INSTRUCTION MANUAL
Welcome to
the Pureit family
W

KNOW YOUR PUREIT
COPPER+ECO MINERAL RO+UV+MF
01. LED Display Panel
02. Touch buttons – Copper Enriched
Water & Ambient RO Water
03. Water Dispensing Outlet
04. Pre-sediment Filter
05. Inlet Water Tube
06. Reject Water Tube
07. Diverter
08. Ball Valve
09. Drip Tray
10. Manual Dispense Tap
6
1
2
3
4
10
9
5
8
7
1

*For all water contact parts. **Advance Alert System will alert you 15 days before or 15 hours before completion of every 260 hours of pump running time(Which gives Approximately 6000liters of purified water). The purifier will communicate
the alert only if the purifier is in a switched on condition during the scheduled alert time. Post the completion of the scheduled alert time, Auto Shut off™ of water will be activated automatically only for GKK, even if the purifier is in a switched
of condition. ***Under test condition, Input TDS – 750 ppm, Turbidity – <1 NTU, Input Pressure – 10 psi, Input Hardness – 300 ppm, Temp. – Room temp. ~Copper Charge Technology is a unique proprietary technology which is based on
electrochemical dissolution of copper in water. #Smart technology which ensures precise dosing in every glass of water. Consumption of 2 litres of copper charged RO water every day, will add upto approximately 30% of the RDA for
copper( for adults, as guided by the Indian Council of Medical Resarch, ICMR) ^7.6 to 8 litres in running water conditions.
UNIQUE FEATURES
2
1. Pre-Sediment Filter (SF)
Removes fine and coarse particulate impurities/dirt and improves life of the Carbon
Filter.
2. Pre-RO Carbon Filter
Removes chlorine and organic impurities such as harmful pesticides. It also absorbs
bad taste and odor-causing organic compounds from water.
3. Mesh Filter
Filters water further to ensure removal of finer particulate impurities.
4. RO Membrane
Removes dissolved salts, hardness, pesticides and heavy metals like arsenic, lead
and mercury. It also removes microbial contaminants like bacteria, virus, protozoa
and cysts.
5. UV Chamber
Acts as an additional stage of purification to further inactivate bacteria, virus and
parasites to deliver safe water.
6. Post RO Carbon Filter
This level of purification acts as a polisher and enhances the taste of purified water.
7. Micro Filtration Membrane
Micro Filtration Membrane is stage after Post-RO and UV, which ensures that the
water is purified not once but thrice.
UNIQUE TECHNOLOGY
An advanced purifier that brings together modern technology and traditional
goodness to enhance your family’s health. It's advanced 7 stage purification process
with RO+UV+MF purifies water and its proprietary Copper Charge TechnologyTM~
charges it with goodness of copper.
1 2 3 4 5 6 7
This is a graphic representation of filters
COPPER CHARGE TECHNOLOGYTM~
A unique modern technology that charges water with 99.8% pure copper,
in real time.
DUAL WATER DISPENSING
Two buttons gives you the choice of RO water and copper charged RO water.
INTELLIGENT COPPER CLEANING MODE
Smartly senses and schedules copper auto-cleaning, for fresh copper infusion
at all times.
PRECISE COPPER DOSING#
Infuses right amount of copper in every glass of water.
ADVANCED 7 STAGE PURIFICATION WITH RO+UV+MF
That ensures 100% RO purified water.
DOUBLE PURITY LOCK
Digital Advance Alert System, alerts you 15 days** before life of the Germkill
Kit gets over and Auto Shut off stops water if filter is not changed, providing
100% gurantee of safe and sweet water.
LARGE STORAGE CAPACITY
Upto 8 litres^storage capacity of purified water so that you never run out of
RO water.
ECO RECOVERY™ TECHNOLOGY
Delivers efficient purification to give a high water recovery rate of up to 60%.
100 % FOOD GRADE PLASTIC*
Prevents harmful toxins from leaching into water.
UNITED STATES ENVIRONMENT PROTECTION AGENCY
(USEPA) COMPLIANT
Meets the toughest safety standards by removing 1 crore virus and 10 crore
bacteria from 1litre water.
%
%
%%%
%
7
8

Disposal Guidelines (Electrical): To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate electrical items in this product such as power supply adaptor, control circuits, LED panel,
and wiring from other types of waste and recycle them responsibly to promote sustainable use of material resources.
Contact either the retailer where you purchased this product, or local government office for details of where and
how these items can be taken for environmentally safe recycling.
