Beko RFSM200T30WN User manual

Freezer
User manual
EN / UK / RUS / DE
57 8101 0000 / AP
1/2
Морозильник
Посібник користувача
Руководство пользователя
Морозильная камера
Gefrierschrank
Bedienungsanleitung
RFSM200T30WN

Please read this user manual first!
Dear Customer,
We hope that your product, which has been produced in modern plants and
checked under the most meticulous quality control procedures, will provide you
an effective service.
Therefore, read this entire user manual carefully before using the product and
keep it as a reference. If you handover the product to someone else, give the
user manual as well.
The user manual will help you use the product in a fast and safe
way.
• Read the manual before installing and operating the product.
• Make sure you read the safety instructions.
• Keep the manual in an easily accessible place as you may need it later.
• Read the other documents given with the product.
Remember that this user manual is also applicable for several other models.
Differences between models will be identified in the manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
CImportant information or useful tips.
AWarning against dangerous conditions for life and property.
BWarning against electric voltage.
A
A
A
C
SUPPLIER’S NAME MODEL IDENTIFIER (*)
INFORMATION
C
The model information as stored in the product data base
can be reached by entering following website and searching
for your model identifier (*) found on energy label.
https://eprel.ec.europa.eu/

EN
2
1 Your Freezer 3
2 Safety and environment
instructions 4
3 Installation 8
Points to be paid attention to when the
relocation of the freezer ........................8
Electrical connection ...............................9
Disposing of the packaging...................9
Disposing of your old freezer ...............9
Placing and Installation.........................10
4 Preparation 12
5 Using your freezer 13
Freezing fresh food ................................14
Recommendations for preservation of
frozen food.................................................14
Placing the food.......................................14
Deep-freeze information.....................15
6 Maintenance and
cleaning 16
Protection of plastic surfaces ...........16
7 Troubleshooting 17
CONTENTS

EN
3
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1Your Freezer
1. Thermostat
2. Flap (Fast-Freeze compartment)
3. Drawers
4. Adjustable front feet
1
4
4
2
3
*

EN
4
2. Safety and environment instructions
This section provides the safety
instructions necessary to prevent the
risk of injury and material damage.
Failure to observe these instructions
will invalidate all types of product
warranty.
Intended use
A
WARNING:
Keep ventilation openings,
in the appliance enclosure
or in the built-instructure,
clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other means to
accelerate the defrosting
process, other than those
recommended by the
manufacturer.
AWARNING:
Do not damage the
refrigerant circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments
of the appliance, unless
they are of the type
recommended by the
manufacturer.
This appliance is intended to be used
in household and similar applications
such as
– staff kitchen areas in shops, offices
and other working environments;
– farm houses and by clients in
hotels, motels and other residential
type environments;
– bed and breakfast type
environments;
– catering and similar non-retail
applications.
1.1. General safety
• This product should not be
used by persons with physical,
sensory and mental disabilities,
without sufficient knowledge and
experience or by children. The device
can only be used by such persons
under supervision and instruction of
a person responsible for their safety.
Children should not be allowed to
play with this device.
• In case of malfunction, unplug the
device.
• After unplugging, wait at least 5
minutes before plugging in again.
• Unplug the product when not in use.
• Do not touch the plug with wet
hands! Do not pull the cable to plug
off, always hold the plug.
• Do not plug in the refrigerator if the
socket is loose.
• Unplug the product during
installation, maintenance, cleaning
and repair.
• If the product will not be used for
a while, unplug the product and
remove any food inside.
• Do not use the product when the
compartment with circuit cards
located on the upper back part of
the product (electrical card box
cover) (1) is open.

