909 RL3003 User manual

INSTRUCTION MANUAL
RL3003
Rechargeable Spotlight

2
CONTENTS
Warranty
For full details please visit us at www.909.com
Warranty 2
Introduction 3
Environmental protection 3
Specifications 3
General safety warnings and instructions 4
Important safety instructions 4
Additional safety instructions for the charger 5
Know your product 7
Introduction 8
Charging/recharging the spotlight 8
Operating Instructions 8
Care and maintenance 8
Troubleshooting 10
Accessories 11
Service information 11

3
Specifications
Spotlight bulb: 100W Halogen Bulb 12V H3
Battery: Maintenance-free, sealed lead
acid, 12 volt, 3Ah
AC Charger:
AC Charger Input: 230-240Vac
AC Charger Output: 12V 500mA
DC charger plug fuse: 10A/250V
Introduction
Your new 909 appliance will more than satisfy
your expectations. It has been manufactured under
stringent 909 Quality Standards to meet superior
performance criteria.
You will find your new appliance easy and safe to operate,
and, with proper care, it will give you many years
of dependable service.
CAUTION. Carefully read through this entire Instruction
Manual before using your new 909 appliance. Take
special care to heed the Cautions and Warnings.
Your 909 appliance has many features that will make your
job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.
Environmental protection
Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally safe way.

4
General safety warnings and instructions
Read all instructions
WARNING: Read all instructions before operating spotlight.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
Safety guidelines / definitions
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates
potentially hazardous situation which, if not avoided, may
result in property damage.
Risk of unsafe operation.
When using tools or equipment, basic safety precautions
should always be followed to reduce the risk of personal
injury. Improper operation, maintenance or modification
of tools or equipment could result in serious injury and
property damage. There are certain applications for
which tools and equipment are designed. Manufacturer
strongly recommends that this product NOT be modified
and/or used for any application other than for which it was
designed. Read and understand all warnings and operating
instructions before using any tool or equipment.
Important safety instruction
Instructions pertaining to a risk of fire, electric shock,
exposure to excessive uv radiation, or injury to persons
Lighted lamp is HOT.
WARNING: to reduce the risk of fire, electric shock,
exposure to excessive uv radiation, or injury to
persons:
• Turn off/unplug and allow to cool before replacing the
Halogen bulb.
• Halogen bulb gets HOT quickly!
• Do not touch the bulb at any time when operating.
• Only contact switch/plug when turning on.
• Do not touch hot lens or enclosure.
• Do not remain in light if skin feels warm.
• Use only with a 12Volt/100watt or smaller halogen bulb.
• When changing bulb, use a soft cloth. Oil from skin may
damage bulb.
• Do not operate the spotlight with a missing or damaged
lens or enclosure.
WARNING – when using electrical appliances, basic
precautions should always be followed, including the
following:
• To reduce the risk of injury, close supervision is
necessary when the spotlight is used near children.
• Use only attachments recommended or sold by the
manufacturer.
WARNING: to reduce the risk of electric shock:
• Do not put spotlight in water or other liquid. Do not place
or store appliance where it can fall or be pulled into a tub
or sink.
• Do not clean this appliance with a water spray or the like.
• Use only the charger supplied by the manufacturer to
recharge.

5
Additional safety instructions for the charger
• Before using the charger, read all the instructions and
cautionary markings on the charger and torch.
• Only charge your torch indoors as the charger is
designed for indoor use only.
• WARNING. Do not allow any liquid to come into contact
with the charger. There is a danger of electric shock.
• The charger is not intended for any use other than
charging the exact type of rechargeable torch as supplied
with the charger. Any other use may result in the risk of
fire, electric shock or electrocution.
• The charger and torch are specifically designed to work
together. Do not attempt to charge the torch with any
other charger than the one supplied.
• Do not place any object on top of the charger as it could
cause overheating. Do not place the charger near any
heat source.
• Do not pull on the lead of the charger to disconnect it
from the power source.
• Make sure that the charger cable is positioned where
it will not be stepped on, tripped over or otherwise
subjected to damage or stress.
• Do not use an extension cord unless it is absolutely
necessary. The use of an improper extension cord could
cause the risk of fire, electric shock or electrocution.
• Do not use the charger if it has been subjected to a
heavy knock, dropped or otherwise damaged in any way.
Take the charger to a power tool repair centre for a check
or repair.
• Do not disassemble the charger. Take it to power tool
repair centre when service or repair is required. Incorrect
re-assembly may result in the risk of fire, electric shock or
electrocution.
• The charger is designed for use from a standard
household electrical supply (230–240 volts). Do not
attempt to connect the charger to a supply with a
different supply.
WARNING: FIRE HAZARD: Never contact combustible
material to the lens and never tape or tie the switch in
the on position.
CAUTION: To reduce the risk of injury or property
damage:
• All halogen lights give off heat:
– Do not touch lens while operating.
– Keep combustibles away from spotlight lens.
Extreme heat can cause fires.
– Never place the light face-down on any surface
when lit.
• Never look directly into the light or shine the light into
another person’s eyes.
• Keep sharp objects away from lens — it is glass and can
break.
• Do not immerse spotlight in water.
• Do not expose this unit to extremely high temperatures.
• Do not drop or throw spotlight. It contains glass and a
sealed lead acid battery.
• Use only with AC or DC charging adapters that are
provided with unit. Plug in the charging adapter at the
spotlight first, then plug into the charging source.
• DO NOT OVERCHARGE: CHARGE UP TO 24 HOURS
MAXIMUM USING THE AC CHARGING METHOD; UP
TO 7 HOURS MAXIMUM USING THE DC CHARGING
METHOD.
• NEVER ATTEMPT TO USE THE AC CHARGER AND
DC CHARGING PORT SIMULTANEOUSLY.
• After charging/recharging, disconnect charging adapter or
extension cord and wait 5 minutes before use.
• Do not crush, cut, pull or expose charging adapter cords
to extreme heat.
• Position charging adapter cords so they do not become
entangled or become a safety hazard. Keep charging
adapter cords away from sharp edges.

