Accentrics Home DS-D321-141 User manual

I
x1 M6 Allen Key *
x1 Clé allen m6
x1 Llave allen M6
x8(Extra 1) M6*35mm Bolt *
x8(Extra 1) Boulon M6*35mm
x8(Extra 1) Perno M6*35mm
DESCRIPTION / DESCRIPCIÓN : Outdoor X Back Side Chair (2PCS) / Sièges extérieurs à dossier X (2PCS) / Silla de respaldo X al aire libre (2PCS)
C
x2 Chair Seat Panel
x2 Panneau de siège de chaise
x2 Panel del asiento de la silla
D
x2 Chair Back Panel
x2 Panneau arrière de la chaise
x2 Panel trasero de la silla
E
x2 Seat Cushion
x2 Coussin de siege
x2 Cojín del asiento
F
G
H
x8(Extra 1) M6*25mm Bolt *
x8(Extra 1) Boulon M6*25mm
x8(Extra 1) Perno M6*25mm
x16(Extra 2) M6 Washer *
x16(Extra 2) Rondelle M6
x16(Extra 2) Lavadora M6
Page 1 of 4
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D321-141
 A
x2 Left Side Panel
x2 Panneau du bras gauche
x2 Panel del brazo izquierdo
 B
x2 Right Side Panel
x2 Panneau de bras droit
x2 Panel del brazo derecho
PARTS LIST / LISTE DES PIÈCES / LISTA DE PIEZAS
Residential Use Only Made in China / Fabriqué au Chine / Hecho en China
* Replaceable Part

I
G
H
I
I
G
F
H
H
DESCRIPTION / DESCRIPCIÓN : Outdoor X Back Side Chair (2PCS) / Sièges extérieurs à dossier X (2PCS) / Silla de respaldo X al aire libre (2PCS)
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D321-141
A
C
A
B
C
D
B
A
C
B
A
E
C
D
Step3
Step1 Step2
Made in China / Fabriqué au Chine / Hecho en China
Page 2 of 4
Step4
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
Residential Use Only
* Replaceable Part
Attach Back Panel (Part D) to Arm
Panels (A&B) using 25mm Bolts
(Part F) & Washers (Part H). Use
Allen Wrench (Part I) to tighten all
four bolts completely.
Turn the assembled chair upright and
add the seat cushion.
Lay Side Panel (Part A) on its side
on a soft dry surface. Attach using
35mm Bolts (Part G) & Washers
(Part H). Use Allen Wrench (Part I)
to tighten both bolts completely.
Repeat Step 1 to attach Side
Panel (Part B).

Step5
Made in China / Fabriqué au Chine / Hecho en China
Page 3 of 4
ASSEMBLY INSTRUCTIONS / NOTICE DE MONTAGE / INSTRUCCIONES DE MONTAJE
Residential Use Only
* Replaceable Part
DESCRIPTION / DESCRIPCIÓN : Outdoor X Back Side Chair (2PCS) / Sièges extérieurs à dossier X (2PCS) / Silla de respaldo X al aire libre (2PCS)
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D321-141

DESCRIPTION / DESCRIPCIÓN : Outdoor X Back Side Chair (2PCS) / Sièges extérieurs à dossier X (2PCS) / Silla de respaldo X al aire libre (2PCS)
ITEM NO. / ARTICLE NO. / ARTICULO NO : DS-D321-141
Page 4 of 4 Made in China / Fabriqué au Chine / Hecho en China
REPLACEABLE PARTS / PARTIE REMPLAÇABLE / PARTE REEMPLAZABLE
x1 RDS-D321-141-HWKIT - Hardware Kit *
Liste des pièces de quincaillerie
Lista del kit de materiales
Residential Use Only
* Replaceable Part
