User’s Manual
Revision Date: Jul. 22. 2019
ROC285B
MIL-STD Rugged Computer
User’s Manual

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
1
Safety Information
Electrical safety
To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before
relocating the system.
When adding or removing devices to or from the system, ensure that the power cables for the
devices are unplugged before the signal cables are connected. If possible, disconnect all power cables
from the existing system before you add a device.
Before connecting or removing signal cables from the motherboard, ensure that all power cables are
unplugged.
Seek professional assistance before using an adapter or extension cord. These devices could interrupt
the grounding circuit.
Make sure that your power supply is set to the correct voltage in your area.
If you are not sure about the voltage of the electrical outlet you are using, contact your local power
company.
If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or
your local distributor.
Operation safety
Before installing the motherboard and adding devices on it, carefully read all the manuals that came
with the package.
Before using the product, make sure all cables are correctly connected and the power cables are not
damaged. If you detect any damage, contact your dealer immediately.
To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and
circuitry.
Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may
become wet.
Place the product on a stable surface.
If you encounter any technical problems with the product, contact your local distributor
Statement
All rights reserved. No part of this publication may be reproduced in any form or by any means,
without prior written permission from the publisher.
All trademarks are the properties of the respective owners.
All product specifications are subject to change without prior notice

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
2
Revision History
Revision
Date (yyyy/mm/dd)
Changes
Version 1.0
2019/9/23
Initial release
Packing list
□ 19” 1U Rack-mount Intel® Q370 Fanless Rugged System
□ Accessories
Ordering Information
Model Number
Description
ROC285B
1U Rackmount Fanless System with Intel® Q370, 3 x DisplayPort, 1 1 x
PCIex16 slot, 90~264V AC-In, operating Temp -20 to 60°C
ROC285BB
1U Rackmount Fanless System with Intel® Q370, 3 x DisplayPort, 1 x
PCIex16 slot, 90~264V Redundant AC-In, operating Temp -20 to 60°C

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
3
Table of contents
Safety Information .............................................................................................................................................1
Electrical safety..............................................................................................................................................1
Operation safety ............................................................................................................................................1
Statement ......................................................................................................................................................1
Revision History..................................................................................................................................................2
Packing list..........................................................................................................................................................2
Ordering Information.........................................................................................................................................2
Chapter 1: Product Introduction ........................................................................................................................5
1-1 Key Features......................................................................................................................................5
1.2 Mechanical Dimensions ........................................................................................................................7
1.3 Panel Component.....................................................................................................................................8
Chapter 2: Jumpers and Connectors Locations ..................................................................................................9
2.1 Rear Panel Connector Pin Definitions ......................................................................................................9
Chapter 3 Getting Started .............................................................................................................................10
Chapter 4: AMI BIOS UTILITY............................................................................................................................11
4.1 Starting...................................................................................................................................................11
4.2 Navigation Keys......................................................................................................................................11
4.3 Main.......................................................................................................................................................12
4.4 Advanced ...............................................................................................................................................13
4.4.2 CPU Configuration...........................................................................................................................14
4.4.3 ACPI Setting.....................................................................................................................................15
4.4.4 Smart Setting...................................................................................................................................15
4.4.5 F81866 Super IO Configuration .......................................................................................................16
4.4.6 Hardware Monitor...........................................................................................................................17
4.4.7 Platform Function............................................................................................................................18
4.5 Chipset Menu.........................................................................................................................................22

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
4
4.5.1 System Agent (SA) Configuration.....................................................................................................23
4.5.2 PCH-IO Configuration ......................................................................................................................25
4.6 Security Menu........................................................................................................................................29
4.7 Boot Menu.............................................................................................................................................30
4.8 Save & Exit .............................................................................................................................................31

