AAXA Technologies P300 User manual

aaxa
TECHNOLOGIES
User Guide
P3OO Pico Projector

Caution!
WARNING: Please use this product as instructed. Misuse may cause
injury or death.
DO NOT use while driving
DO NOT expose to water or wet
surfaces. Electric shock may occur.
DO NOT expose the projected LED
image to your eyes or the eyes of
others
DO NOT block or restrict airow
from ventilation holes as this may
cause the projector to overheat
Keep the projector, battery, or
charger away from any heat sources
Caution for Battery Use
• Do not pierce or puncture the battery
with sharp objects
• Do not heat the product or expose it to
high temperature.
• Do not wet it or place it in any liquid
Caution for Earphone (Earplug) Use
• Prolonged use at high volume may
impair your hearing.
• High volume during walking or driving
may cause distractions and result in
injury or death
Table of Contents
Chapter 1: P300 at a glance
Main Unit Front/Back
Remote & Keypad
Accessories
Chapter 2: Getting Started
Powering On / OFF
Focus Adjustment / Throw
Distance
Battery Installation
Connecting to a Computer VGA
Connecting to a Computer HDMI
Connecting to Composite Video
Connecting to HDMI Video
Connecting to Speaker or Head-
phones
1
2
3
4
5
6
7
8
10
12
14
16
17
19
21
22
24
25
27
28
30
31
32
37
39
40
41
Connecting a Micro SD Card
Connecting to a USB Host
Chapter 3: Menu Screens
Main menu
Video Player Menu
Video FAQ
Photo Viewer Menu
Photo FAQ
Music Player Menu
Music FAQ
Ebook Viewer Menu
Setup Menu
Keystone Adjustments
Chapter 4: Technical Details
Troubleshooting
Specications 1

P300 at a Glance
2
Chapter 1 Remote & Keypad
3
NOTICE: Pressing power on the remote will only put the projector in STANDBY
mode. Please press the power button on the projector if you want to turn it off.
Power On/Off
Main Menu
Navigation
Select Source
Media Player Menu
Navigation
Input Exit/Back
Direction Pad
Both the keypad and remote can be used to navigate through the menus. The Main Menu
Navigation on the remote functions exactly the same as the directional pad on the P300 unit.
On / Off
LED Lights
Power Switch
Micro SD Card
VGA Port
USB Port
Main Unit Front/Back
Headphone Port
AV Input
Power Button
DC Adapter Port
HDMI
Focus Adjustment

Accessories
4
*Under various circumstances, the actual accessories may be different from
those shown in the pictures above.
Tripod Remote
Power Adapter
VGA Cable
A/V Cable
Getting Started
1. Connect the power cord to the P300.
2. Connect the wall plug into the wall power source.
3. Switch the On / Off switch on the side of the projector to the “ON” position to enter
“standby” mode
4. Press POWER button on the keypad and hold for 2-3 seconds to start the projector
5
Powering ON the projector
Chapter 2
Powering OFF the projector
1. Press and hold the power button on the keypad for 3 seconds.
2. The optical engine should power off and the fan should stop spinning. The projector
is now in “stand by mode” and can be turned on using the remote control. “Stand by
mode” consumes a little bit of power
3. To fully turn off the projector, switch the On / Off switch on the side of the projector to
the “Off” position
Note: The P300 Projector battery does not charge when it is in operation.
Internal Battery
(sold separately)

Focus Adjusment / Throw Distance
Focus Adjustment
• Spin the focus wheel up or down until the image becomes
clear.
6
DIAGONAL SCREEN SIZE
16:9 Aspect Ratio
Throw Distance Chart
Distance inch (“)
12
24
36
48
60
72
84
96
Diagonal Inch (“)
8.57
17.14
25.71
34.28
42.86
51.43
60
68.57
Throw Ratio 1.4
*minimum throw distance: 10 inches
Installing the Battery Pack
7
1. Remove the three screws circled in blue holding
the P300 battery.
2. Connect the battery harness to the battery recep-
tacle on the PCBA
3. Install the new battery housing

