Accuphase DP-77 Operating and installation instructions

Bi-lingual
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
These servicing instructions are for use by qualified personnel only.
To reduce the risk of electric shock do not perform any servicing
other than that contained in the operating instructions unless you are
qualified to do so. Refer all servicing to qualified service personnel.
ここに記載したサービスに関する指示事項は、サービスに関する資格を
有する者のみが使用するものです。感電防止の観点から、サービス資格
を有していない方は、取扱指示事項以外のサービスは絶対に行わないよ
うにして下さい。
CAUTION /
Authorized Technical Service Only
回路図

Side Panel
ｻｲﾄﾞﾊﾟﾈﾙ
(139-0035-22)
Push-button for POWER
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5044-03)
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0143-00)
Power Switch
ﾊﾟﾜｰｽｲｯﾁ
(354-1024-00)
Front Panel Assembly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0169-01)
Front Glass
ﾌﾛﾝﾄｶﾞﾗｽ
(172-0116-03)
Foot
脚
(238-0023-00)
Knob
ﾂﾏﾐ
(383-1201-03)
Decoration Screw
飾りﾈｼﾞ
(630-0304-14)
Washer
ﾜｯｼｬ
(637-9045-04)
Sub Panel /not supply
ｻﾌﾞﾊﾟﾈﾙ
(134-0138-03)
Bottom Plate
ﾎﾞﾄﾑﾌﾟﾚｰﾄ
(155-0078-02)
Top Plate Assembly
ﾄｯﾌﾟﾌﾟﾚｰﾄAss'y
(150-0069-12A)
Top Plate(B)
ﾄｯﾌﾟﾌﾟﾚｰﾄB
(150-0053-03)
－１－
E
X
PLANATION OF SU
R
FACE PA
R
TS
Push-button /5-gang
ﾌﾟｯｼｭﾎﾞﾀﾝ/5連
(388-5059-13)
Tray Sub-panel
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙ
(134-0130-04) Sub Panel
ｻﾌﾞﾊﾟﾈﾙ
(134-0138-03)
★
★
★mark parts not supplied
★★
★
★
★
Knob
ﾂﾏﾐ
(383-1201-03)
Tray Sub-panel
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙ
(134-0130-04)
Binding Screw
ﾊﾞｲﾝﾄﾞねじ/4pcs.
(604-0408-00)
Washer
平ﾜｯｼｬ/4pcs.
(637-0042-07)
Panel End-cap
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
(132-0098-04)
★

FRONT VIEW (前面)
REAR VIEW (面後)
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /2pcs.
(302-0116-00)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ/4pcs.
(254-2015-04)
Foot
脚
(238-0023-00)
Square Plate
ｽﾛｯﾄﾊﾟﾈﾙ
(159-0069-14)
XLR (Cannon) Plug Receptacle
ｵｰﾃﾞｨｵｺﾈｸﾀﾌﾟﾗｸﾞ /2pcs.
(301-8005-00)
Connector Cover /Male
ｺﾈｸﾀｶﾊﾞ /2pcs.
(254-2011-00)
AC Inlet
AC ｺﾈｸﾀﾌﾟﾗｸﾞ
(301-3306-00)
＊Power Supply Cord
電源ｺｰﾄﾞ
J type:680-1404-00
U,T type:680-2401-00
E type:680-3402-00
Rear Panel
ﾊﾞｯｸﾊﾟﾈﾙ
(135-0158-02)
Front Panel Assebly
ﾌﾛﾝﾄﾊﾟﾈﾙ Ass'y
(130-0169-01)
1 Front Panel=131-0169-01
ﾌﾛﾝﾄﾊﾟﾈﾙ
2 Sub-panel =134-0138-03
ｻﾌﾞﾊﾟﾈﾙ
3 Tray Sub-panel=134-0130-04
ﾄﾚｨｻﾌﾞﾊﾟﾈﾙ
4 Push-button/5-gang=388-5059-13
ﾌﾟｯｼｭﾎﾞﾀﾝ /5連
5 Decoration Screw=630-0304-14
飾りﾈｼﾞ
5-1 Washer=637-9045-04
ﾜｯｼｬ
5-2 Nut=633-2032-02
六角ﾅｯﾄ
6 Front Glass=172-0116-03
ﾌﾛﾝﾄｶﾞﾗｽ
1pce.
1pce.
1pce.
1pce.
2pcs.
2pcs.
2pcs.
1pce.
6 Display Assembly=723-0081-00
ﾃﾞｨｽﾌﾟﾚｨAss'y
6-1 Fixed Bracket=159-0097-03
化粧板
6-2 Rubber Cussion=250-2140-04
ｺﾞﾑｸｯｼｮﾝ
6-3 Filter=179-0029-04
ﾌｨﾙﾀｰ
7 Push-button=388-5044-03
ﾌﾟｯｼｭﾎﾞﾀﾝ/POWER
7-1 Push-button Frame=113-0100-14
ﾌﾟｯｼｭﾎﾞﾀﾝﾌﾚｰﾑ
7-2 Coil Spring=285-1016-04
ｺｲﾙｽﾌﾟﾘﾝｸﾞ
7-3 E-ring=647-1054-00
Eﾘﾝｸﾞ
8 Panel End-cap=132-0098-04
ﾊﾟﾈﾙｴﾝﾄﾞｷｬｯﾌﾟ
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
1pce.
2pcs.
1
2
6
5
4
37
－2－
Decoration Screw
飾りﾈｼﾞ/4pcs.
(630-0302-04)
Washer
ﾜｯｼｬ
(637-9045-04)
Pin Jack
ﾋﾟﾝｼﾞｬｯｸ /2pcs.
(302-0116-00)
Pin Jack Cover
ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ/4pcs.
(254-2015-04)
Optical Rceiver
ｵﾌﾟﾄﾚｼｰﾊﾞ /IC4
(GP1FA513RZ)
Knob
ﾂﾏﾐ
(383-1201-03)
Binding Serew /脚用
ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄ /4×14
(611-0414-02)
Optical Rceiver
ｵﾌﾟﾄﾚｼｰﾊﾞ /IC2
(GP1FA513TZ)
8 8

SACD Kit /SACD ｷｯﾄ
Mechanical Assembly
ﾒｶﾆｶﾙ Ass'y
(731-0007-00)
TOP
V
IE
W
BOTTOM VIEW (底面)
AC Inlet / Line Filter
ACｺﾈｸﾀﾌﾟﾗｸﾞ
(301-3306-00)
IO Assembly
IO Ass'y
(726-0142-00)
Metalized Polyester Capacitor
ﾒﾀﾗｲｽﾞﾄﾞﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
C001:0.01μF/250V
(CF99MF2E103M)
Fuse for 100-120V
T1.25A L 250V
(310-1104-00)
Fuse for 220-240V
T630mA L 250V
(310-1061-00)
Attention mark indicating critical components for safety.
Replacement must be made with identical parts of special part number.
このマークのついている部品は、安全上重要な部品です。
必ず指定されている部品番号の部品を使用して下さい。
－３－
DAC Assembly
DAC Ass'y
(725-0041-00)
DSP Assembly
DSP Ass'y
(724-0055-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-4031-00)
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0143-00)
Mother Board Assembly
ﾏｻﾞｰﾎﾞｰﾄﾞ Ass'y
(726-0144-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-4032-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-4031-00)
SACD Kit /SACD ｷｯﾄ
Mechanical Assembly
ﾒｶﾆｶﾙ Ass'y
(731-0007-00)
DAC Assembly
(725-0041-00)
Power Transformer
ﾊﾟﾜｰﾄﾗﾝｽ
(510-4032-00)
Mother Board Assembly
ﾏｻﾞｰﾎﾞｰﾄﾞ Ass'y
(726-0144-00)
Main Board Assembly
ﾒｲﾝﾎﾞｰﾄﾞ Ass'y
(1-679-080-12)
*This assembly is
contained in SACD Kit.
*このAss'y はSACDｷｯﾄに
含まれます。
RF Board Assembly
RF ﾎﾞｰﾄﾞAss'y
(1-679-092-11)
*This assembly is
contained in SACD Kit.
*このAss'y はSACDｷｯﾄに
含まれます。
Power Push Switch
ﾌﾟｯｼｭｽｲｯﾁ /POWER
(354-1024-00)
Terminal
端子板
(313-4046-00)

