909 10301 User manual

INSTRUCTION MANUAL
10301
Rechargeable
Heavy-Duty
Swivel-Head Lantern

2
CONTENTS
Warranty
For full details please visit us at www.909.com
Warranty 2
Introduction 3
Environmental protection 3
Specifications 3
General safety warnings and instructions 4
Important safety instructions 4
Additional safety instructions for the charger 5
Know your product 7
Introduction 8
Charging/recharging the spotlight 8
Operating Instructions 8
Care and maintenance 8
Battery replacement/disposal 9
Troubleshooting 9
Accessories 10

3
Specifications
Spotlight bulb: 6 Volt H3 light Quartz Halogen
LED 3 LED light
Battery: Built-in 6-volt 4 Ah sealed lead-
acid rechargeable battery
100- 240Vac plug pack charger:
Output 9Vdc 0.3A
DC charger plug fuse: 2 A/250 V
Introduction
Your new 909 appliance will more than satisfy
your expectations. It has been manufactured under
stringent 909 Quality Standards to meet superior
performance criteria.
You will find your new appliance easy and safe to operate,
and, with proper care, it will give you many years
of dependable service.
CAUTION. Carefully read through this entire Instruction
Manual before using your new 909 appliance. Take
special care to heed the Cautions and Warnings.
Your 909 appliance has many features that will make your
job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.
Environmental protection
Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally safe way.

4
General safety warnings and instructions
Read all instructions
WARNING: Read all instructions before operating spotlight.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
Safety guidelines / definitions
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates
potentially hazardous situation which, if not avoided, may
result in property damage.
Risk of unsafe operation.
When using tools or equipment, basic safety precautions
should always be followed to reduce the risk of personal
injury. Improper operation, maintenance or modification
of tools or equipment could result in serious injury and
property damage. There are certain applications for
which tools and equipment are designed. Manufacturer
strongly recommends that this product NOT be modified
and/or used for any application other than for which it was
designed. Read and understand all warnings and operating
instructions before using any tool or equipment.
Important safety instruction
Instructions pertaining to a risk of fire, electric shock,
exposure to excessive UV radiation, or injury to
persons
Lighted lamp is HOT.
WARNING: to reduce the risk of fire, electric shock,
exposure to excessive UV radiation, or injury to
persons:
• Turn off/unplug and allow to cool before replacing the
Halogen bulb.
• Halogen bulb gets HOT quickly!
• Do not touch the bulb at any time when operating.
• Only contact switch/plug when turning on.
• Do not touch hot lens or enclosure.
• Do not remain in light if skin feels warm.
• Use only with a 6V H3 Halogen Bulb.
• When changing bulb, use a soft cloth. Oil from skin may
damage bulb.
• Do not operate the spotlight with a missing or damaged
lens or enclosure.
WARNING – when using electrical appliances, basic
precautions should always be followed, including the
following:
• To reduce the risk of injury, close supervision is
necessary when the spotlight is used near children.
• Use only attachments recommended or sold by the
manufacturer.
WARNING: to reduce the risk of electric shock:
• Do not put spotlight in water or other liquid. Do not place
or store appliance where it can fall or be pulled into a tub
or sink.
• Do not clean this appliance with a water spray or the like.
• Use only the charger supplied by the manufacturer to
recharge.

5
• When an extension cord is used:
– The marked rating of the detachable power supply
cord or extension cord should be at least as great as
the electrical rating of this appliance.
– The cord should be arranged so that it will not drape
over the countertop or tabletop where it can be
tripped over, snagged, or pulled on unintentionally
(especially by children).
– The extension cord should be kept dry and off the
ground.
– Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one
heavy enough to carry the current your product will
draw. An undersized cord will cause a drop in line
voltage resulting in loss of power and overheating.
The following table shows the correct size to use
depending on cord length and nameplate ampere
rating. If in doubt, use the next heavier gage. The
smaller the gage number, the heavier the cord.
– When tool is used outdoors, use only extension cords
intended for use outdoors and so marked.
WARNING: FIRE HAZARD: Never contact combustible
material to the lens and never tape or tie the switch in
the on position.
Additional safety instructions for the charger
• Before using the charger, read all the instructions and
cautionary markings on the charger and torch.
• Only charge your torch indoors as the charger is
designed for indoor use only.
• WARNING. Do not allow any liquid to come into contact
with the charger. There is a danger of electric shock.
• The charger is not intended for any use other than
charging the exact type of rechargeable torch as supplied
with the charger. Any other use may result in the risk of
fire, electric shock or electrocution.
• The charger and torch are specifically designed to work
together. Do not attempt to charge the torch with any
other charger than the one supplied.
• Do not place any object on top of the charger as it could
cause overheating. Do not place the charger near any
heat source.
• Do not pull on the lead of the charger to disconnect it
from the power source.
• Make sure that the charger cable is positioned where
it will not be stepped on, tripped over or otherwise
subjected to damage or stress.
• Do not use an extension cord unless it is absolutely
necessary. The use of an improper extension cord could
cause the risk of fire, electric shock or electrocution.
• Do not use the charger if it has been subjected to a
heavy knock, dropped or otherwise damaged in any way.
Take the charger to a power tool repair centre for a check
or repair.
• Do not disassemble the charger. Take it to power tool
repair centre when service or repair is required. Incorrect
re-assembly may result in the risk of fire, electric shock or
electrocution.
• The charger is designed for use from a standard
household electrical supply (230–240 volts). Do not
attempt to connect the charger to a supply with a
different supply.
CAUTION: To reduce the risk of injury or property
damage:
• All halogen lights give off heat:
– Do not touch lens while operating.
– Keep combustibles away from spotlight lens. Extreme
heat can cause fires.
– Never place the light face-down on any surface
when lit.
• Never look directly into the light or shine the light into
another person’s eyes.

