Absolute Process Instruments IsoSplitter APD 4930 User manual

Options—add to end of model number
M19 Channel 1 high voltage output (>10 to 20 VDC max.)
M29 Channel 2 high voltage output (>10 to 20 VDC max.)
M39 Channel 1 and channel 2 high voltage output (>10 to
20 VDC max.)
EXT1 Sinking mA output channel 1
EXT2 Sinking mA output channel 2
EXT3 Sinking mA output channel 1 and 2
UConformal coating for moisture resistance
Accessory—order as separate line item
API BP4 Spare 4-terminal plug, black
Model Input Output Power
APD 4930 Factory configured
specify input range and type
Factory configured
specify output ranges and type for
channel 1 and channel 2
85-265 VAC or 60-300 VDC
APD 4930 D 9-30 VDC or 10-32 VAC
Description
The APD 4930 IsoSplitter accepts a DC voltage or current
input and provides two optically isolated DC voltage or current
outputs that are linearly related to the input. The input range
and each output range are independent and can be specified as
required. This provides an economical solution when one signal
must be sent to two different devices.
Typical applications include isolation, output splitting, output
device separation and redundancy (i.e. to prevent failure of
the entire loop if one device fails), or a combination of these.
The input signal is filtered, amplified, split, and then passed
through an opto-coupler to the output stages. Full 4-way isola-
tion (input, output 1, output 2, power) make this module useful
for ground loop elimination, common mode signal rejection,
and noise pickup reduction.
Independent Outputs
Each output channel is factory ranged to your specifications
and provides an optically isolated DC voltage or current output
that is linearly related to the input. Sourcing mA outputs are
standard. Sinking milliamp or high voltage outputs are optional.
Isolation
The full 4-way (input, output 1, output 2, power) isolation
makes this module useful for ground loop elimination, common
mode signal rejection or noise pickup reduction.
LoopTracker
API exclusive features include two LoopTracker LEDs (one for
each output channel) that vary in intensity with changes in the
process output signals. These provide a quick visual picture of
your process loop at all times and can greatly aid in saving time
during initial startup and/or troubleshooting.
DC Input Range
Factory configured, please specify input range or consult fac-
tory for special ranges.
Voltage: 0-100 mVDC to 0-300 VDC
Bipolar voltage: ±100 mVDC to ±10 VDC
Current: 0-1 mADC to 0-1000 mADC
Input Impedance and Burden
Voltage: 200 kΩminimum
Current: 50 Ωtypical
Voltage burden: 1.25 VDC max. at 20 mA current input
Input Loop Power Supply
15 VDC ±10%, regulated, 25 mADC
May be selectively wired for sinking or sourcing mA input
LoopTracker
Variable brightness LEDs indicate output loop level and status
One red LED for each output
Channel 1 and Channel 2 DC Output Ranges
Factory configured, please specify for each output channel
Outputs are independent and do not need to be the same
Voltage: 0-1 VDC to 0-10 VDC, 10 mA max
Up to 20 VDC with M19, M29, M39
Bipolar voltage: ±1 VDC to ±10 VDC
Current: 0-1 mADC to 0-20 mADC, 4-20 mADC
20 V compliance, 1000 Ωat 20 mA
Output Calibration
Multi-turn zero and span potentiometers for each output channel
±15% of span adjustment range typical
Output Loop Power Supplies
20 VDC nominal, regulated, 25 mADC for each output channel
May be selectively ordered for sinking mA output
Output Test/Manual Override
Terminals for customer-supplied external contacts to manu-
ally set output levels for each channel
Output test level factory set to 50 % of span
Specify if special output percentage levels are required
Output Ripple and Noise
Less than 10 mVRMS ripple and noise
Linearity
Better than ±0.1% of span
Ambient Temperature Range and Stability
–10°C to +60°C operating ambient
Better than ±0.04% of span per °C stability
Response Time
70 milliseconds nominal
Isolation
Full 4-way, 1200 VRMS minimum
Installation Environment
IP 40, requires installation in panel or enclosure with ade-
quate ventilation
For use in Pollution Degree 2 Environment
Mount vertically (as shown in picture) to a 35 mm DIN rail
allowing minimum 1" (25 mm) above and below housing
vents for air circulation
Power
85-265 VAC, 50/60 Hz or 60-300 VDC, 6 W maximum
D versions: 9-30 VDC or 10-32 VAC 50/60 Hz, 6 W maximum
Dimensions and Connectors
0.89" W x 4.62" H x 4.81" D
