Acqua GY-NE255FR User manual

GY-NE255FR

Contents
Safety and warning information
2
General safety
Caution! Keep ventilation openings
clear of obstructions.
Safety for children and others who are
vulnerable people
For your safety and correct usage before
installing and first using the appliance, read
this user manual carefully, including its hints
and warnings. To avoid unnecessary
mistakes and accidents, it is important to
make sure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save these
instructions and be sure that they remain
with the appliance if it is moved or sold, so
that a using it throughout its life will be
properly informed on its correct appliance
usage and safety.
For the safety of life and property, keep the
precautions of these user's instructions as
the manufacturer is not responsible for
damages caused by omission.
, connection cable (as close to the
appliance as you can) and remove the
door to prevent children playing from
suffering an electric shock or from closing
themselves inside it.
If this appliance, featuring a magnetic
door seals, is to replace an older
appliance having a spring lock (latch) on
the door or lid, be sure to make the spring
lock unusable before you discard the old
appliance. This will prevent it from
becoming a death trap for a child.
The appliance is intended for keeping
food and/or beverages in a normal
household as explained in this instruction
manual.
Do not use a mechanical device or any
artificial means to speed up the thawing
process.
Do not use other electrical appliances
(such as ice cream makers) on the inside
of refrigerating appliances, unless they
are approved for this purpose by the
manufacturer.
Do not damage the refrigerant circuit. The
refrigerant isobutane (R600a) is contained
within the refrigerant circuit of the
appliance. It is a natural gas with a high
level of environmental compatibility, which
is nevertheless flammable.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or a lack of experience and knowledge,
unless they have been given supervision
or instruction concerning the use of the
appliance by a person responsible for
their safety. C h i l d r e n should b e
supervised to ensure that they do not play
with the appliance.
Keep all packaging away from children as
there is risk of suffocation.
If you are discarding the appliance, pull
the plug out of the socket, cut the
Safety and warning information_ __ _ _ _ _ 2
Description of the appliance!_ _ _ _ _ _ _ _
Control panel _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
First use and installation_ _ _ _ _ _ _ _ _ _
4
5
6
_ _ _ _ _ _ _ _ _ _ _
_ _ _ _ _ _ _ _ _ _ _ _
7
8
9
Helpful hints and tips
Cleaning and care
What to do if_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Daily use _ _ _ _ _ _ __ _ _ _ _ _ _ _ _ _ _ 7

During the transportation and installation of
the appliance, make certain that none of the
components of the refrigerant circuit become
damaged.
-avoid open flames and sources of ignition.
-thoroughly ventilate the room in which the
appliance is located.
Caution: Risk of fire!
It is dangerous to alter the specifications
or modify this product in any way. Any
damage to the cord may cause a
shortcircuit, fire, and/or electric shock.
Warning! Any electrical component
(power cord, plug, compressor) must
be replaced by a certified service
agent or qualified service personnel.
1. The power cord must not be lengthened.
2. Make sure that the power plug is not
or damaged. A or damaged
power plug may overheat and cause a fire.
crushed crushed
3. Make sure that you can
plug of the appliance.
access the main
4. Do not pull the main cable.
5. If the power plug socket is loose, do not
insert the power plug. There is a risk of
electric shock or fire.
6. You must not operate the appliance
without the interior lighting lamp cover.
Do not remove nor touch items from the
freezer compartment if your hands are
damp/wet, as this could cause skin
abrasions or frost/freezer burns.
Do not place the appliance in direct
sunlight.
Daily use
Do not store flammable gases or liquids
inside the appliance. There is a risk of an
explosion.
Do not operate any electrical appliances
within the appliance (e.g. electric ice
cream makers, mixers, etc.).
When unplugging, always pull the plug
from the . Do not pull on the
cord.
main outlet
Store pre-packaged frozen food in
accordance with the frozen food
manufacturer's instructions. 2)
The appliance's manufacturing storage
recommendations should be strictly adhered
to. Refer to instructions for
storage.
Do not place carbonated or fizzy drinks in
the freezer compartment as it creates
pressure on the container, which may
cause it to explode, resulting in damage to
the appliance. 2)
Ice lollies can cause frost
burns if consumed straight from the
refrigerated compartment. 2)
the relevant
(popsicles)
Warning!
Care and cleaning
Before maintenance, switch off the
appliance and disconnect the main plug
from the main outlet.
Do not clean the appliance with metal
objects, steam cleaners, ethereal oils,
organic solvents or abrasive cleansers.
Do not use sharp objects to remove frost
from the appliance.
Important!
Installation
For electrical connection, carefully, follow the
instructions given in this manual.
Unpack the appliance and check it. If it is
damaged, do not plug in the appliance;
contact the shop immediately from where
you purchased it. In this case, keep all
packing materials.
It is advisable to wait at least four hours
before connecting the appliance to allow
the refrigerant to flow back into the
compressor.
Adequate air circulation should be around
the appliance, as a lack of this leads to
overheating. To achieve sufficient
3
Do not place hot items near the plastic
components of this appliance.
Do not place food products directly
against the air outlet on the rear wall. 1)
Frozen food must not be refrozen once it
has been thawed out. 2)
Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance.
This appliance is intended to be used in
household and similar applications such as
Staff kitchen areas in shops, offices and
other working environments;
Farm houses and by clients in hotels, motels
and other residential type environments;
Bed and breakfast type environments;
Catering and similar non-retail applications