EN
5
1
1
• Do not use steam or steamed
cleaning materials for cleaning
the refrigerator and melting the
ice inside. Steam may contact the
electrified areas and cause short
circuit or electric shock!
• Do not wash the product by spraying
or pouring water on it! Danger of
electric shock!
• In case of malfunction, do not use
the product, as it may cause electric
shock. Contact the authorised
service before doing anything.
• Plug the product into an earthed
socket. Earthing must be done by a
qualified electrician.
• If the product has LED type lighting,
contact the authorised service for
replacing or in case of any problem.
• Do not touch frozen food with wet
hands! It may adhere to your hands!
• Do not place liquids in bottles and
cans into the freezer compartment.
They may explode.
• Place liquids in upright position after
tightly closing the lid.
• Do not spray flammable substances
near the product, as it may burn or
explode.
• Do not keep flammable materials
and products with flammable gas
(sprays, etc.) in the refrigerator.
• Do not place containers holding
liquids on top of the product.
Splashing water on an electrified
part may cause electric shock and
risk of fire.
• Exposing the product to rain,
snow, sunlight and wind will cause
electrical danger. When relocating
the product, do not pull by holding
the door handle. The handle may
come off.
• Take care to avoid trapping any part
of your hands or body in any of the
moving parts inside the product.
• Do not step or lean on the door,
drawers and similar parts of the
refrigerator. This will cause the
product to fall down and cause
damage to the parts.
• Take care not to trap the power
cable.
1.1.1 HC warning
If the product comprises a cooling
system using R600a gas, take care to
avoid damaging the cooling system
and its pipe while using and moving
the product. This gas is flammable. If
the cooling system is damaged, keep
the product away from sources of fire
and ventilate the room immediately.

EN
6
C
The label on the inner left
side indicates the type of
gas used in the product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet shall
be maximum 90 psi (6.2 bar). If
your water pressure exceeds 80
psi (5.5 bar), use a pressure limiting
valve in your mains system. If you
do not know how to check your
water pressure, ask for the help of a
professional plumber.
• If there is risk of water hammer
effect in your installation, always
use a water hammer prevention
equipment in your installation.
Consult Professional plumbers if you
are not sure that there is no water
hammer effect in your installation.
• Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and 100°F
(38°C) maximum.
• Use drinking water only.
1.2. Intended use
• This product is designed for home
use. It is not intended for commercial
use.
• The product should be used to store
food and beverages only.
• Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
• Original spare parts will be provided
for 10 years, following the product
purchasing date.
1.3. Child safety
• Keep packaging materials out of
children’s reach.
• Do not allow the children to play
with the product.
• If the product’s door comprises a
lock, keep the key out of children’s
reach.
1.4. Compliance with WEEE
Directive and Disposing
of the Waste Product
This product complies with
EU WEEE Directive (2012/19/EU). This
product bears a classification symbol
for waste electrical and electronic
equipment (WEEE).
This product has been
manufactured with high
quality parts and materials
which can be reused and
are suitable for recycling.
Do not dispose of the
waste product with
normal domestic and other wastes at
the end of its service life. Take it to the
collection center for the recycling of
electrical and electronic equipment.
Please consult your local authorities
to learn about these collection
centers.
1.5. Compliance with
RoHS Directive
• This product complies with EU WEEE
Directive (2011/65/EU). It does
not contain harmful and prohibited
materials specified in the Directive.

EN
7
1.6. Package information
Packaging materials of the product
are manufactured from recyclable
materials in accordance with our
National Environment Regulations. Do
not dispose of the packaging materials
together with the domestic or other
wastes. Take them to the packaging
material collection points designated
by the local authorities.

EN
8
3Installation
BThe manufacturer will not be
liable for any event caused by
disregarding the information
supplied in this user manual.
Points to be paid attention
to when the relocation of
the freezer
1. Your freezer should be
unplugged.Before transportation of
your freezer, it should be emptied
and cleaned.
2. Before it is re-packaged,
shelves, accessories, crisper, etc.
inside your freezer should be fixed
with adhesive tape and secured
against impacts. Packaging should
be adequate and the transportation
rules on the package should be
strictly observed.
3. Original packaging and foam
materials should be kept for future
transportations or moving.
Before you start the freezer,
Check the following before you
start to use your freezer:
1. Attach 2 plastic wedges as
illustrated below. Plastic wedges
are intended to keep the distance
which will ensure the air circulation
between your freezer and the
wall. (The picture is drawn up as
a representation and may not be
identical with your product.)
2. Clean the interior of the freezer
as recommended in the “Maintenance
and cleaning” section.
3. Connect the plug of the freezer
to the wall socket. When the freezer
door is opened,freezer internal lamp
will turn on.
The condenser of your appliance is located on the back as shown below. In
order to achieve better energy efficiency with lower energy consumption,
please pull the condenser towards yourself as illustrated in picture below.
*may not be available in all models
2-b
PULL
PULL
better energy
efficiency
initial position