6
• Keep sharp objects away from lens — it is glass and can
break.
• Do not immerse spotlight in water.
• Do not expose this unit to extremely high temperatures.
• Do not drop or throw spotlight. It contains glass and a
sealed lead acid battery.
• Use only with AC or DC charging adapters that are
provided with unit. Plug in the charging adapter at the
spotlight first, then plug into the charging source.
• DO NOT OVERCHARGE: CHARGE UP TO 15 HOURS
MAXIMUM USING THE AC CHARGING METHOD; UP
TO 8 HOURS MAXIMUM USING THE DC CHARGING
METHOD.
• After charging/recharging, disconnect charging adapter or
extension cord and wait 5 minutes before use.
• Do not crush, cut, pull or expose charging adapter cords
to extreme heat.
• Position charging adapter cords so they do not become
entangled or become a safety hazard. Keep charging
adapter cords away from sharp edges.
• Use in a dry location only.
• Except for the bulb, there are no user-serviceable parts
inside. Do not attempt to disassemble any other parts of
the unit.
• To reduce risk of damage to electric plug and cord, pull
by plug rather than cord when disconnecting.
• Turn the power switch off after using. Leaving the switch
on may cause permanent damage to the battery.
Save these instructions

7
Know your product
1. On/Off trigger
2. On/Off trigger lock-on button
3. Soft rubberised grip
4. Charging indicator
5. Charging port
6. 3-LED flashlight On/Off button
7. 3-LED flashlight
8. Halogen bulb
9. 240Vac plug pack charger
10. 12V DC car charger adaptor
6
8
123
4
5
7
910

8
Introduction
Congratulations on purchasing your new spotlight. Read
this Instruction Manual and follow the instructions carefully
before using your new Rechargeable Spotlight.
Charging/recharging the spotlight
This unit is shipped in a partially charged state. Charge unit
BEFORE first use using the 240VAC plug pack charger
for 10-15 Hrs. Charge after each use. Whilst charging with
either the AC charger or the DC vehicle charger, the status
indicator will glow RED.
IMPORTANT. To prevent permanent damage to the battery
ensure to fully charge the battery within 6 months of the
production date.
Refer to the serial number. The first number is the year of
manufacture, ie 1 is 2011. The next 2 numbers are the week
of manufacture in that year. ie 14. So in this example, the
Lantern was manufactured in week 14 of 2011.
Charging/recharging using the 240V AC plug pack charger
• Make sure the spotlight is off (the trigger lock is in the off
position and the trigger is not depressed).
• Insert the plug of the 240V ac Plug Pack charger into the
charging port at the rear of the Lantern. Plug the 240Vac
Plug Pack charger into a normal house hold 240V Power
point and turn on. The status indicator should glow RED.
• The red LED will remain ON while the charging process
is operating. It will change to trickle charging after the
battery is fully charged.
Charging/recharging using the 12 volt DC charger
(optional accessory)
• Make sure the spotlight is off (the trigger lock is in the off
position and the trigger is not depressed).
• Plug the barrel tip of the 12 volt DC charger into the car
DC charging port at the rear of the lantern.
• Insert the 12 volt DC plug end into the accessory outlet of
your vehicle or other 12 volt DC power source.
• Charge the Battery for a max of 8 hours. The red LED will
remain ON during the charging process.
Make sure the DC source (jump-starter, battery pack,
vehicle accessory outlet, etc.) is 12 volt DC and is able to
supply at least one half amp at 12 volt DC for 8 hours.
Notes: When using a vehicle’s 12 volt DC accessory outlet
as a charging source, be aware that some vehicles require
you to turn on the ignition to power the accessory outlet.
WARNINGS:
• To avoid the risk of property damage, charge up to
15 hours maximum using the ac charging method; up to
8 hours maximum using the dc charging method.
• Never attempt to use the ac charger and dc charging port
simultaneously.
Operating instructions
Operating the spotlight
1. Disconnect from charger.
2. The On/Off trigger is located in the front of the handle of
the spotlight.
3. To turn the spotlight on, squeeze the trigger.
4. To turn off the spotlight, release the trigger.
Note: The On/Off trigger can be locked in the on position
using the trigger lock switch on the side of the unit.
Operating the 3 LED Flash lights
1. Disconnect from the charger.
2. To turn on the LED lights, depress the 3 LED flashlight on
/ off button (refer diagram, Know your product)
3. To turn off the LED flashlights, depress the on / off button.
Care and maintenance
All batteries lose energy from self-discharge over time and
more rapidly at higher temperatures. When the unit is not
in use, we recommend that the battery is charged at least
every 60 days.