INSTALLING YOUR PUREIT
COPPER+ECO MINERAL RO+UV+MF
CLEANING AND MAINTENANCE
TAKING CARE OF PUREIT
COPPER+ECO MINERAL RO+UV+MF
1. Use only the plug provided with the purifier
2. The purifier should not be connected to any hot water tap. Do not run hot water
over 45°C through the purifier
3. Make sure that the power is kept on to dispense the water. Press the Touch
button to dispense water from the storage tank.
4. Water from waste water tube is not suitable for drinking. You can use that water
for gardening or cleaning floors.
5. Store water only in the purifier and don't use bottles and containers. If you do
so, water may get contaminated.
RECOMMENDATIONS/CAUTIONS:
1. Discard first glass of RO water when dispensed immediately after dispensing
Copper RO water, to avoid any traces of Copper in RO water.
2. Doctor's advice is recommended for Consumption of more than 30% RDA
equivalent Copper RO water in adults.
3. Elders kindly moderate consumption of Copper RO water for children.
4. Stop using the Copper RO water if you feel any change in taste / discomfort &
call Pureit call centre to inspect the device.
5. Consult your doctor, if you are sensitive to copper water.
1. The purifier should be installed by a trained Pureit technician
2. It can be wall-mounted or used as a table top purifier
3. The purifier should be placed in area which is free of ants/insects/other pests.
4. The purifier should be placed close to the plumbed inlet connection
(not more than 2 metres).
5. Do not install the purifier above any electric socket
6. Avoid sharp bends to the pipes of the product
7. Do not use an extension cord
8. Make sure you test the input water TDS (Total dissolved salts) before installing
the purifier. The maximum input TDS should not exceed 2000 PPM.
Water Dispensing
Point
1. Do not use detergents, soap or wet cloth to clean the external parts. Use dry and soft
cloth to clean the front cover. It is recommended to use a 3M mop cloth for cleaning.
2. Clean the dispenser by using disinfectants like bleach/hypochlorite (50 PPM available
chlorine). Discard 2 litres of water after cleaning the dispenser.
3. Discard water from detachable tray & maintain in dry condition.
Storage Tank
1. Discard the water in the storage tank once in 15 days.
2. Drain the water in the storage tank if purifier is not used for 2 days.
3. Clean the storage tank once a month with disinfectant solution. To purchase this
solution, call us at 1860-210-1000 now.
4. How to clean the tank: Open the cleaning solution dispenser and put 1 ml of the
disinfectant solution (10–15 drops) into the storage tank. (Ensure the tank is full).
Drain the entire tank after 10 minutes.
5. No foreign material (like dust/ants/insects/other pests) should enter the storage tank.
The filtered water in the storage tank may deteriorate in the process.
6. The point-of-use reverse osmosis drinking water treatment systems addressed by
NSF-58
standard are designed to be used for the reduction of specific substances that may
be present in drinking water supplies (public or private) which are considered to be
microbiologically safe and are of known quality.
7. The output water may continue to have flora which are harmless and pose no health
hazard to normal healthy adults and children.
3

KEEP YOURSELF SAFE CLEANING AND MAINTENANCE
1. Do not open the purifier for cleaning or for any replacements. This can be done
only by a qualified company personnel or an authorized agent.
2. Do not plug or unplug the power cord with wet hands to avoid any untoward
accident due to electrical shock or fire.
3. Do not splash the filtration system with water while cleaning.
4. Do not put heavy or sharp objects on the purifier.
5. Never put the cord near stoves or heaters.
6. If the power cord is damaged, it must be replaced and not used again.
7. Always switch-off the “Ball Valve” and electrical power in case you notice any
leakage from the purifier or you are going out of home for more than 2 days.
8. Ensure input pressure is more than 10 PSI and less than 30 PSI ***
9. In case UV lamp breaks, carefully sweep all the fragments, wipe the area with a
wet towel, and dispose all the fragments including the used towel in a sealed
plastic bag. Open windows to allow room to ventilate. Do not use vacuum
cleaner. Hand over the bag to the service technician for proper disposal of the
same when he visits to replace UV lamp.
10.In case of any smoke or burning smell, switch-off power, remove the plug
immediately and call us at 1860-210-1000.
•
P
U
R
E
I
T
C
U
S
T
O
M
E
R
C
A
R
E
N
O
•
*** If the pressure is more than 30 PSI, you need to use ‘Pressure reducing Valve’ which must be bought at an
additional cost. If the pressure is less than 10 PSI then you need to buy ‘Pressure enhancing Pump’ which can
be bought at an additional cost.
