HYDAC FILTER SYSTEMS MRF 3 Manual

MRF 3
MultiRheo Filter
Operating and Maintenance Instructions
English (translation of original instructions)
Document-No. 3218003c

MRF 3 Imprint
HYDAC FILTER SYSTEMS GMBH en Page 2 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Imprint
Publisher and responsible for the content:
HYDAC FILTER SYSTEMS GMBH
Postfach 1251
66273 Sulzbach / Saarland
Germany
Telephone: [phone]
Telefax: [phone]
E-Mail: [email protected]
Homepage: www.hydac.com
Court of Registration: Saarbrücken, HRB 17216
Executive director: Mathias Dieter,
Dipl.Kfm. Wolfgang Haering
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Telephone: ++49 (0)6897 509 1511
Telefax: ++49 (0)6897 509 1394
E-Mail: [email protected]
© HYDAC FILTER SYSTEMS GMBH
All rights reserved. No part of this work may be reproduced in any form (print,
photocopy or by other means) or processed, duplicated or distributed using
electronic systems without the written consent of the publisher.
These documents have been created and inspected with the greatest care.
However, errors cannot be ruled out completely.
All details are subject to technical modifications. Technical specifications are subject
to change without notice.
The trademarks of other companies are exclusively used for the products of those
companies.

MRF 3 Content
HYDAC FILTER SYSTEMS GMBH en Page 3 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Content
Imprint .......................................................................................................................2
Documentation Representative...............................................................................2
Content......................................................................................................................3
Preface ...................................................................................................................... 5
Customer Service ...................................................................................................6
Modifications to the Product ...................................................................................6
Warranty .................................................................................................................6
Using the documentation ........................................................................................7
Safety information and instructions.......................................................................8
Obligations and Liability..........................................................................................8
Explanation of Symbols and Warnings ................................................................... 9
Proper/Designated Use .......................................................................................... 9
Improper Use .......................................................................................................... 9
Safety Devices........................................................................................................9
Informal Safety Precautions.................................................................................. 10
Training and Instruction of Personnel ...................................................................10
Safety Measures to Be Followed during Normal Operation..................................10
Hazards Posed by Stored Residual Energy .........................................................11
Modifications to the MRF ......................................................................................11
Transporting the MRF ............................................................................................ 12
Storing the MRF......................................................................................................13
Checking the scope of delivery ............................................................................14
Technical Description ............................................................................................15
Suitable Fluids ......................................................................................................15
Filter Design.......................................................................................................... 15
Pressure loss curve, housing ............................................................................16
Design of the MultiRheoFilter (MRF) .................................................................... 17
Port Versions — Inlet/Outlet ................................................................................. 18
Dimensions ...........................................................................................................19
Commissioning ...................................................................................................... 20
Set up ................................................................................................................... 20
Notes on Piping / Hosing ......................................................................................20
Connecting the IN suction port connection ...........................................................21
Performing maintenance ....................................................................................... 22
Replacing the filter elements ................................................................................22
Disposal of MRF ..................................................................................................... 26

MRF 3 Content
HYDAC FILTER SYSTEMS GMBH en Page 4 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Disposing of the MRF ............................................................................................26
Spare parts.............................................................................................................. 27
Technical data ........................................................................................................ 28
Model Code .......................................................................................................... 29