Connecting to a Computer via VGA
Connect the large end of the
8
VGA Cord
to your computer’s
VGA Adapter
Connect the small end of the
VGA Cord
to your P300’s
VGA Adapter
Step 1:
Step 2:
Step 3:
In the Main Menu
Select “VGA” icon
Connecting to a Computer Cont.
Step 4:
Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com-
puter most computers require “turning on” the video output feature. Each computer is different.
Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are
standard instructions for a Windows XP computer – not all systems are the same.
Press function & “F5” to instruct
the computer to enable multiple
displays.
You can also press Windows+P to
toggle through display settings.
*NOTE: different operating sys-
tems may differ
Step 5:
1. Right click on computer desk-
top and select “Properties”
2. Display Properties window
will pop up
3. Click on the “Settings” Tab
4. If a secondary monitor is
grayed out, click on it and
check “Extend my Windows
Desktop onto this monitor”
5. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 1280x800.
Step 6:
9
Select “INPUT” icon *NOTE: Selecting 1280x720 or
1920x1080 will cause overscan

Connecting to a Computer via HDMI
Connect one end of the
10
HDMI Cord
to your computer’s
HDMI Adapter
HDMI Cord
to your P300s
HDMI Adapter
Step 1:
Step 2:
Step 3:
Select “INPUT” icon
In the Main Menu
Connecting to a Computer Cont.
Step 4:
Enabling VGA or HDMI output on your Computer – To enable VGA or HDMI output on your com-
puter most computers require “turning on” the video output feature. Each computer is different.
Please consult your owner’s manual for instructions to enable VGA or HDMI output. Below are
standard instructions for a Windows XP computer – not all systems are the same.
Press function & “F5” to instruct
the computer to enable multiple
displays.
You can also press Windows+P to
toggle through display settings.
*NOTE: different operating sys-
tems may differ
Step 5:
1. Right click on computer desk-
top and select “Properties”
2. Display Properties window
will pop up
3. Click on the “Settings” Tab
4. If a secondary monitor is
grayed out, click on it and
check “Extend my Windows
Desktop onto this monitor”
5. If the image is blurry or the
text is not legible, adjust
the screen resolution. We
recommend 1280x800.
Step 6:
11
Connect one end of the
Select “HDMI” icon

Connecting to Composite Video Cont.
Connectivity with multimedia devices
The P300 can connect to many media devices including: iPod, iPhone, iPad, VHS
players, DVD players, smart phones, cameras, video game consoles and other
peripherals with ease.
*Apps on smart phones require video out capabilities to be displayed with the P300.13
Step 3:
Select “INPUT” icon
In the Main Menu
Turn on your multimedia device.
Step 4:
Connecting to Composite Video
Connect one end of the
Composite Cord
to your P300’s
A/V Adapter
Connect opposite end of to your devices
Step 1:
Step 2:
Composite Cord Composite Cord
12
Select “AV” icon

Connecting to HDMI Video Cont.
Connectivity with multimedia devices
The P300 can connect to many media devices including: iPod, iPhone, iPad, VHS
players, DVD players, smart phones, cameras, video game consoles and other
peripherals with ease.
*Apps on smart phones require video out capabilities to be displayed with the P300.15
Step 3:
In the Main Menu
Turn on your multimedia device. If avaiable select 1280x720 or 1920x1080
Step 4:
Connecting to HDMI Video
Connect one end of the
HDMI
to your P300’s
HDMI Adapter
to your devices
Step 1:
Step 2:
HDMI Adapter
14
Connect one end of the
HDMI
Select “INPUT” icon Select “HDMI” icon
14

Micro SD Card
17
How to insert your Micro SD Card
• Slide in your SD card into the SD card
slot on the front of the P300. (as shown
in picture)
• Gently slide the SD card until it *clicks*
into place.
*Review the Specication
section of this manual to read
about the supported le
formats.
How to access your Micro SD Card
• Once your SD Card has been inserted,
you can navigate to any media content
in the main menu..
• After selecting the media content,
choose the SD card selection.
• You can now access the data on your
SD card through the onboard media
player
Connecting Speakers/Headphones
Connect your speakers/headphones
to the projector’s speaker adapter.
16
3.5 mm cord Speaker Adapter
Step 1:
Step 2:
*CAUTION for Earphone (Earplug) Use
• Prolonged use at high volume may impair
hearing
Ensure the power and volume on your
speaker or headphones is turned on
Step 3: Place the headphones on and enjoy!