6
• Use in a dry location only.
• Except for the bulb, there are no user-serviceable parts
inside. Do not attempt to disassemble any other parts of
the unit.
• To reduce risk of damage to electric plug and cord, pull
by plug rather than cord when disconnecting.
• Do not attempt to charge the unit if the 240 volt AC
charger plug is damaged – return the unit to manufacturer
for repair.
Save these instructions

7
Know your product
1. On/Off trigger
2. DC plug pack charging socket
3. Quartz halogen bulb
4. Charge status LED indicator
5. 240Volt AC plug pack charger
6. Trigger lock
7. 12Volt DC car adaptor.
8. Carry lanyard
(optional accessory)
9. DC car charging port
2
6
3
4
1
9
8
5 7

8
Introduction
Congratulations on purchasing your new spotlight. Read
this Instruction Manual and follow the instructions carefully
before using your new Rechargeable Spotlight.
Charging/recharging the spotlight
This unit is shipped in a partially charged state. Charge
unit BEFORE first use using the 240 volt AC charger for
24 hours. Charge after each use. The charge status LED
flashes while charging and lights solid when the unit is fully
charged while using the AC charging method.
Charging/recharging using the 240 volt AC charger
• Make sure the spotlight is off (the trigger lock is in the off
position and the trigger is not depressed).
• Insert the barrel connector of the plug pack charger into
the DC Plug Pack charging socket on the back of the
spotlight. Insert the plug end into a standard 240V ac
power point.
• Charge until the charge status LED lights solid
(approximately 18-24 hours).
Charging/recharging using the 12 volt DC charger
(optional accessory)
• Make sure the spotlight is off (the trigger lock is in the off
position and the trigger is not depressed).
• Plug the double pin tip of the 12 volt DC charger into the
12 volt DC charging port.
• Insert the 12 volt DC plug end into the accessory outlet of
your vehicle or other 12 volt DC power source.
• Charge for approximately 5-7 hours..
Make sure the DC source (jump-starter, battery pack,
vehicle accessory outlet, etc.) is 12 volt DC and is able to
supply at least one half amp at 12 volt DC for 10 hours.
Notes: When using a vehicle’s 12 volt DC accessory outlet
as a charging source, be aware that some vehicles require
you to turn on the ignition to power the accessory outlet.
WARNINGS:
• TO AVOID THE RISK OF PROPERTY DAMAGE,
CHARGE UP TO 24 HOURS MAXIMUM USING THE
AC CHARGING METHOD; UP TO 7 HOURS MAXIMUM
USING THE DC CHARGING METHOD.
• NEVER ATTEMPT TO USE THE AC CHARGER AND
DC CHARGING PORT SIMULTANEOUSLY.
Operating instructions
Operating the spotlight
1. Disconnect from charger.
2. The On/Off trigger is located in the front of the handle of
the spotlight.
3. To turn the spotlight on, squeeze the trigger.
4. To turn off the spotlight, release the trigger.
Note: The On/Off trigger can be locked in the on position
using the trigger lock switch on the side of the unit.
Operating the unit corded
Plug the double pin tip of the 12 volt DC charger (optional
accessory) into the 12 volt DC charging port. Insert the 12
volt DC plug end into the accessory outlet of your vehicle or
other 12 volt DC power source. Operate the unit as outlined
in the previous section.
Notes: When using a vehicle’s 12 volt DC accessory outlet
as a charging source, be aware that some vehicles require
you to turn on the ignition to power the accessory outlet.
IMPORTANT: The spotlight will operate while the 240 volt
AC charger is attached, but will continue to draw power
from the unit’s acid battery and will not continue charging
while the spotlight operates. Manufacturer recommends
only operating the unit in corded mode using the 12 volt
DC charger.
Care and maintenance
All batteries lose energy from self-discharge over time and
more rapidly at higher temperatures. When the unit is not
in use, we recommend that the battery is charged at least
every 60 days.