4
Description of the appliance
Note: Due to unceasing modification of our products your refrigerator may be slightly different
from this Instruction Manual, but its functions and using methods remain the same.
View of the appliance
1. Control panel
2. Ice tray (inside)
3. Upper drawer
4. Air outlet
5. Drawers
6. Drawers
7. Drawer
8. Drawer
9. Adjustable feet
10. Door
11. Shelf
ventilation, follow the instructions relevant
to the installation. Any electrical work required to do the
servicing of the appliance should be
carried out by a qualified electrician or
person.
This product must be serviced by an
authorized service center, and only
genuine spare parts must be used.
authorized
Service
2) If the appliance contains a freezer compartment.
1) If the appliance is Frost Free.
Wherever possible, the back of the
product should be against a wall to avoid
touching or catching wa rm parts
(compressor, condenser) and to prevent
the risk of fire; follow the instructions
relevant to installation.
The appliance must not be located close
to radiators or
Make sure that the main plug is accessible
after installation of the appliance.
cooking appliances.

5
SUPER FREEZE
By simply pressing the Super Freeze button,
the freezer will operate in the super freeze
mode. The indicator light of super freeze will
be on. In super freeze mode, the temperature
inside freezer will drop rapidly Automatically
after 26 hours of freezing. Then the freezer will
automatically quit the super freeze mode. The
indicator light of super freeze will be off. Before
that you can also manually quit the super
freeze mode by pressing the Super Freeze
button again.
ALARM
ALARM FOR DOOR
If the door is left open for 2 minutes,the
alarm will sound to remind you closing the
door.If the door is still open, the alarm will
sound 3 times per 30 seconds and last for
10 minutes.Then the alarm will automatically
stop.
Alarm of Freezer
The abnormal high temperature inside
freezer might be resulted from:
1. The freezer goes wrong.
2. A long time of power cut.
NOTE:
Freezer for the first time when power use
"Alarm" is normal, then press the
“Alarm/M" button.
alarm will flash continually even if the data
the temperature display shows is bellow
–10°C.
Under the High Temperature Alarm
circumstance, if the Alarm/M button has
not been pressed,the indicator light of
If the temperature inside the freezer rises to
above -10 °C, the alarm will sound,at the
same time the indicator light of alarm will
begin to flash.If you don’t touch any
button,the temperature display will flash and
show the current temperature inside the
freezer for about 10 seconds,then the
temperature display show the selected
temperature.And the alarm will sound 3
timesper 30 seconds and last for 2
minutes,then the alarm will automatically
stop.If you press the Alarm/M button,the
alarm is stop.And the indicator light of alarm
will stop flashing.And the remperature
display will show the highest temperature
inside the freezer for 4 seconds,then show
the selected temperature.When it reaches to
bellow –10 °C,the indicator light of alarm will
be off.
Control panel
THERMOSTAT OF THE FREEZER
COMPARTMENT
If you press the▲or▼button, you can select
the temperature ranging from -24°C to -15
°C. If you press the▲or▼button once, the
temperature will increase or decrease
1°C,until the required temperature
is displayed.
The thermostat control panel,controls the
temperature inside the FREEZER
compartment, and is located on the top
cover plate.

