a2b Blake User manual

Manual for A2B Pedelecs/eBikes

2
Table of contents
1. use of your A2B
2. notes on road safety
3. adjustment of ergonomics and components
4. range - that's how you get ahead!
5. operation of the drive system
6. cleaning, care and maintenance
7. transport
8. warnings
9. torque specifications
10. technical data
11. battery disposal
12. maintenance schedule
13. vehicle registration
14. manufacturer data
15. warranty certificate and hotline
Validity:
These operating instructions are valid until revoked. Technical improvements of the product
can be incorporated at any time. No liability for typographical errors.
Models:
These operating instructions are valid for the following models at the time of printing:
A2B Blake, A2B Kroemer, A2B Ride Plus
Congratulations on the purchase of your new A2B Pedelecs! At A2B we have set ourselves the goal of redefining your daily
mobility and bringing you from A to B in style. With an A2B, you'll have more fun than with a car, avoid the frustrating
search for a parking space, save fuel costs and at the same time protect the environment. With A2B you can redefine your
paths. Whether you go to work, go shopping or just for fun with your A2B, you'll discover your world anew.
1. use of your A2B as directed
Equipped with a modern drive system, the A2B is a Pedelec (Pedal Electric Cycle) to the standard
Passenger transport of a person in public road transport. Adjustments and repairs to the A2B and its components
Components shall only be deemed to be intended use to the extent that they are declared and permitted in these operating
instructions, the instructions of the component manufacturers or other documents enclosed with the purchase of the
pedelecs. The manufacturer assumes no liability for negligently caused damage due to misuse, improper use, improper or
omitted maintenance or repairs. It is the responsibility of the driver to check the pedelec as prescribed, to have it repaired
and used responsibly. This instruction manual describes the use of your A2B, the components installed on it and
corresponds to the current state of the art when printing. The manufacturer reserves the right to make changes resulting
from the further development of the mechanics, the software or from legal requirements.
2. important information on road safety
This user manual contains important information on safety, performance and maintenance.

3
Please read it carefully before your first trip.
Your A2B should be properly assembled and charged before your first trip. In case of ambiguity or obvious
defects, please contact us immediately, otherwise your warranty will expire. Please make sure that all A2B users
read and understand the following important information.
According to the Road Traffic Licensing Regulations, a bicycle must be equipped with two independent,
functional brakes, a clearly audible bell, headlamp, taillight, pedal reflex reflector, side reflectors for wheels or
integrated light strips on the tyre as well as front and rear reflectors.
The A2B is suitable for driving on paved roads and pathways. Do not drive off the beaten track or off-road. A2B
mountain bikes can also be used off-road.
Do not use the A2B for water crossings, cross-country jumps or sporting events.
We recommend that you wear a certified bicycle helmet when using the A2B at all times and that you wear
bright or reflective clothing at night.
Make sure that you know and observe the rules of conduct for safe and responsible driving. When driving with
the A2B, there is always a risk of serious / fatal injury or damage to property caused by an accident. By deciding
to use the A2B, you assume full responsibility for this risk.
This user's manual does not guarantee the safe use of the A2B in all conditions.
3. components on the bike and adjustment features
3.1 Replacement of components, mounting of accessories
Before installing any components or accessories (including other tyres), check with your dealer to see if they are
suitable for your A2B. Read and follow the instructions for each component or accessory you have purchased
for your A2B. Follow the manufacturer's instructions for the components or accessories if they differ from these
instructions.
As with all mechanical components, your A2B is subject to a certain amount of wear and tear. Particularly at
higher loads, wear characteristics must be taken into account. If a component's service life is exceeded, this can
lead to an unexpected loss of function of the component, which can result in serious or even fatal injury.
For this reason, pay attention to wear and tear such as cracks, scratches and colour changes in highly stressed
areas on the frame, fork, wheels and handlebars, which indicate that the service life has been reached or
exceeded. Have worn components replaced immediately by your dealer.
Failure to test, install, use and maintain any components or accessories properly may result in serious or even
fatal injury.
Use of non-original components or spare parts may endanger the driving safety of your A2B and void the
warranty. Replacement of components or the attachment of accessories is at your own risk, as these parts may
possibly cause damage to the equipment. have not been tested by Hero Eco for suitability, reliability or safety
with your A2B.
3.2 Adjusting the brake levers
Can you operate the brake levers comfortably? If this is not the case, take your A2B to a dealer and ask them to
adjust the angle of the brake levers. Otherwise, you can adjust the angle of the brake levers yourself as follows:
Loosen the screw under the brake lever with a suitable Allen key.
Adjust the angle as required.
Tighten the screw again and make sure that the brake lever is securely fixed in position.
Before a short test drive, check that the brake levers are firmly seated and that they cannot be twisted. To
adjust the brakes yourself, you should take your A2B to a dealer.

