ACG Cadillac ESCALADE eGC 2014 User manual

2014 Owner’s Manual
Cadillac ESCALADE eGC
Electric Golf Cart (eGC)
This Manual is effective as of May 1, 2013

Manufactured by:
American Custom Golf Cars, Inc. (ACG)
1 740 El Prado Rd.
Chino, CA 91710 USA
(909) 97-288
(909) 97-7183 fax
www.californiaroadster.com
Copyright © 2009-2013 American Custom Golf Cars, Inc.
American Custom Golf Cars, Inc., an ACG logo
Are registere tra emarks of American Custom Golf Cars, Inc.
Ca illac an Escala e
Are registere tra emarks of General Motors Corporation.
Cadillac ESCALADE eGC
Is Officially License Pro uct by GM
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 2

Notice
The American Custom Golf Cars, Inc., herein known as ACG, “Limited Warranty”
for owners of the Cadillac ESCALADE eGC is inclu e with this manual.
(see Appen ix W-1).
No other warranties, expressed or implied, are contained herein.
ACG an your authorize ealer or representative checke this vehicle before it
was elivere to you.
This vehicle oes not conform to Fe eral Motor Vehicle Safety Stan ar FMVSS #500 for
LSV (low-spee vehicles), an is not equippe for operation on public streets an roa s.
Cadillac ESCALADE eGC oes conform to the current American National Stan ar s
Institute’s Z130 Safety an Performance Requirements for Golf Cars, as of ate of
manufacture as shown on the vehicle’s “Certification Label”.
ACG is not liable of errors in this manual or for inci ental or consequential amages that
result from the use of the material in this manual. The information containe in this
ocument inclu ing the warranty information containe in separate “Warranty” ocument is
subject to change without notice.
ACG reserves the right to make esign an equipment changes to vehicles without
obligation to make these changes on units sol prior to the changes being ma e.
Throughout this “Owner s Manual”, the wor s “golf cart”, “eGC” an “vehicle” are use
interchangeably.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 3

Table of Contents
Notice…………………………………………………………………………….......…… 3
Table of Contents……………………………………………………………….......…… 4
Forewor ………………………………………………………………………......…….. 5
Intro uction………………………………………………………………………....……. 6
ABOUT THIS MANUAL………………………………………………………….....…… 6
Insurance Notice………………………………………………………………….....……7
Warranty Registration……………………………………………………………....…… 7
General Warnings………………………………………………………………...…….. 8
SAFE OWNERSHIP OF ACG eGC……………………………………………...……. 10
Cautions, Warnings an Notes…………………………………………………...…..…11
Controls an In icators………………………………………………………….....…….12
Key Switch……………………………………………………..…….……..….... 12
Forward-Neutral-Reverse Switch……………………………………..….….… 13
Accelerator Pedal……………………………………………..……………..….. 14
Brake Pedal…………………………………………………………..……..…… 15
Park Brake Pedal……………………………………………………..……..….. 16
Light Switch………………………………………………………….……..….… 17
Turn Signal Lever Switch…………………………….…………….……..….… 18
Hazard Warning Lights Switch………………………………………….......… 19
Turn Signal Directional Indicators…………………………………..…..…….. 19
Display Panel…..........................…………………………...……..........…..… 20
Locking Glove Boxes……………………………………………………….……27
Front Trunk Release…………………………………………………………….. 27
Accessory 12 V DC Power Outlet………………………..…..……………….. 28
Safety Belts…………………………………………………………………………..……29
Tires & Wheels………………………………………………………………………...…. 36
Tire Changing an Jacking Points………………………………………………..……. 39
Brakes……………………………………………………………………………….……. 40
Pre-Operation an Daily Safety Checklist………………………………………......… 41
Performance Inspection………………………………………………………….....….. 42
Driving Instructions…………………………………………………………………........ 43
Starting the Vehicle……………………………………………………….....….. 45
Stopping or slowing the Vehicle………………………………………......…… 45
Parking and Leaving the Vehicle……………………………………….....……45
Batteries………………………………………………………………………….....…….. 46
Battery Care……………………………………………………………......…… 46
Battery Inspection & Maintenance…………………………………………..... 47
INSPECTION……………………………………………………………….….. 47
CLEANING………………………………………………………………….…. 49
WATERING……………………………………………………………………. 50
Charging Batteries…………………………………………………………….... 52
Battery Replacement………………………………………………………...…. 53
Battery Disposal……………………………………………………………........ 53
Perio ic Maintenance……………………………………………………………....…… 55
DAILY TASKS………………………………………………………………...…. 55
MONTHLY TASKS…………………………………………………………...…. 56
Cleaning………………………………………………………………………………...… 57
Specifications…………………………………………………………………………..... 60
Warranty……………………………………………………………………………...….. W-1
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 4

