ABI INTERIORS KINGSLEY MINIMAL HANDLE KIT 14014 User manual

KINGS LE Y MIN IMAL HANDLE KIT
Dis cla imer: P ro d u c ts in th is ma n u a l mu s t by la w b e in s talled b y licen s ed an d reg is tered tra d es p eo p le in a cco rd a n ce w ith th e releva n t stan d a rds . A B I a n d th e ma n u fa ctu rer/d is trib u to r
res erve t h e rig h t to va ry s p ecif ic a tio n s o r d elete mo d els fro m t h eir ra n g e w ith o u t prio r n o tif ic a t io n . Dimen s io n s a re n o min a l mea s u remen ts o n ly. Th e in f o rmatio n lis ted is co rrect at th e time
o f p u b lica tio n , h o w ever A B I a n d th e man u f a c tu rer/d is trib u to r ta kes n o res p o n s ib ility fo r p rin tin g erro rs. C o p yrig h t © A B I I n terio rs 2 02 2 Pty Ltd
SPECIFICATIONS
RECOMMENDED USE Domestic
MATERIAL Solid Brass
AS/NZS 3718:2005
WM-022852

Regularly clean with mild
liquid detergent or soap
and water
DO NOT use cream
cleaners or bleach.
These substances are
abrasive
DO NOT use cleaning
pads with abrasive
surfaces as this may
scratch the material
12
Choose sleeve based on how far your
In-wall protrudes from finish wall and
slide on.
Finished wall
30
15
Long Sleeve
Short Sleeve
B
Slide back plate on.
Screw dome on. 3Tighten grub screw with allen key.
Replace grub screw cap.
WHAT'S IN THE BOX
1. Back plate
2. Long sleeve
3. Dome
4. Grubs screw cap
5. Grub screw
6. Handle
7. Short sleeve
8. Allen key
7
8
NOTE: See Minimal Mixer Body installation guide for In-Wall set out.
A
MIXER OPERATION
1
2
45
6
3
INSTALLATION GUIDE
Note: This product must be installed by a licensed plumber. This is a general installation guide - there are many factors involved that
can alter the installation method. AU/NZ: For installations within Australia and New Zealand, this product must be installed in
compliance with AS/NZS 3500. UK: For installations in the United Kingdom this product must be installed in compliance with the
Water Supply (Water Fittings) Regulations and Water Supply (Water Fittings) (Scotland) Byelaws. Other: For installations outside
hese countries, this product must be installed in compliance with the standards in your respective country.
