AAG Linx Argo 40/15 User manual

www.australianawning.group
1300 791 010
[email protected] linxautomation.com.au
Linx®Argo 40/15
Motor Instructions
1. Setup
► Remove remote from box.
► Remove battery cover plate on rear and remove battery to access and remove plastic battery isolating tab.
► Re-insert battery.
*Linx remotes should be kept out of reach of children at all times.
2. Set the number of Channels (for 15 channel remote)
2. Set the number of Channels (for 15 channel remote)
► Hold LEFT and RIGHT buttons simultaneously for 2 seconds.
► LCD should display C rst, then 15 after about 3 seconds.
► Use LEFT or RIGHT to change the number of required channels.
► Press and hold STOP button for 3 seconds, “O” will appear, the new settings are saved.
(This hides the unused channels, which can be shown again by repeating the above steps)
UP Button
STOP Button
DOWN Button
LEFT Arrow
RIGHT Arrow
3.Pairing Remote to Motor
►Select the desired Channel on remote (15 Channel Remote Only).
►Press and hold the button on the motor head for about 2 seconds
until the motor jogs and gives 1 long beep.
►Hold the STOP button on remote for 5 seconds (motor double
jiggles in response).
ONLY WORKS WITHIN 7 SECONDS OF POWERING THE MOTOR.
4. Check Motor Direction
► WARNING: MAKE SURE DIRECTION IS CORRECT BEFORE SETTING LIMITS.
UP should roll the blind fabric onto the roller.
► To change direction, hold the UP and DOWN buttons simultaneously for about 2 seconds.
► Motor jogs to conrm direction changed.
5. Setting Limits
First decide if you wish to set the inner limit manually or automatically. Manually setting the inner limits is the default setting.
If you wish to set your own inner limit, move onto steps 5a and 5b.
If you wish to set the inner limit automatically (ONLY ON FULL CASSETTE AWNINGS) use steps 5c and 5d.
5a SET INNER LIMIT MANUALLY
► Move to the inner limit position (blind will move in Step Mode).
► (Hold the button down for 3 seconds for Continuous Run Mode). BE CAREFUL AS LIMITS AREN’T SET YET.
► Hold UP and STOP buttons simultaneously for 3 seconds to set limit. (2 jogs + 3 beeps).
5b SET OUTER LIMIT MANUALLY
► Move to the outer limit position (blind will move in Step Mode).
► (Hold the button down for 3 seconds for Continuous Run Mode). BE CAREFUL AS LIMITS AREN’T SET YET.
► Hold DOWN and STOP buttons simultaneously for 3 seconds to set limit. (2 jogs + 3 beeps).

www.australianawning.group
1300 791 010
[email protected] linxautomation.com.au
Linx®Argo 40/15
Motor Instructions
5d SET THE REBOUNDING FUNCTIONS (only if you have used 5c to set the limits)
►OUTER REBOUND - in this mode the motor will rebound about 10cm at the outer limit to tension the fabric.
To turn this function Off or ON again, press P2, then STOP, then DOWN (off is indicated by 1 jog and a long beep)
or (on is indicated by 2 jogs and 3 beeps).
►INNER TENSION RELEASE - in this mode the motor will pull the cassette closed rmly, then give a slight tension release
of a few millimetres. If you do not want the tension released, Press P2 then STOP, then UP (Motor will jog once and beep once).
To reinstate the tensioning, repeat this command (Motor will jog twice and beep 3 times).
6. Adjusting Limits
►First delete all the limits as per step 10.
►Return to step 5 to set your limits via your preferred method.
7. Favourite position
► To set a favourite position, rst ensure the main limits are set.
► Move the awning to the position you want to set as favourite
► Press P2 (1 jog 1 beep), STOP (1 jog 1 beep), STOP (2 jogs and 3 beeps). The favourite position is set.
► Repeat this process to remove the favourite position.
► To access the favourite position, hold down STOP for 2 seconds until the awning moves.
8. Pairing/Unpairing Additional Remote
► On programmed remote press P2 (motor 1 jog + 1 beep) then P2 (motor 1 jog + 1 beep) then P2 on the second remote
you want to add or delete (2 jogs + 3 beeps)
9. Remove all the Remotes
► P2 (1 jog + 1 beep) then STOP (1 jog + 1 beep) then P2 (2 jogs + 3 beeps).
10.Delete all the Limits
► P2 (1 jog + 1 beep) then DOWN (1 jog + 1 beep) then P2 (2 jogs + 3 beeps).
11. Factory Reset Motor
►The P1 button is clear button on the motor head.
►Hold the P1 button until the motor cycles through 4 x down/up jogs (14 sec), then release P1 button, motor beeps 4 times
to conrm RESET.
5c SET THE INNER LIMIT AUTOMATICALLY (Full cassette awnings only)
►First set the motor to ‘Auto inner limit mode” Press P2, then UP then UP.
Motor will jog twice and beep 3 times.
►If the motor makes 1 jog and a long beep, repeat the step above.
►Move to the outer limit position (blind will move in Step Mode).
►(Hold the button down for 3 seconds for Continuous Run Mode).
BE CAREFUL AS LIMITS AREN’T SET YET.
►Hold DOWN and STOP buttons simultaneously for 3 seconds to set outer limit.
(2 jogs + 3 beeps).
►Now hold the UP button until the awning starts to run continuously in.
(The motor will close the cassette and stop)
P2

