Absolute Process Instruments IsoSplitter APD 6393 User manual

IsoSplitter
®AC to DC Signal Splitter/Isolator/Transmitter, Factory Configured APD 6393
1 Input: True RMS 0-50 mVAC to 0-300 VAC, 0-1 mAAC to 0-1000 mAAC
2 Outputs: 0-1 V to 0-10 V, ±1 V to ±10 V, 0-1 mA to 20 mA, 4-20 mA
OOne Input to Two Outputs with Full Isolation
OZero and Span Output Calibration Potentiometers
OFull 1200 V Input/Output /Power Isolation
OInput and Output LoopTracker®LEDs
OOutput Test Button for Each Channel
OBuilt-In Loop Power Supplies for Sink/Source I/O
QSplit, Convert, Boost, and Rescale Process Signals
QSplit Process Signals for Control and Validation
QInterface a Process Signal with Multiple Panel Meters,
PLCs, Recorders, Data Acq., DCS, & SCADA Systems
Applications
Options—add to end of model number
R1 Channel 1 I/O reversal (ie. 4-20 mA in to 20-4 mA out)
R2 Channel 2 I/O reversal (ie. 4-20 mA in to 20-4 mA out)
R3 Channel 1 and channel 2 I/O reversal
M19 Channel 1 high voltage output >10 V up to 20 V
M29 Channel 2 high voltage output >10 V up to 20 V
M39 Channel 1 and channel 2 high voltage output
UConformal coating for moisture resistance
Accessory—order as separate line item
API BP4 Spare removable 4 terminal plug, black
Description
The APD 6393 IsoSplitter accepts an AC voltage or current
input and provides two optically isolated DC voltage or current
outputs that are linearly related to the input. The input range
and each output range are independent and can be specified as
required. This provides an economical solution when one signal
must be sent to two different devices.
Typical applications include isolation, output splitting, output
device separation and redundancy (i.e. to prevent failure of
the entire loop if one device fails), or a combination of these.
The input signal is filtered, amplified, split, and then passed
through an opto-coupler to the output stages. Full 4-way isola-
tion (input, output 1, output 2, power) make this module useful
for ground loop elimination, common mode signal rejection,
and noise pickup reduction.
I/O Sink/Source Versatility
Standard on the APD 6393 is a 15 VDC sensor excitation supply
for the input channel and 20 VDC loop excitation supplies for
each output channel. These power supplies can be selectively
wired for sinking or sourcing allowing use with any combina-
tion of powered or unpowered milliamp I/O devices.
LoopTracker
API exclusive features include three LoopTracker LEDs (green
for input, red for each output) that vary in intensity with
changes in the process input and output signals.
These provide a quick visual picture of your process loop at all
times and can greatly aid in saving time during initial startup
and troubleshooting.
Output Test
An API exclusive feature includes output test buttons for each
channel to provide a fixed output (independent of the input)
when held depressed. A test button is provide for each output
channel. The output test greatly aids in saving time during
initial startup and/or troubleshooting.
The test output level for each channel is potentiometer adjust-
able from 0 to 100% of the output span.
Terminals are provided to operate the test functions remotely
for each channel. This also allows use as a remote manual
override to provide a temporary fixed output if desired.
AC Input Range
Factory configured, please specify input type and range
Voltage: 0-50 mVAC to 0-300 VAC
Current: 0-1 mAAC to 0-1000 mAAC
Measurements are true RMS
Input Frequency
40 Hz to 1000 Hz sinusoidal
Input Impedance (Voltage Input)
220 kΩminimum
Input Voltage Burden (Current Input)
1.0 VRMS maximum
Input Protection, Common Mode
750 VDC or 750 VACp
LoopTracker
Variable brightness LEDs indicate I/O loop level and status
One for input, one for each output
Channel 1 and Channel 2 DC Output Ranges
Factory configured, please specify for each output channel
Voltage: 0-1 VDC to 0-10 VDC, 10 mA max
up to 20 VDC with M19, M29, M39
Bipolar voltage: ±1 VDC to ±10 VDC
Current: 0-1 mADC to 0-25 mADC, 4-20 mADC
20 V compliance, 1000 Ωat 20 mA
Output Calibration
Multi-turn zero and span potentiometers for each output channel
±15% of span adjustment range typical
Output Loop Power Supplies
20 VDC nominal, regulated, 25 mADC for each output channel
May be selectively wired for sinking or sourcing mA output
Output Test/Override
Front momentary buttons or external contact closures for
each channel to set output test levels.
Each output test level potentiometer adjustable 0-100% of span
Output Ripple and Noise
Less than 10 mVRMS
Linearity
Better than ±0.1% of span
Ambient Temperature Range and Stability
–10°C to +60°C operating ambient
Better than ±0.04% of span per °C stability
Response Time
70 milliseconds nominal
Isolation
Full 4-way, 1200 VRMS minimum
Installation Environment
IP 40, requires installation in panel or enclosure with ade-
quate ventilation
For use in Pollution Degree 2 Environment
Mount vertically (as shown in picture) to a 35 mm DIN rail
allowing minimum 1" (25 mm) above and below housing
vents for air circulation.