EN
9
4. When the compressor starts to
operate, a sound will be heard. The
liquid and gases sealed within the
refrigeration system may also give
rise to noise, even if the compressor
is not running and this is quite normal.
5. Front edges of the freezer may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
Electrical connection
Connect your product to a grounded
socket which is being protected by a
fuse with the appropriate capacity.
Important:
The connection must be in
compliance with national regulations.
• The power plug must be easily
accessible after installation.
• Electrical safety of your freezer
shall be guaranteed only if the earth
system in your house complies with
standards.
• The voltage stated on the label
located at left inner side of your
product should be equal to your
network voltage.
• Extension cables and multi plugs
must not be used for connection.
BA damaged power cable must be
replaced by a qualified electrician.
BProduct must not be operated
before it is repaired! There is the risk
of electric shock!
Disposing of the packaging
The packing materials may be
dangerous for children. Keep the
packing materials out of the reach
of children or dispose of them by
classifying them in accordance with
the waste instructions stated by your
local authorities. Do not throw away
with regular house waste, throw away
on packaging pick up spots designated
by the local authorities.
The packing of your freezer is
produced from recyclable materials.
Disposing of your old
freezer
Dispose of your old freezer without
giving any harm to the environment.
• You may consult your authorized
dealer or waste collection center of
your municipality about the disposal
of your freezer.
Before disposing of your freezer,
cut out the electric plug and, if there
are any locks on the door, make them
inoperable in order to protect children
against any danger.

EN
10
Placing and Installation
AIf the entrance door of the room
where the freezer will be installed is
not wide enough for the freezer to
pass through, then carefully remove
the doors of your freezer and pass it
sideways through the door.
1. Install your freezer to a place
that allows ease of use.
2. Keep your freezer away from
heat sources, humid places and direct
sunlight.
3. There must be appropriate
air ventilation around your freezer
in order to achieve an efficient
operation. If the freezer is to be
placed in a recess in the wall, there
must be at least 5 cm distance with
the ceiling and at least 5 cm with the
wall. Do not place your product on the
materials such as rug or carpet.
4. Place your freezer on an even
floor surface to prevent jolts.

EN
11
Reversing the doors
Proceed in numerical order .
3
2
7
8
9
10
11
13
14
17
15
16
1
4
5
6
12

EN
12
4Preparation
• For a freestanding appliance;
‘this refrigerating appliance is not
intended to be used as a built-in
appliance’ ;.
• Your refrigerator should be installed
at least 30 cm away from heat
sources such as hobs, ovens, central
heater and stoves and at least 5
cm away from electrical ovens and
should not be located under direct
sunlight.
• The ambient temperature of
the room where you install your
refrigerator should at least be
-15°C. Operating your refrigerator
under cooler conditions is not
recommended with regard to its
efficiency.
• Please make sure that the interior
of your refrigerator is cleaned
thoroughly.
• If two refrigerators are to be
installed side by side, there should
be at least 2 cm distance between
them.
• When you operate your refrigerator
for the first time, please observe the
following instructions during the
initial six hours.
• The door should not be opened
frequently.
• It must be operated empty without
any food in it.
• Do not unplug your refrigerator. If
a power failure occurs out of your
control, please see the warnings in
the “Recommended solutions for
the problems” section.
• Original packaging and foam
materials should be kept for future
transportations or moving.
• The baskets/drawers that are
provided with the chill compartment
must always be in use for low energy
consumption and for better storage
conditions.
• Food contact with the temperature
sensor in the freezer compartment
may increase energy consumption
of the appliance. Thus any contact
with the sensor(s) must be avoided.
• In some models, the instrument
panel automatically turns off 5
minutes after the door has closed.
It will be reactivated when the door
has opened or pressed on any key.
• Due to temperature change as
a result of opening/closing the
product door during operation,
condensation on the door/body
shelves and the glass containers is
normal.
• Since hot and humid air will not
directly penetrate into your product
when the doors are not opened,
your product will optimize itself
in conditions sufficient to protect
your food. In this energy saving
function, functions and components
such as compressor, fan, heater,
defrost, lighting, display and so on
will operate according to the needs
to consume minimum energy while
maintaining the freshness of your
foodstuff.

