Abocom WU5200 User manual

WU5200
802.11n/b/g compliant 2.4GHz
USB Adapter
Description
The WU5200 is an IEEE802.11 n/b/g USB adapter that
connects your notebook to a wireless local area. The WU5200
2*2 MIMO Technology improves effective throughput and
range over existing 802.11 b/g products better expands the
receiving distance and efficiently eliminates wireless
connection dead spots compared with normal 11g products.
The WU5200 is a very small adapter that can connects
notebook, handheld or desktop computer equipped with
USB interface for wireless network applications. It allows
you to take full advantage of your notebook’s mobility with
access to real-time information and online services anytime
and anywhere. It slides easily into the USB expansion slot
to enable a wireless connection to your network.
Specification
Standards IEEE 802.11 n/b/g standards compliant
Antenna Internal fix antenna
Frequency
Range
802.11 n/b/g
USA (FCC): 2.412GHz ~ 2.462GHz
Europe (ETSI): 2.412GHz ~ 2.472 GHz
Japan (TELEC): 2.412GHz ~ 2.483GHz
Number
of Selectable
Channels
802.11n 20MHz/40MHz ;802.11b/g
USA (FCC) 11 channels;
EU (ETSI) 13 channels;
Japan (TELEC) 13 channels
Data Rate 802.11n: up to 300Mbps 802.11b: 1, 2, 5,5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
Coverage
Area Up to 12 times faster then existing 802.11 b/g products
Transmit
Power(EIRP)
11n HT40 : +16dBm
11b CCK: +15dBm
11g OFDM: +16dBm
Receiver
Sensitivity
-67dBm at 300Mbps
-73dBm at 54Mpbs, 10% PER
-88dBm at 11Mpbs, 8% PER
Support OS Windows XP, 2000, Vista, Linux
Power
Requirement 5 Vdc
Certifications FCC, CE
Features
z300MHz PHY Rate Support
z20MHz/40MHz bandwidth
zWEP 64/128, WPA, WPA2 Support
zQoS – WMM, WMM-PS
zUSB interface
zLow Power with Advanced Power
Management
