Series ACPC8625 Industrial I/O Pack
CompactPCI Bus Non-Intelligent Carrier Board
USER’S MANUAL
ACROMAG INCORPORATED
30765 South Wixom Road
P.O. BOX 437
Wixom, MI 48393-7037 U.S.A.
Tel: [phone]
Fax: [phone]
Copyright 1999, Acromag, Inc., Printed in the USA.
Data and specifications are subject to change without notice.
8500-622-E02A006
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 2 -
The information contained in this manual is subject to change
without notice. Acromag, Inc. makes no warranty of any kind with
regard to this material, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose.
Further, Acromag, Inc. assumes no responsibility for any errors that
mayappear in this manual and makes no commitment to update, or
keep current, the information contained in this manual. No part of
this manual may be copied or reproduced in any form, without the
prior written consent of Acromag, Inc.
Table of Contents Page
1.0 GENERAL INFORMATION............................................... 2
KEY ACPC8625 FEATURES............................................ 2
CompactPCI BUS INTERFACE FEATURES.................... 3
SIGNAL INTERFACE PRODUCTS.................................. 3
IP MODULE OLE CONTROL SOFTWARE..................... 3
2.0 PREPARATION FOR USE................................................ 4
UNPACKING AND INSPECTION..................................... 4
CARD CAGE CONSIDERATIONS................................... 4
BOARD CONFIGURATION….......................................... 4
Interrupt Configuration…................................................ 4
CONNECTORS…............................................................. 4
Carrier Field I/O Connectors (IP modules A-D)….......... 4
IP Field I/O Connectors (IP modules A-D)..................... 4
IP Logic Interface Connectors (IP modules A-D).......…. 5
CompactPCI BUS Connections (J1).......................…... 5
CompactPCI I/O Connections (J4,J5).....................…... 6
DATA TRANSFER TIMING....................................…....... 6
FIELD GROUNDING CONSIDERATIONS.............…...... 7
3.0 PROGRAMMING INFORMATION......................….......... 7
CompactPCI Configuration Address Space................... 7
Configuration Transactions............................................ 7
Configuration Registers….............................................. 7
MEMORY MAP......................................................…........ 8
Carrier Board Status Register..............................…....... 8
IP Interrupt Pending Register......................................... 9
IP Module Interrupt Space….......................................... 9
IP Module ID Space……..….......................................... 9
IP Module I/O Space…....…........................................... 9
GENERATING INTERRUPTS.................................…..... 9
Sequence of Events for an Interrupt.........................…. 9
4.0 THEORY OF OPERATION........................................….... 10
CARRIER BOARD OVERVIEW..............................…...... 10
CompactPCI BUS Interface........................................... 10
Carrier Board Registers......................................…........ 10
IP Logic Interface................................................…........ 10
Carrier Board Clock Circuitry.............................…......... 10
CompactPCI Interrupter….................................…......... 10
Power Failure Monitor................................................…. 11
Power Supply Fuses………………………….............. 11
Power Supply Filters..............................................… 11
5.0 SERVICE AND REPAIR................................................ 11
SERVICE AND REPAIR ASSISTANCE........................... 11
PRELIMINARY SERVICE PROCEDURE......................... 11
6.0 SPECIFICATIONS............................................................. 11
PHYSICAL SPECIFICATIONS........................................ 11
CompactPCI BUS COMPLIANCE..................................... 12
INDUSTRIAL I/O PACK COMPLIANCE........................... 12
ENVIRONMENTAL……………………….......................... 12
APPENDIX......................................................................... 13
CABLE, SCSI-2 to Flat Ribbon (Shielded):
MODEL 5028-187.............................................................. 13
TERMINATION PANEL: MODEL 5025-552..................... 13
CompactPCI TRANSITION MODULE:
MODEL TRANS-C200....................................................... 13
DRAWINGS Page
4501-788 ACPC8625 IP LOCATIONS…………………… 14
4501-789 IP MECHANICAL ASSEMBLY DRAWING...... 14
4501-790 ACPC8625 BLOCK DIAGRAM...........……….. 15
4501-758 CABLE, SCSI-2 to Flat Ribbon (Shielded):
5028-187.......................................................... 15
4501-464 TERMINATION PANEL 5025-552...............…. 16
4501-791 CompactPCI TRANSITION MODULE
TRANS-C200..............................................…. 16
IMPORTANT SAFETY CONSIDERATIONS
It is very important for the user to consider the possible adverse
effects of power, wiring, component, sensor, or software failures
in designing any type of control or monitoring system. This is
especially important where economic property loss or human life
is involved. It is important that the user employ satisfactory
overall system design. It is agreed between the Buyer and
Acromag, that this is the Buyer's responsibility.