Power
85-265 VAC, 50/60 Hz or 60-300 VDC, 6 W maximum
D versions: 9-30 VDC or 10-32 VAC 50/60 Hz, 6 W maximum
Dimensions and Connectors
1.78" W x 4.62" H x 4.81" D
45 mm W x 117 mm H x 122 mm D
Eight 4-terminal removable connectors, 14 AWG max wire size
How to Order
Models are factory ranged. See I/O ranges above left.
Please specify ranges and options on order
Input range
Channel 1 output range
Channel 2 output range
See options at right
Model Description Power
APD 6393 IsoSplitter
1 input to
2 outputs
85-265 VAC, 50/60 Hz or
60-300 VDC
APD 6393 D 9-30 VDC or 10-32 VAC
Options and Accessories
© 11-19
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
Quick Link: api-usa.com/6393
Removable Plugs
Sink or Source
mA Output for
Each Channel
Output LoopTracker
LED for Each
Channel
Input LoopTracker
LED
Zero and Span for
Each Channel
Connect Sink or
Source mA Input
Custom I/O Ranges
Adjustable Output
Test Function for
Each Channel
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
25 26 27 28 29 30 31 32
17 18 19 20 21 22 23 24
See Wiring
Diagrams on
Next Page
Universal Power
Free Factory
I/O Setup!
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
HHHHH
HHHHHH
Made in USA
File E145968
85-265 VAC, 60-300 VDC
model only
Applications Link
api-usa.com/apps
Pb Lead
Free

Instructions APD 6393
1413 15 16109 11 12
External
Contacts
for Test
Function
Voltage
Output
– +
Voltage
Device 1
– +
Voltage
Device 2
21 3 4
Ch. 1 Ch. 2
65 7 8
To maintain full isolation avoid combining power supplies in
common with inputs, outputs, or unit power.
AC Input 1
1817 19 20
+15 VDC, 25 mA
sensor power avail-
able at terminal 18
AC Voltage
or mA Input
Calibration
Input and output ranges are factory pre-configured (at 24°C
±1°C). Front-mounted Zero and Span potentiometers for
each channel can be used to compensate for load and lead
variations.
1. Apply power to the module and allow a minimum 20 minute
warm up time.
2. Using an accurate calibration source, provide an input to
the module equal to the minimum input required for the
application.
3. Using an accurate measurement device for the output,
adjust the Zero potentiometer for the exact minimum output
desired. The Zero control should only be adjusted when the
input signal is at its minimum. This will produce the cor-
responding minimum output signal. For example: 4 mA for
a 4-20 mA output or –10 V for a ±10V output.
4. Set the input at maximum, and then adjust the Span pot for
the exact maximum output desired. The Span control should
only be adjusted when the input signal is at its maximum.
This will produce the corresponding maximum output
signal. Example: for 4-20 mA output, the Span control will
provide adjustment for the 20 mA or high end of the signal.
5. Repeat adjustments for both output channels for maximum
accuracy.
Output Test Function
When the Test button is depressed it will drive the output with a
known good signal that can be used as a diagnostic aid during
initial start-up or troubleshooting. When released, the output
will return to normal.
Each Test Cal. potentiometer can be adjusted to set the test
output from 0 to 100% of the output span. Press and hold the
Test button and adjust the corresponding Test Cal. potentiom-
eter for the desired output level.
They may optionally be externally wired for remote test opera-
tion or a manual override. See wiring diagram at right.
Operation
The APD 6393 IsoSplitter®accepts an AC voltage or current
input and provides two optically isolated DC voltage or current
outputs that are linearly related to the input.
The green LoopTracker®input LED provides a visual indica-
tion that the signal is being sensed by the input circuitry
of the module. It also indicates the input signal strength by
changing in intensity as the process changes from minimum
to maximum.
If the LED fails to illuminate, or fails to change in intensity as
the process changes, check the module power or signal input
wiring.
Two red LoopTracker output LEDs provide a visual indication
that the output signals are functioning. They become brighter
as the input and each corresponding output change from
minimum to maximum.
For a current output the red LED will only light if the output loop
current path is complete. For either current or voltage outputs,
failure to illuminate or a failure to change in intensity as the
process changes may indicate a problem with the module
power or signal output wiring. Note that it may be difficult to
see the LEDs under bright lighting conditions.
Precautions
WARNING! All wiring must be performed by a qualified electrician
or instrumentation engineer. See diagram for terminal designa-
tions and wiring examples. Consult factory for assistance.
WARNING! Avoid shock hazards! Turn signal input, output, and
power off before connecting or disconnecting wiring, or remov-
ing or installing module.
Précautions
ATTENTION! Tout le câblage doit être effectué par un élec-
tricien ou ingénieur en instrumentation qualifié. Voir le dia-
gramme pour désignations des bornes et des exemples de
câblage. Consulter l'usine pour assistance.