22.5 mm W x 117 mm H x 122 mm D
Four 4-terminal removable connectors, 14 AWG max wire size
Removable Plugs
2 Output Channels;
Voltage or mA with
Sink or Source Options
Output LoopTracker
LED
Zero and Span for
Each Output
Custom I/O Ranges
DC Input: Voltage or
Sink/Source mA
IsoSplitter
®DC to DC Signal Splitter/Isolator/Transmitter, Factory Configured APD 4930
1 Input: 0-100 mV to 0-300 V, ±100 mV to ±10 V, 0-1 mA to 0-1000 mA, 4-20 mA
2 Outputs: 0-1 V to 0-10 V, optional up to 20 V, ±1 V to ±10 V, 0-1 mA to 20 mA, 4-20 mA
OOne Input to Two Outputs with Full Isolation
OZero and Span Output Calibration Potentiometers
OFull 1200 V Input/Output /Power Isolation
OOutput LoopTracker®LEDs
OOutput Test/Manual Override for Each Channel
OBuilt-In Loop Power Supply for Sink/Source Input
QSplit, Convert, Boost, and Rescale Process Signals
QSplit Process Signals for Control and Validation
QInterface a Process Signal with Multiple Panel Meters,
PLCs, Recorders, Data Acq., DCS, & SCADA Systems
Applications
1 2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
See Wiring
Diagrams on
Next Page
© 08-20
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
Quick Link: api-usa.com/4930
Universal
Power
Free Factory
I/O Setup!
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
Made in USA
Applications Link
api-usa.com/apps
Pb Lead
Free

Precautions
WARNING! All wiring must be performed by a qualified electri-
cian or instrumentation engineer. See diagram for terminal
designations and wiring examples. Consult factory for assis-
tance.
WARNING! Avoid shock hazards! Turn signal input, output, and
power off before connecting or disconnecting wiring, or remov-
ing or installing module.
Précautions
ATTENTION! Tout le câblage doit être effectué par un élec-
tricien ou ingénieur en instrumentation qualifié. Voir le dia-
gramme pour désignations des bornes et des exemples de
câblage. Consulter l'usine pour assistance.
ATTENTION! Éviter les risques de choc! Fermez le signal
d'entrée, le signal de sortie et l'alimentation électrique avant
de connecter ou de déconnecter le câblage, ou de retirer ou
d'installer le module.
Ranges
See the model/serial number label for information, options, and
I/O range information. The voltage and/or milliamp I/O ranges
are factory set for each channel to your exact specifications.
Electrical Connections
See wiring diagrams at right. Observe polarity. If the output
does not function, check wiring and polarity.
*Do not make any connections to unused terminals or use
them as wiring junctions for external devices. This may cause
permanent damage to the module!
Signal Input Terminals
Polarity must be observed when connecting the signal input.
Terminal 3 provides 20 VDC to power a passive mA transmitter
if required.
The APD 4930 splits and converts a single input signal into two
outputs. See the wiring diagrams at right.
Signal Output Terminals
Polarity must be observed when connecting the signal outputs.
See the module label for the voltage or milliamp output range
for each channel. The standard milliamp output is sourcing. It
provides 20 VDC power to your device.
Optional sinking mA output(s) will be indicated on the module
label as EXT1 for channel 1, EXT2 for channel 2, or EXT3 for
both channel 1 and channel 2.
If the output does not function, check wiring and polarity for
both input and outputs. See note about terminating an unused
mA output channel.
Module Power Terminals
Check model/serial number label for module operating voltage
to make sure it matches available power. The power supply
is fuse protected and the unit may be returned to API for fuse
replacement.
When using DC power, either polarity is acceptable, but for
consistency with similar API products, positive (+) can be wired
to terminal 13 and negative (–) can be wired to terminal 16.
Mounting to a DIN Rail
Install module vertically on a 35 mm DIN rail in a protective
enclosure away from heat sources. Do not block air flow. Allow
1" (25 mm) above and below housing vents for air circulation.
1. Tilt front of module downward and position against DIN rail.
2. Clip lower mount to bottom edge of DIN rail.
3. Push front of module upward until upper
mount snaps into place.
Removal
1. Push up on the bottom back of the module.
2. Tilt front of mod-
ule downward
to release upper
mount from top
edge of DIN rail.
3. The module can
now be removed
from the DIN rail.