EN
13
5Using your freezer
CFigures that take place in this instruction manual are schematic and may not
correspond exactly with your product. If the subject parts are not included in the
product you have purchased, then it is valid for other models.
1 2 3 4
1.Freezer Set Function
This function allows you to make the
freezer compartment temperature
setting.
Press this button to set the
temperature of the freezer
compartment to - (warmest), --, ---,
----, ----- (coldest) respectively.
2.High Temperature Error /
Warning Indicator
This light comes on during high
temperature failures and error
warnings.
3- Quick Frezee Indicator
This icon lits when the Quick Freeze
function is active.
4-Quick Frezee Function
When you press Quick Freeze button,
the temperature of the compartment
will be colder than the adjusted values.
This function can be used for food
placed in the freezer compartment
and required to be cooled down rapidly.
If you want to cool large amounts
of fresh food, it is recommended to
active this feature before putting the
food into the freezer.
Quick Freezer indicator will remain
lit when the Quick Freezer function is
enabled. To cancel this
function press Quick Freezer button
again. Quick Freezer indicator will turn
off and return to its normal settings.
If you do not cancel it, Quick Fridge
will cancel itself automatically
after 2 hours or when the freezer
compartment reaches to the required
temperature. This function is not
recalled when power restores after a
power failure.

EN
14
Freezing fresh food
• It must be preferred to wrap or cover
the food before placing them in the
refrigerator.
• Hot food must cool down to the
room temperature before putting
them in the refrigerator.
• The foodstuff that you want to
freeze must be fresh and in good
quality.
• Foodstuff must be divided into
portions according to the family’s
daily or meal based consumption
needs.
• The foodstuff must be packaged in
an airtight manner to prevent them
from drying even if they are going to
be kept for a short time.
• Materials to be used for packaging
must be tear-proof and resistant to
cold, humidity, odor, oils and acids
and they must also be airtight.
Moreover, they must be well closed
and they must be made from easy-
to-use materials that are suitable for
deep freeze usage.
• Frozen food must be used
immediately after they are thawed
and they should never be re-frozen.
• Please observe the following
instructions to obtain the best
results.
1. Do not freeze too large
quantities of food at one time. The
quality of the food is best preserved
when it is frozen right through to the
core as quickly as possible.
2. Placing warm food into
the freezer compartment causes
the cooling system to operate
continuously until the food is frozen
solid.
3. Take special care not to mix
already frozen food and fresh food.
Recommendations for
preservation of frozen food
• Prepacked commercially frozen food
should be stored in accordance with
the frozen food manufacturer's
instructions for a ( 4 star)
frozen food storage compartment.
• To ensure that the high quality
achieved by the frozen food
manufacturer and the food retailer is
maintained, the following should be
remembered:
1. Put packages in the freezer as
quickly as possible after purchase.
2. Ensure that contents are
labeled and dated.
3. Do not exceed "Use By", "Best
Before" dates on the packaging.
Defrosting
The freezer compartment defrosts
automatically.
Placing the food
Freezer compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Egg tray Egg
Fridge compartment
shelves
Food in pans, covered
plates and closed
containers
Fridge compartment
door shelves
Small and packaged food
or drinks (such as milk, fruit
juice and beer)

EN
15
Crisper Vegetables and fruits
Freshzone
compartment
Delicatessen products
(cheese, butter, salami
and etc.)
Deep-freeze information
Food must be frozen as rapidly
as possible when they are put in a
refrigerator in order to keep them in
good quality.
It is possible to keep the food for
a long time only at -18°C or lower
temperatures.
You can keep the freshness of food
for many months (at -18°C or lower
temperatures in the deep freeze).
WARNING! A
• Foodstuff must be divided into
portions according to the family’s
daily or meal based consumption
needs.
• Foodstuff must be packaged in an
airtight manner to prevent them
from drying even if they are going to
be kept for a short time.
• Materials necessary for packaging:
• Cold resistant adhesive tape
• Self adhesive label
• Rubber rings
• Pen
Materials to be used for packaging
the foodstuff must be tear-proof and
resistant to cold, humidity, odor, oils
and acids.
Foodstuff to be frozen should not
be allowed to come in contact with
the previously frozen items to prevent
their partial thawing.
Frozen food must be used
immediately after they are thawed
and they should never be re-frozen.
- Active”quıck freeze function” at
least 24 hour before loading fresh
food.
- Put 2 pcs ice packs ( if available )
inside the bottom drawer.
- Place fresh food on the shelves of
2 nd&3rd from the bottom.(maximum
capacıty can be achieved by removing
the drawers