Ensure you buy them from the authorized service personnel of Pureit.
ATTENTION
• Close the ball valve before opening SF housing for cleaning.
• Please do not use any abrasive / pointed tool to clean the Sediment
Filter as it may damage the Sediment Filter.
• In case you observe the rubber ring is dirty, clean the rubber ring &
fix it on the housing again properly.
• Clean the inner portion of the housing as well.
• If required, a Spanner for opening ESF housing can be bought from
Pureit service technician.
SF (Sediment Filter)
STEP 1 :
Close the ball valve
before opening ESF
housing for cleaning
STEP 5 :
Clean the Sediment Filter
under jet of water,
rub by hand / tap gently
to clean
STEP 6 :
After cleaning the Filter,
put it back in the housing
and then put the grey
coloured Carbon Sleeve
back into the housing
STEP 8 :
Connect the water
inlet tube to the housing
STEP 2 :
Remove the water
inlet tube which is
attached to the housing
STEP 3 :
Rotate the housing
clock-wise and remove it
completely from the cap
STEP 4 :
Take out the grey
coloured Carbon Sleeve
and the Sediment Filter
from the housing
STEP 7 :
Insert the housing inside
the cap and rotate it
anticlockwise to engage
the threads Ensure the
housing is tightened till
it’s original marking
4

TECHNICAL SPECIFICATIONS
^While the Germkill Kit and the Sediment Filter have a fixed replacement schedule, you might be required to clean/change
the SF in the interim depending on the quality of your input water. If the External Sediment Filter is not replaced/cleaned
in time (when the blue blinking happens), it may affect the performance of the purifier. Blinking for sediment filter will
occur to clean/replace sediment filter after approximately 132 hours of pump running time. You can either clean SF or call
Pureit helpline to replace filters at a nominal cost.
* Permeate flow rate and recovery are based on standard test conditions and may vary depending on input water quality,
TDS, pressure and life of Filter elements.
*** Input water quality and TDS content are important determinants of output water quality.
**** If input pressure exceeds 30 PSI, please install a company provided pressure reducing valve at an additional cost. If
the pressure is lesser than 10 PSI then you need to buy ‘Pressure enhancing pump’ at an additional cost. Device should
not be installed in a house where input pressure is greater than 60 psi.
###After every 275 hours of pump running time the Germkill Kit needs to be changed. Every 275 hours of pump running
time typically gives 6000 liters of purified water under test conditions of 10 PSI input pressure, 750 ppm TDS and 25 °C
temperature. Any variations from the test conditions will lead to variations in the filtered life.
#### Every 78 hours of Cu Valve running time typically gives 8000 liters of copper enriched water under ideal condition
(10 PSI input pressure, 750 ppm TDS and 25°C temperature).
# Technical specifications are subject to change or improvement without prior notice.
> In case the TDS is >1000 PPM, a company provided anti-scalant is recommended to be installed. This has to be
purchased at extra cost.
>>If the iron content in the input water is more, it is recommended to install a company provided iron filter at an
additional cost.
$ 7.6 to 8 litres in running water conditions. 5
Pureit Copper+Mineral RO+UV+MF
Height ~447 mm
Width ~350 mm
Depth ~361 mm
Weight ~9.5 kg
Flow rate* Up to 24 litres per hour
Storage tank capacity Upto 8 litres$
7 -Stage Purifying Technology
Membrane type
Pump type Diaphragm pump, 24V dc
Thin-film composite spiral wound
% Recovery* Typically 60%
TDS reduction*** 90% (min)
Input water pH range pH range 6.5-8.5, Temperature range 10°C- 40°C
Rated Power 60 Watts
Pressure rating 10-30 PSI****
Rated Voltage 100-240V AC 50/60 Hz (Device can withstand voltage
fluctuation from 100 to 300 V AC.)
Material of construction for plastic parts Food safe, non-toxic, engineering grade plastics
Length of Power Cord 1.5 metres
Total Dissolved Solids Upto 2000 mg/lit
Total hardness 500 mg/lit (max.)
Iron 0.3 mg/lit (max.)
Turbidity 1NTU (max.)
