Accentrics Home DS-D419-003 User manual

X1 Top panel
X1 Techo
X1 Le toit
X1 Front frame
X1 Placa in feruor
X1 Plaque de fond
X1 Drawer back
X1 Panneau arrirere pour tiroir
X1 Parte posterior del cajon
X1 Left side panel
X1 Panel izquierdo
X1 Panneau gauche
X1 Adjustable shelf
X1 Etageres
X1 Es tante ajustable
X1 Drawer right
X1 Cote droit du tiroir
X1 lado derecho del cajon
X1 Right side panel
X1 Panel lateral derecho
X1 Panneau lateral droit
X1 Bottom panel
X1 Panel inferio
X1 Panneau inferieur X1 Drawer left
X1 Cote gauche du tiroir
X1 lado izquierdo del cajon
X1 Back panel
X1 Placa posterior
X1 Fond de panier
X1 Drawer front
X1 Pour tiroir droit
X1 Anterior de cajon
X1 Drawer bottom panel
X1 Dibuijar la placa inferior
X1 Dessiner la plaque inferieure
PARTS LIST/ LISTE DES PIÈCES/ LISTA DE PIEZAS
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE / KD CONSOLE DE TIROIRÀ DEUX PORTES / CONSOLA DE DOS PUERTAS Y UN CAJONES
Page 1 of 9 Residential Use only Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
***
*
*
*
***
*
*
*

X6 Bolt Ø1/4"x32mm
X6 Perno Ø1/4"x32mm
X6 Boulon Ø1/4"x32mm
X4 Knob
X4 Mancjar
X4 Poignee
X4 Shelft support Ø6*29*17*13mm
X4 Soprte laminado Ø6*29*17*13mm
X4 Support en stratifie Ø6*29*17*13mm
X4 Handle screw Ø5/32"x20mm
X4 Tornillo de la manija Ø5/32"x20mm
X4 Vis de poignee Ø5/32"x20mm
X4 Legs
X4 Jambes
X4 Piernas
X4 Bolt Ø1/4"x23mm
X4 Perno Ø1/4"x23mm
X4 Boulon Ø1/4"x23mm
5
Page 2 of 9 Residential Use only Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
**
*
*
*
*
PARTS LIST/ LISTE DES PIÈCES/ LISTA DE PIEZAS
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES / CONSOLA DE DOS PUERTAS Y UN CAJONES

Step 1.
Put down the L/R side panels and Front Frame
(Part B&C&E) on a soft floor, screw the Legs ( Part M)
into the bottom of panels in the clockwise direction.
Page 3 of 9 Residential Use only For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES

Step 2.
Attach the Left / Right Side Panel (Part B&C)
into the Front Frame (Part E) and press down to
secure into place. Make sure that the tops of the side
panels and front frame are flushed.
Step 3.
Make sure that all of the switch locking hardware
in the panels are in the open position as indicated by the
straight arrow in the diagram then align the hardware in
the Top Panel (Part A) with the hardware on the top of
frame and press down so make sure the top panel is
flushed with the panels. Lock the top panel into place by
turning the switches indicated the by the curved arrow
in the diagram below.
Page 4 of 9 Residential Use only For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES

Step 4.
Screw the Bolts (Part 1) into pre-buried holes on
the Back Panel (Part D) in the clockwise direction to
attach the Back panel with the frame.
Step 5.
Open the doors and insert Bottom Panel (Part G)
inside the cabinet to the position where there is the
bottom of cabinet. Note that the side of the back panel
with notched corners should be inserted first facing the
back of the cabinet.
Page 5 of 9 Residential Use only For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES

Step 6.
Insert Shelf Supports (Part 3) into the holes as
shown. Then, insert the Adjustable Shelf (Part F) into the
cabinet to the position where there are shelves supports.
Step 7.
Insert the Handle Screws for the Knob (Part 4) into the
holes from the back side of the doors. Add the Knobs (Part 5)
and turn the handle screws clockwise to tighten. You will need
a phillips head screw driver to tighten completely.
Page 6 of 9 Residential Use only For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES

