A4Tech PowerSaver R7 RKS-6&R7-70MD User manual

PowerSaver R7
Wireless Desktop
User’s Guide
Model: RK（S）-6&R7-70MD，RK（S）-6&R7-70D，RK（S）-8&R7-70D
www.a4tech.com

PowerSaver R7 Wireless Optical Mouse
- 1 -
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1)
THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPTANY INTERFERENCE RECEIVED,
INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Federal Communications Commission Requirements
The equipment has been testedand found to comply with the limits for Class B DigitalDevice, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in aresidential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction, may cause harmful interference to
radio communication. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio ortelevision reception, which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
zReorient of relocate the receiving antenna.
zIncrease the separation between the equipment and receiver.
zConnect the equipment into anoutlet on a circuit different from that towhich the receiver is connected.
zConsult the dealer or an experienced radio/TV technician for help.
The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.

PowerSaver R7 Wireless Optical Mouse
- 2 -
INTRODUCTION
Congratulations on your purchase!
Congratulations on your purchase!
PowerSaver R7 Wireless Desktop is the optimal high science products for power & desktop space saving. Its
innovative lightweight, mini & thin wireless keyboard design gives you a consistent desktop look as well as an
amazingly high level of comfort. your new RF-Mouse is designed with R7 Extremely Low-Power Technology only
requires 8mA electric current while others require 25mA. Wow! Just turn your mouse battery –life 3 times longer.
Same time, PowerSave R7 performs high-speed RF technology with report rate of 125Hz [**Normal wireless optical
mice performs with reports rate of only 90Hz (Tested by Mouse Rate Program)]
zPackage contains：
PowerSaver R7 Wireless Keyboard
PowerSaver R7 Wireless Optical Mouse
USB RF Receiver
USB Extension Cable
4 AAAAlkaline Batteries
User’s Quick Guide
CD Driver

PowerSaver R7 Wireless Optical Mouse
- 3 -
zSystem Requirements:
To use the mouse presenter, your computer must meet the following hardware requirements and run one of the
operating system listed below.
Hardware
1. IBM or compatible system
2. UBS v1.1 or higher interface
3. Hard Disk Driver
4. USB Port
Operating System
Windows®98/Me/2000/2003/XP/x64
zThis user’s guide describes how to：
1. Connect the receiver to your computer
2. Set up the wireless link and use the mouse
3 .Install software driver

PowerSaver R7 Wireless Optical Mouse
- 4 -
Inserting the Batteries
zInstall 2 AAA alkaline（or rechargeable batteries）in the
wireless keyboard.
1. Remove the battery compartments cover on the bottom of the
keyboard by squeezing the cover in front the tab to release it.
2. Insert the batteries; make sure to properly orient the positive (+)
and the negative (-) ends as specified by the battery compartment
labels.
3. Replace the cover.
zInstall 2 AAA alkaline（or rechargeable batteries）in the wireless mouse.
1. Press the tab on the bottom of the mouse cover as shown here and remove the cover.
2. Insert the supplied batteries, making sure that the positive (+) and negative (-) ends of the battery match the
polarity indicators inside the battery housing.
3. Slide the batter cover back into position until it “clicks” firmly into place.

PowerSaver R7 Wireless Optical Mouse
- 5 -
Step1 Step2 Step3
To connect the receiver
Insert the Receiver USB port connector into the available computer USB port. You can choose anyway to
connect the USB receive with computer as blow:
For PC computer usage:
1. Insert the USB receive mouse port connector into the USB port on the
USB extend cable (accessories),

PowerSaver R7 Wireless Optical Mouse
- 6 -
2. Insert the USB receives mouse port connector into the USB HUB port.
Locating the USB RF-Mouse Receiver
Your RF-Mouse has limitations on the range or distance from its receiver. To make sure that your mouse sends and
receives properly, refer to the following instructions:
1. For optimal performance, place the receiver at least 8 inches
(20 centimeters) away from other electrical devices, such as
the computer, the monitor, or external storage drives.
2. The RF-Mouse should be no farther than 4 feet (1. 5meter)
from the mouse receiver. This will ensure optimal
communication between the mouse and receiver.
Keep 8 inches
Kee
p
4 feet

PowerSaver R7 Wireless Optical Mouse
- 7 -
Operating Hints: For optimal performance and RF reception:
1. Avoid suing the mouse on a metal surface, Metals, such as iron, aluminum or copper, shield the radio frequency
transmission and may slow down the mouse’s response time or cause the mouse presenter to fail temporarily.
2. The mouse will enter a suspend mode at the same time your computer dose, click a button on the mouse
presenter to activate it.
3. Never use the mouse on a glass or mirrored surface as these surface will the mouse to fail temporarily
Establish Frequency Channel and ID Code
Step one: how Connecting the Wireless Keyboard ID Code?
1. USB RF Mouse Receiver: lanuch frequency channel
and ID code to RF-keyboard
Press and release the connect button on the front of USB receiver
(shown as right image), the GREEN PWR LED light turns “Off” and
starts “Blinking.

PowerSaver R7 Wireless Optical Mouse
- 8 -
2. Wireless Keyboard : Respond frequency channel
and ID code from Receiver
zPress and release (1 second) the (Frequency Button) orange
connect button on the bottom of keyboard
zThe RED PWR LED light of USB RF Receiver turns “Off” and
starts “Blinking with right frequency channel and ID code.
zIf the GREENPWR LED light of USB RF Receiver is black out, it
indicates that the right frequency channels and ID codes are
launched successfully between the receiver and the keyboard,
Step two: how to Connecting the Wireless Mouse ID Code?
1. USB RF Mouse Receiver: lanuch frequency channel
and ID code to RF-Mouse
Press and release the connect button on the front of USB receiver
(shown as right image), the GREEN PWR LED light turns “Off” and
starts “Blinking.
Frequency Button

PowerSaver R7 Wireless Optical Mouse
- 9 -
Wireless optical mouse : Respond frequency channel
and ID code from Receiver
zPress and release (1 second) the orange connect button on
the bottom of mouse,
zThe RED PWR LED light of USB RF Receiver turns “Off” and
starts “Blinking with right frequency channel and ID code .
zWhen the mouse is inactive, If the GREENPWR LED light of
USB RF Receiver is black out, it indicates that the right
frequency channels and ID codes are launched successfully
between the receiver and the mouse, otherwise, repeat the
procedures of the right frequency channel and ID codes. You
are now ready to use the mouse.
Note：The connect button has two functions. One function is correspond frequency with USB receiver. Other
function is power switch. you can control power on-off through it (please operate as “Power Management”
show )
1. Frequency Button
2. Power on/off