Foreword
Thank you for choosing the Cadillac ESCALADE eGC for your golf an
community transportation nee s. American Custom Golf Cars, Inc. woul like to
welcome you to the new revolution in the Custom Golf Cart In ustry.
Please protect your investment to make sure that yourCadillac ESCALADE eGC
will provi e you with years of reliable performance.
Your safety is important to us, so please make sure that prior to operating the
vehicle you have rea the following instructions an warnings.
If you rent or loan your vehicle to others, please make sure that they have rea this
manual prior to operating this vehicle.
Please consi er this manual to be a permanent part of this vehicle an if it is sol ,
please make sure that the new owner receives the manual so that they will have the
operating information that it contains as well.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 5

Introduction
ABOUT THIS MANUAL
Thank you for purchasing yourCadillac ESCALADE eGC vehicle manufacture by
American Custom Golf Cars, Inc. (ACG)
Your vehicle is esigne to operate exclusively on battery power.
It is a “Zero Emission Vehicle” (ZEV).
The ACG company objective inclu es customer safety an pro uct satisfaction.
This “Owner’s Manual” is esigne to acquaint you with the proper an safe
operation of your ACG vehicle.
Please take the time to rea an un erstan the manual before operating your
vehicle.
Maintenance sche ules an general care instructions are inclu e in the Operation
an Maintenance section.
This manual is applicable only to the following ACG mo els:
2014Cadillac ESCALADE eGC
If any questions arise after rea ing the manual, please contact ACG Customer
Service at (909) 97-288 .
Please have your Vehicle I entification Number (VIN) an ate of purchase
information available.
NOTE:
All information an specifications in this “Owner’s Manual” are current at the time
of printing. However, ue to ACG’s policy of continuous pro uct improvement, we
reserve the right to make changes, at any time, without written notice or obligation.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 6

Insurance Notice
Your Insurance may not provide coverage for accidents involving the use of
this vehicle. To determine if coverage is provided you should contact your
insurance company or agent.
Warranty Registration
The separate “Warranty” ocument inclu es a “Warranty Registration Card”.
Your new Cadillac ESCALADE eGC (Electric Golf Cart) comes with a:
One (1) Year Limited Warranty.
The Warranty begins from the ate that the Cadillac ESCALADE eGC is
purchase from an approve Dealer or Distributor of American Custom Golf
Cars, Inc. pro ucts, provi e that the “Warranty Registration Card” is receive
by American Custom Golf Cars, Inc. within 45 Days of the purchase ate of the
vehicle.
If the “Warranty Registration Card” is not receive within 45 ays of purchase
ate, the Warranty commencement date will be the vehicle production date, as
shown on the vehicle’s “Certification Label”.
Please protect your Warranty and mail your “Warranty Registration Card”
today!
There are no other expresse warranties on your ACG vehicle beyon those set in
the accompanying “Warranty” ocument (Appen ix W-1), an no implie warranties
of merchantability or fitness to the full extent allowe by law.
ACG an its ealers shall not be liable for loss of use, inconvenience, lost time,
commercial loss or any inci ental, consequential or other amages.
A separate “Tire Registration Card” is provi e for Warranty an potential Tire
Recall campaign, the Tire Registration is require by Fe eral Law un er the TREAD
Act.
Please fill out and mail both Registration Cards today!
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 7

