909 SL2443 User manual

INSTRUCTION MANUAL
SL2443
Compact HID Spotlight

2
CONTENTS
Warranty
For full details please visit us at www.909.com
Warranty 2
Introduction 3
Environmental protection 3
Specifications 3
General safety warnings and instructions 4
Important safety instructions 4
Additional safety instructions for the charger 5
Know your product 7
Introduction 8
Reading the battery/charge status LED indicator 8
Charging/recharging the spotlight 8
Operating Instructions 8
Care and maintenance 9
Troubleshooting 9
Accessories 10

3
Specifications
Spotlight bulb: 20 watt HID bulb
Battery: Maintenance-free, sealed lead
acid, 12 volt, 1.2 Ah
240V AC plug
pack charger: 12 volt DC (500 mA)
DC charger plug fuse: 5 A/250 V
Introduction
Your new 909 appliance will more than satisfy
your expectations. It has been manufactured under
stringent 909 Quality Standards to meet superior
performance criteria.
You will find your new appliance easy and safe to operate,
and, with proper care, it will give you many years
of dependable service.
CAUTION. Carefully read through this entire Instruction
Manual before using your new 909 appliance. Take
special care to heed the Cautions and Warnings.
Your 909 appliance has many features that will make your
job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.
Environmental protection
Recycle unwanted materials instead
of disposing of them as waste. All tools,
hoses and packaging should be sorted,
taken to the local recycling centre and
disposed of in an environmentally safe way.

4
General safety warnings and instructions
Read all instructions
WARNING: Read all instructions before operating spotlight.
Failure to follow all instructions listed below may result in
electric shock, fire and/or serious injury.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
Safety guidelines / definitions
DANGER: Indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation
which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates
potentially hazardous situation which, if not avoided, may
result in property damage.
Risk of unsafe operation.
When using tools or equipment, basic safety precautions
should always be followed to reduce the risk of personal
injury. Improper operation, maintenance or modification
of tools or equipment could result in serious injury and
property damage. There are certain applications for
which tools and equipment are designed. Manufacturer
strongly recommends that this product NOT be modified
and/or used for any application other than for which it was
designed. Read and understand all warnings and operating
instructions before using any tool or equipment.
Important safety instruction
Instructions pertaining to a risk of fire, electric shock,
exposure to excessive uv radiation, or injury to persons
Lighted lamp is HOT.
WARNING: to reduce the risk of fire, electric shock,
exposure to excessive uv radiation, or injury to
persons:
• HID bulb gets HOT quickly! Only contact switch/plug
when turning on.
• Do not touch the HID bulb at any time.
• Do not touch hot lens or enclosure.
• Do not remain in light if skin feels warm.
• Do not operate the spotlight with a missing or damaged
lens or enclosure.
WARNING – when using electrical appliances, basic
precautions should always be followed, including the
following:
• To reduce the risk of injury, close supervision is
necessary when the spotlight is used near children.
• Use only attachments recommended or sold by the
manufacturer.
WARNING: to reduce the risk of electric shock:
• Do not put spotlight in water or other liquid. Do not place
or store appliance where it can fall or be pulled into a tub
or sink.
• Do not clean this appliance with a water spray or the like.
• Use only the charger supplied by the manufacturer to
recharge.
WARNING: Fire hazard: Never contact combustible
material to the lens and never tape or tie the switch in the
on position.