4
3.4 Seat height adjustment - theory
The seat height must be adjusted correctly. Ask your dealer to do so before your first trip. Alternatively, you can
also adjust the seat height yourself as follows.
Determination of the correct seat height for the driver
There are several ways to determine the correct seat height, the following is a description of the method to be
used without any additional aids: Sit down in the saddle and stretch one leg. Place the foot with the heel on the
pedal, which is at the lowest point of the crank revolution. The knee should now be almost pushed through. If
you are sitting on the saddle in this position, it has the right height.
Of course, do not drive with your legs stretched. If you put your foot on the pedal in the correct driving position
(footballs with a toe base joint above the pedal axle), the knee remains slightly angled even at the lowest point
of the crank revolution with the saddle height set correctly. A short practice session is enough to find out if the
saddle is too high. If the pelvis tilts to the left and right at the rhythm of pedaling, the saddle is too high. If the
saddle is too low, you will notice this only after many kilometres, mostly due to knee pain.
How to adjust the seat height - Practice:
The seat height can be adjusted by loosening the quick-release or the Allen screw for the seat post.
Set the saddle to the desired height. DO NOT place the saddle ON ANY OCCASION higher than the minimum
insertion mark on the seat post.
mapping
Push the lever of the quick release lever towards the frame until it is closed again. The lever must not protrude
to prevent you from getting injured. The lever is securely secured when it requires a certain amount of force to
push it into the closed position. You can see the appropriate amount of force by the fact that the lever leaves an
impression on your palm when you squeeze it. A properly closed quick-release can no longer be moved, except
by re-opening it using the procedure described above. If you can move the mechanism easily, open the lever of
the quick-release, turn the locknut another 180º and try again. If the seat post should be clamped with a
hexagon socket screw (INBUS), tighten the screw with the specified tightening torque.
After adjusting the saddle height, check that the saddle cannot be turned in any direction.
A saddle that is not properly secured can cause serious or even fatal injuries. Make sure that the saddle fixation
bolt (saddle support - saddle) is tightened to the specified torque.
Carrier:
Your vehicle may have a luggage carrier.
The maximum load capacity is 10 kg, unless the carrier indicates a higher load capacity.
Make sure that the luggage is securely secured on the rack and cannot fall off while driving. Make sure that
loose straps or other objects cannot get caught in the spokes while driving.
Do not load the carrier.
The vehicle is not designed or approved for the transport of a second person or a child without a child seat.
The permissible total weight of your A2B must not be exceeded. The maximum permissible total weight is
specified in the specification.
Distribute the weight of the luggage or items to be transported evenly on both sides of the rack.
Note that luggage or other loads on the rack will change the driving behaviour of your A2B. This applies in
particular to the steering and braking characteristics.
Failure to observe these instructions may result in serious or even fatal injury and/or damage to property.
At the end of your first journey
If you have any questions or have the impression that your A2B is not yet optimally adjusted and tuned to you,
we recommend that you consult your dealer before continuing to use your A2B.

