Aaeon AGD-310D User manual

LCD Display AGD-310D
AGD-310D
10.4” SVGA Rugged
Touch Display
On Screen Display Control
IP-65 Front Bezel
5-wire Resistive Touch Screen
AGD-310D Manual 1st Ed
August 2011

LCD Display AGD-310D
i
Copyright Notice
This document is copyrighted, 2011. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in this
manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, nor for
any infringements upon the rights of third parties, which may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON, assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.

LCD Display AGD-310D
ii
Acknowledgments
Intel®is registered trademarks of Intel®Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft®Windows is a registered trademark of Microsoft®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
SiS is a trademark of Silicon Integrated Systems Corp.
VIA is a trademark of VIATechnology, Inc.
All other product names or trademarks are properties of their
respective owners.

LCD Display AGD-310D
iii
Packing List
The LCD monitor comes with the following standard parts shown as
below. Check and make sure they are included and in good condition.
If anything is missing or damaged, contact the dealer immediately.
1 AGD-310D
1 Utility CD-ROM
Contains User’s Manual (in PDF format), Drivers and
Utilities
1 VGA Cable
1 USB Cable
1 RS-232 Cable
1 DC Adapter
If any of these items are missing or damaged, you should contact your
distributor or sales representative immediately.

LCD Display AGD-310D
iv
Safety & Warranty
1. Read these safety instructions carefully.
2. Keep this user's manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Do
not use liquid or spray detergents for cleaning. Use a damp cloth.
4. For pluggable equipment, the power outlet must be installed near
the equipment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation.
Dropping it or letting it fall could cause damage.
7. The openings on the enclosure are for air convection. Protect the
equipment from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not
place anything over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient over-voltage.
12. Never pour any liquid into an opening. This could cause fire or
electrical shock.
13. Never open the equipment. For safety reasons, only qualified
service personnel should open the equipment.

LCD Display AGD-310D
v
14. If any of the following situations arises, get the equipment
checked by service personnel:
a. The power cord or plug is damaged.
b. Liquid has penetrated into the equipment.
c. The equipment has been exposed to moisture.
d. The equipment does not work well, or you cannot get it to
work according to the users manual.
e. The equipment has been dropped and damaged.
f. The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS
BELOW -10° C (14°F) OR ABOVE 55°C (131° F). IT MAY
DAMAGE THE EQUIPMENT.
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause
harmful interference, and (2) this device
must accept any interference received
including interference that may cause
undesired operation.
Caution:
It may cause the danger of explosion if battery is incorrectly
replaced. Replace only with same or equivalent type
recommended by the manufacturer.

LCD Display AGD-310D
vi
Below Table for China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Display
有毒有害物质或元素
部件名称 铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件 ×○○○○○
外部信号
连接器及线材 ×○○○○○
外壳 ×○○○○○
液晶模块 ×○○○○○
触控模块 ×○○○○○
电源 ×○○○○○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006 标准规定的限量要求以下。
X：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006 标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质触控模块为选购品。

LCD Display AGD-310D
vii
Contents
Chapter 1 General Information
1.1 Introduction................................................................1-2
1.2 Features....................................................................1-3
1.3 General Specification................................................1-4
1.4 Dimension .................................................................1-6
Chapter 2 Hardware Installation
2.1 Before Unpacking......................................................2-2
2.2 Connecting Power.....................................................2-3
2.3 Connecting to the Computer.....................................2-4
2.4 VGA Port Connector..................................................2-5
2.5 DVI Port Connector...................................................2-6
2.6 Serial Port Connector For Touch Screen..................2-7
2.7 Mini USB Connector For Touch Screen....................2-8
2.8 Panel Mounting .........................................................2-9
2.9 VESA Wall Mounting.................................................2-10
Chapter 3 On Screen Display Control
3.1 On Screen Display (OSD) Board Description...........3-2
3.2 OSD Main Menu: Push The MENU Keys..................3-3
3.3 Select Input Source...................................................3-4
3.4 Contrast/ Brightness- Submenu................................3-5
3.5 Geometry Menu.........................................................3-6

LCD Display AGD-310D
viii
3.6 Color Temperature- Submenu OSD Main Menu: Push
The MENU Keys..............................................................3-7
3.7 RGB Color- Submenu. ..............................................3-8
3.8 Language- Submenu.................................................3-9
3.9 Auto Config- Submenu..............................................3-10
3.10 Mode Resolution- Submenu Chapter......................3-11
3.11 Exit Menu- Submenu...............................................3-12
Chapter 4 Touch Screen Driver Installation
4.1 Introduction................................................................4-2
4.2 Resistive Touchscreen Driver Installation.................4-5
4.3 Installing Driver for Windows® XP/ Windows® 7 / Linux
.........................................................................................4-7

LCD Display AGD-310D
Chapter 1 General Information 1-1
General
Chapter
1
Information