5
Additional safety instructions for the charger
• Before using the charger, read all the instructions and
cautionary markings on the charger and torch.
• Only charge your torch indoors as the charger is
designed for indoor use only.
• WARNING. Do not allow any liquid to come into contact
with the charger. There is a danger of electric shock.
• The charger is not intended for any use other than
charging the exact type of rechargeable torch as supplied
with the charger. Any other use may result in the risk of
fire, electric shock or electrocution.
• The charger and torch are specifically designed to work
together. Do not attempt to charge the torch with any
other charger than the one supplied.
• Do not place any object on top of the charger as it could
cause overheating. Do not place the charger near any
heat source.
• Do not pull on the lead of the charger to disconnect it
from the power source.
• Make sure that the charger cable is positioned where
it will not be stepped on, tripped over or otherwise
subjected to damage or stress.
• Do not use an extension cord unless it is absolutely
necessary. The use of an improper extension cord could
cause the risk of fire, electric shock or electrocution.
• Do not use the charger if it has been subjected to a
heavy knock, dropped or otherwise damaged in any way.
Take the charger to a power tool repair centre for a check
or repair.
• Do not disassemble the charger. Take it to power tool
repair centre when service or repair is required. Incorrect
re-assembly may result in the risk of fire, electric shock or
electrocution.
• The charger is designed for use from a standard
household electrical supply (230–240 volts). Do not
attempt to connect the charger to a supply with a
different supply.
CAUTION: To reduce the risk of injury or property
damage:
• For household use only.
• High intensity discharge bulbs give off heat:
– Do not touch lens while operating.
– Keep combustibles away from spotlight lens. Extreme
heat can cause fires.
– Never place the light face-down on any surface when lit.
• Never look directly into the light or shine the light into
another person’s eyes.
• Keep sharp objects away from lens — it is glass and can
break.
• Do not immerse spotlight in water.
• Do not expose this unit to extremely high temperatures.
• Do not drop or throw spotlight. It contains glass and a
sealed lead acid battery.
• Use only with AC or DC charging adapter provided with
unit. Plug in the charging adapter at the spotlight first,
then plug into the charging source.
• DO NOT OVERCHARGE: Charge up to 8 hours
maximum using the AC charging method; up to 5 hours
maximum using the DC charging method.
• Never attempt to use the ac charger and dc charging
port simultaneously.
• After charging/recharging, disconnect the charger and
wait 5 minutes before use.
• Do not crush, cut, pull or expose charging adapter cords
to extreme heat.
• Position charging adapter cords so they do not become
entangled or become a safety hazard. Keep charging
adapter cords away from sharp edges.
• Use in a dry location only.
• Do not open body casing. There are no user-serviceable
parts inside.

6
• To reduce risk of damage to electric plug and cord, pull
by plug rather than cord when disconnecting.
• Do not attempt to charge the unit if the charger is
damaged – return the charger to manufacturer for repair
or replacement.
Save these instructions

7
Know your product
1. Battery/charge status LED indicator
2. AC-to-DC charging port (for use with
240VAC plug pack charger)
3. 12 volt DC power and charging port
(for use with 12 volt DC adapter)
4. On/Off trigger
5. Trigger lock
6. 12V DC plug storage
(bottom of the handle)
7. Detachable 12V DC power and
charging cord and plug
8. 240V AC plug pack charger
3
5
4
1
2
6
78

8
Introduction
Congratulations on purchasing your new spotlight. Read
this Instruction Manual and follow the instructions carefully
before using your new spotlight.
Reading the battery/charge
status LED indicator
The battery/charge status LED indicator lights solid green
to indicate the battery is charged; solid red to indicate
the battery is operating at low voltage, and needs to be
recharged.
The battery/charge status LED indicator flashes red while
the unit is charging using the AC charging method. It will
light solid green when the unit is fully charged.
Charging/recharging the spotlight
Charging/recharging using the
240V AC plug pack charger
• Make sure the spotlight is off (the trigger lock is in the off
position and the trigger is not depressed).
• Insert the barrel connector of the 240V AC plug pack
charger into the AC-to-DC charging port on the back of
the unit. Insert the 240V ac Plug pack into a house hold
power outlet and turn on. The battery status LED flashes
red.
• Charge until the battery status LED lights green
(approximately 7 to 8 hours).
Charging/recharging using the 12 volt DC charger
IMPORTANT: The battery/charge status LED does not light
or flash when the unit is charging using the DC charging
method.
• Make sure the spotlight is off (the trigger lock is in the off
position and the trigger is not depressed).
• Plug the double pin tip of the supplied 12 volt DC charger
into the 12 volt DC power and charging port on the back
of the unit.
• Insert the 12 volt DC plug end into the accessory outlet of
your vehicle or other 12 volt DC power source.
• Charge for approximately 5 hours.
Note: When using a vehicle’s 12 volt DC accessory outlet
as a charging source, be aware that some vehicles require
you to turn on the ignition to power the accessory outlet.
WARNINGS:
• To avoid the risk of property damage, charge up to
8 hours maximum using the ac charging method; up to
5 hours maximum using the dc charging method.
• Never attempt to use the ac charger and dc charging
port simultaneously.
Operating instructions
Operating the spotlight
IMPORTANT: While most HID spotlights take several
minutes to achieve optimal brightness, this spotlight will light
dimmer for approximately 15 seconds, then brighten slightly
to the correct brightness level. It was designed this way to
function quickly; the slight dimming is not a malfunction.
1. Disconnect from charger.
2. The on/off trigger is located in the front of the handle of
the spotlight.
3. To turn the spotlight on, squeeze the trigger.
4. To turn off the spotlight, release the trigger.
Note: The on/off trigger can be locked in the on position
using the trigger lock switch on the side of the unit.
Operating the unit corded
Plug the double pin tip of the supplied 12 volt DC adapter
into the 12 volt DC power and charging port. Insert the 12
volt DC plug end into the accessory outlet of your vehicle or
other 12 volt DC power source. Operate the unit as outlined
in the previous section.
Note: When the 12 volt DC adapter is not in use, stores the
12 volt DC plug in the storage compartment located at the
bottom of handle.

