Installation Manual SF101
1/8
SF101
Installation Manual
Fingerprint Reader / Proximity Reader

1. Device Installation.
1.1. Using the mounng paper as
reference make the perforaons
in the wall for the included
anchors.
2/8
1.2. Gently remove the sensor
cover.
1.3. Before screwing, put on
the rubber protecon and
ghten the four screws.
1.4. Aer screwing the device,
place the sensor cover.
Installation Manual SF101

Led Indicator
2.The parts of the SF101 are described below:
2. Reader Parts
3/8
Fingerprint Reader
Reader cover
Enroll Buon
(User Registry )
Delete Buon
(Delete Users)
Bell Buon
USB Connecon
Reset Buon
Installaon Manual SF101

3. Connecons
4/8
J6
SEN
AGND
BUT
NO
COM
NC
AL+
AL-
12V
AGND
D0
D1
RED
GREEN
BUZZER
12V
AGND
RXD
TXD
485A
485B
BELL+
BELL-
J8
J4
J6 FUNCTION
SEN Door Sensor
AGND Ground
BUT Output Buon
NO Normally open for
lock
COM Common for lock
NC Normally closed for
lock
AL+ Alarm output (+)
AL-Alarm output (-)
J8 FUNCTION
12V 12VCD+
AGND 12VCD-
D0 Wiegand Output D0
D1 Wiegand Output D1
RED LED Control
GREEN
BUZZER Buzzer Sound
J4 FUNCTION
RXD RS232 RX
TXD RS232 TX
485A RS485 +
485B RS485 +
BELL+ TIMBRE+
BELL-TIMBRE-
12VCD
Installaon Manual SF101
LED Control

3.1.Connecon Diagram of the SF101 with a Magnec Sheet Sharing the Same Source:
3. Connecons
5/8
J6
SEN
AGND
BUT
NO
COM
NC
AL+
AL-
12V
AGND
D0
D1
RED
GREEN
BUZZER
12V
AGND
RXD
TXD
485A
485B
BELL+
BELL-
J8
J4
12V+
12V-
12V-
12V+
N.C.
Magnec
Sheet
12VDC SHARED
POWER SUPPLY
N.A. Exit
Buon
N.C. Door
Sensor
Nota: The exit buon
and door sensor share
the GND as common.
Diode
Installaon Manual SF101

3.2. Connection diagram of the SF101 with a counterstrike sharing the same source:
3. Connections
6/8
J6
SEN
AGND
BUT
NO
COM
NC
AL+
AL-
12V
AGND
D0
D1
RED
GREEN
BUZZER
12V
AGND
RXD
TXD
485A
485B
BELL+
BELL-
J8
J4
12V+
12V-
12V-
12V+
12VCD SHARED
POWER SUPPLY
N.A. Exit
Buon
N.C. Door
Sensor
Note: The exit buon
and door sensor share
the GND as common
N.A. Electric
Strike
Diode
Installaon Manual SF101

3.3. Connecon diagram of the SF101 with an Access Control Panel:
3. Connecons
7/8
12V
AGND
D0
D1
RED
GREEN
BUZZER
J8
D0
D1
Cable AWG .22
GND
Access Control
Panel
3.4. Connecon diagram of the SF101 with the PC via USB:
PC
USB
Installaon Manual SF101

4. Characteriscs
8/8
More Informaon:
Youtube Channel
www.youtube.com/accessprosecurity
•Opc sensor.
•Communicaons: RS232, RS485 and USB.
•Built-in proximity reader.
•Voltage: 12 VDC.
•Operang temperature: 0 - 45 ºC.
•Dimensions: 120 x 120 x 35.1 mm.