5
3.4 Your range
Factors affecting range:
support level
battery charge level
Use of the correct gears for the respective
applications
pace
tire pressure
Wheel bearings and both brakes (narrow bearings
or abrasive pads reduce the range)
Total weight (accelerating a heavier person or
high payload requires more energy)
Their speed and wind conditions (fast kicking in
strong headwinds reduces the range)
Terrain (driving on soft surfaces or uphill requires
more power)
Frequent starts and stops (full power from
standstill requires the most power from the
battery) To maximize your range:
Fully charge the battery before every ride.
Check the tyre pressure regularly and inflate the
tyres to a pressure as indicated on the tyre.
Have your A2B serviced regularly to ensure that
the wheel bearings rotate freely and that the
brake pads do not rub against the brake discs.
Keep the total weight as low as possible.
Drive at lower speeds.
Use the power save mode as often as possible
and support the motor by pedaling on your own.
Lubricate the chain and derailleur with a chain
spray recommended for bicycles.
5. operating instructions drive system
5.1.1 Important information - please observe!
Please observe all the documents enclosed with your A2B and all the instructions in this manual and on the
vehicle with stickers.
5.1.2 Intended use of the engine components
Equipped with an A2B by Bafang drive system, the A2B is a Pedelec (pedal electric cycle) for the normal
passenger transport of a person on public roads.
Adjustments and repairs to the A2B and its components shall only be considered as intended use to the extent
that they are explained and permitted in these operating instructions, the instructions of the component
manufacturers or other documents enclosed with the purchase of the pedelec. The manufacturer assumes no
liability for negligently caused damage due to misuse, improper use, improper or omitted maintenance or
repairs. It is the responsibility of the driver to check the pedelec as prescribed, to have it repaired and used
responsibly.
The following chapters of this manual describe the use of the components installed on your A2B only and
correspond to the state of the art in printing. The manufacturer reserves the right to make changes resulting
from the further development of the mechanics, the software or from legal requirements.
The manufacturer regards the following cases as abuses of the components used on your A2B:
Use of the drive system contrary to the instructions and recommendations in this operating manual
Exceeding of the technical performance limits defined in this operating manual

6
Technical changes to the engine components
Changes to the software of the drive components
Unauthorized mounting or use of the engine components on bicycles or other than the A2B Pedelec supplied to
you.
5.1.3 Permissible operating conditions / locations
A2B pedelecs can be operated at temperatures between -10°C and +45°C.
Observe the safety and hazard notes in the individual chapters of these operating instructions. whose
Limitations of the permissible operating conditions (e. g. maximum temperature, total weight) must also be
observed when using the pedelec! Observe the safety and hazard notes in the individual chapters of these
operating instructions.
5.1.4 Electrical drive components:
engine
operating panel
Indicator (display)
battery
charger and wiring
5.1.4.1 Instructions on display, menu, adjustments
by pressing the middle push-button (S2) the display shows this information in sequence:
-
Time
clock
-
ODO
total kilometres
-
AVG
Average speed
-
MAX
Maximum speed
-
Trip
Daily kilometres
If the push button (S2) is not pressed for approx. 5 seconds, the display returns to the start view.
-Press & hold the "+" (S3) and "-" (S4) keys simultaneously to access the first submenu level.
-tC Reset AVG, MAX Time & Trip (N/Y) parameters by selecting "Y".
-bli backlight ( 1-5 )
-57 unit selectionl ( km/h –mp/h )
-OFF automatic system shutdown after time without use (1-10 minutes)
-
By pressing and holding the "+" key (S3) the display backlighting can be switched on/off.

