Acqua GY-NE15CF User manual

Model NO:GY-NE15CF
GY-NE20CF
GY-NE40CF
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . 6 - 8
HOW TO USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CLEANING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
IN CASE OF THE FOLLOWING . . . . . . . . . . . . . .10
BEFORE REQUESTING SERVICE . . . . . . . . . . . 11
PART NAMES AND FUNCTIONS . . . . . . . . . . . . 12
TEMPERATURE ADJUSTMENT
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . 13
SAFETY AND WARNING INFORMATION . . . . 1 - 5

For your safety and
correct usage, before
installing and first using the
appliance, read this user
manual carefully, including its
hints and warnings. To avoid
unnecessary mistakes and
accidents, it is important to
make sure that all people
using the appliance are
thoroughly familiar with its
operation and safety features.
Save these instructions and
be sure that they remain with
the appliance if it is moved or
sold, so that anyone using it
throughout its life will be
properly informed on usage
and safety notices.
For the safety of life and
property, keep the
precautions of these user's
instructions as the
manufacturer is not
responsible for damages
caused by omission.
Safety for children and others
who are vulnerable
According to IEC standard
This appliance is not intended
for use by persons (including
children) with reduced
physical, sensory or mental
capabilities, or lack of
experience and knowledge,
unless they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
Keep all packaging away
from children as there is risk
of suffocation
If you are discarding the
appliance, pull the plug out
of the socket, cut the
connection cable (as close
to the appliance as you can)
and remove the door to
prevent children playing
from suffering an electric
shock or from closing
themselves inside.
1

General safety
This appliance is
intended to be used in
domestic households
WARNING — Do not store
explosive substances such
as aerosol cans with a
flammable propellant in this
appliance.
WARNING —If the supply
cord is damaged, it must be
replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid a
hazard.
 WARNING — Keep
ventilation openings in the
appliance enclosure or in
any built-in structure clear of
obstruction.
WARNING — Do not use
mechanical devices or other
means to accelerate the
defrosting process, other
than those recommended by
the manufacturer.
WARNING — Do not
damage the refrigerant
circuit.
WARNING — Do not use
electrical appliances inside
the food storage
compartments of the
appliance, unless they are of
the type recommended by
the manufacturer.
WARNING — The
refrigerant and insulation are
flammable. When disposing
of the appliance, do so only
at an authorized waste
disposal center. Do not
expose to flame.
WARNING —When
positioning the appliance,
ensure the supply cord is not
trapped or damaged.
WARNING —Do not locate
multiple portable
socket-outlets or portable
power supplies at the rear of
the appliance.
WARNING —Damaged supply
cord must be repalced by a
special cord or assembly
available from the manufacture
or its service agent.
Refrigerant
The refrigerant isobutene
(R600a) is contained within
the refrigerant circuit of the
appliance, a natural gas with
a high level of environmental
compatibility, which is
nevertheless flammable.
During transportation and
installation of the appliance,
ensure that none of the
components of the refrigerant
circuit becomes damaged.
The refrigerant (R600a) is
flammable.
2

contain refrigerant and
gases in the insulation.
Refrigerant and gases must
be disposed of professionally
as they may cause eye
injuries or ignition. Ensure
that tubing of the refrigerant
circuit is not damage prior to
proper disposal.
If the refrigerant circuit is
damaged:
-Avoid naked flames and
sources of ignition.
-Thoroughly ventilate the
room in which the appliance
is situated.
Warning: risk of fire/Warning: risk of fire
flammable materials
Electrical safety
1. The power cord must not
be lengthened.
2. Make sure that the power
plug is not crushed or
damaged. A crushed or
damaged power plug may
overheat and
cause a fire.
3. Make sure that you can
access the main plug of the
appliance.
4. Do not pull the main cable.
5. If the power plug socket is
loose, do not insert the power
plug. There is a risk of
electric shock or fire.
6. The fridge is only supplied
with power supply of single
phase alternating current of
220 ~ 240 V/50Hz. If
fluctuation of voltage in the
district of user is so large that
the voltage exceeds the
above scope, for safety sake,
be sure to apply A.C.
WARNING — Refrigerators
It is dangerous to alter the
specifications or modify this
product in any way.
Any damage to the cord may
cause a short circuit, fire,
and/or electric shock.
Automatic voltage regulator
of more than 350W to the
fridge. The fridge must
employ a special power
socket instead of common
one with other electric
appliances. Its plug
must match the socket
with ground wire.
3

Daily use
Do not store flammable
gas or liquids in the
appliance. There is a risk of
an explosion.
Do not operate any
electrical appliances in the
appliance (e.g. electric ice
cream makers, mixers etc.).
When unplugging always
pull the plug from the mains
socket, do not pull on the
cable.
Do not place hot items near
the plastic components of
the fridge.
Store pre-packed frozen
food in accordance with the
frozen food manufacturer’s
instructions.
The manufactures storage
recommendations should be
strictly adhered to. Refer to
relevant instructions for
storage.
Do not place carbonated or
fizzy drinks in the freeze
compartment as it creates
pressure on the container,
explode,
resulting in
damage to the
appliance .
Frozen food can cause frost
burns if consumed straight
compartment.
Do not place the appliance
in direct sunlight.
from the freezer
which may cause it to
Clean regularly surfaces that can
come in contact with food and
accessible drainage systems.
If the refrigerating appliance is
left empty for long periods, switch off,
defrost, clean, dry, and leave the door
open to prevent mould developing
within the appliance.