MRF 3 Preface
Preface
For you, as the owner of a product manufactured by us, we have produced this
manual, comprising the most important instructions for its operation and
maintenance.
It is intended to help you become acquainted with the ins and outs of the product
and use it properly.
You should keep it in the vicinity of the product so it is always at your fingertips.
Sometimes the information contained in this documentation cannot always keep up
with changes made to the product as we attach considerable importance to keeping
our products cutting-edge.Consequently, there might be deviations in technical
details, figures and dimensions.
If you discover errors while reading the documentation or have suggestions or other
useful information, please don’t hesitate to contact us:
HYDAC FILTER SYSTEMS GMBH
Technische Dokumentation
Postfach 12 51
66273 Sulzbach / Saar
Germany
The editor would welcome your involvement.
Our motto: “Putting experience into practice”
HYDAC FILTER SYSTEMS GMBH en Page 5 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Preface
HYDAC FILTER SYSTEMS GMBH en Page 6 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Customer Service
If you have any questions, suggestions, or encounter any problems of a technical
nature, please don't hesitate to contact us. When contacting us, please always
include the model/type designation and article no. of the product:
Fax.: ++49 (0) 6897 / 509 - 846
E-Mail: [email protected]
Modifications to the Product
We would like to point out that changes to the product (e.g. purchasing options, etc.)
may result in the information in the operating instructions no longer being completely
accurate or sufficient.
When making modifications or performing repair work to components affecting the
safety of the product, the product may not be put back into operation until it has
been examined and released by a HYDAC representative.
Please notify us immediately of any modifications made to the product whether by
you or a third party.
Warranty
For the warranty provided by us, please refer to the General Terms of Sale and
Delivery of HYDAC FILTER SYSTEMS GmbH.
You will find these under www.hydac.com -> General terms and conditions.

MRF 3 Preface
Using the documentation
Please note that the method described above of locating specific
information does not release you from your responsibility for carefully
reading the entire manual prior to starting the unit up for the first time
and carefully rereading the manual at regular intervals later on.
WHAT do you want to know?
I determine which topic I am looking for.
WHERE can I find the information I’m looking for?
The document has a table of contents at the beginning. I select the chapter I'm
looking for and the corresponding page number.
de
HYDACFiltertechnikGmbH
BeWa12
34
56a
d
e
Seit e x
Produkt/Kapitel
200x-xx- xx
Chapter
Page number
Edition date
Document language
Documentation No.
with Index /
File name
The documentation number with its index enables you to order another copy of the
operating and maintenance instructions. The index is incremented by one number
every time the manual is revised or changed.
HYDAC FILTER SYSTEMS GMBH en Page 7 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Safety information and instructions
HYDAC FILTER SYSTEMS GMBH en Page 8 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Safety information and instructions
These operating instructions contain the key instructions for properly and safely
operating the MRF.
Obligations and Liability
The basic prerequisite for the safe and proper handling and operation of the MRF is
knowledge of the safety instructions and warnings.
These operating instructions in general, and the safety precautions in particular, are
to be adhered by all those who work with the MRF.
Adherence is to be maintained to pertinent accident prevention regulations
applicable at the site where the product is used.
The safety precautions listed herein are limited solely to using the MRF.
The MRF has been designed and constructed in accordance with the current state
of the art and recognized safety regulations. Nevertheless, hazards may be posed to
the life and limb of the individual using the product or to third parties. Risk of
damage may be posed to the product or other equipment and property.
The MRF is only to be used as follows:
solely for its designated use
only when in a safe, perfect condition
Immediately remedy any malfunctions that might impair safety.
Our General Terms and Conditions apply. They are made available to the owner
upon concluding purchase of the unit at the latest. Any and all warranty and liability
claims for personal injuries and damage to property shall be excluded in the event
they are attributable to one or more of the following causes:
improper use of the MRF or use deviating from its designated use
improper assembly, installation, commissioning, operation and maintenance of
the MRF
operating the MRF when the system equipment or systems are defective
modifications to the MRF made by the user or purchaser
improper monitoring of product components subject to wear and tear
improperly performed repair work