9
Using the carry lanyard (optional accessory)
The carry lanyard may be used to carry the unit or to hang it
for storage. Always adjust the slide on the cords to keep the
lanyard secure around any supporting object.
CAUTION: To reduce the risk of product damage:
• When light is hung by the carry lanyard, do not shake the
spotlight or object that it is hanging from. Do not hang the
spotlight from any electrical wires or anything that it is not
secure.
• Only use the carry lanyard for hanging this spotlight. The
carry lanyard is not intended to support additional weight.
Do not attach or hang anything additional to the spotlight
or risk of breakage may occur.
Care and maintenance
All batteries lose energy from self-discharge over time and
more rapidly at higher temperatures. When the unit is not
in use, we recommend that the battery is charged at least
every 60 days.
Never submerge the unit in water. If the unit gets dirty,
gently clean the outer surfaces of the spotlight unit with
a soft cloth moistened with a mild solution of water and
detergent.
There are no user-replaceable parts. Periodically inspect
the condition of adapters, connectors and wires. Contact
manufacturer to replace any components that have become
worn or broken.
Battery replacement/disposal
Battery replacement
The battery should last the service life of the unit. Contact
manufacturer for any information you may need.
Safe battery disposal
Contains a maintenance-free, sealed, non-spillable, lead
acid battery, which must be disposed of properly. Recycling
is required, contact your local authority for information.
Failure to comply with local, state and federal regulations
can result in fines, or imprisonment.
WARNINGS:
• Do not dispose of the battery in fire as this may result in
an explosion.
• Before disposing of the battery, protect exposed terminals
with heavy-duty electrical tape to prevent shorting
(shorting can result in injury or fire).
• Do not expose battery to fire or intense heat as it may
explode.
12 volt DC charger plug fuse replacement
The fuse in the plug end of the 12 volt DC charger protects
the adapter’s charging circuit. If the 240V ac plug pack
charger operates, but the DC charging adapter does not,
then this fuse may be opened (blown).
To replace the fuse:
1. Unscrew the end cap of the DC plug (counterclockwise).
2. Remove spring centre contact and fuse.
3. Check fuse with a continuity checker.
4. If blown, locate a replacement 5 amp/250 volt fuse.
5. Replace the fuse, spring, contact and end cap.
6. Screw end cap clockwise until it is finger tight – DO NOT
OVER-TIGHTEN.
7. Test for proper operation of the 12 Volt DC Charging
Adapter.
Troubleshooting
The battery/charge status LED indicator does not flash
when charging
1. Check connection to the AC-to-DC charging port.
2. Check connection to AC power source.
3. Confirm there is a functioning AC current.
Note: The battery/charge status LED does not light or flash
when the unit is charging using the DC charging method.

10
Unit will not operate
1. The spotlight will not operate when charging using the AC
method. Be sure the AC charger is disconnected before
spotlight use.
2. The battery may be completely discharged. Charge the
unit following the directions in the charging recharging
section of this manual.
3. If the spotlight does not operate after recharging as
directed, contact manufacturer.
Accessories
Recommended accessories for use with your tool are
available from your local dealer or authorized service centre.
The use of any accessory not recommended for use with
this appliance could be hazardous.

11
