ACCU-CHEK®Inform II
BLOOD GLUCOSE MONITORING SYSTEM
Addendum to the Operator’s
Manual
ACCU-CHEK Inform II Base Unit (NEW)

20 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual
Revision History
Purpose of document
This document provides additional information to the Operator's Manual.
This addendum is valid for and intended to be used in conjunction with the ACCU-CHEK
Inform II Operator’s Manual (all versions up to 5.0). It is not a replacement for the complete
ACCU-CHEK Inform II Operator’s Manual.
© 2015, Roche Diagnostics. All rights reserved.
The contents of this document, including all graphics, are the property of Roche Diagnostics. No
part of this document may be reproduced or transmitted in any form or by any means, electronic
or mechanical, for any purpose, without the express written permission of Roche Diagnostics.
Roche Diagnostics has made every reasonable effort to ensure that all the information contained
in this manual is correct at the time of printing. However, Roche Diagnostics reserves the right to
make any changes necessary without notice as part of ongoing product development.
Please send questions or comments about this document to your local Roche representative.
Document version Revision date Changes
Version 1.0 2015-07 New Document, Addendum to Operator's Manual:
ACCU-CHEK Inform II Base Unit (NEW) - description
of changes
Be sure to read the complete ACCU-CHEK Inform II Operator's Manual.

0 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual 3
Purpose of document ....................................................................................................................................... 2
Addendum to Operator's Manual: ACCU-CHEK Inform II Base Unit (NEW) 5
Changes................................................................................................................................................................. 5
Overview of the ACCU-CHEK Inform II Base Unit (NEW)........................................................................... 6
Connecting the ACCU-CHEK Inform II Base Unit (NEW) .......................................................................... 7
Technical data ............................................................................................................................................................ 8
Further Information ................................................................................................................................................... 9
Ordering................................................................................................................................................................. 9

40 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual
This page intentionally left blank.

0 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual 5
Addendum to Operator's Manual: ACCU-CHEK Inform II
Base Unit (NEW)
The following description of changes applies only to the
ACCU-CHEK Inform II Base Unit with NEW hardware/
software (REF 07671717190).
For a description of older versions of the ACCU-CHEK
Inform II Base Unit (REF 05060290001) refer to the
ACCU-CHEK Inform II Operator’s Manual (all versions
up to 5.0).
The ACCU-CHEK Inform II Base Unit Light remains
unchanged; the description in the ACCU-CHEK Inform II
Operator's Manual applies.
Changes ■New generation processor
■Faster boot time
■Redesigned charging contacts
■USB cable now has micro B connector plug
■Power cord with improved connector plug
Note for System Administrator: For further technical
information on setting up and configuring the
ACCU-CHEK Inform II Base Unit (NEW), consult the
package insert accompanying the device and the
“Technical Note” stored on the ACCU-CHEK Inform II
Base Unit (NEW) as a PDF file. You can access this file
by connecting the base unit to a PC with the USB
cable.

60 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual
Overview of the ACCU-CHEK Inform II Base Unit (NEW)
1Charging contacts
2Infrared window
3Status LED
4Removable mount for wall
installation
5Power input jack for the power supply unit
6Network connection — LAN, Ethernet (RJ45)
7USB connection
8Power supply unit ( )
9USB cable (USB A to USB micro B)
2
1
3
5
4
6
7
89
12V 1,25A

0 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual 7
Connecting the ACCU-CHEK Inform II Base Unit (NEW)
1 Slide the base unit upward and remove it from the
wall mount (if in use).
2 Connect the power supply to the power input jack.
3If you want to connect the ACCU-CHEK
Inform II Base Unit in a wired environment:
Connect the Ethernet (RJ45) cable or the USB cable
to the respective port. Use only the USB cable pro-
vided with the ACCU-CHEK Inform II Base Unit.
4 Slide the base unit back onto the wall mount (if in
use). Please note that the ACCU-CHEK Inform II
Base Unit Wall Mount fits the ACCU-CHEK Inform II
Base Unit (both old and new versions) and the
ACCU-CHEK Inform II Base Unit Light.
NOTICE To ensure continuous safe and reliable operation, use
only the power supply unit provided for the ACCU-CHEK
Inform II Base Unit (for ordering information see page 9
of this Addendum).
For details on configuring the ACCU-CHEK Inform II
Base Unit, consult your Roche representative.