Keep burning candles,
lamps and other items with
naked flames away from the
appliance so that do not set
the appliance on fire.
The appliance is intended
for keeping food and/or
beverages in normal
households as explained in
this instruction booklet.
The appliance is heavy.
Care should be taken when
moving it.
Do not remove or touch
items from the freezer
compartment if your hands
are damp/wet, as this could
cause skin abrasions or
frost/freezer burns.
Do not consume
ice
orpopsicles ice cubes
straight from the freezer as
this can cause freezer burn
to the mouth and lips.
4

Installation i portant!
For electrical connection
carefully, follow the
instructions given in this
manual.
Unpack the appliance and
check if there are damages
on it. Do not connect the
appliance if it is damaged.
Report possible damages
immediately to the place you
bought it. In this case retain
packing.
It is advisable to wait at least
four hours before connecting
the appliance to allow the oil
to flow back in the
compressor.
Adequate air circulation
should be allowed around
the appliance reducing the
risk of overheating. To
achieve sufficient ventilation,
follow the instructions
relevant to installation.
Wherever possible the back
of the product should not be
close to a wall to avoid
touching or catching warm
parts (compressor,
condenser) to prevent the
risk of a fire, follow the
instructions relevant to
installation
The appliance must not be
locate close to radiators or
cookers.
Make sure that the mains
plug is accessible after the
installation of the appliance.
Service
Any electrical work required
to do the servicing of the
appliance should be carried
out by qualified electrician or
competent person. This
product must be serviced by
an authorized Serviced
enter, and only genuine
spare parts must be used.
Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances.
Caution!
Care and cleaning
Before maintenance, switch
off the appliance and
disconnect the mains plug
from the mains socket.
Do not clean the appliance
with metal objects, steam
cleaner, ethereal oils,
organic solvents or abrasive
cleansers.
Do not use sharp objects to
remove frost from the
appliance. Use a plastic
scraper.
1
5

It is advisable to wait at least four hours before connecting the appliance to allow gas to settle.
6

Do not place on carpet
Never touch interior surface with wet hands,
this could result in frost bite.
Correct Disposal of this product
This symbol on the product or in its
packing indicates that this product may
not be treated as household waste.
Instead, it should be taken to the
appropriate waste collection point for the
recycling of electrical and electronic
equipment
7

Do not place chest freezer on carpet.
Condensation may condense on the exterior
surface during hot/humid days. This may
cause mould on carpet.
Chest freezer and walls.
8

When 5mm frost forms in the freezer, please shave it and throw it away.
If you defrost completely, please do it as follows.
1 Please ensure inside is empty, and disconnect the power cord plug.
2 When frost starts thawing, please shave it.
3 After draining, please wipe the inside, and put a rubber cap on the drain bolt
and the inside drain.
For defrosting the chest freezer, don’t use a hammer, knife or sharp
object. This can damage the lining and evaporator.
• Remove shipping packaging, tape, etc, and leave lids open for ventilation for a while.
• Leave chest freezer for four hours before turning on to allow gas to settle.
• The unit is cleaned before shipment. However clean the compartment interior once after delivery.
• Following installation, refrigeration will start about 10 minutes after operation is started.
• Operate for about 2 hours to cool the refrigerator compartment before placing items in the freezer.
9

•Sudden power failure
Keep opening and closing of the door to a minimum to prevent cold air from escaping from the freezer compartment.
Covering exterior surfaces with a blanket, etc. will further help to maintain a low temperature.
•Announced power outage
In case of a long power outage, place dry ice in the freezer compartment.
•Keep opening and closing of the door to a minimum.
•Avoid placing new items in the freezer as this will raise the temperature inside the compartment.
•Place wood between door and chest freezer so as not to close it up.
•Please don’t put chest freezer in a place where children can play.
•Remove all items from the compartment and disconnect the power cord plug from the wall outlet.
•Clean the compartment interior and wipe away all water.
To prevent mold formation and bad smell, leave the door open to dry the compartment completely.
• Clean the freezer regularly to keep it clean at all times.
• Never use polishing powder, soap powder, benzine, oil or hot water as
these will damage the painting and plastic components.
10

•Are the power fuses blown and/or the circuit breaker activated?
•Turn the temperature control dial in the direction of MAX. If too cold, turn dial
down.
Transfer the items stored in the freezer to a box or other container. Then contact the dealer from whom you
purchased this unit and be ready to provide
•Is the lid opened and closed frequently?
•Are items stocked beyond the load line?
•Turn the temperature control dial in the direction of MAX. If too cold, turn dial in
direction of MIN.
•Unit needs to be defrosted?
•Unitisonawoodenoor?
•Is the rear panel of the unit contacting a wall, etc?
•The compressor will generate a rather loud sound for a while after operation is
started. The noise will cease together with refrigeration.
•Especially in summer or on start up the circumference of chest freezer may feel
hot. This is because the chest freezer has a pipe for radiating and preventing
condensation.
The heat does not affect frozen goods
11
serial and model number.

Fast Freeze - (Turn on the button and the light will be on, the freezer
will be in the state of fast freezing.
Turn off the button once cold or the compressor will run continually.)
Model NO:GY-NE15CF
Fa st Fa st
ezi gFr e ne zi gFr e n
Fa st Fa st
ezi gFr e ne zi gFr e n
GY-NE20CF GY-NE40CF
Door handle
12

•
•
Width Depth Height
625 559 854
145L
GY-NE15CF
Width Depth Height
802 559 854
200L
GY-NE20CF
Off
Colder
Cold
Mid
Width Depth Height
1125 636 830
306L
GY-NE40CF
Mid/MID
Colder/MAX
OFF
Cold
13