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
5
Chapter 1: Product Introduction
1-1 Key Features
System
High Performance
Processor
Socket LGA 1151 for Intel® Core i7/i5/i3/Celeron® (Supports up to 65W) Intel® Core™
i7-9700TE (8C x 3.8 GHz), 12MB Cache
Memory type
2 x SO-DIMM DDR4 2400/2666 MHz up to 64GB
Chipset
Intel® Q370 Chipset
Expansion Slot
1 x PCIe x16 (Graphics card dimension should not be large than 170x110mm) 1x M.2 (Key
M, 2242/2260/2280) with PCIe x4 and SATA3
Display
VGA
Resolution up to 1920×1200@60Hz
Storage
Display Port
Resolution up to 4096 x 2304 60@Hz
HDD/SDD
2 x 2.5” SATA HDD/SSD easy swap tray
Ethernet
Ethernet
Intel® I210 & I219LM GbE LAN (support 10/100/1000 Mbps for x2 RJ45 ports)
Rear I/O
Display Port
3 x DP, resolution up to 4096 x 2304
Ethernet
2 x RJ45 Intel® I210 & I219LM GbE LAN (support 10/100/1000 Mbps)
Audio
2 x 3.5mm Audio Jacks (1 x MIC, 1 x Line-Out)
COM
1 x RS232/422/485
USB Port
4 x USB 3.1(10Gb/s)
AC-IN
1 x AC Inlet
Front I/O
Button
1 x Power Button w/Indicator LED
Indicator LED
HDD
USB Port
2 x USB 2.0
Easy Swap SSD Tray
2
Applications, Operating System
Applications
Commercial and Industrial Platforms, Embedded Computing, Process Control,

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
6
Intelligent Automation and manufacturing applications
Operating System
Windows 10 64Bit
Ubuntu13.04, Ubuntu13.10, Ubuntu14.04, Fedora 20
Physical
Dimension (W x D x H)
440 x430 x 44 mm
Weight
8.5Kg
Chassis
SECC
Heatsink
Aluminum Alloy, Corrosion Resistant
Finish
Anodic aluminum oxide
Environmental
MIL-STD-810G Test
Method 507.5, Procedure II (Temperature & Humidity)
Method 501.5, Procedure I (Storage/High Temperature)
Method 501.5, Procedure II (Operation/High Temperature)
Method 502.5, Procedure I (Storage/Low Temperature)
Method 502.5, Procedure II (Operation/Low Temperature)
Method 503.5, Procedure I (Temperature shock)
Green Product
RoHS compliance
Operating Temperature
w/o Graphic Card (ET: -20 to 60°C; UT: -30 to 70°C) ; w/Graphic Card (0 to 50°C)
Storage Temperature
-40 to 85°C
Relative Humidity
5% to 95%, non-condensing
EMC
CE and FCC compliance
*Specifications are subject to change without notice*

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
7
1.2 Mechanical Dimensions

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
8
1.3 Panel Component

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
9
Chapter 2: Jumpers and Connectors Locations
2.1 Rear Panel Connector Pin Definitions

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
10
Chapter 3 Getting Started

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
11
Chapter 4: AMI BIOS UTILITY
This chapter provides users with detailed descriptions on how to set up a basic system configuration
through the AMI BIOS setup utility.
4.1 Starting
To enter the setup screens, perform the following steps:
Turn on the computer and press the <Del> key immediately.
After the <Del> key is pressed, the main BIOS setup menu displays. Other setup screens can be
accessed from the main BIOS setup menu, such as the Chipset and Power menus.
4.2 Navigation Keys
The BIOS setup/utility uses a key-based navigation system called hot keys. Most of the BIOS setup
utility hot keys can be used at any time during the setup navigation process.
Some of the hot keys are <F1>, <F10>, <Enter>, <ESC>, and <Arrow> keys.

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
12
4.3 Main

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
13
4.4 Advanced

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
14
4.4.2 CPU Configuration

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
15
4.4.3 ACPI Setting
4.4.4 Smart Setting

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
16
4.4.5 F81866 Super IO Configuration

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
17
4.4.6 Hardware Monitor
4.4.6.1 Smart Fan Mode Configuration

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
18
4.4.7 Platform Function

ROC285B User’s Manual
Revision Date: Jul. 22. 2019
19
4.4.8 Serial Consolr Redirection