－４－
F
R
ONT VIE
W
Sub-chassis side
Power Switch Assembly
ﾊﾟﾜｰｽｲｯﾁ Ass'y
(726-0143-00)
Power Push Switch
ﾊﾟﾜｰｽｲｯﾁ
SACD kit /SACD ｷｯﾄ
Mechanical Assembly
ﾒｶﾆｶﾙ Ass'y
(731-0007-00)
Rotary Encoder
ﾛｰﾀﾘｴﾝｺｰﾀﾞｰ/ S6
(339-0006-00)
Push-button
ﾌﾟｯｼｭﾎﾞﾀﾝ
(388-5044-03)
Frame
ﾌﾚｰﾑ
(113-0100-14)
Push-button /5-gang
ﾌﾟｯｼｭﾎﾞﾀﾝ /5連
(388-5059-13)
Explanation of Front-panel back view
mark parts not supplied
Display Assembly
ﾃﾞｨｽﾌﾟﾚｨ Ass'y
(723-0081-00)
Front Glass
ﾌﾛﾝﾄｶﾞﾗｽ
(172-0116-03)
Filter
ﾌｨﾙﾀ
(179-0029-04)
Display Tube
蛍光表示管/FL1
(434-0013-00)
Push Switch
ﾌﾟｯｼｭｽｲｯﾁ/S1～5
(354-1116-00)
★
★
★
★
★
★
★
Main Board Assembly
ﾒｲﾝﾎﾞｰﾄﾞ Ass'y
(1-679-080-12)
Display Assembly
ﾃﾞｨｽﾌﾟﾚｨ Ass'y
(723-0081-00)
Infrared Receiver
赤外線ﾚｼｰﾊﾞ /IC2
(NJL64H380A)
Rotary Encoder
ﾛｰﾀﾘｴﾝｺｰﾀﾞｰ/ S7
(339-0008-00)
Rubber Cushion
ｺﾞﾑｸｯｼｮﾝ
(250-2131-04)
Fixed Bracket
化粧板
(159-0097-03)

MISCELLANEOUS(本体その他使用部品)
No.
C001
Packing
Material
梱包材
Description
PC Board for
DSP Ass'y
DAC Ass'y
IO Ass'y
Mother Board Ass'y
SACD Kit / ｷｯﾄ
RF Board /RF ﾎﾞｰﾄﾞ
Main Board /ﾒｲﾝﾎﾞｰﾄﾞAss'y
Optical Pick-up /光ﾋﾟｯｸｱｯﾌﾟ
Switch Assembly /ｽｲｯﾁAss'y
Loading Motor /ﾛｰﾃﾞｨﾝｸﾞﾓｰﾀｰ
Belt / ﾍﾞﾙﾄ
Fuse T1.25A L 250V
ﾌｭｰｽﾞ T630mA L 250V
Metalized Polyester
Capacitor
ﾒﾀﾗｲｽﾞﾄﾞﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
Outer Carton Box
ﾀﾞﾝﾎﾞｰﾙ箱
Top Pad (F)
ﾄｯﾌﾟﾊﾟｯﾄﾞF
Top Pad(R)
ﾄｯﾌﾟﾊﾟｯﾄﾞR
Bottom Pad(F)
ﾎﾞﾄﾑﾊﾟｯﾄﾞF
Bottom Pad(R)
ﾎﾞﾄﾑﾊﾟｯﾄﾞR
Top Board /天地当板
Cover /保護ｶﾊﾞ
Accessories Case /付属品ｹｰｽ
Wrapping Sheet /ｼｰﾄ
Bag for AC Cord,Remote,
Audio Cord
Poly Bag /ﾋﾞﾆｰﾙ袋 for Manual
Cover /保護ｶﾊﾞ for Remoote
Part No.
115-1436-00
115-1438-10
115-1439-10
115-1441-10
731-0007-00
1-679-092-11
1-679-080-12
8-820-132-03
1-641-764-11
1-641-765-11
4-927-649-01
310-1104-00
310-1061-00
CF99MF2E103M
801-0243-14
803-0324-00
803-0325-00
803-0326-00
803-0327-00
803-0033-14
810-4843-04
801-0251-10
810-4545-04
810-2030-04
810-2030-04
812-2435-04
810-1030-00
Remarks
not supplied
KHM-230AAA/J1RP
for 100-120V
for 220-240V
0.01uF/250V
(前)
(後)
(前)
(後)
(本体)
ACｺｰﾄﾞ,ﾘﾓｺﾝ
ｵｰﾃﾞｨｵｺｰﾄﾞ
取説用
ﾘﾓｺﾝInner用
No.
Screws
for
ﾈｼﾞ類
Accessories
付属品
Description(部品名)
Front Panel /ﾌﾛﾝﾄﾊﾟﾈﾙ用ﾈｼﾞ
Binding Screw /ﾊﾞｲﾝﾄﾞﾂﾒﾂｷ
Top Plate Ass'y /ﾄｯﾌﾟﾌﾟﾚｰﾄ
Round Head Screw /ﾌﾞﾚｻﾞｰﾂﾒﾂｷ
Binding Screw /ﾊﾞｲﾝﾄﾞﾞﾂﾒﾂｷﾈｼﾞ
Side Panel /ｻｲﾄﾞﾊﾟﾈﾙ
Oval Head Screw /丸ｻﾗﾈｼﾞ
Binding Screw /ﾊﾞｲﾝﾄﾞﾈｼﾞ
Washer /ﾜｯｼｬ
Bottom Plate /ﾎﾞﾄﾑﾌﾟﾚｰﾄ
Binding Screw /ﾊﾞｲﾝﾄﾞﾂﾒﾂｷﾈｼﾞ
Foot / 脚用
Binding Screw /ﾌﾞﾚｻﾞｰﾀｯﾌﾟﾀｲﾄﾈｼﾞ
Option Slot Panel/ ｵﾌﾟｼｮﾝｽﾛｯﾄﾊﾟﾈﾙ
Decoration Screw /飾りﾈｼﾞ
Washer /ﾜｯｼｬ
Power Transforer/ﾊﾟﾜｰﾄﾗﾝｽ用
Binding Screw /ﾊﾞｲﾝﾄﾞﾈｼﾞ
Spring Washer /ｽﾌﾟﾘﾝｸﾞﾜｯｼｬ
Owner's Manual
取扱説明書
Notes
注意書
Power Supply Cord (J type)
電源ｺｰﾄﾞ (U,T type)
(E type)
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞｰ
Battery / 電池
Audio Cord (L)/ ｵｰﾃﾞｨｵｺｰﾄﾞ
Audio Cord (R)/ ｵｰﾃﾞｨｵｺｰﾄﾞ
Pin Jack Cover / ﾋﾟﾝｼﾞｬｯｸｶﾊﾞ
Connector Cover for male
ｺﾈｸﾀｶﾊﾞ
Part No.
631-0047-00
616-0306-02
631-0054-00
612-0308-00
604-0408-00
637-0042-07
631-0054-00
611-0414-02
630-0302-04
637-9045-04
604-0408-02
638-0041-02
820-2213-00
820-0213-00
821-0011-00
821-0010-00
680-1404-00
680-2401-00
680-3402-00
729-0028-00
569-0006-00
685-0416-10
685-0417-10
254-2015-04
254-2011-00
Remarks
3×8mm 6pcs.
3×6mm 6pcs.
3×10mm 2pcs.
3×8mm 4pcs.
4×8mm 4pcs.
4mm dia. 4pcs.
3×10mm 9pcs.
4×14mm 4pcs.
4pcs.
4pcs.
4×8mm 8pcs.
8pcs.
English
Japanese
English
Japanese
2-conductor
2-conductor
3-conductor
RC-28
R03 /UM-4/単4
White /1m
Red /1m
4pcs.
2pcs./出力用
－５－
SACD
Laserdiodens specifikationer Laserdiodespecifikationer Laserdiode-spesifikasjoner Laserdiodin ominaisuudet
*Material: GaAlAs *Materiale: GaAlAs *Materiale: GaAlAs *Materiaali: GaAlAs
*Våglängd: 780nm *Bølgelængde: 780nm *Bølgelengde: 780nm *Aallonpituus: 780nm
*Laseruteffekt: 28.5uW *Laserudgangseffekt:28.5uW *Laserutgangseffekt: 28.5uW *Laserin teho: 28.5uW
Laserdiodens specifikationer Laserdiodespecifikationer Laserdiode-spesifikasjoner Laserdiodin ominaisuudet
*Material: AlGalnP *Materiale: AlGalnP *Materiale: AIGalnP *Materiaali: AIGalnP
*Våglängd: 650nm *Bølgelængde: 650nm *Bølgelengde: 650nm *Aallonpituus: 650nm
*Laseruteffekt: 73.7uW *Laserudgangseffekt:73.7uW *Laserutgangseffekt:73.7uW *Laserin teho: 73.7uW
CD
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO BEAM
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
VARNING-LASERSTRÅLNING NÄR DENNA DEL AR ÖPPNAD
STRÅLEN ÄR FARLIG
VARO!-AVATTAESSA OLET ALTTIINA LASERSÄTEILYLLE
ÄLÄ KATSO'SÄTEESEN BETRAKTA EJ STRÅLEN
ADVARSEL-LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÅLING
ADVARSEL-LASERSTRÅLING NÅR DEKSEL ÅPNES
UNNGÅ EKSPONERING FOR STRÅLEN
Please perform lens cleaning of an optical pickup by air blow.
The cleaning in a swab etc. causes failure.
光ﾋﾟｯｸｱｯﾌﾟのﾚﾝｽﾞｸﾘｰﾆﾝｸﾞはｴｱｰﾌﾞﾛｱｰで行って下さい。
綿棒などでのｸﾘｰﾆﾝｸﾞは故障の原因となります。