1.0 GENERAL INFORMATION
The ACPC8625 card is a personal computer Compact
Peripheral Component Interconnect (CompactPCI) bus card and a
carrier for the Industrial I/O Pack (IP) mezzanine board field I/O
modules. The carrier board provides a modular approach to system
assembly, since each carrier can be populated with any combination
of analog input/output, digital input/output, communication, etc. IP
modules. Thus, the user can create a board which is customized to
the application. This saves money and space - a single carrier
board populated with IP modules may replace several dedicated
function CompactPCI bus boards. The ACPC8625 non-intelligent
carrier board provides impressive functionality at low cost.
Model is available in one standard CompactPCI bus 6U size.
With support for up to four IP modules.
MODEL CompactPCI
Board Size Supported IP Slots Operating Temperature
Range
ACPC8625 6U 4(A,B,C,D) 0 to +70°C
ACPC8625E 6U 4(A,B,C,D) -40 TO +85°C
KEY ACPC8625 FEATURES
•PCI Specification Version 2.1 and PICMG 2.0, R2.1
Compliant Slave Carrier -Provides a CompactPCI bus
interface to control and communicate with industry standard IP
modules.
•Interface for Four IP Modules - Provides an electrical and
mechanical interface for up to four industry standard IP
modules. IP Modules are available from Acromag and other
vendors in a wide variety of Input/Output configurations to meet
the needs of varied applications.
•Plug-And-Play CompactPCI bus Carrier - The carrier card
contains standard CompactPCI bus configuration memory.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 3 -
Upon power-up the system auto-configuration process assigns
the carrier’s base address in memory space.
•Plug-And-Play Interrupt Support - The personal computer
system software will allocate one interrupt line to the carrier.
The carrier’s interrupt pending register can be used to quickly
identify IP module pending interrupts.
•Supports Two Interrupt Channels per IP - Up to two
interrupt requests are supported for each IP. Additional
registers are associated with each interrupt request for control
and status monitoring.
•Full IP Register Access - Makes maximum use of logically
organized programmable registers on the carrier boards to
provide for easy configuration and control of IP modules.
Supports accesses to IP input/output, interrupt, and ID ROM
data spaces. No hardware jumper settings are required on the
carrier board.
•IP Module Access Time Out - Allows access to emptyIP
slots without system failure. If the IP module accessed does
not respond within 32u seconds the bus access is terminated
without system failure. This allows each IP slot to be probed to
determine if an IP is installed. A control register bit will be set
and/or issue of an interrupt request to indicate IP module time
out access has occurred.
•LED Indicators Simplify Debugging - Front panel LED's are
dedicated to each IP module to give a visual indication of
successful IP accesses
•Rear Backplane Connectors Access I/O - Rear backplane
connectors P4 and P5 access to field I/O signals mapped per
the IP on CompactPCI Specification (PICMG 2.4, R1.0). A
transition module (Acromag Model TRANS-C200) routes the
field I/O signals from P4 and P5 to the rear of the cage system
with separate SCSI-2 connectors for each IP module. All
SCSI-2 connectors can be connected with a standard SCSI-2
cable from the transition module without interference from
boards in adjacent slots. Spring latch hardware on the
transition module provides for excellent connection integrity and
easy cable removal.
•Optional Screw Termination Panel - Model supports field
connection via screw terminals using the optional DIN rail
mount termination panel (Model 5028-182).
•Supervisory Circuit for Reset Generation - A
microprocessor supervisor circuit provides power-on, power-
off, and low power detection reset signals to the IP modules per
the IP specification.
•Individually Filtered Power - Filtered +5V, +12V, and -12V
DC power is provided to the IP modules via passive filters
present on each supply lineserving each IP. This provides
optimum filtering and isolation between the IP modules and the
carrier board and allows analog signals to be accurately
measured or reproduced on IP modules without signal
degradation from the carrier board logic signals.
•Individually Fused Power - Fused +5V, +12V, and -12V DC
power is provided. A fuse is present on each supply line
serving each IP module.
•ESD Strip on ACPC8625 Board - The ACPC8625 board has
been designed to provide electrostatic discharge (ESD)
capability byusing an ESD strip on the board per ANSI/VITA
1.1-1997 and IEEE1101.10.
•Injector/Ejector Handles - The ACPC8625 uses modern
injector/ejector handles, which push the board into the rack
during installation and have a positive self-locking mechanism
so they cannot be unlocked accidentally. These handles are
fully IEEE 1101.10 compliant and are needed to give leverage
to install and remove the board.
•EMC Front Panel - The ACPC8625 uses the preferred EMC
front panel per IEEE 1101.10 specification.
