Aartesys EasyGateway EG400-HE User manual

1
EasyGateway®
Operating Instructions

2
Introduction
About this document
These opeating instructions provide a geneal oveview of the in-
stallation and stat-up of the Aatesys EasyGateway EG400 for use
with the connect2control (C2C) sevice.
Aatesys EasyGateway® and C2C –
uncomplicated, worldwide, secure
With C2C from Aatesys Sevices, any Internet connection beco-
mes an end-to-end connection, which is secure and cost-effective
at the same time. This sevice allows you unproblematic access to
your systems, be it machines, equipment, controls, locking systems,
and many more – at any time and anywhere. Opeation, mainte-
nance or suppot of these targets become as easy as sufing the Web.
The Aatesys EasyGateway® with C2C sevice is the ideal solution for
remote control and remote maintenance in the machine-2-machine
(m2m) environment. Communication is exclusively implemented via
IP networks. This can either be mobile via GPRS or 3G network or
alternatively via Fast Ethernet connection using wired IP networks,
such as ADSL connections, fibre-optic or cable networks, or even via
satellite tansmission systems.

3
EN
Table of Contents
04 Safety notes and technical specifications
06 Delivey scope
08 Device connections
10 Step 1 – Installation
12 Step 2 – Antenna & SIM card
14 Step 3 – Power connection & terminal covers
16 Step 4 – Network RJ45
18 Step 5 – Opeation and status display
20 Step 6 – Configuation settings and stat-up process
24 Other intefaces

4
Safety notes and
technical specications
Safety notes
This device must be opeated as described in these opeating
instructions as othewise the provided protection will no longer be
ensured and the device may produce risks.
Disconnect the system and the device from the
power supply before you stat working on it.
Voltages exceeding 300 VAC to ground must be
connected via voltage tansformers.
Conductors made up of individual wires
must be provided with cable end sleeves.
Consult the network administator before
connecting the EasyGateway to the Ethernet.
The building installation must have a disconnect
switch or circuit breaker for the supply voltage. The disconnect
switch must be mounted near the unit and must be easy to reach by
the opeator. The switch must be marked as disconnector for this
device. Voltages exceeding the permissible ange may destroy
the device.

5
EN
Technical specications
Display elements 3 LEDs, bicolor red/green,
for stat-up and opeation indicator
1 LED oange GSM status
Communication Full Internet capability with
cetificate-based authentication and
encyption
LAN/WAN connection Fast Ethernet 10/100 Mbps, auto-MDIX,
RJ45 shielded, 2 status LEDs
Fiber optic connector 100 megabits FX, SC connector
(single mode, dual or single fiber)
Mobile communication GPRS (Quad Band GPRS class 10)
or HSPA+ (Dual band GSM/GPRS/EDGE,
dual Band UMTS/HSPA) or LTE
SIM Plug-in and/or soldering SIM
(SIM Multiplexer)
Local IP inteface Fast Ethernet 10/100 Mbps, auto-MDIX,
RJ45 shielded, 2 status LEDs
Local serial intefaces RS485, RS422, RS232
Power supply 85 to 264 V AC, optionally 18 to 75 V DC
or 9 to 27 V DC
Housing DIN ail mount housing 6 units wide
(l=107.5 mm, w=90 mm, h=62 mm)
Environment Tempeature ange -20 to +70 °C,
relative humidity up to 95% max.
Declaation of Conformity, considered standards:
EMC EN 301 489-1:2008; EN 301 489-1:2008;
EN 61000-3-2:2006; EN 61000-3-3/A2:2005;
EN 61000-6-2:2005 and Customer Requirements
Radio EN 301 511:2003 (GSM)
Safety IEC 60950-1:2005 + A1:2009
EN 60950-1 + A11:2009 + A1:2010

6
2
1
Delivery Scope
Terminal cover
EasyGateway®

7
EN
5
4
Network cable RJ45
SIM card (optional)
SMA antenna
3

8
Device connections
121110913
7
6
5
43
8
1
2

9
EN
1
8
9
2
3
10
4
11
5
12
6
7
13
SMA antenna socket
LED status display
Reset
Micro SD card slot
SIM card slot
Ethernet RJ45
USB Host
Stat-up button
RS485
CS / CS-LED
Pulse output
I/O
Power connection

10
Step 1
2
1
74.35 mm

11
EN
1
2
Wall mounting
The EasyGateway® is mounted directly to the wall using
the holes provided in the housing bottom and 2 x 3.5 mm
screws. Use the distance of the holes in the housing
bottom as reference.
DIN snap ail
The EasyGateway® is snapped on a 35 mm DIN ail.
When installing the unit on the DIN ail, verify that the locking
hook is securely attached and adjust its position by gently pressing
against it, if necessay.
Installation
The EasyGateway® is either snapped on a 35 mm DIN ail
or mounted using screws.