MRF 3 Safety information and instructions
Explanation of Symbols and Warnings
The following designations and symbols are used in this manual to designate
hazards, etc.:
DANGER
DANGER denotes situations
which can lead to death if
safety precautions are not
observed.
WARNING
WARNING denotes situations
which can lead to death if
safety precautions are not
observed.
CAUTION
CAUTION denotes situations
which can lead to severe
injuries if safety precautions
are not observed.
NOTICE
NOTICE denotes situations
which can lead to property
damage if safety precautions
are not observed.
Proper/Designated Use
The MultiRheoFilter (MRF) is a stationary filtration unit used for the full-flow and
bypass filtration of low-viscosity fluids.
Any other uses shall be deemed to be improper and not in keeping with the
product's designated use.
The manufacturer will not assume any liability for any damage resulting from such
use.
Proper or designated use of the product extends to the following:
Maintaining adherence to all the instructions contained herein.
Performing requisite inspection and maintenance work.
Improper Use
Any use deviating from the proper/designated use described above is prohibited.
Improper use may result in hazard to life and limb.
Safety Devices
Prior to starting up the product each time, make sure that all the safety devices are
properly fitted to the hydraulic system in which the product is to be used and are in
proper working order.
HYDAC FILTER SYSTEMS GMBH en Page 9 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Safety information and instructions
HYDAC FILTER SYSTEMS GMBH en Page 10 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Informal Safety Precautions
Make sure to always keep the operating instructions in the vicinity of the product.
In addition to the manual, the general and local regulations concerning accident
prevention and protection of the environment should be available and observed.
Make sure to keep the safety and hazard symbols and warnings on the product in a
legible condition.
Check the unit daily for leaking (perform a visual check). Any loose connections are
to be replaced immediately.
Training and Instruction of Personnel
The MRF may only be operated by properly trained and instructed personnel.
The areas of responsibility of your staff must be established in a clear-cut manner.
Trainees may only work with the MRF when supervised by an experienced
individual.
Individuals Individuals undergoing training Individuals with technical training Electrician Supervisor with the appropriate authority
Activity
Packing Transportation X X X
Commissioning X X X
Operation X X X X
Troubleshooting / locating
the source of malfunction X X X
Remedying faults
Mechanical X X
Troubleshooting, electrical
problem X X
Maintenance X X X X
Repair work X
Decommissioning/storage X X X X
Safety Measures to Be Followed during Normal Operation
The product is to be checked at least once a day for external damage and the
proper functioning of the safety devices.