6
First use and installation
This appliance performs well in T. The
appliance may not work properly if it is left
for a longer period at a temperature above
or below the indicated range.
Important!
For this reason,
space should be
available around the .It is advisable
for there to be 75mm separating the back
of the to the wall at least 100mm
of space on its two of over
100mm from its top and a clear space in
front to allow the doors to open 160°.
It is necessary to have good
ventilation around the freezer to allow for
the dissipation of heat, high efficiency, and
low power consumption.
sufficiently cleared
freezer
freezer
sides, a height
Warning! Before installing, read the
instructions carefully for your safety
and the correct operation of the appliance.
Position the appliance away from sources
of heat such as stoves, radiators, direct
sunlight, etc.
Maximum performance and safety are
guaranteed by maintaining the correct
indoor temperature for the class of unit
concerned, as specified on the rating
plate.
Before using the appliance for the first
time, wash the interior and all internal
accessories with lukewarm water and
neutral soap in order to remove the typical
smell of a brand new product, then dry
thoroughly.
Appliances must not be exposed to rain.
Sufficient air must be allowed to circulate
in the lower rear section of the appliance,
as poor air circulation can affect perfor-
mance. Built-in appliances should be
positioned away from heat sources such
as heaters and direct sunlight.
Leveling
Electrical connection
Caution! Any electrical work required to
install this appliance should be carried out by
a qualified or person.authorized
Warning!This appliance must be grounded.
The manufacturer declines any liability should
these safety measures not be observed.
the floor. You can also adjust the level by
the appropriate level
the front (use your fingers or a suitable
spanner).
unscrewing adjustment
in
The appliance should be level in order to
eliminate vibration. To make the appliance
level, it should be upright and both
adjusters should be with in stable contact
Cleaning before use
Installation Positioning
75mm
100mm
100mm
Fixing the handleBefore you use the
product,plesae check the handle of the
refrigerator.If the handle is loose, you should
fix it with the hexangular screwdriver in the
clockwise direction, then it can be used
normally.

7
Daily use
Helpful hints and tips
Accessories 1)
Freezer Drawer
For storing frozen food.
Ice-cube tray
For making ice and storing ice-cubes.
Freezer food compartment 2)
Thawing food 2)
In the freezer compartment.
At room temperature.
In a microwave oven.
In a conventional or convection oven.
Food once thawed should be re-frozen
with the exception of special cases.
1) If the appliance contains related accessories
and functions.
2) If the appliance contains a freezer compartment.
For freezing fresh food and storing frozen
and deep-frozen food for long periods of
time.
Noises during operation
Clicks- Whenever the compressor switches
on or off, a click can be heard.
Humming- As soon as the compressor is in
operation, you can hear it humming.
Bubbling- When refrigerant flows into thin
tubes, you can hear bubbling or splashing
noises.
Splashing- Even after the compressor has
been switched off, this noise can be heard
for a short time.
Energy saving tips
Do not install the appliance near stoves,
radiators or other sources of warmth.
Keep the time the appliance is open to a
minimum.
Do not set the temperature colder than
necessary.
Make sure the side plates and back plate
of the appliance are at some distance
from the wall, and follow the instructions
relevant to installation.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
it would produce an effect on energy
consumption.
Hints for freezing
When first starting-up or after a period out
of use. Before putting the food in the
compartment, let the appliance run at
least 2 hours on the higher settings.
Hints for the storage of frozen food
Make sure that commercially frozen food
was stored by the retailer.
Once defrosted, foods deteriorate rapidly
and can not be re-frozen.
Do not exceed the storage period
indicated by the food manufacturer.
Note: If the appliance contains related
accessories and functions.
Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible to thaw
only the quantity required.
subsequently
Wrap up the food in aluminum foil or
and make sure that
the packages are airtight.
Do not allow fresh, unfrozen food to touch
food that is already frozen, thus avoiding a
rise in the temperature of the latter.
polyethylene (plastic)
It is recommended to label and date each
frozen package in order to keep track of
the storage time.
Iced products, if consumed immediately
after removal from the freezer compartment,
can possibly cause skin to become freezer
burnt.