EN
16
6Maintenance and cleaning
A Never use gasoline, benzene or
similar substances for cleaning
purposes.
B We recommend that you unplug the
appliance before cleaning.
B Never use any sharp abrasive
instrument, soap, household
cleaner, detergent and wax polish
for cleaning.
B For non-No Frost products,
water drops and frosting up to a
fingerbreadth occur on the rear wall
of the Fridge compartment. Do not
clean it; never apply oil or similar
agents on it.
B Only use slightly damp microfiber
cloths to clean the outer surface
of the product. Sponges and other
types of cleaning cloths may scratch
the surface.
C Use lukewarm water to clean the
cabinet of your refrigerator and wipe
it dry.
C Use a damp cloth wrung out in
a solution of one teaspoon of
bicarbonate of soda to one pint of
water to clean the interior and wipe
it dry.
B Make sure that no water enters the
lamp housing and other electrical
items.
B If your refrigerator is not going to
be used for a long period of time,
unplug the power cable, remove all
food, clean it and leave the door ajar.
C Check door seals regularly to ensure
they are clean and free from food
particles.
A To remove door racks, remove all the
contents and then simply push the
door rack upwards from the base.
A Never use cleaning agents or water
that contain chlorine to clean the
outer surfaces and chromium coated
parts of the product. Chlorine causes
corrosion on such metal surfaces.
A Do not use sharp, abrasive tools,
soap, household cleaning agents,
detergents, kerosene, fuel oil,
varnish etc. to prevent removal and
deformation of the prints on the
plastic part. Use lukewarm water
and a soft cloth for cleaning and
then wipe it dry.
Protection of plastic
surfaces
CDo not put the liquid oils or oil-
cooked meals in your refrigerator
in unsealed containers as they
damage the plastic surfaces of your
refrigerator. In case of spilling or
smearing oil on the plastic surfaces,
clean and rinse the relevant part
of the surface at once with warm
water.

EN
17
7Troubleshooting
Check this list before contacting the
service. Doing so will save you time
and money. This list includes frequent
complaints that are not related to
faulty workmanship or materials.
Certain features mentioned herein
may not apply to your product.
The refrigerator is not working.
• The power plug is not fully settled. >>>
Plug it in to settle completely into the
socket.
• The fuse connected to the socket
powering the product or the main fuse is
blown. >>> Check the fuses.
Condensation on the side wall of
the cooler compartment (MULTI
ZONE, COOL, CONTROL and FLEXI
ZONE).
• The door is opened too frequently >>>
Take care not to open the product’s door
too frequently.
• The environment is too humid. >>>
Do not install the product in humid
environments.
• Foods containing liquids are kept in
unsealed holders. >>> Keep the foods
containing liquids in sealed holders.
• The product’s door is left open. >>> Do
not keep the product’s door open for long
periods.
• The thermostat is set to too low
temperature. >>> Set the thermostat to
appropriate temperature.
Compressor is not working.
• In case of sudden power failure or pulling
the power plug off and putting back on,
the gas pressure in the product’s cooling
system is not balanced, which triggers
the compressor thermic safeguard. The
product will restart after approximately 6
minutes. If the product does not restart
after this period, contact the service.
• Defrosting is active. >>> This is normal
for a fully-automatic defrosting product.
The defrosting is carried out periodically.
• The product is not plugged in. >>>
Make sure the power cord is plugged in.
• The temperature setting is incorrect.
>>> Select the appropriate temperature
setting.
• The power is out. >>> The product will
continue to operate normally once the
power is restored.
The refrigerator’s operating
noise is increasing while in use.
• The product’s operating performance
may vary depending on the ambient
temperature variations. This is normal
and not a malfunction.
The refrigerator runs too often
or for too long.
• The new product may be larger than the
previous one. Larger products will run
for longer periods.
• The room temperature may be high.
>>> The product will normally run
for long periods in higher room
temperature.
• The product may have been recently
plugged in or a new food item is placed
inside. >>> The product will take longer
to reach the set temperature when
recently plugged in or a new food item is
placed inside. This is normal.
• Large quantities of hot food may have
been recently placed into the product.
>>> Do not place hot food into the
product.
• The doors were opened frequently or
kept open for long periods. >>> The
warm air moving inside will cause the
product to run longer. Do not open the
doors too frequently.