80 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual
Technical data
Specification ACCU-CHEK Inform II
Base Unit (NEW)
Power supply unit (NEW)
Height 4.84 in / 123 mm (max.) 1.38 in / 35 mm +
AC plug (1.1-1.6 in / 28-40 mm)
Width 5.12 in / 130 mm (max.) 2.01 in / 51 mm
Length 5.12 in / 130 mm (max.) 3.43 in / 87 mm
Weight ACCU-CHEK Inform II
Base Unit
671 g with wall mount
170 g
User interface LED (tricolor: red, green, blue) N/A
Operating temperature 37 to 122 °F
3 to 50 °C
32 to 104 °F
0 to 40 °C
Storage conditions (long-term storage) 41 to 104 °F / 5 to 40 °C at 10 - 85% RH (non-condensing)
Humidity (operating) 10 - 90 % RH (non-condensing)
Input voltage +12V DC 100 to 240 V AC
Input frequency DC 50 to 60 Hz
Input current 1.25 A (max) 350 to 150 mA
Interfaces Charging contacts
IR port
RJ45 Ethernet
USB type Micro B
DC connector
Replaceable AC input contacts
Data transfer rate IR: 9.6K - 115K bps
Ethernet: 10/100 Mbps
USB: 12 Mbps
N/A

0 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual 9
Further Information
Ordering Changes to the ordering information in the current
ACCU-CHEK Inform II Operator’ Manuals version 4.0 and
5.0 are shown in red.
Item Description REF/Catalog
Number
ACCU-CHEK Inform II Meter Meter, equipped with WLAN functionality 05060303001
ACCU-CHEK Inform II Battery Pack Rechargeable battery pack (for meters with
serial no. above UU14000000)
06869904001
ACCU-CHEK Inform II
Battery Compartment Cover
Replacement cover for meter battery
compartment (for meters with serial no. above
UU14000000)
06869823001
ACCU-CHEK Inform II Base Unit Light Equipped with charging functionality 05920353001
Power Supply Power supply for Base Unit Light
(North America)
05388805001
ACCU-CHEK Inform II Base Unit (NEW) Equipped with charging and connectivity
functionality
07671717190
Power Supply Power supply for Base Unit (NEW)
REF 07671717190 (North America)
07455976190
USB Cable Micro B Replacement cable for Base Unit (NEW) 07572204001
ACCU-CHEK Inform II Base Unit
Wall Mount
Wall Mount for Base Unit (fits old and new
versions)/Base Unit Light
05404878001

10 0 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual
ACCU-CHEK Inform II Base Unit Hub Equipped with power and connectivity
functionality for the ACCU-CHEK Inform II
Base Unit Light
05888760001
Power Cord Required to power the Base Unit Hub
(North America)
03868133001
ACCU-CHEK Inform II Code Key
Reader
04884671001
ACCU-CHEK Inform II Accessory Box
Kit
05060281001
ACCU-CHEK Inform II Battery Pack Rechargeable battery pack (for meters with
older hardware and serial no. below
UU14000000)
04882326001
ACCU-CHEK Inform II RF Card Kit Wi-Fi card replacement (for meters with older
hardware and serial no. below UU14000000)
05112699001
Item Description REF/Catalog
Number

0 7765053001 (01) 2015-07 EN-USA • ACCU-CHEK Inform II Addendum to Operator’s Manual 11
This page intentionally left blank.

0 7765053001 (01) 2015-07 EN-USA
ACCU-CHEK, ACCU-CHEK INFORM and COBAS
are trademarks of Roche.
RX only
Manufactured for and distributed in the U.S.A. by:
Roche Diagnostics
9115 Hague Road
Indianapolis, IN 46256
MRoche Diagnostics GmbH
Sandhofer Strasse 116
68305 Mannheim, Germany
www.roche.com
www.accu-chekinformii.com/