General Warnings _
1. This “Owner’s Manual” shoul be rea completely before attempting to rive or
service the vehicle. Failure to follow the instructions in this manual coul result in
property amage, severe personal injury, or eath.
2. When charging the vehicle, be sure that the key switch is in the “OFF” position.
If the key is left in the “ON“ position, it may amage the charger or the EGC.
3. Your vehicle is equippe with an on-boar UL- liste charger. When charging
your EGC, please be sure to use a proper, groun e cor to provi e power to
the charger. Please be sure to raise the hoo of the golf cart to allow ventilation
of the charger so that it oes not overheat.
Please refer to the separate “Charging Procedures Manual” for further
detailed information on your eGC charging.
4. Always obey all traffic regulations when operating the vehicle.
5. When stopping an leaving the vehicle:
a) Make sure vehicle has come to a complete stop.
b) Switch “Forward-Neutral-Reverse Switch” to the “Neutral” position.
c) Engage parking brake
) Turn the “Key Switch” to “OFF” position an remove key.
6. Wear safety glasses or approve eye protection when servicing the vehicle.
Wear a full-face shiel an rubber gloves when working with the batteries.
7. Use insulate tools when working aroun batteries or electrical connections.
Use extreme caution to avoi shorting of components or wiring.
8. Improper use of the vehicle or failure to properly maintain it coul result in
ecrease vehicle performance or severe personal injury.
9. Any mo ification or change to the vehicle that affects the stability or han ling
of the vehicle or increases maximum spee beyon factory specifications, coul
result in severe personal injury or eath.
10. Prior to servicing Vehicle:
a. Chock the wheels.
b. Turn the “Key Switch” to “OFF“ position an remove the key.
c. Disconnect battery cables, negative (-) cable first.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 8

WARNING!
1. If renting or loaning the vehicle, make sure that the river is familiar with all
controls an operating proce ures before allowing the vehicle to be riven.
2. Any mo ification or change to the vehicle that affects the stability or han ling
of the vehicle, or increases maximum vehicle spee beyon factory
specifications, coul result in severe personal injury or eath.
3. Do not shift the “Forward-Neutral-Reverse Switch” while the vehicle is
moving. To avoi amaging the vehicle or injuring an unsuspecting
passenger, always bring the vehicle to a full an complete stop before
switching from Forward to Reverse.
4. To avoi unintentionally starting or rolling the vehicle:
A). Set the “Parking Brake”,
B). Turn the “Key Switch” to the “OFF” position,
C). Remove keys prior to leaving the vehicle.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 9

SAFE OWNERSHIP OF ACG ELECTRIC VEHICLES
ACG pure battery electric vehicles are ifferent from vehicles you might be
accustome to owning. Special precautions shoul be followe when owning an
operating an ACG vehicle.
Please rea this “Owner’s Manual” an pay particular attention to the “Cautions”
an “Warnings” in this Manual, as well as those place on the vehicle in various
locations.
In general, ACG Golf Carts are esigne an are inten e only for use at low
spee , up to 15 mph, an are not inten e for use on public roa s.
Specific to ACG vehicles, the following safe habits shoul always be followe :
• ACG vehicles are open vehicles. For this reason, safety belts shoul always be
worn by all occupants to prevent being thrown from the vehicle uring operation.
If your ACG is equippe with optional canvas or plastic oors, these were esigne
an are inten e only to keep win an water out of the vehicle an shoul not be
relie upon to keep occupants in the vehicle or to protect them in case of collision.
• ACG vehicles are not esigne to meet any collision or roll-over requirements.
Therefore, you shoul always rive your ACG vehicle in a safe manner while being
alert to potential angerous situations aroun you. As with all motor vehicles, never
rink alcohol an attempt to rive an ACG vehicle.
• Operate an ACG vehicle only on Golf courses or private roa s where the spee
limits are appropriate for low spee vehicles an the traffic is light.
(in ivi ual state laws vary, so check with your DMV)
• You shoul never operate an ACG vehicle so that you are an obstacle an
become an annoyance for faster moving traffic.
• ACG vehicles are esigne to be recharge from a stan ar 120 VAC-15 Ampere
electrical househol outlet that is groun -fault protecte . Charging from a circuit of
lesser capacity an /or using a cor from the outlet to the ACG vehicle that is not
sufficient in wire gauge (AWG) coul create a fire hazar .
Please consult “Charging Procedures Manual” for the proper extension cor
gauge which epen s on its length.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 10