LCD Display AGD-310D
Chapter 1 General Information 1-2
1.1 Introduction
Thank you for purchasing of the Industry Display Panel TFT LCD
monitor - a marvelous contribution of cutting edge technology.
The LCD monitor has been designed with serious thoughts to
present the best performance for most applications. Symbol of
elegance, its compact and slim profile is well suited in working
locations where space is at a premium.
The TFT LCD monitor displays sharper, more brilliant, crisper and
flicker-free images. Complying with the power management
regulations of VESA DPMS, the LCD monitor is extremely energy
efficient and a power saver. Plus, the LCD monitor has extremely
low radiation emissions and near zero electromagnetic fields which
are supreme benefits.
Fully compatible with PC system, the LCD monitor provides full
interface for all sorts of related standards. Supported by “Plug &
Play” complying with DDC1/DDC2B, installing the LCD monitor is
absolutely trouble free.
The On Screen Display menu provides user a convenient interface
to make right adjustment for optimum display performance.

LCD Display AGD-310D
Chapter 1 General Information 1-3
1.2 Features
10.4” SVGA (800 x 600) TFT LCD Display
Wide Temperature Operation (-10°C ~ 55°C)
Rugged IP-65 Aluminum Die Cast Front Bezel
Reliable On Screen Display (OSD) button
Wide Power Input Range: 9-30V DC
Panel/ VESA/ Wallmount: VESA 75 standard

LCD Display AGD-310D
Chapter 1 General Information 1-4
1.3 General Specification
Type Color TFT
Size 10.4" TFT LCD
Construction IP-65 Aluminum Die Cast Front Bezel
Mounting Panel/ VESA/ Wallmount
Input signal VGA, DVI
Control OSD (On Screen Display) on the rear panel
Power Supply External power adapter
Dimension AGD-310D
12.17” (W) x 8.5”(H) x 1.93”(D) (309mm x
216mm x 49mm)
Cutout Size
9.09”(W) x 7.8”(H) (231mm x 198mm)
Gross Weight 8.58 lb (3.9 Kg)
Net Weight 5.06 lb (2.3 Kg)
Power
Consumption
AC Input: 100-240V AC, 1.5A , 50-60Hz
DC Output: 12V DC, 5A (60W Max.)
Brightness 400 cd/m2(TYP.)
MTBF 50,000 hrs
Contrast Ratio 1000:1
Viewing Angle 170°(H)/160°(V)
Resolution 800 x 600
Display Modes Full Screen in 640x480 , 800x600 Modes
Color 262K

LCD Display AGD-310D
Chapter 1 General Information 1-5
Touchscreen
Type 5-wire resistive
Resolution 2048 x 2048
Light
Transmission
88 ±2% (Pure)
Controller USB interface
Environmental
Operating
Temperature
14°F~ 131°F (-10°C to 55°C)
Vibration 1g rms/5-500Hz/random operation
Shock 20 G peak acceleration (11 msec. duration)
EMC CE/FCC Class A

LCD Display AGD-310D
Chapter 1 General Information 1-6
1.4 Dimension
AGD- 310D
CUT OUT:231*198mm
Untis:m m
309.00
216.00
49.00
10.40 76.20
205.60
6.00
288.20
75.00
75.00
195.20
VESA 75

LCD Display AGD-310D
Chapter2HardwareInstallation2-1
H
ardware
Chapter
2
Installation

LCD Display AGD-310D
Chapter 2 Hardware Installation 2-2
2.1 Before Unpacking
It is very important to place the LCD Display in a suitable
environment.
The surface for placing the LCD Display should be
stable and level.
Make sure the place has good ventilation, and out of
direct sunlight; away form sources of excessive dust,
dirt, heat, water, moisture and vibration.
Convenience for connecting the LCD Display the
related facilities should be well considered too.

LCD Display AGD-310D
Chapter2HardwareInstallation2-3
2.2 Connecting Power
To power up the LCD Display, use the provided AC-DC adapter and
the power cord to connect to the power output socket of the monitor.
Fasten the connector securely.
A “Surge Protection” device plugged between the AC-DC adapter
and the wall outlet is recommended to prevent the effects of sudden
current variations from reaching the LCD Display. The sudden
peaks of electricity may harm the LCD Display.

LCD Display AGD-310D
Chapter 2 Hardware Installation 2-4
2.3 Connecting to the Computer
Turn off the computer and the LCD Display before connecting.
Use the Monitor-to-PC VGA、DVI cable to connect the LCD
Display to your computer. The cable heads are the same on
either side.
Fasten the connectors securely.

LCD Display AGD-310D
Chapter2HardwareInstallation2-5
2.4 VGA Port Connector
This DB-15 connector can be connected to the system via the
external 15-pin DB-15 connector through the I/O from this unit.
Pin Signal Pin Signal
1 Red 2 Green
3 Blue 4 N.C.
5 GND 6 GND
7 GND 8 GND
9 N.C. 10 GND
11 N.C. 12 SDA
13 HSYNC 14 VSYNC
15 SCL