SACD Kit (731-0007-00)
Including Main Board Ass'y
See page 10.
－６－
Mechanical Assembly (731-0007-00M)
Ass'y
Disc Table(4-948-353-18)
ﾃﾞｨｽｸﾃｰﾌﾞﾙ /not supplied
Optical Pick-up(8-820-132-03)
ｵﾌﾟﾄﾋﾟｯｸｱｯﾌﾟ
Belt(4-927-649-01)
ﾍﾞﾙﾄ
not suppled
It does not need to be adjusted at the time of this
machine performing part exchange etc.,
since automatic adjustment is performed for every disk.
本機はﾃﾞｨｽｸ毎に自動調整が行われる為に、部品交換などを
行った際の調整は必要ありません。
ｵﾌﾟﾄﾋﾟｯｸｱｯﾌﾟのﾚｰｻﾞﾀﾞｲｵｰﾄﾞは、衣服や人体に帯電した静電
荷等で電位差を生じ、静電破壊を生じる危険があります。
修理時においては充分に注意し行って下さい。
The laser light of this machine is condensed so that
a focus may be connected in the shape of a reflective
side with the object lens in an Optical pickup.
Therefore,when you check luminescence of a laser diode,
please look aside more than 30㎝ from an object lens.
本機のﾚｰｻﾞ光は、ｵﾌﾟﾄﾋﾟｯｸｱｯﾌﾟ内の対物ﾚﾝｽﾞによってﾃﾞｨｽｸ
の反射面状に焦点を結ぶように集光されます。従って、ﾚｰｻﾞ
ﾀﾞｲｵｰﾄﾞの発光を確認する時は、対物ﾚﾝｽﾞより30㎝以上目を
離して下さい。
Handling needs to keep in mind that a flexible printed
circuit board tends to go out.
* When there is the necessity for solder, perform solder
iron point temperature before and after 270 degrees C.
* Please do not apply the solder iron point to
* same pattern to be careful repeatedly for power not to
join a pattern.
ﾌﾚｷｼﾌﾞﾙﾌﾟﾘﾝﾄ基板は切れ易いので取扱いは注意が必要です。
･ﾊﾝﾀﾞの必要がある時はｺﾃ先温度は270℃前後で行います。
･ﾊﾟﾀｰﾝに力が加わらないように注意が必要です｡
･同一ﾊﾟﾀｰﾝに何度もｺﾃ先を当てないで下さい。
The laser diode of an Optical pickup has a risk of pro-
ducing potential difference in electrical charged on
clothes or the human body, and producing Static
electricitydestruction.
At the time of repair, be carefully and carry out.
Switch Assembly (1-641-764-11)
ｽｲｯﾁ Ass'y
Loading Motor (1-641-765-11)
ﾛｰﾃﾞｨﾝｸﾞﾓｰﾀ
RF Board (1-679-092-11)
Optical Pick-up (8-820-132-03)
ｵﾌﾟﾄﾋﾟｯｸｱｯﾌﾟ
A cam is turned counterclockwise strongly.
ｶﾑを反時計方向に強く回します。
Remove the holder./ﾎﾙﾀﾞｰを外します｡
A Disc table is pulled out, 4 screws is removed
and a Optical Pickup is removed.
ﾃﾞｨｽｸﾃｰﾌﾞﾙを引き出します。ｵﾌﾟﾄﾋﾟｯｸｱｯﾌﾟを固定
するﾈｼﾞ、ｲﾝｼｭﾚｰﾀを外し､ﾋﾟｯｸｱｯﾌﾟを交換します｡
A,B Two connectors are removed.
A,B ２カ所のｺﾈｸﾀｰを外します。
A
B
Holder /ﾎﾙﾀﾞｰ
Disc Table /ﾃﾞｨｽｸﾃｰﾌﾞﾙ
Solder is removed from a pattern land.
ﾊﾝﾀﾞをﾊﾟﾀｰﾝﾗﾝﾄﾞから除きます｡
Insulator
ｲﾝｼｭﾚｰﾀｰ
Screw / ﾈｼﾞ(2.6X8)
Stopper /ｽﾄｯﾊﾟｰ
Cam / ｶﾑ
IMPORTANT
重要
The parts of this mark are not supplied.
ｽﾀｰﾏｰｸの部品は供給で き ません｡
Caution /注意
Up
①
②
③
④
⑤
⑥
⑦⑤⑥ ⑦

－７－
IC3 CS8404A-CS
IC4 TC74VHCT04AF
IC5,6 TMS57070FFT
IC7 427-0010-10
IC IC7 S-80845CLY
IC8 CS8427-CS/REVA2
IC9 M93C46-BN6
IC10 TMP87PH00N
IC101 TC74HC00AF
IC201 TC74VHCU04F
Variable/ﾊﾞﾘｷｬｯﾌﾟ D101,102 HVM17
Capacitance Diode
Ferrite Beads BK1608HM601-T FB1,2
ﾌｪﾗｲﾄﾋﾞｰｽﾞ
Ceramic C1～10,21～24 CK725B1E223M16T 0.022uF/25V
Capacitor C25,26,101,201 CG14Y1C103MS 0.01uF / 50V
磁器ｺﾝﾃﾞﾝｻ C34,35,111 CK92Y5V1H104Z 0.01uF /50V
C36,37 CK14B1H102KS 0.001uF/50
V
C50,51 CC14SL1H470JS 47pF / 50V
C105,107 CC14CH1H680JS 68pF / 50V
C106,108 CC14CH1H4R7KS 4.7pF / 50
V
Electorlytic C11,28,104,109,110 CE04W0J471VR 470uF /6.3V
Capacitor C27,29 CE04W0J470SR 47uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C102 CE04W1H2R2SL 2.2uF / 50V
Polyester Film C30,31 CQ922M1H103J-B 0.01uF /50
V
Capacitor C32 CQ922M1H682J-B 6,800pF/50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ C33 CQ922M1H104J-B 0.1uF / 50
V
Polyester Film C103 CF922N1H224JMTFF 2.2uF /50
V
Capacitor
ﾎﾟﾘｴｽﾃﾙ ﾌｲﾙﾑ
ｺﾝﾃﾞﾝｻ
Carbon Film R1 RD142CA101J 100Ω 1/6W
Resistor R2,105,108 RD142CA471J 470Ω 1/6W
炭素被膜抵抗器 R4 RD142CA470J 47Ω 1/6W
R6 RD142CA242J 2.4kΩ 1/6W
R7,9,10,14～18 RD142CA473J 47kΩ 1/6W
R8,106,109 RD142CA103J 10kΩ 1/6W
R11 RD142CA332J 3.3kΩ 1/6W
R13 RD142CA472J 4.7kΩ 1/6W
R20～22,24,31～35 RD142CA221J 220Ω 1/6W
R23 RD142CA100J 10Ω 1/6W
R30 RD142CA331J 330Ω 1/6W
R101,103 RD142CA102J 1kΩ 1/6W
R102 RD142CA393J 39kΩ 1/6W
R104,107 RD142CA105J 1MΩ 1/6W
Resistor Array RA1 RD92AK05C473J18
抵抗ｱﾚｨ RA2 RD92AK16C473J18
RA3 RD92AK13C473J18
RA4 RD92AK04C473J18
RA5 RD92AK09C473J18
DSP
A
ssembly (724-0055-00)
IC Socket SOCKET1 300-1104-00
ICｿｹｯﾄ
Connector Plug K1 308-1402-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K3,4 308-0905-00
K903 308-0707-00
K904 308-0306-00
Connector Jack K2 307-3001-00
ｺﾈｸﾀｼﾞｬｯｸ K901 307-1607-00
Crystal IC11 425-0015-00
水晶発振器 IC12 425-0016-00
水晶振動子 XTAL101 527-0038-00
水晶振動子 XTAL102 527-0039-00
ｾﾗﾛｯｸ XTAL3 527-0025-00
Choke Coil L1 507-4705-00
ﾁｮｰｸｺｲﾙ
Transistor Q1 2SC3113-B
ﾄﾗﾝｼﾞｽﾀ Q101 2SC982TM
FET Q2 2SJ105-GR,Y
K2
K1
Q1
IC10
IC3
IC4
IC5
IC6
IC201
IC9
K903
K901
K904
K3
IC101 IC8
IC11
XTAL101 XTAL102
IC12
IC7
K4
SOCKET1
IC7
IC1
LPF1
X1 K1
IC2
IC3
IC5
JK1 JK3
IC4
Pin Jack JK1,3 302-0116-00
ﾋﾟﾝｼﾞｬｯｸ
Connector Plug K1 308-0707-00
ｺﾈｸﾀﾌﾟﾗｸﾞ
Choke Coil L1 507-4705-00
ﾁｮｰｸｺｲﾙ
Low Pass Filter LPF1 520-5005-00
ﾛｰﾊﾟｽﾌｨﾙﾀｰ
IC IC1,3 TC74HCU04AF
IC5 TC74VHCT04AF
Opt-transmitter IC2 GP1FA513TZ
ｵﾌﾟﾄﾄﾗﾝｽﾐｯﾀ
Optical Receiver IC4 GP1FA513RZ
ｵﾌﾟﾄﾚｼｰﾊﾞ
Digital Transistor X1 RN1202
ﾃﾞｨｼﾞﾀﾙﾄﾗﾝｼﾞｽﾀ
Ceramic Capacitor C1,6 CK92FJ1H474Z 0.47uF /50V
磁器ｺﾝﾃﾞﾝｻ C2 CK92Y5V1H104Z 0.1uF /50V
C4,8,9 CG14Y1C103MS 0.01uF /16V
Electorlytic Capacitor C3,5,7 CE04W0J470VR 470uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Carbon Film Resistor R1 RD142CA241J 240Ω 1/6W
炭素被膜抵抗器 R2,3 RD142CA101J 100Ω 1/6W
R4 RD142CA473J 47kΩ 1/6W
R5 RD142CA104J 100kΩ1/6W
R7 RD142CA221J 220Ω 1/6W
R8 RD142CA222J 2.2kΩ1/6W
Metal Film Resistor R6 RN142CK75R0F 75Ω 1/6W
金属被膜抵抗器
IO Assembly (726-0142-00)

