AccessZone® - GC430 & GC470 Quick User Guide
All information is subject to c ange wit out notice. All ot er products and brand names are registered trademarks of t eir respective companies 2014-04-22 US 0.03
Copyrig t © 2012 - 2014 All rig ts reserved MVC-Data ApS Skal use 5 9240 Nibe Web www.mvc-data.com E-mail [e-mail] Telefon [phone]
GC430 & GC470 Quick User Guide
AccessZone® System - A Key to a Safer Future
Congratulations on choosing an AccessZone®
Access Control System with Wiegand bus.
It is a fle ible and easy to use
system for controlling access to
doors and gates.
It enables quick configuration
with a few simple commands
entered on a standard mobile
phone with Bluetooth without installing any
software. No license or subscription is required.
By default it will forward all Bluetooth
addresses (IDs) in Wiegand 26 format.
Please see the "GC430 & GC470 User Manual"
and "GC430 & GC470 Quick Guide" for more
details.
Configuration Mode - Programming:
The system must be set into configuration
mode before it will accept the system
commands. Thus some commands can be
e ecuted by the system administrators.
Method 1:
Enter configuration mode:
1) Power off the module
2) Press and held down the REX (Request E it) push
button (IN1)
3) Power on the module again
4) The REX push button can be released after the short
beep
Method 2:
Enter the system command “E02” on the administrator
phone and enter the 8 digit master PIN code.
The system will now be in configuration mode
for 10 minutes and will flash with the Blue LED.
Restore Factory Default Settings:
The Master PIN code and the other system
configuration settings can be restored to
factory settings:
Please follow the below steps:
1) Power off the device
2) In J2 connector:
Short Pin 2 T A to Pin 4 R A
Short Pin 3 T B to Pin 5 R B
3) Power on the device – Wait - a short beep
acknowledges that the factory settings have been
restored
4) Power off the device again
5) In J2 connector:
Remove short from PIN 2 and PIN 4
Remove short from PIN 3 and PIN 5
6) Device can safely be re-powered with the restored
factory settings.
Execute a system command:
The 8-digit master PIN code must always be
used to e ecute a system command.
Default master PIN code: 12345678
1) Set system into configuration mode
2) Enable Bluetooth on mobile phone and set it to
hidden
3) Enter the required system command in the
Bluetooth name field on the mobile phone
4) Set the mobile phone to visible
5) Place mobile phone within the detection range of
the system
6) Wait for 3 short beeps
7) Enter Master PIN code when prompted
8) Wait for short beep for successful e ecution of the
command
9) Set the mobile phone to invisible/hidden
10) Erase command from mobile phone
System Command Overview:
All mobile phones with Bluetooth can be used to e ecute the system commands.
 Change Master PIN Code  Change System Configuration 1
 Add new User  Change System Configuration 2
 Add new User – Easy Enrolment  E ecute System Commands
 Delete User  E ecute System Configurations
The commands are entered in the Bluetooth friendly name field.
E ample

AccessZone® - GC430 & GC470 Quick User Guide
All information is subject to c ange wit out notice. All ot er products and brand names are registered trademarks of t eir respective companies 2014-04-22 US 0.03
Copyrig t © 2012 - 2014 All rig ts reserved MVC-Data ApS Skal use 5 9240 Nibe Web www.mvc-data.com E-mail [e-mail] Telefon [phone]
System Command Description:
Only in configuration mode:
 C ange Master PIN Code
Change the 8-digit master PIN Code
E.g. to change Master PIN to 12345678 enter:
"12345678"
 Add new User – Easy Enrolment
By default no users have to be added. The
reader forwards all Bluetooth ID on the
Wiegand bus. Add users if a personal IN code
is required.
Command must be e ecuted on the users
mobile phone. It adds the used mobile phone to
the specified storage position.
E.g. add user with PIN code 1234 on position 3
enter: "03,1234"
 C ange System Configuration 1
This command handles Wiegand facility code,
Wiegand type. 10 different formats are
supported. Default is Wiegand 26.
See User Manual for details
 C ange System Configuration 2
This command handles system detection range
and I/O configuration. See User Manual for
details.
System Command Description:
By administrators or in configuration mode:
 Add new User
By default no users have to be added. The
reader forwards all Bluetooth ID on the
Wiegand bus. Add users if a personal IN code
is required.
Adds a new user on the specified storage
position. The users Bluetooth address must be
entered. Deletion of current user is not required
E.g. add user with ID 0022b4b62918 and PIN
code 1234 on position 1 enter:
"01,0022b4b62918,1234"
 Delete User
Deletes the user on the specified storage
position.
E.g. delete administrator stored on position 1
enter: "01"
 Execute System Commands
See description below
 Execute System Configurations
See description below
Execute System Commands:
Some predefined system commands.
 “E01” - Performs a System Reset
 “E02” - Performs a Factory Reset
 “E03” - Enter Configuration Mode
 “E04” - Performs a Factory Reset and enters
Configuration Mode (“E02” + “E03”)
 “E05” - Erases the complete user list and adds
the default Any user “FFFFFFFFFFFF” on
storage position 01 as new administrator
 “E06” - Increases the RX range to allow access to
the users further away (+3 dBm steps)
 “E07” - Decreases the RX range to allow the
users to be closer to the reader before
access (-3 dBm steps)
Execute System Configurations:
Some predefined system configurations which
helps adjusting the system to the required
detection distance.
 “C01” - Very short range ≈ 10 cm
 “C02” - Door access - short ≈ < 50 cm
 “C03” - Door access - normal ≈ < 2 m
 “C04” - Gate access ≈ < 5 m
 “C05” - Gate access - long ≈ < 10 m
 “C06” - Very long range ≈ < 100 m
The specified distance is indicative only and will
depend on actual installation.
Smart P one Apps:
An AccessZone Administrator app helps building
up the system commands. App is available for
iOS and Android.
Please see our web page for further details:
http://www.mvc-data.com/Smart_Phones.html
E ample with iPhone