Germkill Kit™
Material of construction Food safe, non-toxic, engineering-grade plastics
Copper Germkill Kit™ Copper Module with Harness – 1 Nos
Germkill Kit™
Pre-Sediment Filter – 1 Number Pre-RO Carbon Filter – 1 Number
Mesh Filter – 1 Number Post-RO Carbon Filter – 1 Number
Mineral Cartridge – 1 Number MF Membrane – 1 Number
RO Membrane – 1 Number
Anti-Scalant Cartridge – 1 Number
PP Melt Blown Pre-Sediment Filter, Pre-RO Carbon Filter,
Mesh Filter, Reverse Osmosis Membrane, UV Reactor,
Post-RO Carbon Filter and Micro Filter Membrane
Germkill performance standard Meets stringent international criteria for
microbiologically safe drinking water – e.g.,
Environmental Protection Agency (EPA), USA
3. COPPER CHANGE
SOLID GREEN
Copper is safe to use
RED BLINKING
Advance alert to change Copper
After every 77Hours and 50 minutes
of Copper DSV running time post
device installation or Copper
replacement.
RED SOLID
Auto-shut off, replace Copper
GKK.
After every 78 hours#### of
Copper DSV running time, post
device installation or Copper GKK
replacement.
RED, BLUE, GREEN
BLINKING IN SEQUENCE
Electric Fault
4. COPPER RO WATER
YELLOW SOLID
Copper RO water is dispensing
YELLOW BLINKING
Auto-Cleaning Mode,
water cannot be dispensed
RED SOLID
Fault, water cannot be dispensed
5. RO WATER
BLUE SOLID
RO water is dispensing
RED SOLID
Fault, water cannot be dispensed
1. TANK FULL
SOLID GREEN
Tank full
SOLID RED
Low / No input water
2. SF / GKK CHANGE
SOLID GREEN
SF / GKK is safe to use
BLUE BLINKING
Replace / clean SF^
RED BLINKING
Advance alert to replace GKK
After every 260 hours of pump
running time, post device installation
or GKK replacement.
RED SOLID
Auto-shut off, replace GKK
After every 275 hours### of pump
running time, post-device installation
or GKK replacement.
LED INDICATOR GUIDE

FAQ S
Pureit Helpline
1860-210-1000
www.pureitwater.com
How does Pureit Copper+Eco Mineral
RO+UV+MF work?
Pureit Copper+Eco Mineral RO+UV+MF has a
7 stage purification system that ensures you get
‘Safer than boiled waterTM’. It also removes
excess total dissolved salts (TDS) to make the
water tastier.
What is the storage capacity of Pureit Copper+
Eco Mineral RO+UV+MF?
Pureit Copper+ Eco Mineral RO+UV+MF has a
storage tank capacity of upto 8 Litres under
running water. The process of filling the storage
tank is fully automatic. When you take water out
of the tank the purification process automatical-
ly refills the storage tank.
How much time it takes to purify water in Pureit
Copper+ Eco Mineral RO+UV+MF?
Pureit Copper+ Eco Mineral RO+UV+MF can
purify water upto 24 litres per hour. However,
the time taken to purify is influenced by life of
the filters, the input water pressure, and other
impurities present in water.
How will I get new Consumables/Membranes
and Copper module replaced?
You need to call the Pureit Helpline and order
for a Germkill Kit™. A technician will visit your
place to replace it, at a nominal cost.
Can I drink the first purification cycle of water
from the purifier?
After Pureit Copper+ Eco Mineral RO+UV+MF
is installed or whenever the Germkill Kit™ (s)
are replaced, discard the first cycle of water (8
litres) that is filled in the storage tank.
What should I do if there is no water being
dispensed from the spout?
In case you cannot dispense water from the
spout, first check whether the power supply is
on. If it is on, then check if there are any fault
indicators on, or “SF/GKK” indicator is blinking.
Get either the fault resolved or Germkill Kit™
replaced. If none of these indicators are lit up
on the indicator panel, then check if the ball
valve is closed. If none of these cases are true,
then please call Pureit helpline for assistance.
Can I open and service my purifier?
It is not recommended to open and service the
device yourself. Call the Pureit helpline if you
face any issue which requires servicing and
opening the device.
Can I use any type of water to purify through
my Pureit Copper+ Eco Mineral RO+UV+MF?
Pureit Copper+ Eco Mineral RO+UV+MF will
purify “potable” water for removal of hardness
and other impurities to give you safe drinking
water. If the input water has impurities normally
not present in drinking water (high iron/
turbidity/ microbial contamination etc.) or water
is from unknown source (river/lake/pond/bore-
well etc.) then suitable pre-treatment may be
required.