－８－
Heat Sink 240-1061-04
ﾋｰﾄｼﾝｸ
XLR(Canon) JK2,3 301-8005-00
Plug Receptacle
ｵｰﾃﾞｨｵｺﾈｸﾀﾌﾟﾗｸﾞ
Pin Jack JK1,4 302-0116-00
ﾋﾟﾝｼﾞｬｯｸ
Connector Plug K1,2,102 308-0304-00
ｺﾈｸﾀﾌﾟﾗｸﾞ K3 308-1402-00
K101 308-1013-00
K103 308-0508-00
K104 308-0606-00
K701 308-0905-00
IC Protector F1～6 310-8251-00
ICﾌﾟﾛﾃｸﾀ
Relay RELAY1,2,3 362-0202-00
ﾘﾚｨ
LED D1,2 TLS262-C
Diode D5,6 LN1VB60
ﾀﾞｲｵｰﾄﾞ D11,108,109,112,113 MA165
D101,102,103 S1VB60
D104,105 D4SBS4
D110,111 EK03
Zener Diode D7,8,9,10 RD3.0EB1
ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ D106 HZ332L
D107 RD7.5F-B
Transistor Q1,2,3,4 2SA1316-BL
ﾄﾗﾝｼﾞｽﾀ Q5,6 2SC3421-Y
Q7,8 2SA1358-Y
Q101 2SA1048-GR
IC IC1,2,3 ISO150AU
IC4,5,6,7 PC817-B/C
IC8,9,101 TC74VHC14F/EL
IC10,11,12,13 AD1853JRS
IC14,15,18,19 NJM4580D-D
IC16,17 NJM2114D
IC20,22 NJM78M05FA
IC001 UPC2412AHF
IC002 UPC2405AHF
IC003,005 UPC29M33HF
IC004 UPC24M05AHF
IC006 UPC2408AHF
IC007 UPC7908AHF
D
A
C
A
ssembly (725-0041-00)
Ceramic Capacitor C1,2,3,6,100,103,104,105 CG14Y1C103MS 0.01uF/16V
磁器ｺﾝﾃﾞﾝｻ C7,8,9,10,15,16,17,18 CK725B1E223M16T 0.022uF/25V
C19～22,27～30 CC92CH1H221J 220pF/50V
C85,86,221～227,229 CK92Y5V1H104Z 0.1uF /50V
C11,12,13,14 CE04W1C560LXY 56uF /16V
C23,24,25,26 CE04W1E100VR 10uF /25V
C31,32,81,～84,91,92 CE04W2C100RE3 10uF /160V
Electorlytic Capacitor C45,46,55,56,57,58 CE04W1C101PZ 100uF /16V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C67,68,95,97,98 CE04W2C4R7RE3 4.7uF /160V
C73,74,75,76 CE04W1C222VR 2,200uF/16V
C77,78,79,80 CE04W1E561LXV 560uF /25V
C87,88,89,90 CE04W1H100CA 10uF /50V
C101,211～215,218,219 CE04W1C101CA 100uF /16V
C201,202 CE04W1E332CZ 3,300uF/25V
C203,204,205 CE04W1A682VR 100uF /16V
C206 CE04W1H101VR 100uF /50V
C207,208,209,210 CE04W1C332VR 3,300uF/16V
C216,217,220 CE04W1H100VR 10uF /50V
Polypropylen Capacitor C33～40 CQ93PP2A332JM-F 3,300pF/100V
ﾎﾟﾘﾌﾟﾛﾋﾟﾚﾝｺﾝﾃﾞﾝｻ C41,42,43,44 CQ93PP2A331JM-F 330pF /100V
C61,62,65,66 CQ93PP2A471JM-F 470pF /100V
Polyester Film Capacitor C47 ～54 CQ922M1H101K-B 100pF /50V
ﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ C93,94 CF922MF2E473KD-AZ 0.047uF/250V
積層ｺﾝﾃﾞﾝｻ C228 CF922N1H104J 0.1uF /50V
PPS Capacitor/PPSｺﾝﾃﾞﾝｻ C63,64 CQ922M1H471JAHS 470pF / 50V
Carbon Film Resistor R1,2,3,4 RD142CA391J 390Ω 1/6W
炭素被膜抵抗器 R5～8,67～70,91～94 RD142CA102J 1kΩ 1/6W
R9,10,11,13 RD142CA221J 220Ω 1/6W
R12,14,15,87～90 RD142CA101J 100Ω 1/6W
R21,22,23,24 RD142CA151J 150Ω 1/6W
R25,26,107 RD142EA102J 1kΩ 1/4W
R37,38,39,40 RD142EA182J 1.8kΩ 1/4W
R43,44,63,64,65,66 RD142EA470J 470Ω 1/4W
R45,46,71,72,73,74 RD142CA103J 10kΩ 1/6W
R75,76,77,78,79,80 RD142CA222J 2.2kΩ 1/6W
R81,82 RD142CA332J 3.2kΩ 1/6W
R83,84,85,86 RD142CA470J 470Ω 1/6W
R101 RD142EA682J 6.8kΩ 1/4W
R102,104,105 RD142EA101J 100Ω 1/4W
R103 RD142EA104J 100kΩ 1/4W
R106 RD142EA183J 18kΩ 1/4W
R108 RD142EA335J 3.3MΩ 1/4W
R109,110,111,112,113 RD142EA472J 4.7kΩ 1/4W
Metal Film Resistor R17,18,19,20 RN142CK2701F 2.7kΩ 1/6W
金属被膜抵抗器 R27,28,29,30 RN142EK6340F 6.34Ω 1/4W
R31～36,41,42 RN142EK2001F 2kΩ 1/4W
R47～54 RN142EK4991D 4.99kΩ 1/4W
R55～62 RN142EK5111D 5.11kΩ 1/4W
IC8
RELAY2
IC11
K101
IC003
K102
K103
JK1
JK2
RELAY3
Q101
IC100
IC101
IC001
IC002 IC007
IC12
IC13 IC22
IC004
IC005 IC006
JK4
JK3
RELAY1
K2
K1 K3
IC10 IC14
IC18
IC16
IC15 IC19 IC17
IC3
IC2
IC1
K701
K104
IC20
F1～6

