Powerline Filter for PLC communication
- AC 90-120V 50-60Hz 15A
- One AC plug, one AC outlet
- 30dB attenuation at 2-30MHz band
Description
The PLF100 provides excellent homeplug/in-home
noise filtering to user for maintaining a good powerline-
network environment. This filter enables you to isolate the
power outlet’s noise and your PowerLine Communication
(PLC) device.
Features
 One AC plug
 One AC outlet
 Built in PLC notched filter

AboCom Confidential
2 OF 2
Specification
Interface One AC plug.
One AC outlet.
Max. output capacity AC 90-120V; 15A, 50-60Hz.
Dimension (L x W x H) 65mm x 48mm x 35mm.
Filter capacity -30 to -45dB attenuation among 2-30MHz band.
Flammability Class V1 class.
Operating Temperature 0~40ºC (32~104ºF).
Relative Humidity: 10%~90% non-condensing.
Storage Temperature: -20~60ºC (-4~140ºF).
Relevant Humidity: 5%~95% non-condensing.
Housing color White.
Certification PSE.
Typical insertion loss chart General usage