EN
18
• The freezer or cooler door may be ajar.
>>> Check that the doors are fully
closed.
• The product may be set to temperature
too low. >>> Set the temperature to a
higher degree and wait for the product
to reach the adjusted temperature.
• The cooler or freezer door washer
may be dirty, worn out, broken or not
properly settled. >>> Clean or replace
the washer. Damaged / torn door
washer will cause the product to run for
longer periods to preserve the current
temperature.
The freezer temperature is very
low, but the cooler temperature
is adequate.
• The freezer compartment temperature
is set to a very low degree. >>> Set the
freezer compartment temperature to a
higher degree and check again.
The cooler temperature is very
low, but the freezer temperature
is adequate.
• The cooler compartment temperature is
set to a very low degree. >>> Set the
freezer compartment temperature to a
higher degree and check again.
The food items kept in cooler
compartment drawers are
frozen.
• The cooler compartment temperature is
set to a very low degree. >>> Set the
freezer compartment temperature to a
higher degree and check again.
The temperature in the cooler or
the freezer is too high.
• The cooler compartment temperature
is set to a very high degree. >>>
Temperature setting of the cooler
compartment has an effect on the
temperature in the freezer compartment.
Wait until the temperature of relevant
parts reach the sufficient level by
changing the temperature of cooler or
freezer compartments.
• The doors were opened frequently or
kept open for long periods. >>> Do not
open the doors too frequently.
• The door may be ajar. >>> Fully close
the door.
• The product may have been recently
plugged in or a new food item is
placed inside. >>> This is normal. The
product will take longer to reach the set
temperature when recently plugged in or
a new food item is placed inside.
• Large quantities of hot food may have
been recently placed into the product.
>>> Do not place hot food into the
product.
Shaking or noise.
• The ground is not level or durable. >>>
If the product is shaking when moved
slowly, adjust the stands to balance the
product. Also make sure the ground is
sufficiently durable to bear the product.
• Any items placed on the product may
cause noise. >>> Remove any items
placed on the product.
The product is making noise of
liquid flowing, spraying etc.
• The product’s operating principles
involve liquid and gas flows. >>> This is
normal and not a malfunction.
There is sound of wind blowing
coming from the product.
• The product uses a fan for the cooling
process. This is normal and not a
malfunction.
There is condensation on the
product’s internal walls.
• Hot or humid weather will increase icing
and condensation. This is normal and
not a malfunction.

EN
19
• The doors were opened frequently or
kept open for long periods. >>> Do not
open the doors too frequently; if open,
close the door.
• The door may be ajar. >>> Fully close
the door.
There is condensation on the
product’s exterior or between
the doors.
• The ambient weather may be humid,
this is quite normal in humid weather.
>>> The condensation will dissipate
when the humidity is reduced.
The interior smells bad.
• The product is not cleaned regularly.
>>> Clean the interior regularly using
sponge, warm water and carbonated
water.
• Certain holders and packaging materials
may cause odour. >>> Use holders
and packaging materials without free of
odour.
• The foods were placed in unsealed
holders. >>> Keep the foods in sealed
holders. Micro-organisms may spread
out of unsealed food items and cause
malodour. Remove any expired or spoilt
foods from the product.
The door is not closing.
• Food packages may be blocking the
door. >>> Relocate any items blocking
the doors.
• The product is not standing in full
upright position on the ground. >>>
Adjust the stands to balance the
product.
• The ground is not level or durable.
>>> Make sure the ground is level and
sufficiently durable to bear the product.
The vegetable bin is jammed.
• The food items may be in contact with
the upper section of the drawer. >>>
Reorganize the food items in the drawer.
If The Surface Of The Product Is
Hot.
• High temperatures may be observed
between the two doors, on the side
panels and at the rear grill while the
product is operating. This is normal and
does not require service maintenance!Be
careful when touching these areas.
AWARNING:
Iftheproblempersistsafterfollowing
theinstructions in thissection,contact
your vendor or an Authorised Service.
Do not try to repair the product.