Po
w
er S
w
itch
A
ssembly (726-0143-00)
Ass'y Fuse Holder FH1,2 306-2001-00
ﾌｭｰｽﾞﾎﾙﾀﾞｰ
Connector Plug K1 308-0236-00
ｺﾈｸﾀﾌﾟﾗｸﾞ
Power Push Switch S1 354-1024-00
電源ｽｲｯﾁ
Metalized Polyester C1 CF99MF2E103M 0.01uF/250V
Capacitor
ﾒﾀﾗｲｽﾞﾄﾞﾎﾟﾘｴｽﾃﾙｺﾝﾃﾞﾝｻ
－９－
Mother Board Assembly (726-0144-00)
Ass'y
Connector Jack 307-3001-00 K2
ｺﾈｸﾀｼﾞｬｯｸ 307-3204-00 K10,20
Connector Plug 308-0609-00 K1
ｺﾈｸﾀﾌﾟﾗｸﾞ 308-0708-00 K3
Digital Transistor RN2223 X1
ﾃﾞｨｼﾞﾀﾙﾄﾗﾝｼﾞｽﾀ
Diodes MA165 D10,20
ﾀﾞｲｵｰﾄﾞ
TC74VHC125F/EL IC10,20,30
IC TC74VHC244F/EL IC11,31
TC74HC595AF/EL IC100,101,102
TC74VHC14F/EL IC103
Electorlytic Capacitor C1,2 CE04W0J330MA 33uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ
Ceramic Capacitor C10,11,20,30,31, CK92Y5V1H104Z 0.1uF/50V
磁器ｺﾝﾃﾞﾝｻ 100,101,102,103
Carbon Film Resistor R1,2,3,10,20 RD142CA221J 220Ω 1/6W
炭素被膜抵抗器 R4 RD142CA102J 1kΩ 1/6W
Resistor Array RA1,10,20 RD92AK06C473J18
抵抗ｱﾚｨ RA2,3 RD92AK04C104J25
Display Assembly (723-0081-00)
Ass'y
Rubber Cushion 250-2131-04
ｺﾞﾑｸｯｼｮﾝ
Connector Jack Ass'y K1 309-2543-04
ｺﾈｸﾀｼﾞｬｯｸAss'y K2,3 309-0927-04
Rotary Encoder S6 339-0006-00
ﾛｰﾀﾘｴﾝｺｰﾀﾞｰ S7 339-0008-00
Push Switch S1,2,3,4,5 354-1116-00
ﾌﾟｯｼｭｽｲｯﾁ
Display Tube FL1 434-0013-00
蛍光表示管
IC IC1 ML9205-01GP
Infrared Receiver IC2 NJL64H380A
赤外線ﾚｼｰﾊﾞ
Electorlytic Capacitor C1 CE04W0J330MA 33uF /6.3V
ｱﾙﾐ電解ｺﾝﾃﾞﾝｻ C8 CE04W0J470SR 47uF /6.3V
Ceramic Capacitor C2～6 CK92Y5V1H104Z 0.01uF/400V
磁器ｺﾝﾃﾞﾝｻ C7 CC14SL1H470JS 47pF /50V
C9 CK14B1H102KS 1000pF/50V
Carbon Film Resistor R5 RD142CA332J 3.3kΩ 1/6W
炭素皮膜抵抗器 R6 RD142CA470J 47Ω 1/6W
R7 RD142CA101J 100Ω 1/6W
R8 RD142CA472J 4.7kΩ 1/6W
Resistor Array RA1 RD92AK05C473J18
抵抗ｱﾚｨ
FH1
S1
C1
K1
FH2
K10
IC103
RA2
X1
RA10
RA3 K20 IC102 IC101 IC100
RA1
K2
K3
IC20
IC10
K1
IC31
IC11
IC30
RA20
C1C2
S1
FL1
S5
S4
S3
S2
IC2 IC1
S6
S7
K1
K2 K3

－１０－
BACK/NEXT:track search Button,external input selector button
REPEAT Button / ﾘﾋﾟｰﾄﾎﾞﾀﾝ
Input Selector Button / 入力ｾﾚｸﾀｰ･ﾎﾞﾀﾝ
EXT DSP Button / EXT DSP ﾎﾞﾀﾝ
OPEN/CLOSE Button / ｵｰﾌﾟﾝ･ｸﾛｰｽﾞ･ﾎﾞﾀﾝ
PLAY/PAUSE Button / PLAY･PAUSE ﾎﾞﾀﾝ
FR / FF Button / FR:早戻 し ･FF早送 り ･ﾎﾞﾀﾝ
PROGRAM Button / ﾌﾟﾛｸﾞﾗﾑ･ﾎﾞﾀﾝ
Index serach button
TRACK/INDEX button
STOP button / 停止ﾎﾞﾀﾝ
Time mode selector button
Output Level button /
出力ﾚﾍﾞﾙ調整ﾎﾞﾀﾝ
Direct play button /
ﾀﾞｲﾚｸﾄ選択ﾎﾞﾀﾝ
CD/PROC selector button /
CD/PROC切替ﾎﾞﾀﾝ
Top side Bottom side
Disc Table(4-948-353-18)
ﾃﾞｨｽｸﾃｰﾌﾞﾙ /not supplied
Optical Pick-up(8-820-132-03)
ｵﾌﾟﾄﾋﾟｯｸｱｯﾌﾟ
Belt(4-927-649-01)
ﾍﾞﾙﾄ The parts of this mark are not supplied.
ｽﾀｰﾏｰｸの部品は供給で き ません｡
Caution /注意

Accuphase Laboratory Inc.
Issued 2003-12-10
MODEL : DP-77
機種
SUBJECT :(1) To prevent the output becomes nothing in unusual
(2) To be improve the reliability of lock in at external in
項目 :電源オン時、出力無しとなる可能性を防止する
:外部入力時、ロック外れになるのを防止する 。
Details ;(1).At the time of a power supply on,the IC8 of DSP Ass'y carries out incorrect
operation,and output relay does not turn on.
Countermeasure is follows,remove the R5 (22Ω) and add the jumper to both end
of R5 that located on DSP Ass'y (724-0055-00).
(2) An input is put into a coaxial input or an optical input, An output may be
interrupted when it is made to operate.
Countermeasure as follows, change the resistor value of R105 & R108 from 150Ω
to 330Ωthat located on DSP Ass'y(724-0055-00).
詳細; POWER ON時 DSP Ass'y内IC8 CS8427が誤動作し 出力ﾘﾚｲがONしない。
対策は DSP Ass'y(724-0055-00) R5(22Ω)削除しｼﾞｬﾝﾊﾟｰする。
; COAXおよびOPTに入力をいれ、出力すると音がとぎれる場合があります。
対策はDSP Ass'y(724-0055-00)内抵抗 R105,108(150Ω→330Ω)の定数を
変更します。
－１１－
DSP Ass'y (724-0055-00)
Jumper R5 Jumper Lead 1pcs.
Resistor R105,108 RD142CA331J(330Ω) 2pcs.
(1)Remove the DSP Ass'y
本体からDSP Ass'yを外す。
(2)Replace the resistors and add the jumper wire.
DSP Ass'y内R5の抵抗,削除しジャンパーに変更します。
R105,108の抵抗を330Ωに変更します 。
(RD142CA151J→RD142CA331J)
Jumper
R5
R105
R108
150Ω→330Ω
Service Information
An applicable serial number as follows, B3Y201 to B3Y300
該当 ｼﾘｱﾙ番号は B3Y201～ B3Y300
DSP Assembly
DSP Ass'y
(724-0055-00)
No. DP-77-001

Caution for AC line Voltage Selection
注意 ： 電源電圧の変更
The unit can be used with differnt voltage of 100V,120V,230V.
(Use the Japanese domestic model at 100V only, and never change the voltage in Japan.)
Refer the photo and illustration for the wiring on the junction terminal as shown below,
andhavetoselectthecorrectfuseandpowersupplycord.
電源電圧は 、 100V､120V､230V に対応で き ますが以下はその方法を示 し ます 。
（ 日本国内は100V仕様ですので 、 この電圧以外の変更は出来ません ）
電源電圧の変更をする場合は 、 フ ュ ーズ 、 電源コ ー ド は以下の指定さ れた コー ド を使用し ます 。
CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE REPLACEMENT ONLY WITH
SAME TYPE FUSE. (See above table)
100V WHT,BLUBLK
BLK
BRN
1
FUSE/ﾌｭｰｽﾞ
T1.25A L AC250V
(310-1104-00)
T630mA L AC250V
(310-1061-00)
AC Cord /電源ｺｰﾄﾞ
J type : 680-1404-00
U type : 680-2401-00
E type : 680-3402-00
－１２－
Photo is shown
Japanese model
wiring.
写真は日本国内
ﾓﾃﾞﾙの配線を示す
120V
230V
2(～)34(～)
WHT,BLU
WHT,BLU
BRN,ORG
YEL,ORG
BLK,ORG
YEL
BRN
YEL
100V WHTBLK
BLK
BRN
1
120V
230V
234
WHT
WHT
BRN
YEL
BLK
YEL
BRN
YEL
For 510-4032-00For 510-4031-00
100V
120V
230V
510-4032-00
１
２
３
４
510-4031-00
N
(W)
301-3306-00
T630mA L 250V at 220-240V
T1.25A L 250V at 100-120
V
FUSE: :
100V
120V
230V
BLK
BLK
BRN
12(~)34(~)
VOLTAGE SELECTION TABLE
WHT-BLU YEL
BRN
YEL
BRN-ORG
YEL-ORG
BLK-ORG
1
K1
POWER SWITCH Ass'y
726-0143-00
K1
2
3
4
POWER TRANSFORMER
510-4031-00
WHT
BRN
YEL
BLK
WHT-BLU
WHT-BLU
POWER TRANSFORMER
510-4032-00
WHT
BRN
YEL
BLK
RED.GRY.RED
BLU.WHI.BLU
YEL. BLK. YEL
(RED.GRN.ORG.YEL.BLU)
*
ORG
BLU
BLU
C001
103/2E
AC 100/120/230V
50/60Hz
電源ﾄﾗﾝｽ
電源ﾄﾗﾝｽ

