Above All MT Series User manual

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
SUITABLE FOR MODEL
IMAGE MAY VARY FROM ACTUAL PRODUCT
1
WIRE CONNECTION
Only For 300W AR
SAFETY INSTRUCTION
Maintenance Caution
READ CAREFULLY BEFORE INSTALLING FIXTURE. PLEASE KEEP THIS MANUAL FOR FUTURE USE.
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper grounding
is required for safety.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
MAKE CERTAIN POWER IS OFF BEFORE INSTALLING OR MAINTAINING FIXTURE.
CHECK THAT VOLTAGE IS COMPATIBLE WITH FIXTURE DRIVER. USE APPROVED CONNECTORS FOR
ALL ELECTRICAL CONNECTIONS.
1. Review the wire connection before beginning, and make sure xture is grounded properly.
2. For lighting controls, follow control instructions carefully.
3. Turn power off and wait for xture to cool before performing maintenance.
4. Maintenance must be done by professionals.
For TR&SF 100W/150W/200W/300W

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
For MS-AR&PC-AR 300W For AR 100W/150W/200W
For MS-TR/PC-TR/MS-SF/PC-SF
100W/150W/200W/300W
For MS-AR&PC-AR 100W/150W/200W
2

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
INSTALLATION
1. Open the side cover , take the wires out of the Place ①and connect the wires. Dress the wire terminals inside the round
2. Insert the luminaire into the pole and tighten Set Screws.
Follow the appropriate installation instructions based on your selected mounting method:
b. Trunnion Mounting
c. Square Pole Arm Mounting
d. Round Pole Arm Mounting
e. Square Pole Extended Arm Mounting
WARNING
Risk of injury or damage. Unit will fall if not installed properly. Follow installation instructions.
Figure 1
Place ①
Set Screws
Suitable for 2-3/8″ round pole
3
Installation convenient rings should
be used with UNC #5/16-18, the
depth of thread no longer than 1"
Installation convenient rings should
be used with UNC #5/16-18, the
depth of thread no longer than 1"

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
WARNING
Under no conditions should sliptter bolts be torqued to a level from 25 to 32 foot pounds.
Figure 3
SPECIFIED DIMENSION
Max 45°
Figure 2
4

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
b. Trunnion Mounting
UNC 3/8-16 bolt
UNC 3/8-16 bolt
Curve washer
Flat washer
Figure 4 Figure 5
DRILLING TEMPLATE TRUNNION MOUNTING
UNC 3/8-16 Expansion screw
1. Drilling the holes in accordance with Figure 5.
2. Attach the luminaire to the installation place and tighten the bolts
3. Adjust the angle to an appropriate angle.
Figure 6
ADJUSTABLE ANGLE :-100°~100°(Spacing angle for 10°)
Figure 7
WARNING
Under no conditions should trunnion bolts be torqued to a level from 25 to 32 foot pounds.
5

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
c. Square Pole Arm Mounting
with Figure 8.
2 Places
Figure 8
DRILLING TEMPLATE SQUARE POLE MOUNTING
4 to 6 inch OD Square Pole Mounting Pole
1. Unscrew the arm cover, and connect the wires in the arm.
3. Tighten the screws, dress the wire terminals inside the arm and screw the arm cover.
6
Figure 9
Figure 10

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
d. Round Pole Arm Mounting
Figure 11.
2 Places
Figure 11
DRILLING TEMPLATE ROUND POLE MOUNTING
4 inch OD Round Pole Mounting Pole
1. Unscrew the arm cover, and connect the wires in the arm.
curve washers and nuts in the round pole.
3. Tighten the screws, dress the wire terminals inside the arm and screw the arm cover.
7
Figure 12
Figure 13

LED MT AREA LIGHT / FLOOD LIGHT
Instruction Manual
Add: 1501 Industrial Way N. Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.aboveallLighting.com ©2016 ABOVE ALL, Inc. All rights reserved
Ref#: 10978-21101
e. Square Pole Extended Arm Mounting
Only suitable for 2 pcs of 300W luminaires installed as 90° on the pole.
-
cordance with Figure 11.
2 Places
Figure 11
DRILLING TEMPLATE SQUARE POLE MOUNTING
4 to 6 inch OD Square Pole Mounting Pole
1. Unscrew the arm cover, and connect the wires in the arm.
curve washers and nuts in the square pole.
3. Tighten the screws, dress the wire terminals inside the arm and screw the arm cover.
8
300W luminaire
MT-Flat 3.15″ Extended Arm
MT-Flat
3.15″ Extended Arm Pole
300W luminaire
Figure 15
Figure 14
MT-Flat 3.15" Extended Arm
(sku 90047)
