A.O. Smith BTF-80 Application guide

A.O. Smith Water Heater Parts Fulfillment
125 Southeast Parkway, Franklin, TN 37068
1-800-433-2545
www.hotwater.com
PRINTED0607 197446-001
COMMERCIAL WATER HEATERS
REPLACEMENT PARTS LIST
MODELS BTF-80 SERIES 200/201
CAST IRON BURNER ASSEMBLY
EPC BLOWER
6
STAMPED STEEL BURNER ASSEMBLY
3/4" T&P RELIEF VALVE
AUTOMATIC, SELF-CLOSING TYPES
13
PART PRESS A = TEMP
NUMBER RELIEF
23740-1 150 LBS. 1 7/8" 210°
A
WIRE HARNESS
15

1 .......... 1 ...... Pipe Nipple ........................................................ 9003743015 ................. 9003743015
2 .......... 2 ...... Stamped Steel Burner........................................9004727205 ........................- - - - -
2A......... 1 ...... Cast Iron Burner..................................................... - - - - - ........................ 9004412005
3 .......... 1 ...... Burner Tube (Stamped Burner) .........................9004023005 ....................... - - - - -
3A......... 1 ...... Burner Tube (Cast Iron Burner) ............................. - - - - - ........................ 9004580005
4 .......... 2 ...... Orifice (Stamped Steel Burner) ..........................9005724015 ....................... - - - - -
4A......... 1 ...... Orifice (Cast Iron Burner) ....................................... - - - - - ........................ 9004105015
5 .......... 1 ...... Ignitor/Flame Sensor (Stamped Steel Burner) ...9003626005 ....................... - - - - -
5A......... 1 ...... Ignitor/Flame Sensor (Cast iron Burner) ................ - - - - - ........................ 9003626005
5B......... 1 ...... Ignitor Bracket (Cast Iron Burner) .......................... - - - - - ........................ 9006000215
6 .......... 1 ...... EPC Blower ........................................................9004027005 ................... 9004027005
7 .......... 1 ...... Inlet Tube, Closed End ......................................9004314005 ................... 9004314005
8 .......... 1 ...... Flue Baffle Assembly .........................................9004031005 ................... 9004031005
9 .......... 1 ...... Anode Rod .........................................................9001830005 ................... 9001830005
10 ......... 1 ...... Inner Door ..........................................................9003735005 ................... 9003735005
11 ......... 1 ...... Outer Door .........................................................9004101005 ................... 9004101005
12 ......... 1 ...... Thermostat.........................................................9004049205 ................... 9004727205
13 ......... 1 ...... T & P Relief Valve ..............................................9003484005 ................... 9003484005
14 ......... 1 ...... Drain Valve ........................................................9001870015 ................... 9001870015
15 ......... 1 ...... Wire Harness .....................................................9005725015 ................... 9005725015
*16 .................. Manual ................................................................. 197440-0 ....................... 197440-0
17 ......... 1 ...... Flue Restrictor ...................................................9003524005 ................... 9003524005
18 ........ 1....... Vent Terminal, 3" ................................................ 9001957005 ................... 9001957005
18 ......... 1....... Vent Terminal, 3" Canadian Model...................... 9006338005 ................... 9006338005
19 ......... 1....... Wall Plate, 3" ..................................................... 9004364105 ................... 9004364105
* Not Illustrated
Item Qty. Description BTF-80 BTF-80
Natural Propane
