Abocom BSM202 User manual

Bluetooth Audio Adapter
This Stereo Bluetooth audio adapter can be easily
plugged into the audio jack of your MP3, PC/NB, TV,
DVD player …etc. It will then search and
automatically pair with a Stereo Bluetooth headset.
Once paired, the nice stereo music plays wireless on
your ears. It is like a breeze to use, no software setup.
The rechargeable battery makes your day with
continuous playing. Perfect for travel entertainment or
as an add-on for your home entertainment system.
FEATURES
zConnect to your Stereo audio source via audio jack
zAutomatically paired with Stereo Bluetooth headset
zRechargeable battery lasts more than 8 hours play
zEasy plug, auto connect, use like a breeze
zNo software set up needed.
SPECIFICATION
Standards Bluetooth specification V1.2 compliant.
Bluetooth A2DP profile (AV Profile)
Frequency Band 2402 ~ 2480 MHz
Tx Power 0.25 ~ 2.5mW (Bluetooth Power Class II)
Rx Sensitivity < -80dBm (BER 0.1%)
Distance > 10m (open space)
Audio Connector Audio Stereo jack 3.5MM
Audio Streaming Format SBC 48.000kHz
Audio Frequency Range 20Hz ~ 22kHz
Audio S/N > 85dB
Audio THD < -83dB
Audio Output Power > 20mWrms
Battery Life 500mA Music play : > 8 hrs
Power supply Supply by integrated Polymer rechargeable battery Operation
>8hrs.
Physical Specification: 75mm(H)x26mm(W)x14.5mm(D)
Environmental Range: Operating temperature:-10 ~ +50℃
Humidity: Relative humidity 0 ~ 95%
Certifications: FCC, CE, BQB, BSMI,TELEC
USER INTERFACE SPEC
Audio input jack 3.5mm female audio stereo jack
Power Switch Power on/off
Power charge connector 0.8mm DC in connector/5V input
LED1 Discovery: Blue steady on, Paired：Blue blinking
LED2 Power low: Red blinking
LED3 Charging：steady on red

ORDERING INFO
BSET201 BSH201 and BUD200 in package
BSET202 BSH202 and BUD200 in package
BSH201 Bluetooth Stereo Headset
BSH202 Bluetooth Stereo Headset
BSH203 Bluetooth Stereo Headset with Mic supports AV and HS/HF profiles
BUD200 Bluetooth USB Audio Dongle as transmitter
BSR202 Bluetooth receiver with MIC supports AV and HS/HF profiles
BSM202 Bluetooth transmitter with Audio in, Bluetooth out supports AV profile
Other Bluetooth Products
UBT2K Bluetooth USB Dongle for PC/NB, new model
UBT1K Bluetooth USB dongle for PC/NB
