KD 7200
20” 1600 x 1200 TFT LCD
1U drawer typem, 24” depth
PS/2 keyboard / touch pad
» Specifications
» Options
» Features
» Ordering Guide
Materal:
Heavy-duty steel
Keyboard and touch pad (PS/2):
106-key keyboard and 2-buttons touch pad
LCD Panel:
Size: 20"
Max. Resolution: 1600x1200 UXGA
Brightness (cd/m^): 300nit
Contrast Ratio: 1000:1
Display Area: 386.4(H) x 289.8(V) mm
Pixel pitch: 0.255(H) x 0.255(W) mm
Response time: Rising Time 15 ms, Falling Time 7 ms
Viewing Angle: 170°(L/R),170°(U/D)
Back Light: 6 x CCFTs
Colors: 16M colors
MTBF: 20,000 hours
LCD Panel protected by tempered glass
On Screen Control:
OSD Control Brightness, Contrast, Phase & Color,
H & V position, Auto-tune & Recall
Video input:
Video Synchronization: 45KHz - 80KHz
Input Signal: Analog RGB 0.7Vp-p
Optional for DVI input
Connectors:
Rear:
1 x D-Sub 15 pin port for VGA
2 x PS/2 for Keyboard and Touch pad
Front control:
5 x OSD menu buttons
Cables:
1 x 6’ all-in-one cable (1-VGA, 2-PS/2)
Optional for 10’ / 15’ cable
Security Lock:
2 x thumb-lock screws for system security
Drawer Design:
1U low profile drawer
Slide rail can be extension up to 36" depth
Remote Power supply Adapter:
External 110/220VAC 50W power adapter
Color:
Black
Environmental:
Temperature:
Operate 0°~ 50°C / 32°~ 122°F
Storage-20°~ 60°C / -4°~ 140°F
Humidity: 8 % ~ 95 % RH
Safty:
CE and FCC certificated
Gross Weight:
34lb
Dimension:
19"(W) x 26.1”(D) x 1.75"(H)
» 1U 20-inch rack drawer design, only 26.1-inch depth
» 20" 1600x1200 TFT LCD display
» OSD (On Screen Display) function
» Built-in PS/2 type keyboard and touch pad
» Standard 15-pin D-sub VGA connector
» External 110/220VAC power adapter
KD 7200:
20” 1600x1200 monitor keyboard drawer