ATTENTION! Éviter les risques de choc! Fermez le signal
d'entrée, le signal de sortie et l'alimentation électrique avant
de connecter ou de déconnecter le câblage, ou de retirer ou
d'installer le module.
Electrical Connections
Each product is factory configured to your exact input and
output ranges as indicated on the serial number label.
See wiring diagrams at right. Observe polarity. If the output
does not function, check wiring and polarity.
*Do not make any connections to unused terminals or use
them as wiring junctions for external devices. This may cause
permanent damage to the module!
Outputs
Polarity must be observed for signal output wiring connec-
tions. If the input and/or output do not function, check wiring
and polarity.
For milliamp output ranges determine if your devices provide
power to the current loop or if the loop must be powered by the
APD module. Typical voltage may be 9-24 VDC at your device's
terminals if it provides power to the loop.
Device for Output Channel 1 Terminal Terminal
Measuring/recording device accepts a
voltage input. 3 (–) 4 (+)
Measuring/recording device has
an unpowered or passive mA input.
APD module provides the loop power. 3 (–) 4 (+20 V)
Measuring/recording device has a mA
input and powers the current loop. 2 (–) 3 (+)
Device for Output Channel 2 Terminal Terminal
Measuring/recording device accepts a
voltage input. 7 (–) 8 (+)
Measuring/recording device has
an unpowered or passive mA input.
APD module provides the loop power. 7 (–) 8 (+20 V)
Measuring/recording device has a mA
input and powers the current loop. 6 (–) 7 (+)
AC Input Terminal Terminal
Device with an AC voltage or
AC milliamp output. 17 19
Transmitter power supply. 18 (+15 VDC) 19
Input
Any polarity may be used for an AC input. A transmitter DC
power supply is available, but is not commonly used with AC
inputs.
APD 6393
AC to DC Isolated Signal Splitter
Transmitter
Test Cal.
Span
Zero
Test
Output
Loop
Tracker
Test Cal.
Span
Zero
Test
Output
Input
Loop
Tracker
Loop
Tracker
Channel 1 Channel 2
IsoSplitter®
Mounting to a DIN Rail
Install module vertically on a 35 mm DIN rail in a protective
enclosure away from heat sources. Do not block air flow. Allow
1" (25 mm) above and below housing vents for air circulation.
1. Tilt front of module down and posi-
tion the lower spring clips against
the bottom edge of DIN rail.
2. Push front of module upward until
upper mount snaps into place.
Removal
Avoid shock hazards! Turn signal
input, output, and power off.
1. Push up on bottom back of module.
2. Tilt front of module downward
to release upper mount from top
edge of DIN rail.
3. The module can now be removed
from the DIN rail.
Spring Clips
Upper Mount
Module Power
Check model/serial number label for module operating voltage
to make sure it matches available power.
When using DC power, either polarity is acceptable, but for
consistency, wire positive (+) to terminal 25 and negative (–)
to terminal 28.
The power supplies are fuse protected and the unit may be
returned to API for fuse replacement.
28 Power AC or DC –
26 Earth Ground
25 Power AC or DC +
2625 27 28
Cu 60/75°C
conductors
14 AWG
max.
api-usa.com
1220 American Way Libertyville, IL 60048
Phone: [phone] Fax: [phone]
AABSOLUTEBSOLUTE PPROCESSROCESS IINSTRUMENTSNSTRUMENTS
12 3 42 3 4 56 7 86 7 8
17 18 19 20
25 26 27 28
Input
Output 1 Output 2
Power
9 10 11 12 13 14 15 16
not used
not used
Output Test 1 Output Test 2Output Test 1 Output Test 2
Wire terminal
torque
0.5 to 0.6 Nm or
4.4 to 5.3 in-lbs
API maintains a constant effort to upgrade and improve its products.
Specifications are subject to change without notice. See api-usa.com for
latest product information. Consult factory for your specific requirements.
WARNING: This product can expose you to chemicals includ-
ing nickel, which are known to the State of California to cause
cancer or birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
– + 20V – + 20V
mA
Device 2
Ri
mA
Device 1
Ri
65 7 821 3 4
*Current
Sourcing
Output
Ch. 1 Ch. 2
Module
powers mA
output loop
– +
mA
Device 2
Ri
Loop
Power
Source 2
– +
+–
mA
Device 1
Ri
Loop
Power
Source 1
*Current
Sinking
Output
Ch. 1 Ch. 2
21346578
+–
Module mA
output is
unpowered
mA output: determine if receiving device has a passive or powered
input. The module can be wired for a sinking or sourcing mA output.
* To avoid damage to the module, do not leave any unused
mA outputs disconnected. Use a 1000 Ohm 1/2 Watt resis-
tor across unused mA terminals.
* Do not
make connec-
tions to unused
terminals!
* Do not
make con-
nections
to unused
terminals!
