1. Overview Presentation
The DUAL INJECTOR PRO+ is a state-of the-art RF+Electroporation system. This device combines the
tightening and pore opening of Radio Frequency with the active ingredient penetration action of
Electroporation. Even after one treatment, patients experience a signicant change in their skin’s texture
and quality.
DUAL INJECTOR PRO+ is suitable for all skin types and is mainly used on the face.
Using the DUAL INJECTOR PRO+, accompanied by skin products that penetrate the top skin layers and
reach the dermis level, will help to replenish natural nutrients, restore cell activity, and promote skin
health. The result is healthy, glowing, beautiful skin.
1.1 Benets of DUAL INJECTOR PRO+
The benets of RF+Electroporation+LED are substantial.
• Overall rejuvenation of skin health
• No recovery or down time
• No anaesthetic requirement
• Reduction of minor to moderate early ageing ne lines
• Stimulation of broblasts for collagen production
• Hyperpigmentation reduction
• Enhanced penetration of active ingredients
1.2 Treatable Conditions
Conditions that can be treated with DUAL INJECTOR PRO+:
• Sun induced pigmentation, melasma, age spots
• Ageing and sagging skin
• Fine lines and minor wrinkles
• Acne and blemishes
• Enlarged pores
• Flaking and dry skin
• Excessive oiliness
• Pre- and post treatment before and after cosmetic surgery
1.3 Contraindications
Recognising contraindications to RF+Electroporation is vitally important. Common sense and medical
supervision should prevail when determining the treatment of a client with any of these conditions:
• Epilepsy
• Pacemaker
• Heart disease
• Heart murmur or irregular heart rate
• Cancer
• Ulcer
• Viral lesions, Herpes Simplex, Shingles
• Eczema or Seborrheic Dermatitis
• Uncontrolled hypertension
• AIDS, HIV or any autoimmune disorder
• Migraines

Dual Injector Pro+ User Manual (Ver. 1-2017) Page 4
2. Illustration of DUAL INJECTOR PRO+
2.1. DUAL INJECTOR PRO+ Control Panel
TREATMENT HANDLE
ELECTROPORATION
LEVEL + -
ON / OFF
RADIO FREQUENCY
TIME
LEVEL
ON / OFF
LEVEL -
LEVEL +

Dual Injector Pro+ User Manual (Ver. 1-2017) Page 5
3. Preparation before treatment
1. A consultation including examination of the skin.
2. Practitioner should wear gloves.
3. Remove any facial piercings.
4. Follow Step by Step instructions below.
4. How to use DUAL INJECTOR PRO+
1. Connect the Power cable (with transformer) and the Treatment handle to the machine.
2. Turn machine on using the POWER button on back of the machine.
3. The timer on the left hand side of the LED display is automatically set to 10 minutes. Using Up/
Down arrows adjust the time to 5 minutes.
4. Press Start button followed by Up/Down arrows to adjust the Radio Frequency intensity level shown
on the right hand side of the LED display to 5 (middle). Always check client comfort. The Radio
Frequency can be increased to 10 depending on comfort. The head of the probe appears RED. The
probe will only take 30 seconds to reach temperature.
5. Treat half the face for 5 minutes with (RF). Press STOP to turn o Radio Frequency. Alternatively it
will turn o automatically when the timer nishes. Repeat on the other side of the face.
6. ELECTROPORATION: Set timer to 5 minutes using Up/Down arrows.
7. Press silver dial down to turn on Electroporation. The head of the probe appears BLUE.
8. Use the silver dial to set the intensity, Min/Max according to the red light around the dial. Start
intensity half way. Always check client comfort
9. Treat one side of the face for 5 minutes, then repeat on opposite side of the face for a further 5
minutes.
10. Press Stop. Turn o the power on the back of the machine.
11. If machine is not in use, take the power plug out of power supply.
To clean the Treatment handle after treatment, use an antibacterial solution or wipe (avoiding alcohol
based products) to wipe o any impurities, and then use disinfecting solution.
4.1. Cleaning and maintenance
1. Before cleaning turn o the machine and take the power plug out of power supply.
2. Machine, cables and treatment handle should be cleaned carefully using a product such as
Globaquat Alcohol Free wipes (avoid alcohol based products).
3. Before and after each treatment all parts which have been in contact with the patient’s skin must be
disinfected.
!!! WARNING !!!
All cleaning and maintenance operations should be carried out with extreme caution (with disposable
gloves.) Dirt, bacteria and other germs can cause severe infections.