Calibration
Input and output ranges are pre-configured at the factory (at
24°C ±1°C) as specified on your order. Front-mounted, Zero
and Span potentiometers for each channel can be used to
calibrate the output to compensate for load and lead variations.
1. Apply power to the module and allow a minimum 20 minute
warm up time.
2. Using an accurate calibration source, provide an input to
the module equal to the minimum input required for the
application.
3. Using an accurate measurement device for the output,
adjust the Zero potentiometer for the exact minimum output
desired. The Zero control should only be adjusted when the
input signal is at its minimum. This will produce the cor-
responding minimum output signal. For example: 4 mA for
a 4-20 mA output or –10 V for a ±10V output.
4. Next, set the input at maximum, then adjust the Span pot for
the exact maximum output desired. The Span control should
only be adjusted when the input signal is at its maximum.
This will produce the corresponding maximum output
signal. Example: for 4-20 mA output, the Span control will
provide adjustment for the 20 mA or high end of the signal.
5. Repeat adjustments for maximum accuracy.
Operation
The APD 4930 is factory configured to your exact input and
output requirements. The voltage or milliamp input is filtered,
either amplified or attenuated as required, then passed through
an optical coupler to the output stage.
A red LoopTracker output LED provides a visual indication that
the output signal is functioning for each channel. It becomes
brighter as the input and the corresponding output change from
minimum to maximum.
For current outputs, the red LED will only light if the output loop
current path is complete. For either current or voltage outputs,
failure to illuminate or a failure to change in intensity as the
process changes may indicate a problem with the module
power or signal output wiring.
Terminal Identification
Installation and Setup APD 4930
109 11 12
– +– +
Voltage
Device 2
Voltage
Device 1
Output 1
Voltage output
Output 2
Voltage output
Output 1
Sinking mA output
with EXT1 or EXT3 option
Output 2
Sinking mA output
with EXT2 or EXT3 option
109 11 12
– +– +
Powered
mA
Device 2
Powered
mA
Device 1
Output 1
Sourcing mA output
+20 V at terminal 10
Output 2
Sourcing mA output
+20 V at terminal 12
109 11 12
–
Passive
mA
Device 2
Passive
mA
Device 1
+20 V
–
+20 V
To maintain full isolation avoid combining power supplies in
common with input, outputs, or unit power.
* Do not make connections to unused terminals!
13 Power AC or DC +
14 Earth Ground
16 Power AC or DC –
1413 15 16
Cu 60/75°C
conductors
14 AWG max.
65 7 8
Customer-supplied
external contacts for
Output Test Function
Switch closure sets output
to approx. 50% of span
Channel 1 Channel 2
Output 1 Span
Output 1 Zero
Output 2 Span
Output 2 Zero
Voltage Input 21 3 4
+ –
Voltage
Xmtr
2134
– +20V
Current Sourcing Input
+20 V at terminal 3
Passive
mA
Xmtr Ri
Current Sinking Input
with powered mA Xmtr
Loop
Power
Source
–
+
21 3 4
+ –
mA
Xmtr
Ri
+ –
21 3 4
+ –
Current Sinking Input with
External Loop Supply
mA
Xmtr
Ri
Loop
Power
Source
– +
+ –
Spring Clip
Upper Mount
Lower Mount
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
API maintains a constant effort to upgrade and improve its products.
Specifications are subject to change without notice. See api-usa.com for
latest product information. Consult factory for your specific requirements.
WARNING: This product can expose you to chemicals includ-
ing nickel, which are known to the State of California to cause
cancer or birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
*Module
powers mA
output loop
*Module mA
output is
unpowered
EXT1= Ch1
EXT2= Ch2
EXT3= both
Module powers
mA input loop
Module mA input is
unpowered
12 3 4
5 6 7 8
9 10 11 12
13 14 15 16
Input
Remote Test
Outputs
Power
Wire terminal
torque
0.5 to 0.6 Nm or
4.4 to 5.3 in-lbs
* To avoid damage to the module, do not leave any unused
mA outputs disconnected. Use a 1000 Ohm 1/2 Watt resis-
tor across terminals 9 & 10 or 11 & 12 if any are not being
used.
* Do not make
connections to
unused terminals!
* Do not make
connections to
unused terminals!
Output
Loop
Tracker
APD 4930
1 DC in to 2 DC out
Isolated Transmitter
Loop
Tracker
Span 2
Zero 2
Output
Span 1
Zero 1