•5 Volt CompactPCI Keying - The ACPC8625 implements a
keying mechanism to differentiate 5V or 3.3V signaling
operation. This board uses 5V signaling operation. The key is
inserted intothe J1 connector. (Key Color: Brilliant Blue)
•OLE Control Software is Available - Acromag provides
Object Linking and Embedding (OLE) controls software for
Windows 95/98/NTTM. This software (Model IPSW-OLE-PCI,
MSDOS format) provides individual drivers that allow IP
modules and Acromag personal computer carriers to be easily
integrated into Windows application programs, such as Visual
C++, Visual Basic, Borland DelphiTM, MicrosoftOffice 97
applications, and others.
CompactPCI BUS INTERFACE FEATURES
•Slave Module- All read and write accesses are implemented
as either a 32-bit, 16-bit or 8-bit single data transfer.
•Immediate Disconnect on Read - The CompactPCI bus will
immediately disconnect after a read. The read data is then
stored in a read FIFO. Data in the read FIFO is then accessed
by the CompactPCI bus when the read cycle is retried. This
allows the CompactPCI bus to be free for other system
operations while the read data is moved to the read FIFO.
•Interrupt Support - CompactPCI bus INTA# interrupt request
is supported. All IP module interrupts are mapped to INTA#.
Carrier board software programmable registers are utilized as
interrupt request control and status monitors.
SIGNAL INTERFACE PRODUCTS
(See Appendixfor more information on compatible products)
This IP carrier board will mate directly to all industry standard 8
MHz IP modules. Acromag provides the following interface products
(all connections to field signals are made through the carrier board
and transition module which passes them to the individual IP
modules):
Cables:
Model 5028-187 (SCSI-2 to Flat Ribbon Cable, Shielded): A
round 50 conductor shielded cable with a male SCSI-2
connector at one end and a flat female ribbon connector at the
other end. The cable is used for connecting ACPC8625 with
the TRANS-C200, or other compatible carrier boards, to Model
5025-552 termination panels.
Termination Panel:
Model 5025-552: DIN-rail mountable panel provides 50 screw
terminals for universal field I/O termination. Connects to
Acromag ACPC8625 with the TRANS-C200, or other
compatible carrier boards, via SCSI-2 to Flat Ribbon Cable,
Shielded (Model 5028-187).
CompactPCI Transition Module:
Model TRANS-C200: This module plugs into the rear
backplane directly behind the carrier board. The field I/O
connections are made through the backplane to J4 and J5
connectors of the carrier board and then routed to four SCSI-2
connectors on the transition module (marked IP module slots “A
through D”) for rear exit from the card cage. It is available for
use in CompactPCI bus card cages which provide rear exit for
I/O connections via transition modules (transition modules can
only be used in card cages specifically designed for them). It is
a double-height (6U), single-slot module with front panel
hardware adhering to the CompactPCI Specification (PICMG
2.0, R2.1-1997) and IEEE Standard (1101.11-1998), with a
printed circuit board depth of 80mm, which is a standard
transition module depth. The transition module connects to
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 4 -
Acromag Termination Panel (Model 5025-552) using SCSI-2 to
Flat Ribbon Cable, Shielded (Model 5028-187) to the rear of the
card cage, and to ACPC8625 boards within the card cage.
IP MODULE OLE CONTROL SOFTWARE
Acromag provides a software product (sold separately)
consisting of IP module OLE (Object Linking and Embedding)
drivers for Windows 95/98 and Windows NT compatible application
programs (Model IPSW-OLE-PCI, MSDOS format). This software
provides individual drivers that allow Acromag IP modules and our
personal computer carriers to be easily integrated into Windows
application programs, such as Visual C++, Visual Basic, Borland
DelphiTM, MicrosoftOffice97applications, and others. The OLE
controls provide a high-level interface to IP modules, eliminating the
need to perform low-level reads/writes of registers, and the writing of
interrupt handlersall the complicated details of programming are
handled by the OLE controls. These functions are intended for use
in conjunction with an Acromag PCI or CompactPCI carrier and
consist of a carrier OLE control, and an OLE control for each
Acromag IP module as well as a generic OLE control for non-
Acromag IP modules.
2.0 PREPARATION FOR USE
UNPACKING AND INSPECTION
Upon receipt of this product, inspect the shipping carton for
evidence of mishandling during transit. If the shipping carton is
badlydamaged or water stained, request that the carrier's agent be
present when the carton is opened. If the carrier's agent is absent
when the carton is opened and the contents of the carton are
damaged, keep the carton and packing material for the agent's
inspection.
For repairs to a product damaged in shipment, refer to the Acromag
Service Policy to obtain return instructions. It is suggested that
salvageable shipping cartons and packing material be saved for
future use in the event the product must be shipped.
