermeters:
1. Spin the crank arms four times to
wake your powermeters
2. Open the 4iiii app on your
smartphone
3. Select your powermeter
from the list
4. Once the left borders for both
sides are green, tap on the Unlink
button (located at the bottom
left of the screen)
Quick Tip: Make sure both cranks are connected
before unlinking. If only one side is unlinked,
the remaining side will continue to search for its
previously linked powermeter.
Quick Tip: If you have previously enabled the
3rd-Party Apps mode on the 4iiii App, you will
need to re-enable this feature on both sides
after unlinking.
9
Table of Contents

2GETTING STARTED
2.4.3 Conguring in single-sided mode
To unlink your Podiiiium, you will need:
• The 4iiii App
• A data connection (cellular or WiFi)
• Bluetooth® enabled on your smartphone
Follow these steps to unlink your Podiiiium:
1. Spin the crank arms four times to wake your powermeter
2. Open the 4iiii App on your smartphone
3. Tap on the menu and select PRECISION Conguration
4. Select your Podiiiium from the list of powermeters
5. Tap on the unlink button to unlink the two sides
Quick Tip: If your powermeter does not appear in the list, check that it is disconnected
from all other Bluetooth® devices, and that both batteries have sucient charge.
10
Table of Contents

3PAIRING
3.1 Pairing with ANT+ enabled displays
To receive power and cadence information
from Podiiiium, it must rst be paired to your
display unit. Pairing procedures vary between
display units, but the following generic
instructions are provided:
1. Turn on your display unit
2. Spin the crank arms four times
to wake your powermeter
3. Go to the Sensors menu on
your display unit
4. Select Add a new sensor
5. A list of available power sensors
will be shown. Select the ANT+ ID
that matches your Podiiiium which is
etched on the edge of the non-drive
side Podiiiium pod
Quick Tip: The ANT+ ID used for pairing is also
displayed on the 4iiii App.
ANT+ ID
114 4 6
11
Table of Contents

3PAIRING
With your powermeter paired, you can add power metrics to the workout screens
of your display unit. Consult your display unit’s instruction manual for more specic
directions.
Fields that are available on many display units include:
• Power (1 sec. 3 sec. 10 sec.)
• Normalized Power
• Intensity Factor
• TSS
• Power Balance
• Cadence
12
Table of Contents

3PAIRING
3.2 Pairing with Bluetooth®
Pairing procedures vary widely between Bluetooth® display units. Please consult the
manufacturer’s instructions to pair your Podiiiium. Following are instructions for
pairing using the 4iiii App.
1. Spin the crank arms four times to wake your powermeter
2. Open the 4iiii App on your smartphone
3. Tap on the menu and select PRECISION Conguration
4. Select your Podiiiium from the list of powermeters
5. If your Podiiiium is congured as a dual-sided powermeter, continue to Step 6;
otherwise, select Single Sided
6. Once the left edge of the Podiiiium info pane turns green, tap on the menu and
select Workout
Quick Tip: If your powermeter does not appear in the list, check that it is disconnected
from all other Bluetooth® devices, and that Bluetooth® is enabled on your phone.
Also, ensure both batteries on your powermeter have sucient charge.
13
Table of Contents

4PERFORMING A ZERO OFFSET
Single-sided mode:
A two digit response
will appear on your
display unit. Refer to
Zero Oset Table on
Page 15
Dual-sided mode:
A four digit number
will appear on
your display unit.
The rst two digits
refer to the zero
oset response of
the non-drive side
of Podiiiium and
the last two digits
refer the zero oset
response of the
drive side. Refer to
Zero Oset Table on
Page 15
4.1 Performing a zero oset via ANT+
For best performance, you should allow the powermeter
to adjust to the ambient riding temperature before
performing a zero oset and starting your ride. Allowing
your powermeter to reach ambient temperatures normally
takes a few minutes.
To perform a zero oset on your powermeter using your
ANT+ display unit, follow these steps:
1. Unclip and dismount from your bike
2. Spin the crank arms four times to wake your
powermeter
3. Place your crank arms in the 12 and 6 o’clock positions
4. Use your display unit to calibrate your powermeter
i. Go to the Sensors menu
ii. Select the ANT+ ID of your powermeter
from the list of available sensors
iii. Choose Calibrate
Quick Tip: Some display units use the term “calibration”
rather than “zero oset”.
14
Table of Contents

4PERFORMING A ZERO OFFSET
Two digit
Response
Result Description What to do LED
indication
10 Success Go Ride! One blue
ash
20 Error Crank
movement
detected
Keep your bike steady Two short
blue ashes
40 Error Firmware
mismatch
Connect to 4iiii App to update
rmware
Four short
blue ashes
50 Error Firmware
error
Connect to 4iiii App to update
rmware
Five short
blue ashes
99 Error Powermeter
side
not found
• Spin crank arms four times to
wake up
• Charge battery
• Conrm linking status on
4iiii App
N/A
0Error Powermeter
not found
• Spin crank arms four times to
wake up
• Charge battery
N/A
If an error cannot be solved with the recommendations above, contact your 4iiii
authorized dealer for support.
15
Table of Contents

4PERFORMING A ZERO OFFSET
12 O’CLOCK
6 O’CLOCK
4.2 Performing a zero oset using your 4iiii App (Bluetooth®)
Zero oset is performed by pairing your powermeter with the
4iiii App, not through the phone’s Bluetooth® settings.
Follow these steps:
1. Unclip and dismount from your bike
2. Spin the crank arms four times to wake your powermeter
3. Place your crank arms in the 12 and 6 o’clock positions
4. Ensure that you have an internet connection
(cellular or WiFi) and that Bluetooth is enabled
in your smartphone settings
5. Open the 4iiii App
6. Tap on the menu and select PRECISION Conguration
7. If your powermeter is not already paired with the 4iiii App,
you will be presented with a list of nearby powermeters,
select your powermeter from the list
8. Once the left edge of the Podiiiium info pane turns green
for both sides, tap the Zero button
16
Table of Contents

4PERFORMING A ZERO OFFSET
Quick Tip: If you receive a calibration error message, refer to the DESCRIPTION
column in the Calibration Results Table on Page 15
17
Table of Contents