USB Host
How to insert your USB Drive
• Slide your USB Drive into USB
adapter. (as shown in picture)
• Gently slide the drive until it cannot go
in any further
*Review the Specication
section of this manual to read
about the supported le
formats.
How to access your USB Drive
• Once your USB Drive has been in-
serted, you can navigate to any media
content in the main menu..
• After selecting the media content,
choose the USB selection.
• You can now access the data on your
USB drive through the onboard media
player
19
Micro SD Card Cont.
18
Media Player menu
• In the Media Player selection you can
choose from Videos, Audio, Pictures,
and Ebooks.
• Select the appropriate menu for the type
of le you wish to view.
Return: Brings you
back to the main
menu
File Menu System
• The P300 will show all folders and les
you have on your SD Card in the C:
drive.
• Use the directional buttons to navigate
to different folders or les.

Menu Screens
21
Main Menu
Chapter 3
The P300 features a built in PMP (Portable Media Player) function.
This function allows the projector to play videos, pictures, music les, and text. To access
the main menu simply turn on the projector.
• Scroll Left/Right by pressing the left and right directional buttons
• To select a submenu, highlight the desired submenu and press the OK button
located in the middle of the keypad or remote.
• To go back to the previous page while in a submenu, press the back on the far
right just underneath the directional keypad.
USB Host Cont.
20
Media Player menu
• In the Media Player selection you can
choose from Videos, Audio, Pictures,
and Ebooks.
• Select the appropriate menu for the type
of le you wish to view.
Return: Brings you
back to the main
menu
File Menu System
• The P300 will show all folders and les
you have on your USB Drive.
• Use the directional buttons to navigate
to different folders or les.

Video Player Menu
22
Opening a le:
• Select the video option
from the main menu.
• Select the hardware
media the le is stored
on
• Choose which le you
wish to play.
Previewing Files:
• Press the directional keys to highlight the item of interest
• Wait 2-3 seconds and a preview of the video will show on the screen
The P300 will show all folders and les you have on your USB or SD Drives.
Use the directional buttons to navigate to different folders or les.
23
Video Player Menu
Playing Videos
To use the video controls, use the directional keys to highlight the option you wish
to choose.
Select the “video” icon
Move selection left
Move selection right
Conrm selection
Play
Video
Rewind
Video Fastforward
Video
Previous
video Next
Video
Stop
Video Repeat
Video
Rewind
• To open the vide player menu,
press “OK” on projector.
• To close the video player menu,
hit “back” on projector.

Photo Menu
25
Opening a le:
• Select the photo option
from the main menu.
• Select the hardware
media the le is stored
on
• Choose which le you
wish to play.
Previewing Files:
• Press the directional keys to highlight the item of interest
• Wait 2-3 seconds and a preview of the picture will show on the screen
The P300 will show all folders and les you have on your USB or SD Drives.
Use the directional buttons to navigate to different folders or les.
Select the “photo” icon
Video Playback FAQ
How do I loop a video?
1. Choose either USB or SD Card
for playback
2. Navigate the folders until you
reach the le you wish to play.
3. Highlight the le you want to
play, then conrm the selection.
4. Move selection on video player
menu to “repeat”, and conrm
the selection.
5. The video will now loop after
playback is nished.
How do I preview a video?
1. Choose the “video” option from the
main menu
2. Navigate using either remote or
onboard buttons to the le you wish to
preview.
3. Highlight the le. *Do not select the
le, just highlight it.
4. Wait for 3-4 seconds.
5. A preview screen will pop up on the
lower right for the video.
24

26
Photo Menu
Viewing Pictures
To use the photo controls, use the directional keys to highlight the option you wish
to choose.
Move selection left
Move selection right
Conrm selection
Start
Slideshow
Previous
Next Photo
Stop
Slideshow Repeat
Stop
Music Show
Playlist
Show
Info
Photo Slideshow FAQ
How do I play a slideshow?
1. Choose either USB or SD Card
for playback
2. Navigate to the folder that
contains the pictures you wish
to see in the slideshow
3. Conrm selection of the rst
picture.
4. Press “play” in the photo menu
5. Slideshow will not play.
6. NOTE: Selecting “repeat” will
loop slideshow.
How do I manually control the
slideshow?
1. After selecting the photo you wish to
be displayed, you can press “play” to
start the slideshow (as outlined in the
previous FAQ).
2. To manually control the slideshow,
you must stop the slideshow with the
“stop” button.
3. You may use either the controls on
your remote or on top of the projector
itself to ip through the pictures in the
current playlist.
27
• To open the vide player menu,
press “OK” on projector.
• To close the video player menu,
hit “back” on projector.