7
By pressing and holding the "-" button (S4) for more than 3 seconds, the pushing aid is activated. The pedelec
now moves forward at 3-5km/h as long as the push button is held down. This mode is not designed for mounted
operation.
5.1.4.2 Brief instructions Battery - Installation and removal, storage, charging built-in and removed
Quick Start Guide Battery:
Fully charge the battery before first use! In the as-delivered condition, the charge is approx. 30%.
Option A: Removing the battery in the frame:
The battery on the downpipe can be removed from the battery rail to the right of the vehicle. To do this, the
key must be inserted into the battery lock and turned? turn towards the front of the vehicle and held in place.
Now the top side of the battery can be tilted out sideways to the right by approx. 10 degrees from the battery
rail. As soon as the battery is in its final position, the battery can be pulled out of the base of the battery rail
along the tilting axis. Be sure to remove and transport the battery with both hands and a secure grip.
Option B: Removal of carrier battery:
Insert the key into the battery lock and turn? turn. Insert the battery towards the rear of the vehicle
Pull out the piece. The end of the battery is designed as a handle half-shell. Pull the battery out of the vehicle
with both hands parallel to the ground. Remove the key to avoid unintentional bending at a later time.
Variant A: Installation of frame battery:
To insert the battery, insert the two holding tabs on the underside of the housing into the battery compartment
provided.
Insert the guide pieces of the battery rail mounting base at an angle of approx. 10 degrees. This should be done
without noticeable
resistance is possible. Now tilt the battery to the left into the battery rail until it clicks into place. You do not
need a key to insert the battery. Make sure to check that the battery is seated in the holding rail before driving.
Option B: Installing the carrier battery: To insert the battery, hold the battery horizontally and locate the rails in
the carrier system. Slide the battery sensitively forward without resistance until it snaps into place. You do not
need a key to insert it. After engaging the battery, carefully pull it backwards to check that the battery is firmly
seated and does not slip backwards again.
Storage (A and B):
The battery and charger must be stored in a clean, dry and well-ventilated environment.
A proximity to corrosive materials, sources of heat and fireplaces must be absolutely excluded.
Storage at temperatures between -20° and +35° at a relative humidity of 5-65% RH is permitted.
For long-term storage, the following information applies:
Completely empty the battery and charge it for about 2-3 hours. The battery should be stored in a dry and well-
ventilated environment. During storage, the battery must be charged every two months for 2-3 hours.
The charger must not be connected to the battery or the mains power supply during storage - it is not a battery
refresher!
For transport, the battery should be packed in a cardboard box and protected from shocks, impacts and direct
sunlight. Avoid immersion of the battery in water!
This battery is approved for transportation by land, sea and air in accordance with the manufacturer's
specifications.
Charging:
The battery can be charged in the vehicle itself as well as when removed. When charging in the vehicle, the
vehicle system must be deactivated before charging!
On the side of the battery, the charging socket cover is located at the height of the battery level indicator
printed on the battery housing. This cover flap can be opened to the left. Underneath it is the actual charging

8
socket. Now connect the charging plug of the supplied charger to the charging socket of the battery. Then
connect the charger's mains plug to an earth contact socket. The LED on the charger will now turn red. As soon
as the charging process is completed, this LED switches to green. First disconnect the charger from the earth
contact socket and then disconnect the charging plug from the battery socket.
Check:
You can check the battery's charge status in two ways at any time:
a. On battery: Press the button next to the charging socket briefly: you will see several LEDs light up.
b. On the display: When the system is switched on, you will see the charge level indicator as a bar graph.
5 LED/bars indicate 80-100% charge
4 LED/bars indicate 60-80% charge
3 LED/bars indicate 40-60% charge
2 LED/bars indicate 20-40% charge
1 LED/bars represent less than 20% charge.
If none of the LEDs are lit, the battery must be charged immediately.
5.1.4.3 - Detailed instructions - Battery
Read and observe the following safety and warning notices before starting
the battery and before starting the charging process. Failure to comply
with the safety instructions and instructions may damage the product or
result in electric shock, fire and/or serious injury. The lithium-ion battery
contains chemical substances that may cause dangerous reactions if the
safety instructions listed here are disregarded. The manufacturer is not
liable for any damage caused by non-observance of these instructions.
5.1.4.3.1 Safety and Warnings for Using the Battery
The battery should be fully charged before first use.
The battery may only be operated at temperatures between -10 degrees and +45 degrees Celsius.
Do not expose the battery to heat (e. g. radiators) or fire. External heat exposure can cause the battery to
explode.
In the (unlikely) event of overheating or fire of the battery, it must not come into contact with water or other
liquids under any circumstances. The manufacturers recommend extinguishing with sand as the only expedient
extinguishing agent.
Your pedelec consumes energy every time you use it. Therefore, charge the battery after each use if possible.
The battery must only be used to power the BAFANG components. Any other use beyond this requires the
written permission of the manufacturer.
The battery must not be opened or dismantled. Improper opening or deliberate destruction of the battery may
cause serious injury. In addition, opening the battery will void the warranty.
Never connect the battery contacts in the socket to metallic objects or make sure that the contacts do not come
into contact with metallic objects (e. g. metal chips) under any circumstances.
If the charging socket is dirty, clean it with a clean and dry cloth.
Never immerse the battery in water. Do not expose the battery to temperatures below zero degrees Celsius.
The battery's service life depends on the storage location. Therefore, do not leave the battery (whether inserted
or removed from the pedelec) in a hot place for long periods of time. In particular, the boot of cars standing in
the sun should only be used for transport, but not generally as a place of storage.
The battery must not be exposed to mechanical shocks. For example, if the pedelec has been tilted over and the
battery is dropped directly on the floor, the battery must be checked by the manufacturer. Please contact your
specialist dealer for this purpose. A damaged battery must not be used again.
If the battery is damaged or defective, it must be checked. Please contact the service department and clarify
how to proceed. The faulty/damaged battery must not be used or opened under any circumstances.
Always ensure that the battery is kept clean and dry.