• The voltage in an ACG vehicle battery pack (the battery pack is what you charge
an provi es the “fuel” to the ACG’s electric rive system) is 48 Volt DC an is
sufficient to cause eath by electric shock - electrocution.
For this reason, ACG owners shoul never attempt to o any maintenance or repair
work on their ACG vehicle’s electric rive system, inclu ing the battery pack, unless
they have ha special training. The one exception is inspection an refilling, if
necessary, of the istille water in floo e type batteries that can be or ere with
ACG vehicles.
• In this “Owner’s Manual”, the above safe ownership an operation habits will be
pointe out to you as the ifferent aspects of owning an operating an ACG vehicle
are explaine . Please rea , un erstan an abi e by them for years of safe
operation an enjoyment of your ACG Electric Golf Cart.
Warnings, Cautions and Notes
Throughout this “Owner’s Manual” you will fin the wor s “WARNING!”
an “CAUTION!” These serve as remin ers that attention is require .
“WARNING!”
In icates an imme iate hazar , which coul result in an acci ent
causing bo ily injury.
“CAUTION!”
I entifies something that coul result in amage to your vehicle.
“NOTE”
Notes are for your information an to make proce ures more easily
un erstoo .
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 11

Controls and Indicators
Key Switch
The “Key Switch” is mounte on the ash to the right of the steering column.
It has two positions:
1. OFF position- There is no power to vehicle. (Key is Vertical as shown in picture below)
2. ON position- vehicle is ON an can be riven. (Key is turned clockwise 45 degrees)
(Key Switch shown in “ON” position)
WARNING!
Never turn the “Key Switch” to the “OFF” position while the vehicle is
in motion. This coul lea to loss of spee control an loss of control
of the vehicle. This can cause a serious acci ent.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 12

Forward – Neutral - Reverse Control Switch
The “Forward-Neutral-Reverse Switch” is locate on the seat support panel.
There are three (3) istinct positions: Forward, Neutral an Reverse.
1.) FORWARD - To operate the vehicle in the forwar irection, rotate the switch
towar s the passenger si e of the vehicle.
2.) REVERSE - To operate the vehicle in the reverse irection, rotate the switch
towar s the river si e of the vehicle. Your Vehicle has been equippe with
a reverse warning beeper so that when the vehicle is in reverse you will hear
a lou beep signaling that the vehicle is in reverse.
3.) NEUTRAL - When the switch is in the straight up an own position the
vehicle is in Neutral an will not move when the accelerator pe al is
epresse .
(Switch shown in Reverse position)
CAUTION!
Always bring the vehicle to a complete stop before changing the
position of the “Forward-Neutral-Reverse Switch”.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 13

Accelerator Pedal
The “Accelerator Pedal” is the pe al on the right, with the wor “GO” mol e into it.
The operation of the accelerator pe al iffers from that of an Automobile. When the
“Key Switch” is in the “ON” position, epressing the accelerator pe al will release
the parking brake. As the accelerator pe al is epresse spee will increase until
full spee is reache . When you release the accelerator pe al the power to the
motor is cut OFF an the motor will stop running causing the vehicle to coast.
WARNING!
The vehicle will not stop automatically when the “Accelerator Pedal” is
released.
You must depress the “Brake Pedal” in order for the vehicle to come to a
stop or to slow down rapidly.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 14

Brake Pedal
The “Brake Pedal” is the large pe al on the left with the wor “STOP” mol e into it.
To slow or stop the vehicle, release the “Accelerator Pedal” an then epress the
brake pe al with your foot until the EGC has come to a complete stop or the vehicle
has slowe to your esire spee .
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 15