Music Player Menu
28
Opening a le:
• Select the audio option
from the main menu.
• Select the hardware me-
dia the le is stored on
• Choose which le you
wish to play.
Previewing Files:
• Press the directional keys to highlight the item of interest
• Wait 2-3 seconds and a preview of the audio will show on the screen
The P300 will show all folders and les you have on your USB or SD Drives.
Use the directional buttons to navigate to different folders or les.
Select the “Audio” icon
29
Music Player Menu
Listening to Audio
To use the audio controls, use the directional keys to highlight the option you wish
to choose.
Move selection left
Move selection right
Conrm selection
Play /
Pause
Rewind
Fastforward
Previous
Track Next
Track
Stop
Playback Repeat
Track
Mute
Sound
• To open the music menu, press
“OK” on projector.
• To close the music menu, hit
“back” on projector.

EBook Viewer Menu
31
Opening a le:
• Choose “Open File” option
• Select device le is stored on
• Select le from list
Viewing text les
The P300 Pico Projector allows you to view text les. Select the le you want to view in
the le menu for the particular storage device on which the le is stored. You can press
the left and right arrow buttons on the directional pad or remote to ip through the pages
you have in the present folder.
*Review Specication section of this manual for supported ebook formats.
The P300 will show all folders and les you have on your USB or SD Drives.
Use the directional buttons to navigate to different folders or les.
Music Playback FAQ
How do I loop a song?
1. Choose either USB or SD Card
for playback
2. Navigate the folders until you
reach the le you wish to play.
3. Highlight the le you want to
play, then conrm the selection.
4. Move selection on music player
menu to “repeat”, and conrm
the selection.
5. The song will now loop after
playback is nished.
How do I create a song playlist?
1. Insert your media device (either mi-
croSD card or USB) into computer.
2. Make a new folder on media device
(folder name will be the name of the
playlist).
3. Transfer songs from computer to the
new folder, name accordingly.
4. Remove media device from computer
and insert into projector.
5. Navigate to Audio section, then
choose appropriate media device.
6. Navigate to your playlist folder.
7. Start at rst song.
8. Playback will follow each successive
song on the list.
*To create a special order for the list, add nu-
merical numbering to the beginning of each le.
30

Setup Menu
32
The Settings Menu can be accessed by selecting “Settings”on the main menu
• Picture Mode
• Color Temperature
• Aspect Ratio
Sound
• Sound Mode
• Balance
• Auto Volume
• Surround Sound
• EQ
Time
• Clock
• Off Time
• Sleep Timer
Option
• OSD Language
• Restore Factory Default
• Blending
• OSD Duration
Within the settings menu there are
four more submenus that allow you to
customize your P300 to the settings
you want.
Picture Settings
33
Picture Mode
• Changes the picture mode to
different settings depending on
your choosing.
Color Temperature
• Adjusts the color temperature
from hot to cool (red to blue).
Aspect Ratio
• Changes the aspect ratio of the
picture - 4:3, 16:9*
Noise Reduction
• Option to reduce the noise
(grain) of the picture
Backlight
• Adjusts the backlight *Caution: Some pictures may be cut off
when aspect ratio is set incorrectly

Sound Settings
34
Sound Mode
• Change the sound mode depend-
ing on what is currently playing.
Balance
• Adjusts the balance of the sound,
from left to right.
Auto Volume
• Sets the projector to auto-detect
for the volume. The projector will
auto detect the appropriate sound
mode.
Surround Sound
• Adjusts the surround sound capa-
bilities of the projector.
EQ
• Changes the equalizer for the
projector, which affects the sound
signature.
Time Settings
35
Clock
• Adjust the time/date.
Off Time
• Sets a time for auto turn off of
projector
On Time
• Sets a time for the projector to
auto turn on.
Sleep Timer
• Sets a timer until the projector to
go into sleep mode
Auto Sleep
• Sets the auto sleep of the unit.

Option Settings
36
OSD Language
• Changes the language of the
device.
Restore Factory Default
• Restores the projector to factory
settings.
Blending
• Adjusts the blending option.
OSD Duration
• Allows the projector to set a
duration for the selected OSD
language.
Keystone Adjustments
37
Digital Keystone Adjustments
By adding a special, selectable, algorithm to the scaling, some new projectors
are able to alter the image before it reaches the projection lens. The result is a
squared image, even at an angle.
What is Keystoning?
“Keystoning” occurs when a projector is aligned non-perpendicularly to a screen,
or when the projection screen has an angled surface. The image that results
from one of these misalignments will look trapezoidal rather than square.