12
Step 2
1
2

13
EN
1
2
Antenna connection
If the EasyGateway® is opeated via the air inteface, i. e. GPRS/
UMTS, an antenna must be connected to the SMA antenna
socket at the back of the unit.
Attach a staight or elbowed (90°) antenna (b), depending on
whether the EasyGateway® is mounted vetically or horizon-
tally. If the unit is installed in a control cabinet, the antenna
must geneally be mounted outside the cabinet as the recep-
tion conditions in closed cabinets will not fulfil the
requirements. Directly attachable antennas and antennas
connected via a cable are available.
Accessories – see sepaate sheet
SIM card slot
Inset the SIM card all the way into the SIM card slot.
The SIM card will engage. Push the SIM again to remove it
(push-push principle).
Accessories – see sepaate sheet
Antenna & SIM card
This step describes the mobile connection via GPRS/UMTS.
Use a spanner to fasten the antenna
(approx. 0.5 Nm). Ensure that the supplied
antenna is aligned vetically at all times.
(b)

14
Step 3
2
1
The supply voltage for the EasyGateway is specified on
the type plate. Supply voltages that do not conform to the specifi-
cations indicated on the type plate may result in malfunction and
destruction of the device.
The connecting lines for the supply voltage must be secured
via a UL listed fuse (6A type C) and must be provided with a
disconnecting switch.

15
EN
1
2
Power connection
3 fully insulated spring-loaded terminals, wire or standed
wire up to 1.5 mm2. Prefeably use a size #0 screwdriver for
opeating the terminals.
The connection is 3 wired.
The installation wire up to 1.5 mm2can be inseted directly into
the spring-loaded terminal. If a standed wire is used for the
installation, push the terminal fully down to inset the standed
wire and only release it once the latter has been positioned
correctly.
Protective eath PE
Neutal conductor (N)
Phase (L)
Terminal covers
Attach the tansparent terminal cover to cary out the
stat-up opeation. The terminal cover can easily be attached
(and removed using a size #0 screw driver). Be careful not to use
too much force.
The terminal cover can be secured with a
conventional lead wire seal.
Power connection & terminal covers
The EasyGateway® is connected directly to 85
to 264 V / 47 – 440 Hz AC voltage.
6 mm stripping length
Connection to the power grid must be carried out by a qualified
electrician in obsevance of the applicable regulations.

16
Step 4
1
2

17
EN
1
2
Network
The connection is via RJ45 jack with standard connector
pin assignment and integated LED display. The inteface is
designed as a so-called auto-MDIX inteface, which means that
staight and crossover Ethernet cables, shielded or unshielded,
can be used.
Additional intefaces
Please refer to page 24 for information on other intefaces.
Green LED
Display “Carrier”
Yellow LED
Display data activity “Data”
Network RJ45
The EasyGateway® is provided with a Fast Ethernet inteface for
communication via wire-bound IP networks.

18
56
Step 5
1
3
2
4

19
EN
1
2
3
4
56
GSM
LED “GSM” (yellow) must be lashing when communication
is realized via the mobile network. This LED is not lit if
communication is realized via Ethernet inteface.
Local
LED “Local” (o) In normal opeation,
the LED is off for C2C sevice
Config
LED “Config” (green) The configuation has been loaded and
functions correctly
Network
LED “Network” (green) The Ethernet inteface
functions correctly
Stat, Reset
Upon delivey, the initial stat-up for the EasyGateway has
already been completed. These buttons are used for changing
the configuation:
a) Setting the IP address, DHCP and Proxy Sever
b) Test of reception level at the mobile reception antenna
Operation & status display
Once the voltage has been connected, the LEDs should have the
following status:

20
Setting the conguration on the Easy Gateway
and start-up process
For this step, use a 1 mm Allen wrench or a paper clip to push
the reset and the stat-up buttons.
Step 6
Setting the IP address of the Ethernet inteface
Mode: Configuation
For setting the IP address of the Ethernet inteface, first press
the Reset button briely, and then press and hold the Stat-up
button for approx. 30 s, until “Local”, “Config” and “Network” are
lashing green. This puts the Gateway into configuation mode.
The configuation page can now be reached with your Browser via
http://10.10.10.10/. Save once the settings have been completed.
The EasyGateway will always remember the Ethernet settings
saved last.
After setting the IP address, press the Reset button.
The EasyGateway will stat in stat-up mode.
The configuation page of the EasyGateway is always set to
10.10.10.10. The default IP address for the opeation-mode is also
set to 10.10.10.10
Time-out: After 5 min., the EasyGateway automatically
peforms a reset and will then return to stat-up mode