Dual Injector Pro+ User Manual (Ver. 1-2017) Page 6
4.2 Post DUAL INJECTOR PRO+ treatment advice
Recommended treatment FREQUENCY:
Initial phase for intense treatment:
Young skin should be 1 per week for 4 weeks; middle aged skin 1 per week for 6 weeks; mature skin 1 per
week for 8 weeks.
Maintenance:
Young skin once every 4 - 6 weeks (up tp 8 weeks); middle aged skin once every 4 - 6 weeks (up to 3
months); and mature skin once every 3 weeks (up to 5 months).
The following AFTERCARE instructions are advised:
12 hours following the treatment, do not expose treated area to direct heat including hot showers.
Do not use a jacuzzi, steam room or sauna. Do not participate in activities that may cause excessive
perspiration.
Erythema can occur following treatment, but will resolve within a few hours.
5. Safety Warnings
Never operate this equipment on a person that has or suers from the following medical conditions
described below. (The salon or operator should consider having the client sign a medical history and
consent form to the eect that he/she is free of any poor health conditions).
• Heart Disease
• Heart Murmur or Irregular Heart Rate
• Has a Pacemaker or other type of heart rate balancer
• Epilepsy
• Ulcers
• Disease of Stomach, Intestine, Liver, or Pancreas
• Breast Cancer
• Undergoing treatment for any form of Cancer
• Untreated hypertension
• Migraines and headaches
• Any serious illness or disease not listed above
Overly aggressive use of RF should not be used on sensitive areas such as eyelids.
The machine is intended for professional use and it can be used only by professionals who have proper
training. The producer is not responsible for liabilities for damages caused by improper use of this
machine.
Any damage to the cables could cause a risk of electric shock, also they may cause serious damage to
the machine and re. Do not open the cover under threat of loss of warranty. Opening the cover may
cause electric shock.
Do not modify nor repair the machine by yourself under threat of loss of warranty. Protect the machine
from moisture, water and dust, and keep the machine away from electric heater and other sources of
heat. Do not cover the ventilation holes.
The machine can not be used for purposes other than those described in this manual.
Do not modify or attempt to repair the machine, contact your dealer or distributor for repair or
maintenance.

Dual Injector Pro+ User Manual (Ver. 1-2017) Page 7
6. Warranty and Service
Limited warranty:
This warranty covers defects for twelve (12) months from date of purchase from authorized dealer or
distributor. Within this period, we will repair the device without charge for parts and labour. Package
the unit in appropriate protective material (if possible in original package), with a copy of your original
purchase receipt and send it to our repair facility (freight pre-paid). Warranty does not cover shipping
costs to us. We will send repaired unit back to you free of charge. Warranty does not cover shipping costs
to us or products subjected to misuse or accidental damage.
Except as provided herein, the supplier makes no warranties, expressed or implied, including warranties
of merchantability and tness for a particular purpose.
Your dealer or distributor will activate this machine’s 12 month warranty.
7. Troubleshooting
Situation/Symptom Probable Cause Solution
System does not start The power on/o switch on the
front panel is in o position.
Turn on the on/o button on the back of
the machine.
System does not start Power disconnected. Turn o the power. Check that the power
cable is plugged into electrical outlet and
connected to the main units power inlet.
8. Technical specications
Main Power: 230V, 50 Hz (DC-12V)
Radio Frequency: 500 kHz + Red LED
Electroporation: 1.9 kHz + Blue LED
Max eect: 30 W
Size: 220 x 100 x 200 mm (W x H x D)
8.1 Marking description
This machine is marked according to Directive 2002/96/EC of the European Parliament and
of the Council of 27 January 2003 on waste electrical and electronic equipment (WEEE).
The machine should be used only in closed spaces.
8.2 EUROPEAN REGULATIONS
The machine is made according to EU directives:
Low Voltage Directive (LVD) 73/23/EEC+93/68/EEC
Electromagnetic compatibility (EMC) 89/336/EEC+92/31/EEC+93/68/EEC and harmonized standards user
for showing compliance with the essential requirements in the specied directives:
PN-EN 55014-1:2002 (U), PN-EN 55014-2:1999, PN-EN 60335-1:2002, PN-EN 60335-2-32:2002, PN-EN
60335-2-23:2001, PN-EN 60335-2-23:2002+A1:2002.
Brand owner: AESTHETECH of Sweden (www.aesthetech.eu)
Supplier: DBB GRUPP OÜ (www.dbbgrupp.ee)
UK Distributor: 4T Medical Ltd (www.4tmedical.com)