PACKING
－１３－
Tray Sub-panel View
ﾄﾚｰｻﾌﾞﾊﾟﾈﾙ図
Tray Sub-panel Fixed Bracket
ﾄﾚｰｻﾌﾞﾊﾟﾈﾙ取付金具(A)
(247-0565-04)
Tray Sub-panel Fixed Bracket(B)
ﾄﾚｰｻﾌﾞﾊﾟﾈﾙ取付金具(B)
(247-0576-24)
Fixing Screw
取付金具ﾈｼﾞ
(614-0308-00)
Sub-panel Fixing Screw
ｻﾌﾞﾊﾟﾈﾙ取付ﾈｼﾞ
(604-2604-01)
Tray Sub-panel
ﾄﾚｰｻﾌﾞﾊﾟﾈﾙ
(134-0130-04)
Sub-panel Fixing Screw
ｻﾌﾞﾊﾟﾈﾙ取付ﾈｼﾞ
(604-2604-01)
Cushion
ｸｯｼｮﾝ
(250-2055-14)
Caution sheet
注意銘板
(180-2039-04)
Tray Sub Fixed Bracket
ﾄﾚｰ補強金具
(244-0090-04)
Wrapping Sheet
ｼｰﾄ
(810-4545-04)
Poly Bag for Owner's Manual
ﾋﾞﾆｰﾙ袋 /取扱説明書
(812-2435-04)
Battery :R6/UM-4
電池 / 単4型
(569-0006-00)
Cover for AC Cord,RC-20,Audio Cord
保護ｶﾊﾞ/電源ｺｰﾄﾞ
(810-2030-04)
Accessories Case
付属品ｹｰｽ
(801-0251-10)
Bag
保護ｶﾊﾞ/ｵｰﾃﾞｨｵｺｰﾄﾞ
(810-2030-04)
Carton Box
ﾀﾞﾝﾎﾞｰﾙ
(801-0243-14)
Cover
保護ｶﾊﾞ
(810-4843-04)
Bottom Pad(R)
ﾎﾞﾄﾑﾊﾟｯﾄﾞ/後部
(803-0327-00)
Bottom Pad(F)
ﾎﾞﾄﾑﾊﾟｯﾄﾞ/前部
(803-0326-00)
Top Pad(F)
ﾄｯﾌﾟﾊﾟｯﾄﾞ/前部
(803-0324-00)
Top Pad(R)
ﾄｯﾌﾟﾊﾟｯﾄﾞ/後部
(803-0325-00)
Top Board
天地当板
(803-0033-14)
Remote Commander
ﾘﾓｰﾄｺﾏﾝﾀﾞ RC-28A
(729-1028-00)
Bag
保護ｶﾊﾞ/ﾘﾓｺﾝ
(810-2030-04)
Bag
保護ｶﾊﾞ
(810-1030-04)

－１4－

N
(W)
301-3306-00
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
T630mA L 250V at 220-240V
T1.25A L 250V at 100-120V
FUSE: :
100V
120V
230V
BLK
BLK
BRN
12(~)34(~)
VOLTAGE SELECTION TABLE
WHT-BLU YEL
BRN
YEL
BRN-ORG
YEL-ORG
BLK-ORG
!
1
313-4046-00
K1
POWER SWITCH Ass'y
726-0143-00
2
3
4
POWER TRANSFORMER
510-4031-00
WHT
BRN
YEL
BLK
K1JK1
JK2
IO Ass'y
726-0142-00
K2
K1
K3
DISPLAY Ass'y
723-0081-00
K3
K2
K1
MOTHER BOARD Ass'y
726-0144-00
K701
K101 JK1 JK2
K102
JK3
K104 K103
JK4K3
K2
K1
DAC Ass'y
725-0041-00
CN005
BASE UNIT
731-0007-00
CN503
CN901
CN902CN903 CN904
CN701
GND
MAIN BOARD Ass'y
731-0007-00
!
!
WHT-BLU
WHT-BLU
!
!
POWER TRANSFORMER
510-4032-00
WHT
BRN
YEL
BLK
!
K1
K2 K4
K903K901 K904
K3
DSP Ass'y
724-0055-00
Analog Output Unbalanced Left chnnel
RED.GRY.RED
BLU.WHI.BLU
YEL.BLK.YEL
(RED.GRN.ORG.YEL.BLU)*2
ORG
BLU
Analog Output Balanced Right chnnel
Analog Output Balanced Left chnnel
Analog Output Unbalanced Left chnnel
Coaxial Output
Coaxial Input
BLU
C001
103/2E
D P - 7 7  M A S T E R  C I R C U I T  D I A G R A M
-15-

AD3
1
AD4
2
SEG1
3
SEG2
4
SEG3
5
SEG4
6
SEG5
7
SEG6
8
SEG7
9
SEG8
10
SEG9
11
SEG10
12
SEG11
13
SEG12
14
SEG13
15
SEG14
16
SEG15
17
SEG16
18
SEG17
19
SEG18
20
SEG24
26
SEG25
27
SEG26
28
SEG27
29
SEG28
30
SEG29
31
SEG30
32
SEG31
33
SEG32
34
SEG33
35
SEG34
36
SEG35
37
VDISP1
38
COM1
39
COM2
40
SEG19
21
SEG20
22
SEG21
23
SEG22
24
SEG23
25
COM14 52
COM15 53
COM16 54
COM17 55
COM18 56
COM19 57
COM20 58
COM21 59
COM22 60
COM9 47
COM23 61 COM24 62
VFL1 63
GND 64
OSC0 65 OSC1 66
/RESET 67
/CS 68 /CP 69
DA 70
VDD 71
P1 72 P2 73 P3 74 P4 75
VFL2 76
NC 77
VDISP2 78
AD1 79 AD2 80
COM3 41
COM4 42
COM5 43
COM6 44
COM7 45
COM8 46
COM10 48
COM11 49
COM12 50
COM13 51
IC1
ML9205-01GP
F1 2
S26 5 S27 6 S28 7 S29 8 S30 9 S31 10 S32 11 S33 12 S34 13 S35 14 S25 15 S24 16 S23 17 S22 18 S21 19 S20 20 S19 21 S18 22 S17 23 S16 24 S15 25 S14 26 S13 27 S12 28 S11 29 S10 30
S9 31 S8 32 S7 33 S6 34 S5 35 S4 36 S3 37 S2 38 S1 39
G1 41 G2 42 G3 43 G4 44 G5 45 G6 46 G7 47 G8 48
G18 49 G17 50 G16 51 G15 52 G14 53 G13 54 G12 55 G11 56 G10 57
G9 58
F2 61
FL1 434-0013-00
VCCVCC
VCC
-33V-33V
F2
F1
-33V
GND
to POWER SUPPLY ASSY
C5
104
C6
104
-33V
1 2 3 4
S1 354-1116-00
1 2 3 4
S2 354-1116-00
1 2 3 4
S3 354-1116-00
1 2 3 4
S4 354-1116-00
1 2 3 4
S5 354-1116-00
OPEN/CLOSE PLAY PAUSE STOP SACD/CD
C7
470
R5 332
C2
104 C3 104
VCC
P33 P35 P34 P32 P31 P30 P29 P28 P27 P26 P25 P24 P23 P22 P21 P20 P19
P18
P17
P16
P15
P14
P13
P12
P11
P10
P9
P8
P7
P6
P5
P4
P3
P2
P1
G1 G2
G3
G4
G5
G6
G7
G8
G9
G10
G11
G12
G13
G14
G15
G16
G17
G18
G9 G10 G11 G12 G13 G14 G15 G16 G17 G18 G8 G7 G6 G5 G4 G3 G2 G1 P1 P2 P3 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P17 P18 P19 P20 P21 P22 P23 P24 P25 P35 P34 P33 P32 P31 P30 P29 P28 P27 P26
/RESET
/CS /CP DA
RA1
RD92AK05C_18
473
D5V 1
2
3
4
5
6
7
8
9
K2 280-9009-00
1
2
3
4
5
6
7
8
9
K3 280-9009-00
to DIGITAL ASSY
to DIGITAL ASSY
/RESET
/CS
/CP
DA
TRACK INPUT SELECTOR
push ENTER
SW_STOP
SW_SACDCD
SW_ENTER
SW_EXTDSP
EN_TRACKA
EN_TRACKB
EN_SELECTORA
EN_SELECTORB
GND
D5V
FL_DA
FL_/CP
FL_/CS
FL_/RESET
SW_OPENCLOSE
SW_PLAY
SW_PAUSE
C4
104
C1
330
/0J
C8
470
/0J
R6
470 G4
G
2
O
1
G
5
V
3
IC2
NJL64H380A
D5V
REMOCON
D
E
1H
B
A
C
2H
S6
339-0006-00
1
2
3
4
5
K1
280-9005-00
D5V
VCC
R8
472
R7
101
D5V D5V
C9
102
/1H
1H
A
B
C
2H
S7
339-0008-00
DP-77DISPLAYASS'Y(723-0081-00)
-16-