www.australianawning.group
1300 791 010
[email protected] linxautomation.com.au
Enabling and disabling remote control
►To disable the remote response of the motor, press the P1 button on the motor head for 6 seconds (motor will jog at 2
seconds, then jog and beep twice at 6 seconds) Motor will not respond to the remote.
►To re-enable the remote response of the motor, press the P1 button on the motor head for 2 seconds until the motor jogs.
The motor will now respond to its remote again.
Locking the limits on the remote control
To render the remote unable to alter limits perform the following:
On a single channel remote
To lock the remote
Step 1 - Remove the battery cover.
Step 2 - Press the STOP button on the front for around 15 seconds until the lights come on solid. Step 3 – Press the “P2” button
on the back. If you get 2 slow ashes, the remote is now locked.
To unlock the remote, perform the same task again, and if the lights ash 8 times quickly, then the remote is unlocked.
On a Multi-channel remote
To lock the remote
Step 1 – Remove the battery cover.
Step 2 - Press the STOP button on the front for around 15 seconds until an “L” appears in the screen. The “L” indicates it is
asking you if you wish to lock the remote.
Step 3 – Within a few seconds press the “P2” on the back to conrm the lock. An “O” will appear in the screen to conrm
the lock.
To unlock the remote
Step 1 - Press the STOP button on the front for around 15 seconds until a “U” appears in the screen. The “U” indicates it is
asking you if you wish to unlock the remote.
Step 2 - Within a few seconds press the “P2” on the back to conrm the unlock. An “O” will appear in the screen to conrm
the unlock.
Linx®Argo 40/15
Motor Instructions

www.australianawning.group
1300 791 010
[email protected] linxautomation.com.au
WARNING CONTAINS HAZARDOUS BATTERY
KEEP OUT OF REACH OF CHILDREN
New or used batteries can cause severe or
fatal injuries in 2 hours or less if swallowed
or placed inside any part of the body.
Seek Medical attention immediately if you
suspect the battery has been swallowed or
placed inside any part of the body.
Button Battery Label Warning.indd 1Button Battery Label Warning.indd 1 6/06/2022 1:57:34 PM6/06/2022 1:57:34 PM
Linx®Argo 40/15
Motor Instructions
RATED TORQUE 40 Nm
SPEED 15 RPM
NOMINAL CONSUMPTION 228 W
OPERATING VOLTAGE 230V AC 50Hz
NOMINAL CURRENT 0.99 A
MAXIMUM RUN TIME (thermal overload) 4 Mins
PROTECTION INDEX IP44
LENGTH 680 mm
TUBE DIAMETER 45 mm
RADIO FREQUENCY 433.92 MHz
Linx® Argo 40/15 Motor Specications
03/23
FOR MOTORS FITTED WITH MOLEX IN LINE CONNECTOR PLUG.
While fully compliant to Australian standards, Linx motors and their connections are not waterproof and
must be protected from the elements, especially water. For safe installation, all the following points must
be observed:
DIY
►The electrical connections must be performed by a licensed electrician.
►Any in-line molex connector must be covered and sealed with the supplied heat-shrink.
►The motor and molex connection must be installed in a dry environment and be
protected from any water exposure and any/all weather elements.
►A drip loop must be installed in the electrical cable so that water cannot reach the
motor if the cable gets wet.
►Never spray the motor or cables while cleaning the awning.
FOR MOTORS FITTED WITH NO MOLEX
While fully compliant to Australian standards, Linx motors and their connections are not waterproof
and must be protected from the elements, especially water. For safe installation, all the following
points must be observed:
►The electrical connections must be performed by a licensed electrician.
►A 3 pin plug needs to be wired to connect to a GPO for the ability to easily isolate for any
maintenance or future repair.
►The motor and electrical connection must be installed in a dry environment and be protected from
any water exposure and any/all weather elements.
►A drip loop must be installed in the electrical cable so that water cannot reach the motor if the
cable gets wet.
►Never spray the motor or cables while cleaning the awning.