Step 8.
Align the hardware on the L/R Drawer Sides
(Part K & J) with the hardware on the Drawer Front
(Part H) making sure that the grooves on the drawer
sides are facing in and at the bottom of the drawer.
Apply downward pressure to secure the drawer sides
in place. Note that the grooves in the side panels and
drawer front should be aligned to allow for the drawer
bottom to be fully inserted. Also ensure the drawer
glides are facing out.
Step 9.
Insert the Drawer Bottom (Part L) into the
grooves in the side panels and press forward until the
front edge goes completely into the groove in the
drawer front. Add the Drawer back (Part I) making sure
the bottom panel insert completely into the groove.
Insert Bolts (Part 2) and turn clockwise to tighten
completely.
2
Page 7 of 9 Residential Use only For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES

5
Page 8 of 9 Residential Use only For further assembly information, please go to www.myfurnitureinstructions.com
* Replaceable Part
ASSEMBLY INSTRUCTION / NOTICE DE MONTAGE/ INSTRUCCIONES DE MONTAJE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES
Step 10.
Insert the drawer into the frame. insert the handle screws
for the knobs (part 4) into the holes inside the back side of the
drawer. Add the knobs (part 5) and turn the handle screws clockwise
to tighten. You will need a phillips head screws driver to tighten
completely.Do not turn the handle itself to tighten. Because you may
scratch the drawer front . Align the drawer glides with those in the
cabinet and press forward.open and close the drawer several times to
get a smooth glide.

* Replaceable Part
Page 9 of 9 Residential Use only
Made in Vietnam / Fabriqué au Vietnam / Hecho en Vietnam
For further assembly information, please go to www.myfurnitureinstructions.com
REPLACEABLE PART / PARTIE REMPLACABLE / PARTE REEMPLAZABLE
ITEM NO./ ARTICLE NO. / ARTICULO NO : DS-D419-003
DESCRIPTION/ LA DESCRIPTION /DESCRIPCIÓN: ASH GREY KD TWO DOOR ONE DRAWER CONSOLE /KD CONSOLE DE TIROIRÀ DEUX PORTES/CONSOLA DE DOS PUERTAS Y UN CAJONES
x1 RDS-D419-003-TOP
Top panel
Techo
Le toit
x1 RDS-D419-003-PANLS
Left side panel
Panel izquierdo
Panneau gauche
x1 RDS-D419-003-RSPAN
Right side panel
Panel lateral derecho
Panneau lateral droit
x1 RDS-D419-003-BAPAN
Back panel
Placa posterior
Fond de panier
x1 RDS-D419-003-FRAMF
Front frame
Placa in feruor
Plaque de fond
x1 RDS-D419-003-SHELF
Adjustable shelf
Etageres
Es tante ajustable
x1 RDS-D419-003-DRAF
Drawer front
Pour tiroir droit
Anterior de cajon
x1 RDS-D419-003-DRAB
Drawer back
Panneau arrirere pour tiroir
Parte posterior del cajon
x1 RDS-D419-003-DRAR
Drawer right
Cote droit du tiroir
Lado derecho del cajon
x1 RDS-D419-003-DRAL
Drawer left
Cote gauche du tiroir
Lado izquierdo del cajon
x1 RDS-D419-003-DOPAN
Drawer bottom panel
Dibuijar la placa inferior
Dessiner la plaque inferieure
x1 RDS-D419-003-BOPAN
Bottom panel
Panneau inferieur
Panel inferio
x6 RDS-D419-003-BOLT1
Bolt Ø1/4"x32mm
Perno Ø1/4"x32mm
Boulon Ø1/4"x32mm
X4 RDS-D419-003-KNOB
Knob
Mancjar
Poignee
x4 RDS-D419-003-SUPP
Shelft support Ø6*29*17*13mm
Soprte laminado Ø6*29*17*13mm
Support en stratifie Ø6*29*17*13mm
x4 RDS-D419-003-SCREW
Handle screw Ø5/32"x20mm
Tornillo de la manija Ø5/32"x20mm
Vis de poignee Ø5/32"x20mm
x4 RDS-D419-003-BOLT2
Bolt Ø1/4"x23mm
Perno Ø1/4"x23mm
Boulon Ø1/4"x23mm
5
X4 RDS-D419-003-LEG
Legs
Jambes
Piernas