1 2
IC201A
TC74VHCU04F
3V
GND
VCC
C201
103
3 4
IC201B
TC74VHCU04F
5 6
IC201C
TC74VHCU04F
9 8
IC201D
TC74VHCU04F
11 10
IC201E
TC74VHCU04F
13 12
IC201F
TC74VHCU04F
I1
I2
I3
I4
I5
I6
O1
O2
O3
O4
O5
O6
R106
103 C105
680
C106
4R7
XTAL101
527-0038-00
22.5792MHz
R104105
D101
HVM17
VCC
Q101
2SC982TM_
R101
102
C102
2R2
/1H R102
393
R103
102
C103
224
VCX44E
PD
5V-OSC
5V-FIL
C101
103
GND
1
23
IC101A
TC74HC00AF
R105
471
R109
103 C107
680
C108
4R7
XTAL102
527-0039-00
24.576MHz
R107105
D102
HVM17
12
13 11
IC101D
TC74HC00AF
R108
471
9
10 8
IC101C
TC74HC00AF
4
56
IC101B
TC74HC00AF
VCX512FS
C104
471
/0J
VCX48E
VCC
C111
104
C109
471
/0J
C110
471
/0J
-17-
D P - 7 7  D S P  A S S ' Y ( 7 2 4 - 0 0 4 1 - 0 0 - 1 )DSPASS'Y(724-0041-00-2)

to DISPLAY ASSY
to DISPLAY ASSY
SW_STOP
SW_SACDCD
SW_ENTER
SW_EXTDSP
EN_TRACKA
EN_TRACKB
EN_SELECTORA
EN_SELECTORB
GND
VCC
FL-DA
FL-/CP
FL-/CS
FL-/RESET
SW-OPENCLOSE
SW-PLAY
SW_PAUSE
REMOCON
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
K2
307-3001-00
to MOTHER BOARD ASSY
SDATAB
SBCKB
SLCK0
SLCK1
SLCK2
SLCK3
SLCK4
1
2
3
4
5
6
7
8
9
K4
308-0905-00
/OPMUTE
1
2
3
4
5
6
7
8
9
K3
308-0905-00
SRDATA
C33
104
/VCCON
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
K901
307-1607-00
CDDATA
DGND
CDBCK
DGND
CDLRCK
DGND
SBCK(128FSO)
DGND
SDATAR
DGND
SDATAL
VCC
DGND
/DIS
1
VSS
2OUT 3
VDD 4
IC11
425-0015-00
12.5MHz
LT64FSO
/DIS
1
VSS
2OUT 3
VDD 4
IC12
425-0016-00
22.5792MHz
DFGND
256FSO
FB2
BK1608HM601-T
DF3.3V
to MAIN BOARD
FB1
BK1608HM601-T
1
2
3
4
5
6
7
K903
308-0707-00
/ACK
/REQ
SOUT
SIN
C51
470
SCK
C50
470
/RESET
GND
to MAIN BOARD
1
2
3
K904
308-0306-00
S
Q2
2SJ105_-GR,Y
to MAIN BOARD
VCC
D3V
DOUT
GND
CLAT
I
G
O
IC7
S-80845CLY
/S-80845ALY
CCLK
CDAT
R13
472
MCLK
DATAR
BCLK
WCLK
RELAY
D+5V
GND
RST
GND
DATAL
GND
VCC
5V-OSC
GND
VCX512FS
PD
VCX44E
5V-FIL
VCX48E
DSP ASSY /VCXO
(724-0041-00-1)
R1
101
R2
471
VCC
ED18
1
ED19
2
ED20
3
ED21
4
ED22
5
ED23
6
VSSa
7
VDDa
8
CKM0
9
CKM1
10
TMS
11
TDI
12
TCK
13
CKIN
14
VSSb
15
VDDb
16
CKOT
17
ED0
18
ED1
19
ED2
20
ED11 31
VSSd 32
VDDd 33
ED12 34
ED13 35
ED14 36
ED15 37
TST0 38
TST1 39
TST2 40
TST3 41
BIO 42
INT1 43
INT2 44
INT3 45
RBC1 46
RBC2 47
X1 48
X2 49
X3 50
LMV 72
DRDY 73
EMU0 74 EMU1 75
TDO 76
/512 77
RLR1 78 RLR2 79
VSSg 80
XBC1 67
VSSe 51
VDDe 52
HX 53
EMP 54
XLR2 55
R1 56 R2 57
HRBK 58
HR 59
HRS 60
VDDg
81
HDIR
82
5V3V
83
MUTE
84
TRST
85
RS
86
IOE
87
RAS
88
CAS
89
VSSh
90
VDDh
91
WE
92
EA0
93
EA1
94
EA2
95
EA3
96
VSSi
97
VDDi
98
ED16
99
ED17
100
ED3
21
VSSc
22
VDDc
23
ED4
24
ED5
25
ED6
26
ED7
27
ED8
28
ED9
29
ED10
30
HXBK 61
HXS 62
CS 63
HBKS 64
VSSf 65
VDDf 66 XBC2 68 XLR1 69
/8 70
LAV 71
IC5
TMS57070FPJ
DSI-WK
DSI-BK
DSI-LR
RA5
RD92AK09C_18
473
R35 221
R34 221
DSO-L
R33 221
R32 221
DSO-WK
R31 221
DSO-BK
R30 331
L1
507-4705-00
470
RESERVE3
VCC
VCC
R11
332
PLLREF
PLLVAR
SLCK4A
SLCK3A
SLCK2A
SLCK1A
SLCK0A
PDOUT
12R5MHZ 512FS
C11
471
/0J
R10
473
VCC
R24 221
R23 100
R22 221
R21 221
DSC-RS
R20 221
DSC-CSL
RA4
RD92AK04C_18
473
1
2
3
4
5
6
7
8
9
10
11
12
13
14
K1
308-1402-00
set to x2
for IC7 427-0010-10
SLCK4A
SLCK3A
SBCKA SDATAA (2FS)
ED18
1
ED19
2
ED20
3
ED21
4
ED22
5
ED23
6
VSSa
7
VDDa
8
CKM0
9
CKM1
10
TMS
11
TDI
12
TCK
13
CKIN
14
VSSb
15
VDDb
16
CKOT
17
ED0
18
ED1
19
ED2
20
ED11 31
VSSd 32
VDDd 33
ED12 34
ED13 35
ED14 36
ED15 37
TST0 38
TST1 39
TST2 40
TST3 41
BIO 42
INT1 43
INT2 44
INT3 45
RBC1 46
RBC2 47
X1 48
X2 49
X3 50
LMV 72
DRDY 73
EMU0 74 EMU1 75
TDO 76
/512 77
RLR1 78 RLR2 79
VSSg 80
XBC1 67
VSSe 51
VDDe 52
HX 53
EMP 54
XLR2 55
R1 56 R2 57
HRBK 58
HR 59
HRS 60
VDDg
81
HDIR
82
5V3V
83
MUTE
84
TRST
85
RS
86
IOE
87
RAS
88
CAS
89
VSSh
90
VDDh
91
WE
92
EA0
93
EA1
94
EA2
95
EA3
96
VSSi
97
VDDi
98
ED16
99
ED17
100
ED3
21
VSSc
22
VDDc
23
ED4
24
ED5
25
ED6
26
ED7
27
ED8
28
ED9
29
ED10
30
HXBK 61
HXS 62
CS 63
HBKS 64
VSSf 65
VDDf 66 XBC2 68 XLR1 69
/8 70
LAV 71
IC6
TMS57070FPJ
DSI-WK
DSI-BK
DSI-LR
SBCKA
DSO-R
SDATAA
DSO-WK DSO-BK
VCC
DSC-RS
DSC-CSR
set to x2
(2FS)
VCX512FS
HSL-TX
VCC
HSL-RX
COAX-TX
EIAJ-RX
C1
223
SACDL-TX
SACDR-TX
/C3
1
/PRO
2
FC0
3
/C2
4
MCK
5
SCK
6
FSYK
7
SDAT
8
V
9
C
10
U
11
/C15
12
FC1 24
M2 23
M1 22
M0 21
TXP 20
VD+ 19
GND 18
TXN 17
/RST 16
CBL 15
/C9 14
/C8 13
IC3
CS8404A-CS/REVA1
SACDW-TX
4OL-RX
4OR-RX
4OW-RX
VCCVCC
8404TXP
8404MCK
8404SCK
8404FCK
8404DAT
C25
103
VCC
C2
223 C3 223
VCC
C27
470
/0J
C4
223 C5 223 C6 223
C7
223
C8
223 C9 223 C10 223
HSL-TX
DGND
/RESET
HSL-RX
4OW-RX
D5V
4OR-RX
COAX-TX
4OL-RX
DGND
SACDW-TX
EIAJ-RX
SACDR-TX
D5V SACDL-TX
SACDL-TX
EIAJ-RX
DGND
COAX-TX
SACDR-TX
HSL-RX
D5V
HSL-TX
SACDW-TX
DGND
4OL-RX
D5V
4OR-RX
DGND
4OW-RX
/RESET
/OPMUTE
SLCK4
SLCK3
SLCK2
I1
O2
3V
O1
I2 I3
I4
O5 I6
O3
O4
I5
O6
GND
3VBUFFER
(724-0041-00-2)
SLCK1
CDOUT
1
/CS
2
/EMPH
3
SDIN
14
RXP
4
RXN
5
VA+
6
AGND
7
FILT
8
/RST
9
RMCK
10
RERR
11
ILRCK
12
ISCLK
13
CCLK 28
CDIN 27
TXP 26
TXN 25
H/S 24
VD+ 23
DGND 22
OMCK 21
U20
INT 19
SDOUT 18
OLRCK 17
OSCLK 16
TCBL 15
IC8
CS8427-CS/REVA2
SLCK0
C30
103
SRDATA
C31 103
SBCK
SDATA
VCC
/VCCON
C32
682
SACD/CD
R6
242
FSCOUNT
SBCKA
VCC
SDATAA
SLCK2A
SLCK1A
C21
223
LOCK
C22
223
RESET-DET
C28
471
/0J
SLCK0A
SACD/CD
FSCOUNT
27O-SK
27O-WK
27O-DA
VCC
27/AUDIO
27EMP
27/AUDIO
R18
473
R17
473
27AES3
R16
473
27RMCK
R15
473
27RERR
DS12R5M
P70
1
P71
2
P72
3
P73
4
P74
5
P75
6
P76
7
P77
8
P00
9
P01
10
P02
11
P03
12
P04
13
P05
14
P06
15
P07
16
P10
17
P11
18
P12
19
P13
20
P14
21
P15
22
P16
23
P17
24
P20
25
TEST
26
P21
27
P22
28
/RST
29
XIN
30
XOUT
31
GND
32
VCC 64
P67 63
P66 62
P65 61
P64 60
P63 59
P62 58
P61 57
P60 56
P56 55
P55 54
P54 53
P53 52
P52 51
P51 50
P50 49
P47 48
P46 47
P45 46
P44 45
P43 44
P42 43
P41 42
P40 41
P37 40
P36 39
P35 38
P34 37
P33 36
P32 35
P31 34
P30 33
IC10
TMP87PH00N
VCC
R7 473
R14 473
C34
104
CS
1
SK
2
DI
3
DO
4
VCC 8
NC 7
ORG 6
GND 5
IC9
M93C46-BN6
C24
223
VCC
R4 470
C23
223
EEPCS
NOUSE3
EEPSK
NOUSE1
EEPDI
VCC
EEPDO
RA3
RD92AK13C_18
473
VCC
12
IC4A TC74VHCT04AF
RA2
RD92AK16C_18
473
34
IC4B TC74VHCT04AF
56
IC4C
TC74VHCT04AF
98
IC4D TC74VHCT04AF
RA1
RD92AK05C_18
473
1110
IC4E TC74VHCT04AF
1312
IC4F TC74VHCT04AF
VCC
VCC
R9
473
VCC
C26
103
SBCKA
SDATAA
/DAC-WCK
/DAC-BCK
/DAC-R
/DAC-L
/DAC-MCK
/MUTE
8427/VCX
RESERVE3
FS1
FS0
DAC-RST
DAC-CLAT
DAC-CCLK
DAC-CDAT
Q1
2SC3113_
-B
R8
103
C37
102
-> 112mA
C36
102
RELAY
LOCK
C35
104
RESET-DET
C29
470
/0J
/MUTE
8427/VCX
FS1
FS0
XI 1
XO 3
G
2
XTAL3
527-0025-00
8MHz
VCC
GND
MODE VCCI VCCA GND
VCCA
GND
GND(LP) VCCI VCCA GND
VCCA
1
2
3
4
5
6
7
8
9
10
11
12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74
75
76
77
78
79
80
81
82
83
84
SOCKET1
300-1104-00
VCC
VCX48E
VCX44E
27EMP
/VCCON
SRDATA
/OPMUTE
MAIN-ACK
MAIN-/REQ
MAIN-SI
VCC MAIN-SO
VCC
MAIN-SCK
MAIN-RESET
VCC
MAIN-ACK
MAIN-/REQ
VCC
MAIN-SI
MAIN-SO
MAIN-SCK
MAIN-RESET
DS12R5M
DS12R5M DSI-BK DSO-R DSI-LR DSO-BK DSO-WK DSI-WK DSO-L
DSC-CSR
DSC-RS
DSC-CSL
/DAC-WCK /DAC-BCK
SW-PAUSE
/DAC-R
SW-STOP
/DAC-L
SW-SACDCD
/DAC-MCK
SW-ENTER
SW-EXTDSP
EN-TRAB
8404MCK
EN-SELB
8404SCK
EN-TRAA
8404FCK
EN-SELA
8404DAT
8404TXP
EN-TRAA
EN-SELA
SW-PAUSE
SW-STOP
SW-SACDCD
SW-ENTER
SW-EXTDSP
EN-TRAB
EN-SELB
SDATAB
SBCKB
SLCK0
SLCK1
SLCK2
SLCK3
SLCK4
NOUSE2
REMOCON
27AES3
FL-DA
27RMCK
FL-/CP
27RERR
FL-/CS
27O-SK
SW-OPCL
27O-WK
SW-PLAY
27O-DA
REMOCON
FL-DA
VCX44E
FL-/CP
VCX48E
FL-/CS
SW-OPCL
EEPCS
SW-PLAY
EEPSK
EEPDI
EEPDO
DAC-CDAT
DAC-CCLK
DAC-CLAT
DAC-RST
/256FSO
/LT64FSO
/SDATAL
/SDATAR
/SBCK
/DOUT
/DOUT
/256FSO
/SBCK
/LT64FSO
/SDATAR
/SDATAL
- 18 -
D P - 7 7  D S P  A S S ' Y ( 7 2 4 - 0 0 4 1 - 0 0 - 0 )
DSP ASSY