9
5.1.4.3.2 Safety and Warnings for Storage of the Battery
Protect the battery immediately after disconnecting the charger or motor. Neither moisture nor foreign
particles (e. g. metal splinters, small nails, chips or other conductive metals) may penetrate the battery.
Do not expose the battery to any moisture (water, rainwater, snow, etc.) during storage!
Store the battery in a cool, dry place where it is protected from damage and unauthorized access.
To achieve optimum battery life, the battery should be stored at a temperature of 10°C to 20°C and a humidity
of 0 to 80 percent. The charge level should be 70 percent.
5.1.4.3.2 Safety and warning notes on the charging process
Do not charge the battery in a ventilated, dry environment.
Never charge the battery in the presence or near flammable liquids or gases.
Do not expose the battery to any moisture (water, rainwater, snow) during charging.
Do not charge the battery in rooms where moisture may accumulate on the battery.
Use only the charger provided to charge the battery.
The use of an unsuitable charger may cause malfunctions and result in a reduced battery life. There is also a risk
of fire and explosion.
Once the charging process is complete, disconnect the charger from the mains socket first and then from the
battery.
Make sure there is sufficient air circulation when the battery is charged.
Always charge the battery only under supervision.
Damaged batteries must not be charged or used.
Damaged chargers (damage to plugs, housing, cables) must not be used
Never tear the power cord to disconnect the charger from the wall outlet.
Do not expose cables and plugs to pressure. Strong stretching or kinking of the cables, jamming of a cable into
the cable
Cable between a wall and a window frame, or placing heavy objects on a cable or plug could cause electric
shock or fire.
Install the power cord and the charger cable located on it in such a way that no one can step on it or trip over
it, or that both cables are not exposed to any other harmful influences or loads.
Do not operate the charger if the power cord, the charging cable, or the plugs on the cables are damaged.
Damaged parts must be replaced immediately by an authorized dealer. Do not use or disassemble the charger
if it has suffered a hard blow, been dropped or otherwise damaged. Take the damaged charger to an
authorized service center for repair.
The charger must not be used by small children. Zerlegen oder modifizieren Sie das Ladegerät nicht.
Do not cover the charger during charging and do not place any objects on the charger.
Never short-circuit the poles of the charging plug with metallic objects.
Make sure that the power plug is firmly plugged into the outlet.
Do not touch the plugs with wet hands.
Do not use the charger plug and/or the mains plug if they are wet or dirty. Clean the plugs with a dry cloth
before inserting them.
5.1.5.1 Rear engine - removal and installation
The drive wheel of your pedelec can be removed from the bicycle frame at any time, for example for cleaning
purposes or in case of a puncture. Proceed with utmost care in this respect and during the subsequent
assembly, paying particular attention to the instructions and information provided by the manufacturers of the
various components attached to the wheel, in particular the brake disc.
5.1.5.2 Removing the drive wheel
Before removing the drive wheel, make a note of the cable laying and the fixing points of the cable ties. First of
all, loosen and remove all cable ties that are used to attach the cable coming from the motor, as well as cables
and leads of other components to the bicycle frame. Then disconnect the plug on the motor cable from the
socket on the battery cable. Loosen the two nuts or quick-release with which the wheel is attached to the