8
Cleaning and Care
Cleaning and care
For hygienic reasons, the appliance interior,
including interior accessories, should be
cleaned regularly.
The appliance should be cleaned and
maintained at least every two months.
Warning! Danger of electrical shock!
The appliance should not be connected to
the during cleaning.
Before cleaning, switch the appliance off
and remove the plug from the
switch off, or the circuit
breaker or fuse.
main power supply
main power
supply, shut off
Notice!
Remove the food from the appliance
before cleaning. Store them in a cool
place well covered.
Never clean the appliance with a steam
cleaner. Moisture could accumulate in
electrical components.
Hot vapors can lead to the damage of
plastic parts.
Ethereal oils and organic solvents can
attack plastic parts, e.g. lemon juice or the
juice from an orange peel, butyric acid,or
cleansers that contain acetic acid. Do not
allow such substances to come into
contact with appliance parts.
Do not use any abrasive cleansers.
and keep
Clean the appliance and the interior
accessories with a cloth and lukewarm
Empty the appliance.
Pull out the power plug.
Clean thoroughly (see section: Cleaning
and Care).
Leave the door open to prevent odours.
Taking the appliance out of service
water. Commercially available dish
washing detergents may also be used.
After cleaning, wipe with fresh water and
a clean dish cloth.
Accumulation of dust at the condenser
increases energy consumption; clean the
condenser at the back of the appliance
once a year with a soft brush or a vacuum
cleaner.(Only for the outside-condenser
product)
Check the water drain hole on the rear
wall of the refrigerator compartment.
Clear a blocked drain hole with the aid of
something like soft green peg, an be
careful not to any damage to the
cabinet by sharp
After everything is dry, the appliance back
into service.
create
objects.

The food is too warm.
Interior lighting does
not work.
Unusual noises.
The compressor does
not start immediately
after changing the
temperature setting.
Water on the floor or
storage shelves.
Temperature is not properly
adjusted.
Door was open for an
extended period.
A large quantity of warm food
was placed in the appliance
within the last 24 hours.
The appliance is near a heat
source.
Light bulb is defective.
Door seal is not air-tight
(possibly after reversing the
door).
Appliance is not level.
The appliance is touching the
wall or other objects.
A component, e.g. a pipe, on
the rear of the appliance is
touching another part of the
appliance or the wall.
This is normal, no error has
occurred.
Water drain hole is blocked.
Please the “Initial Start Up”
section.
refer to
Open the door only as long as
necessary.
Turn the
to a colder setting temporarily.
control panel
Please the “Installation
Location” section.
refer to
Please look in the “Changing the
Light Bulb “section.
Carefully warm the leaking
sections of the door seal with a
hair dryer (on a cool setting). At
the same time, shape the warmed
door seal by hand so that it sits
correctly.
Readjust the feet.
Move the appliance slightly.
If necessary, carefully bend the
component out of the way.
The compressor starts after a
period of time.
Refer to the “Cleaning and Care”
section.
Heavy build-up of
frost, possibly also on
the door seal.
What to do if…
Problem Possible cause Solution
Appliance does not
work.
Appliance cools too
much.
Appliance is not switched on.
Main plug is not plugged in or
is loose.
Fuse has blown or is defective.
Outlet is defective.
Temperature is set too cold.
Switch on the appliance.
Plug the appliance into the
electrical socket.
Check fuse, replace if necessary.
Defective parts need
repaired
to be
by an electrician.
Turn the temperature regulator to
a warmer setting temporarily.
Important!
Repairs to the appliance may only be
performed by competent service engineers.
Improper repairs can give rise to significant
hazards for the user. If your appliance
needs repairing, please contact your
specialist dealer or your local Customer
Service Center.
9
Warning! Before trouble-shooting,
disconnect the power supply. Only a
qualified electrician or other
personnel must carry out the trouble-
shooting that is not in the manual.
Other manuals for GY-NE255FR
1
Table of contents
Other Acqua Freezer manuals

Acqua
Acqua GY-NE155FR User manual

Acqua
Acqua GY-NE270FR/01 User manual

Acqua
Acqua GY-NE200CF User manual

Acqua
Acqua GY-NE80FR User manual

Acqua
Acqua GY-NE26CF User manual

Acqua
Acqua GY-NE175FR User manual

Acqua
Acqua GY-NE175FR User manual

Acqua
Acqua GY-NE30CF User manual

Acqua
Acqua gy-ne19cf User manual

Acqua
Acqua GY-NE15CF User manual