Park Brake Pedal
The “Park Brake Pedal” is the small raise portion in the upper left corner of the
“Brake Pedal”. It has the wor “PARK” mol e into it.
To set the park brake, epress the “Brake Pedal” firmly an tilt the park brake
portion of the pe al forwar with your foot.
WARNING!
The “Park Brake” will release automatically when either the “Accelerator
Pedal” or “Brake Pedal” is depressed. The park brake has multiple locking
positions and should be firmly pressed and locked to prevent the vehicle
from rolling.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 16

Light Switch
The “Light Switch” is locate on the Dashboar to the left of the steering Column.
It is a 2 position switch it is labele with ISO symbol (icon).
1.) OFF - When the top portion of the switch “O” is epresse the lights are off.
2.) ON - When the bottom portion of the switch “I” is epresse , the lights are on.
(Light switch shown in “ON” position)
Fog Light Switch
The “Fog Light Switch” is locate on the Dashboar to the left of the steering
Column, next to the “Light Switch”.
It is a 2 position switch it is labele with ISO symbol (icon).
1.) OFF - When the top portion of the switch “O” is epresse the fog lights are off.
2.) ON - When the bottom portion of the switch “I” is epresse , the fog lights are on.
Auxiliary Switches
Two “Auxiliary Switches” are locate on the Dashboar to the left of the steering
Column, next to the “Fog Light Switch” .
It is a 2 position switch it is labele with ““ symbol (icon).
1.) OFF - When the top portion of the switch “O” is epresse the fog lights are off.
2.) ON - When the bottom portion of the switch “I” is epresse , the fog lights are on.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 17

Turn Signal Lever Switch
The Turn Signals are activate by Lever Switch locate on Left si e of steering
column below Steering Wheel.
It is a 3 position switch.
1.) RIGHT - When the Lever is pushe UP (Clockwise) – the Right Lights Flash.
2.) OFF - When the Lever is Horizontal, the Turn Signal lights are “OFF”.
3.) LEFT – When the Lever is pushe own (Counter Clockwise) – the Left Lights Flash.
NOTE:
The system DOES NOT have a “self-canceling” feature; return the Lever to the horizontal
“OFF” position after completing the inten e Turn or Lane Change!
(Turn Signal Lever Switch shown in “O “position)
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 18

Hazard Warning Flashers
The Hazar Warning Flasher Switch activates both Turn Signals to provi e
“Hazard Warning” by flashing both Right an Left as well as Front an Rear Turn
Signals at the same time.
The “Hazard” function is activate by Pull Switch locate on Left si e of steering
column below Steering Wheel. An imme iately below the Turn Signal Lever.
It is a 2 position switch.
OFF - When the Pull Switch is release (pushe INWARD)
ON - When the Pull Switch is pulle out, the Turn Signal lights are activate .
NOTE:
The Hazar function can be cancele ONLY by moving the “Turn Signal Lever” from the
the horizontal “OFF” position to either “UP” (Right Turn) or “DOWN” (Left Turn) position!
Turn Signal Directional Indicators
The GREEN LED Light to the Left of the Display Panel will flash when the
Left Turn Signal is activate
The GREEN LED Light to the Right of the Display Panel will flash when the
Right Turn Signal is activate

Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 19

Display Panel
The Cadillac ESCALADE eGC LCD isplay has following functions:
Battery State of Charge (SoC) shown on bar graph at right of the screen
an as percent % at top of the bar graph (shown above as 88%)
Trip Distance Travele in miles in NN.N format (shown above as 90.6 mi.)
Odometer TOTAL Distance Travele in miles in NNNN.N format
(shown above as 231.9 mi.)
Vehicle Speed in MPH an KPH shown on semi elliptical bar graph
(shown as 0 MPH/KPH above)
Direction – Monitors the position of the “Direction Control Switch” an
shows:
D for Forwar Drive
N for Neutral (as shown above)
R for Reverse
For additional display features please refer to following section.
Copyright © 2009-2013 American Custom Golf Cars, Inc. Page 20