9
Never submerge the unit in water. If the unit gets dirty,
gently clean the outer surfaces of the spotlight unit with
a soft cloth moistened with a mild solution of water and
detergent.
Except for the 6V/25 watt bulb, there are no user-
replaceable parts. Periodically inspect the condition of
adapters, connectors and wires. Contact manufacturer to
replace any components that have become worn or broken.
Battery replacement/disposal
Battery replacement
The battery should last the service life of the unit. Contact
manufacturer for any information you may need.
Safe battery disposal
Contains a maintenance-free, sealed, non-spillable, lead
acid battery, which must be disposed of properly. Recycling
is required, contact your local authority for information.
WARNINGS:
• Do not dispose of the battery in fire as this may result in
an explosion.
• Before disposing of the battery, protect exposed terminals
with heavy-duty electrical tape to prevent shorting
(shorting can result in injury or fire).
• Do not expose battery to fire or intense heat as it may
explode.
Spotlight bulb replacement
To replace the bulb, you will need a small Phillips
screwdriver and a 6 volt/H3 replacement bulb. During
installation, avoid touching the glass part of the bulb.
Bulb life may be shortened by installing a bulb with dirt or
fingerprints on it. The bulb can be wiped clean with a cloth
moistened with alcohol.
1. Disconnect the unit from any charging adapters.
2. Push the rubber bezel forward toward the front of the
spotlight to reveal two small Phillips screws in the
retaining ring.
3. Using the screwdriver, remove (counterclockwise) the
two screws. Set them aside.
4. Lift off the retaining plastic cover, glass lens and set
them aside.
5. Carefully remove the reflector and bulb assembly.
6. Disconnect the bulb wire from the red power wire.
7. Unsnap the hairpin retaining wires from the reflector’s
flange.
8. Lift out the bulb.
9. Insert the replacement bulb into the reflector’s flange.
Re assemble in the reverse order.
WARNING: Only use a 6 Hs replacement bulb.
12 volt DC charger plug fuse replacement
The fuse in the plug end of the 12 volt DC charger protects
the adapter’s charging circuit. If the 240vAC plug pack
charger operates, but the DC charging adapter does not,
then this fuse may be opened (blown).
To replace the fuse:
1. Unscrew the end cap of the DC plug (counterclockwise).
2. Remove spring center contact and fuse.
3. Check fuse with a continuity checker.
4. If blown, locate a replacement 2 amp/250 volt fuse.
5. Replace the fuse, spring, contact and end cap.
6. Screw end cap clockwise until it is finger tight – DO NOT
OVER-TIGHTEN.
7. Test for proper operation of the 12 Volt DC Charging
Adapter.
Troubleshooting
The charging status indicator LED does not glow red when
charging.
1. Check connection to the 240Vac Plug Pack Charger or
12 volt DC charger.
2. Check connection to AC or DC power source.

10
3. Confirm there is a functioning AC or DC current.
4. For DC charging, check the ignition switch on the car as
this may need to be in the accessory position.
Unit will not operate
1. The halogen bulb may have blown. Check bulb filament.
If the filament is coiled and unbroken, the bulb is
not blown. Otherwise, replace the bulb following the
instructions in this manual.
2. The battery may be completely discharged. Charge the
unit following the directions in this manual.
Accessories
Recommended accessories for use with your tool are
available from your local dealer or authorized service center.
If you need assistance regarding accessories, please
contact manufacturer at www.909.com.
WARNING: The use of any accessory not recommended for
use with this tool could be hazardous.

11