9
Never submerge the unit in water. If the unit gets dirty,
gently clean the outer surfaces of the spotlight unit with
a soft cloth moistened with a mild solution of water and
detergent.
Except for the 12V/100W bulb, there are no user-
replaceable parts. Periodically inspect the condition of
adapters, connectors and wires. Contact manufacturer to
replace any components that have become worn or broken.
Battery replacement/disposal
Battery replacement
The battery should last the service life of the unit. Contact
manufacturer for any information you may need.
Safe battery disposal
Contains a maintenance-free, sealed, non-spillable, lead
acid battery, which must be disposed of properly. Recycling
is required, contact your local authority for information.
WARNINGS:
• Do not dispose of the battery in fire as this may result in
an explosion.
• Before disposing of the battery, protect exposed terminals
with heavy-duty electrical tape to prevent shorting
(shorting can result in injury or fire).
• Do not expose battery to fire or intense heat as it may
explode.
Spotlight bulb replacement (diagram follows)
To replace the bulb, you will need a small Phillips
screwdriver and a 12V/100Watt replacement bulb. During
installation, avoid touching the glass part of the bulb.
Bulb life may be shortened by installing a bulb with dirt or
fingerprints on it. The bulb can be wiped clean with a cloth
moistened with alcohol.
Rubber Bezel
Use a screwdriver to
gently pry the rubber
bezel off.
Retaining
Ring
Glass
Lens
Rubber
“O” Ring
Light
Reflector
Phillips
Screw
On/Off
Trigger
Phillips Screw
Halogen Bulb Assembly
Only replace the bulb in an
interated assembly of lamp
holder, wire and tab.
Retaining
Screw
Light
Reflector
Hairpin
Retaining
Wire
Halogen
Bulb
Assembly

10
1. Disconnect the unit from any charging adapters.
2. Push the rubber bezel forward toward the front of the
spotlight to reveal two small Phillips screws in the
retaining ring.
3. Using the screwdriver, remove (counterclockwise) the two
screws. Set them aside.
4. Lift off the retaining ring, glass lens and rubber “O” ring
and set them aside.
5. Carefully remove the reflector and bulb assembly.
6. Disconnect the bulb wire from the red power wire.
7. Unsnap the hairpin retaining wires from the reflector’s
flange.
8. Using the screwdriver, loosen the retaining screw to
remove the bulb from the reflector (no need to completely
remove this screw).
9. Lift out the bulb and detach wire.
10. Insert the replacement bulb into the reflector’s flange.
11. Put back and secure the hairpin retaining wires.
12. Connect the bulb power wire to the red power wire.
13. Tighten the retaining screw on the flange.
14. Place the reflector in position in the body of the
spotlight.
15. Replace the rubber “O” ring in the groove around the
perimeter of the reflector.
16. Replace glass and retaining ring so the screw holes are
aligned.
17. Secure retaining ring with two screws.
18. Replace rubber bezel.
19. Operate switch to ensure proper operation of spotlight.
WARNING: To reduce the risk of electric shock, replace
bulb with 12 volt, H3 100 watt only.
12 volt DC charger plug fuse replacement
The fuse in the plug end of the 12 volt DC charger protects
the adapter’s charging circuit. If the 240 volt AC charger
operates, but the DC charging adapter does not, then this
fuse may be opened (blown).
To replace the fuse:
1. Unscrew the end cap of the DC plug (counterclockwise).
2. Remove spring centre contact and fuse.
3. Check fuse with a continuity checker.
4. If blown, locate a replacement 10 amp/250 volt fuse.
5. Replace the fuse, spring, contact and end cap.
6. Screw end cap clockwise until it is finger tight – DO NOT
OVER-TIGHTEN.
7. Test for proper operation of the 12 Volt DC Charging
Adapter.
Troubleshooting
The charging status indicator LED does not flash when
charging.
1. Check connection to the 240 volt AC charger.
2. Check connection to AC power source.
3. Confirm there is a functioning AC current.
Unit will not operate
1. The halogen bulb may have blown. Check bulb filament.
If the filament is coiled and unbroken, the bulb is not
blown.
Otherwise, replace the bulb following the instructions in this
manual.
2. The battery may be completely discharged. Charge the
unit following the directions in this manual.
3. If the spotlight does not operate after recharging as
directed, contact manufacturer at www.909.com.
