Above All ACORN LED POST TOP User manual

WIRE CONNECTION
Universal voltage driver permits operation at
120VAC thru 277VAC, 50 or 60 Hz.
INSTALLATION
Add: 1501 Industrial Way N, Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.AboveAllLighting.com ©2016 ABOVE ALL Lighting, Inc. All rights reserved
THE ACORN LED POST TOP (VPTA)
Instructions Manual
SUITABLE FOR MODEL
1
MAINTENANCE CAUTION
1. Review the wire connection before beginning, and make sure xture is grounded properly.
2. For lighting controls, follow control instructions carefully.
3. Turn power off and wait for xture to cool before performing maintenance.
4. Maintenance must be done by professionals.
SAFETY INSTRUCTION
READ CAREFULLY BEFORE INSTALLING FIXTURE. PLEASE KEEP THIS MANUAL FOR FUTURE USE.
Fixtures must be wired in accordance with the National Electrical Code and all applicable local codes. Proper grounding
is required for safety.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
MAKE CERTAIN POWER IS OFF BEFORE INSTALLING OR MAINTAINING FIXTURE.
CHECK THAT VOLTAGE IS COMPATIBLE WITH FIXTURE DRIVER. USE APPROVED CONNECTORS FOR ALL
ELECTRICAL CONNECTIONS.
Note: If fxture is furnished with photocell receptacle,
please make sure install the photocell or shorting cap
ACCESSORY PACK
WIRE NUT X 3
PHOTOCELL X 1
SHORTING CAP X 1
ACCESSORY PACK FOR PHOTOCELL
ACCESSORY PACK FOR 7 PIN

7 PIN PHOTOCONTROL ORIENTATION
The orientation need to be done if the indicator arrow
doesn’t points north.
1. Loosen the two screws.
2. Rotate the center of the receptacle with a screw driver
until the indicator arrow points north.
3. Retighten the two screws.
4. Match the Pins with correct sockets and insert the
photoelectric control ( not included) or shorting cap in
receptacle.
5. Twist the photoelectric control (not included)
clockwise into locking position.
Face to North
Add: 1501 Industrial Way N, Toms River, NJ 08755 Phone: [phone] E-mail: [email protected]
Web: www.AboveAllLighting.com ©2016 ABOVE ALL Lighting, Inc. All rights reserved
THE ACORN LED POST TOP (VPTA)
Instructions Manual
2
POLE MOUNT
1. Remove the Decorative Final and Gasket A
and keep them for use later.
2. Screw the Rod in the luminaire together with
the Adapter and Gasket B.
3. Put the Acorn Shade on the luminare and
secure the Decorative Final. Make sure the
Gasket A is between the shade and nal.
4. Make wire connection with supplied wire
nuts and make waterproof treatment by
others in a tenon or pole per “Electrical
Connections”
5. Slip the xture onto a tenon or pole with
diameter of 2 3/8’’ and rotate the xture to
desired orientation.
6. Tighten all set screws (6).
Set Screw
Pole ø23/8”
Decorative Finial
Acorn Shade
Luminaire
Gasket A
Rod
Adapter
Gasket B
Set Screw
WARNING
1. Risk of injury or damage. Make certain power is OFF before installing or maintaining
xture.
2. If xture is furnished with photocell receptacle, install the photocell or shorting cap.
Ref#:14308-10923
L
N
BLACK:L
WHITE:N
GREEN:GND