10
frame, so that the complete wheel can be removed from the frame of your pedelec. If necessary, you may have
to disengage the brake. Never hold or transport the removed wheel on the cable coming from the motor! There
is a risk of cable breakage.
5.1.5.3 Attaching the drive wheel
Make sure that all components attached to the wheel are installed in accordance with the manufacturer's
instructions and specifications. This applies in particular to the brakes and gear shifting. Do not forget to
reassemble the torque arm/discs in the same position in which they were removed before. Then slide the wheel
into the frame's seat and tighten it with the axle nut in the following order:
First tighten on the side of the gear shift then apply the brake on the side of the brake
The tightening torque of the two nuts is between 30 and 40 Nm. Make sure that the washer is located under
the axle nut, otherwise there is a risk of loosening the axle nut.
If your wheels are equipped with quick-release clamps, please observe the manufacturer's instructions for
assembly and tightening torque.
If the wheel is correctly attached to the frame, the motor can be connected to the end of the cable leading to
the battery. Make sure that the plug is correctly aligned with the socket. Attach all cables and supply lines to the
bicycle frame with cable ties and carry out a final function test. Make sure that the cables are correctly routed,
as the cable could get caught in the brake disc, drive unit or spokes if they are incorrectly routed, which could
cause the wheel to lock and fall.
6. cleaning, care and maintenance
6.1 Maintenance
Have your A2B checked by a dealer at least once a year. Please refer to the section Maintenance schedule.
6.1.1.1 Wheels
The front and rear wheels should be centered in the fork and frame. Check the wheels regularly for correct
spoke tension and rim alignment. DO NOT use your A2B with damaged or missing spokes. The wheels should
run evenly and without fluttering vertically or vertically.
6.1.2 Hub bearings
Check the seat of the hub bearings regularly by lifting and rotating the wheel from the ground and by trying to
move the rim sideways between the fork or frame. There should be no lateral movement. If you notice a
movement in the lateral direction of a wheel, the hub bearings must be adjusted or replaced.
6.1.3 Rims
The rims should not show any cracks, dents or flat spots. If necessary, take your A2B to a dealer for repair
and/or adjustment of the wheels.
6.1.4 Drive chain
Your A2B has a high-quality chain. This must be cleaned regularly and lubricated with a synthetic lubricant
specially recommended for bicycles.
6.1.1 Brakes
Check the brake cables for signs of wear and abrasion. Tighten the brake lever firmly and check that the brakes
function properly. Make sure that the rotors are free of residues and oil. Never wait until the brake linings are
completely worn. Replace the brake pads if necessary. If your brake pads look worn out or the brakes do not
respond as well as usual, ask a specialist dealer to check and replace them. Brakes are less effective in wet
conditions.

11
Driving in wet conditions: You should always remember that your A2B has a longer braking distance. Slow
down, keep a longer distance between yourself and other road users and slow down sooner than usual.
Failure to observe these safety precautions could result in accidents with serious or even fatal injuries and/or
damage to property. If you have any questions about using the brakes, please contact your dealer. Brake discs
and brake linings must be free of oil and grease.
6.1.2 Tyres
Check the tyres for damage, cracks and unusual or severe wear and tear. The tyre should sit correctly in the rim.
Check the tyre bead regularly to ensure that it is seated in the rim. Check that the tread pattern is free of
foreign bodies and that the valve protrudes straight out of the rim.
Damaged or worn tyres should be replaced immediately. Take your A2B to a dealer or qualified bicycle
mechanic to have the tyres replaced if necessary.
In the unlikely event of a puncture, you should be familiar with the correct procedure for removing and
replacing the front and rear wheels.
6.2.1 Cleaning the display
Do not use any cleaning agents such as benzene, thinner, acetone or similar agents for all cleaning processes.
Do not use abrasive or aggressive cleaning agents. Instead, use only commercially available household cleaning
and disinfecting agents (isopropanol) instead.
6.2.2 Cleaning the engine
The motor of your pedelec should be cleaned regularly from dirt, preferably with a dry brush or a damp (not
wet) cloth. Cleaning must not be carried out with running water such as a water hose or even a high-pressure
cleaner. However, driving in the rain and on wet roads is no problem.
Penetrating water can destroy the engine. When cleaning, always ensure that neither liquids nor moisture
penetrate into the motor.
Do not clean the engine while it is warm, e. g. immediately after a trip. Wait until he's cooled down. Otherwise,
damage may occur.
If the motor is removed, e. g. for cleaning purposes, it must never be attached to the cables or transported,
otherwise there is a risk of cable breakage.
If the motor has been removed from the frame of the pedelec, the plug of the motor and the socket of the
cable to the battery pack must be checked or cleaned for possible contamination before assembling.
7 Transport
When transporting the pedelec with a car, the following instructions must be observed:
Protect all components of your pedelec from wetness and dirt by taking appropriate measures.
Remove the battery before attaching the pedelec to the wheel carrier of your car. This also reduces the weight,
which you have to lift especially with a roof rack system.
Always transport the battery in the boot of your car.
The battery should also be removed when transporting indoors (e. g. in a station wagon) to prevent damage
during loading and driving.
For carrier systems with downpipe clamping, ensure that the battery mounting rail is not crushed/damaged
when the clamping device is tightened.
Make sure that the cable ends cannot cause damage to the pedelec or your car while driving.
After driving, check all pedelec contacts for possible foreign bodies or wetness. In order to ensure safe
functioning, all plug connections in particular must be free of dirt and foreign bodies and completely dry.
Never place your pedelec on the side of the gear shift during transport, for example in the boot of a car. This
could damage it.