MRF 3 Safety information and instructions
Hazards Posed by Stored Residual Energy
WARNING
Hydraulic systems are under pressure
Bodily injury leading to death
►The hydraulic system must be depressurized
before performing any work on the hydraulic
system
Note that the unit may pose a hazard as the result of residual stored mechanical and
electrical energy. Take the proper precautions when instructing personnel on the
use of the unit. Detailed information is provided in the respective sections of this
manual.
Modifications to the MRF
Do not make any modifications (design modifications, extensions) to the MRF
without the prior consent of the manufacturer.
Immediately replace any unit components which are not in perfect condition.
Only use original (OEM) spare parts and consumables. When using non-OEM
components it cannot be ensured that they have been designed and manufactured
so as to comply with loading and safety requirements.
HYDAC FILTER SYSTEMS GMBH en Page 11 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Transporting the MRF
Transporting the MRF
Transport the AMRF in an upright
position only.
For transportation using a crane or
forklift, use two slings on the specified
anchor points between the filter
housing and the base.
HYDAC FILTER SYSTEMS GMBH en Page 12 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Storing the MRF
Storing the MRF
Remove all filter elements and completely drain the filter housing. Clean and flush
the filter housing
Storage temperature: 5 … 30°C / 41 … 86°F
Humidity: Up to 80% relative humidity, non-condensing
Air Clean, salt-free air, not near oxidizing substances (rust
film).
Storage duration Indefinite.
Before the unit is started up again after being stored for
more than two years, all seals must be replaced.
Store the MRF in an upright position
only.
HYDAC FILTER SYSTEMS GMBH en Page 13 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Checking the scope of delivery
Checking the scope of delivery
Upon receiving the MRF check it for any damage in transit. Do not put the MRF into
operation unless it is in perfect condition. Any damage in transit is to be reported to
the forwarding agent or the department in charge immediately; the unit may not be
commissioned until this damage is properly remedied.
The following items are supplied:
Item Qty Description
1 1 MultiRheo Filter 3, filter size and version of ports in accordance with
order, (excluding filter elements)
- 1 Operating and Maintenance Instructions
MRF 3 E/xx x 1010 MRF 3 E/xx x 2010
MRF 3 E/xx x 3010 MRF 3 E/xx x 4010
1
1
1
1
HYDAC FILTER SYSTEMS GMBH en Page 14 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Technical Description
Technical Description
The MultiRheo Filter (MRF) is a stationary filtration unit used for the full-flow and
bypass filtration of low-viscosity fluids for the separation of particles of 100 µm to
1 µm (absolute).
The MultiRheo Filter is a filter series for the use of Flexmicron filter elements.
Suitable Fluids
NOTICE
Impermissible operating media
The MRF will be destroyed
►Only use the MRF in connection with:
- lubrication and mineral oils or media based on mineral oil
- cooling lubricants
Filter Design
The total pressure of the filters at a specific flow rate is comprised of the housing
and the element . The pressure loss of the housing can be determined using
the following pressure loss curve.
pp
HYDAC FILTER SYSTEMS GMBH en Page 15 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Technical Description
Pressure loss curve, housing
bar
Flow rate in l/min
The upper housing curve holds for mineral oil with a density of 0.86 kg/dm³ and a
kinematics viscosity of 30 mm²/s. The lower housing curve holds for water at 20°C.
For turbulent flow, the differential pressure will change proportionally to the density;
for laminar flow, it will change proportionally to the density and viscosity. The flow
velocity should not exceed 3 m/s at the filter inlet for oil and 4 m/s for water.
HYDAC FILTER SYSTEMS GMBH en Page 16 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Technical Description
Design of the MultiRheoFilter (MRF)
1111
12
12
12
12
4
4
5
5
6
7
6
7
6
7
6
7
33
6
7
6
7
13 13 13 13
11
1111
11
2
8
9
8
9
8
9
8
9
MRF 3/x 10 ... MRF 3/x 20 ... MRF 3/x 30 ... MRF 3/x 40 ...
Item Description
1 Foot
2 Lower section
3 Extension piece
4 Flat cover
5 Tall cover
6 O-ring
7 Housing clamp
8 Inlet
9 Outlet
10 Drain valve, clean side
11 Drain valve, dirt side
12 Air-vent plug
13 Back-pressure indicator
HYDAC FILTER SYSTEMS GMBH en Page 17 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Technical Description
Port Versions — Inlet/Outlet
MRF3 E /x D MRF3 E /x F
G 1” G 1 ½”
MRF3 E /x G
G 2”
MRF3 E /x J MRF3 E /x L
DIN DN 50 SAE DN 50
HYDAC FILTER SYSTEMS GMBH en Page 18 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Technical Description
Dimensions
HYDAC FILTER SYSTEMS GMBH en Page 19 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22

MRF 3 Commissioning
HYDAC FILTER SYSTEMS GMBH en Page 20 / 32
BeWa MRF3 3218003c en-us 2012-02-22.doc 2012-02-22
Commissioning
The MRF is supplied ex works without any filter elements. Prior to commissioning,
insert the filter elements into the filter housing, as described on page 22.
Set up
Set up the unit horizontally on a level surface.
Make sure that there is sufficient space above the filter housing to remove the filter
elements.
Notes on Piping / Hosing
Make sure that no vibrations or stress/loading from other machinery and equipment
are carried over to the filter housing. If necessary, use expansion joints.
The pressure differential in a hydraulic line depends upon:
flow rate
kinematic viscosity
pipe dimensions
density of fluid
The pressure loss can be estimated for hydraulic oils as follows:
Δp ~ 6.8 * L / d4* Q * V * D
Δp = Pressure differential in [bar]
L= Line length [m]
d= Internal line diameter [mm]
Q= Flow rate [l/min]
V = Kinematic viscosity [mm²/s]
D = Density [kg/dm³] Mineral oil based hydraulic fluid has a density of
~ 0.9 kg/dm³.
This applies to straight pipelines and hydraulic oils. Additional threaded connections
and pipe bends increase the pressure differential.
Keep the height difference between the pump and the oil level in the tank as low as
possible.
Hoses must be suitable for suction pressures of at least -0.5 bar.
Constrictions in the connections and lines should be avoided. This could
compromise suction output and cause cavitation .
Take note that the nominal size of the connected hoses/piping must be at least as
large as the inlet port sizes.