The Advance Alert System™ did not give me 15
days warning before the purifier stopped
working. Why is it so?
There may be several reasons for this: While
the Germkill Kits and the Pre-Sediment Filter
have a pre-determined life, depending on your
input water quality the Pre-Sediment Filter
might need a replacement/cleaning even before
the purifier gives you an alert. In such cases,
please contact Pureit helpline and get the
Pre-Sediment Filter replaced/cleaned. The
purifier will communicate the alert only if the
purifier is in a switched on condition during the
scheduled alert time. Post the completion of the
scheduled alert time, Auto Shut off™ of water
will be activated automatically for GKK.
Does Pureit Copper+ Eco Mineral RO+UV+MF
remove arsenic, fluoride and nitrates?
Yes. RO technology can remove arsenic,
fluoride and nitrates.
Can I use the reject water?
It is not recommended to use rejected water for
any kind of consumption (drinking or cooking). It
can probably be used for gardening or floor
cleaning.
What should I do if any part of the purifier is
broken?
Please call Pureit helpline to guide you on any
repairs required. You might need to buy the
replacement parts at an additional cost.
What should I do if there is a leakage from the
purifier?
Turn off the ball valve and switch off the power,
if you find any failure. Check for any visually
improper fitment and then call Pureit helpline
and register a service request.
How long the stored water in Pureit Copper+ Eco
Mineral RO+UV+MF can be used for drinking?
It is recommended for the stored water to be
consumed within 2 days. Water stored for over
2 days should ideally be discarded.
How do I know when I have to change my
Germkill Kit™?
Pureit Copper+ Eco Mineral RO+UV+MF has
an indicator panel with SF/GKK indicator that
will blink to prompt you to call the Pureit
helpline to get the respective GKK changed,
whenever the life of the Germkill Kit™ is near
expiry (refer to “Understanding LED indicator
panel” section of this user manual for further
details).
Can the Pre-Sediment Filter or the other filter
parts choke before the Advance Alert ?
While the Germkill Kit™ and the Pre-Sediment
Filter have a pre determined life, you might be
required to change the filters in the interim
depending on the quality of your input water.
Should the tap flow rate be very low or if it is
taking too long for the tank to fill, then please
contact the Pureit helpline to change the
membranes. These extra visits will be
chargeable as per T&C.
For how long can I continuously dispense water?
Once the Soft-Touch button is pressed water
dispenses for 3 minutes ( 2 minutes if in Warning/
ASO/Fault condition) and it automatically stops
dispensing after that. In case you need more
water, you need to press the button again. You
can stop the flow of water in between by pressing
the Soft-Touch button again.
Will the Guided Alert System indicate any leakage
complaints?
No. It only indicates key electrical faults.
How can I clean my Pureit Copper+ Eco Mineral
RO+UV+MF?
To clean the device body clean dry or wet
wiping with 3M foam mop/cloth is recommend-
ed. Do not spray water on the device front
cover as it may damage the electronic part. Do
not use soap or hard cleaning detergents.
What should I do if the water from the purifier
tastes unusual or the purification is taking
more time?
Please call the Pureit helpline. A technician will
visit you to help resolve the issue.
What should I do if the copper charged RO water
is not dispensing?
Please check if the Copper RO Water LED is
blinking yellow, if yes then please do wait as
device is in Copper Auto-Cleaning Mode. Once
the auto-cleaning process is complete you can
dispense Copper RO water by pressing the
Soft-Touch button. If the copper LED is red, it
will not allow dispensing. In such a case check
for presence of water from the main line, wait
for sometime, then switch off and switch on the
purifier again. If the LED is still red, then contact
Pureit helpline.
Can I dispense water in the absence of electricity?
Depending on the amount of water already filled
in the tank, you can dispense upto 8 litres of
water even without electricity when tank is full
by installing manual tap as spare by an
authorized service technician. However, Copper
RO water can be dispensed only with electricity
as Copper is infused in real time.
Does Pureit copper water boost immune system?
Consumption of 2 liters of copper charged RO
water every day, will add up to approximately
30% of the RDA for copper( for adults, as
guided by the Indian Council of Medical
Research, ICMR). Copper helps to boost
immunity for individuals with deficiency of
copper.
What are signs of a weak immune system?
Frequently falling sick with signs of inflections
are some of the indications of weak immune
system.

To know more
Contact Pureit helpline number
1860 210 1000
Or Visit: www.pureitwater.com