12
8 Warnings
If not in use, do not expose your pedelec to strong sunlight. As a result,
the engine heats up and in extreme cases the full power cannot be delivered. Plastic parts also age more quickly
under intensive sunlight.
If there is a system standstill due to increased temperatures (e. g. caused by uninterrupted driving or
permanent direct sunlight), allow the engine to cool down for about 10 minutes before continuing your journey.
9 Torque specifications
Nuts front wheel
30 Nm
Screws M6
9-10 Nm
Nuts back wheel
40 Nm
Screws M7
11-12 Nm
Crank fixing screw
30 Nm
Screws M8
14-15 Nm
Brake show mounting
6-8 Nm
Screws M10
34 Nm
Pedals
30 Nm, left Pedal –left side
thread!
Candle type seat post
(13mm tool)
15 Nm
Screws M4
2-3 Nm
Patent type seat post
20 Nm
Screws M5
5-6 Nm
Use a torque measuring tool to tighten to the right torque!
Vehicle specifications:
Vehicle class: Pedelec - rated continuous power 250 Watt - motor support up to 25 km/h depending
on the power stage Operating voltage of the drive system: 36 Volt - maximum discharge current 20
Ampere
Battery voltage: nominal 36 volts, capacity according to vehicle equipment Operating voltage
charger: 220 volts, charging current 2 amps
Maximum weight of driver plus vehicle plus luggage: 120kg (weight of vehicle between 18kg and
24kg) Vehicle tested according to the valid legal standards, CE declaration of the manufacturer
WEEE Manufacturer registration for the placing of batteries on the market and return in accordance
with the Battery Act: DE21196107
10 Obligatory information on battery disposal:
Take-back of used batteries - In connection with batteries and rechargeable batteries as well as
devices operated with batteries or rechargeable batteries, we as the manufacturer are obliged, in
accordance with the Battery Act, to inform you of the regulations and obligations in this regard:
used batteries must not be disposed of in household waste. Consumers are legally obliged to bring
batteries to a suitable collection point at the municipality or the trade. The delivery is free of charge
for you. You can also return your used batteries to us. The
Return to us must be sufficiently franked. Old batteries may contain harmful substances or heavy
metals that can damage the environment or health. In addition, batteries contain valuable raw
materials,
that can be recycled. You can also read this information again in the accompanying documents of
your consignment or in the operating instructions of the respective manufacturer. Further
information on the Battery Act can be found on the website of the Federal Ministry for the
Environment.
11 Maintenance schedule
Your A2B pedelec should be serviced at regular intervals. At least once a year or every 2500 km the

13
most important points should be checked and wear parts replaced. We recommend using the
following maintenance plan. Not regular maintenance can void the warranty on components. We
also recommend an initial inspection.

14

15

16

17

18

19
15 Manufacturer Data
Hero Eco Ltd
Unit 16 Bessemer Industrial Park
250 Milkwood Road London
SE24 0HG
www.wearea2b.com
Versionsstand: A2B_2017_GW_01_ENG

20
www.wearea2b.com