RED
RED
GRN
GRN
ORG
ORG
YEL
YEL
BLU
BLU
from POWER
TRANSFORMER
MOT12V
GND
A3.3V
A5V
GND
D5V
D3.3V
GND
to MAIN BOARD,CN701
to DISPLAY ASSY, K1
1 2
F1
310-8251-00 D101
S1VB60
D105
D4SBS4
1 2
F2
310-8251-00
1 2
F4
310-8251-00 D102
S1VB60
C202
332
/1E
C204
682
/1A
C206
101/1H
C211
101
/1C
Q101 2SA1048_
-GR
D106
HZ332L
C216
100
/1H C217
100
/1H D107
RD7.5F-B
D108
MA165
D109
MA165
C221
104
C222
104
MOT12V
GND
-33V
F1
F2
C223
104
D103
S1VB60
C205
682
/1A
C224
104
1 2
F3
310-8251-00
+12V, 180mA >
+5V, 900mAmax >
+3.3V, 160mA >
+5V, 160mA >
+3.3V, 40mA >
C208
332
/1C
C226
104
C227
104
+8V, 600mAmax >
-8V, 600mAmax <
1 2
F5
310-8251-00
1 2
F6
310-8251-00
YEL
YEL
BLK
from POWER
TRANSFORMER
to MOTHER BOARD ASSY, K1
/RESET
D5V
GND
8VGND
+8V
-8V
/RESET
C220
100
/1H
/RESET
C225
104
C219
101
/1C
C218
101
/1C
C215
101
/1C
C214
101
/1C
C213
101
/1C
C212
101
/1C
C210
332
/1C
D110
EK03
D111
EK03
R101
682 R102
101
R103
104
R104
101
R105
101
R106
183
R107
102 R108
335
D112
MA165 D113
MA165
3 4
IC101B
TC74VHC14F
1 2
IC101A
TC74VHC14F
5 6
IC101C
TC74VHC14F
9 8
IC101D
TC74VHC14F
11 10
IC101E
TC74VHC14F
13 12
IC101F
TC74VHC14F
VCC
VCC
C228
104
C229
104
VCC
1
2
3
4
5
6
7
8
9
10
K101
308-1013-00
1
2
3
K102
308-0304-00
1
2
3
4
5
6K104
308-0606-00
1
2
3
4
5
6
7
8
9
K701
308-0905-00
D104
D4SBS4
C207
332
/1C
C209
332
/1C
C201
332
/1E
C203
682
/1A
D5V
R109
472
R110
472
R111
472
R112
472
R113
472
!Attention mark indicating critical components for safety.
Replacement must be made with identical parts of specified part number.
CAUTION
!
!
!
!
!
!
I
G
O
IC001 UPC24M12AHF
I
G
O
IC002 UPC24M05AHF
I
G
O
IC004 UPC24M05AHF
I
G
O
IC005 UPC29M33HF
I
G
O
IC006 UPC24M08AHF
I
G
O
IC007 UPC7908AHF
I
G
O
IC003 UPC29M33HF
1
2
3
4
5
K103
309-SAN-5P
-


1
9


-
D P - 7 7  D A C  A S S Y  / P O W E R  S U P P L Y  ( 7 2 5 - 0 0 4 1 - 0 0 - 1 )