This board is physically protected with
packing material and electrically protected
with an anti static bag during shipment. It is
recommended that the board be visually
inspected for evidence of mishandling prior to
applying power.
The board utilizes static sensitive
components and should only be handled at a
static-safe workstation.
CARD CAGE CONSIDERATIONS
Refer to the specifications for loading and power requirements.
Be sure that the system power supplies are able to accommodate
the power requirements of the carrier board, plus the installed IP
modules, within the voltage tolerances specified.
IMPORTANT: Adequate air circulation must be provided to prevent
a temperature rise above the maximum operating temperature.
The lack of air circulation within the computer chassis is a
cause for some concern. The dense packing of the IP modules to
the carrier board alone results in elevated IP module and carrier
board temperatures, and the restricted air flow within the chassis
aggravates this problem. Adequate air circulation must be provided
to prevent a temperature rise above the maximum operating
temperature and to prolong the life of the electronics. If the
installation is in an industrial environment and the board is exposed
to environmental air, careful consideration should be given to air-
filtering.
BOARD CONFIGURATION
The carrier board is plug-and-play compatible and, as such, its
board addresses are automatically assigned by the system auto-
configuration routine upon power-up. The base address of the
carrier board’s configuration registers in memory space and I/O
space is assigned. In addition, the base address of the IP modules
and carrier board registers are assigned in 32-bit memory space.
Power should be removed from the board when installing IP
modules, cables, termination panels, and field wiring. Refer to
Mechanical Assembly Drawing 4501-789 and your IP module
documentation for specific configuration and assemblyinstructions.
Interrupt Configuration
No hardware jumper configuration is required. All interrupt
enabling, and status are configured via programmable registers on
the carrier board (see Section 3 for programming details). The
carrier board passes interrupt requests from the IP modules to the
PCI bus. Refer to the IP modules for their specific configuration
requirements.
CONNECTORS
Connectors of the ACPC8625 carrier consist of four carrier IP
module field I/O connectors, four IP module logic connectors, and
one CompactPCI bus interface connector. These interface
connectors are discussed in the following sections.
Carrier Field I/O Connectors (IP modules A through D)
Field I/O connections are made through the rear via transition
module (TRANS-C200) connectors A, B, C, and D for IP modules in
positions A through D, respectively. IP module assignment is
marked on the transition module for easy identification (seelocation
drawing 4501-788 for physical locations of the IP modules). SCSI-2
Round cable assemblies and Acromag termination panels (or user
defined terminations) can be quickly mated to the transition module
connectors. Pin assignments are defined by the IP I/O Mapping to
CompactPCI Specification (PICMG 2.4, R1.0).
Connectors A through D are 50-pin SCSI-2 right angle (female)
connectors (AMP). Connectors are high-density, and there is one
connector for each IP module marked with A, B, C, & D on the
transition module panel. These connectors include spring latch
hardware and 30 microns of gold in the mating area for excellent
connection.
IP Field I/O Connectors (IP modules A through D)
The field side connectors of IP modules A through D mate to
connectors P1, P3, P5, and P7, respectively, on the carrier board.
IP location is silk-screened on the board for easy identification. Field
and logic side connectors are keyed to avoid incorrect assembly.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 5 -
P1, P3, P5, and P7 are 50-pin male plug header connectors.
These AMP 173280-3 connectors mate to AMP 173279-3
connectors (or similar) on the IP modules. This provides excellent
connection integrity and utilizes gold plating in the mating area.
Threaded metric M2 screws and spacers (supplied with Acromag IP
modules) provide additional stability for harsh environments (see
Drawing 4501-788 & 789 for assembly details).
Pin assignments for these connectors are made by the specific
IP model used and correspond identically to the pin numbers of the
transition module panel connectors.
IP Logic Interface Connectors (IP modules A through D)
The logic interface sides of IP modules A through D mate to
connectors P2, P4, P6, and P8 respectively, on the carrier board. IP
location is silk-screened on the board for easy identification. Field
and logic side connectors are keyed to avoid incorrect assembly.
P2, P4, P6, and P8 are 50-pin male plug header connectors.
These AMP 173280-3 connectors mate to AMP 173279-3
connectors (or similar) on the IP modules. This provides excellent
connection integrity and utilizes gold plating in the mating area.
Threaded metric M2 screws and spacers (supplied with Acromag IP
modules) provide additional stability for harsh environments (see
Drawing 4501-789 for assembly details).
Pin assignments for these connectors are defined by the IP
module specification and are shown in Table 2.1:
Table 2.1: Standard IP Logic Interface Connections (P2,4,6,8)
Pin Description Number Pin Description Number
GND 1 GND 26
CLK2+5V27
Reset* 3 R/W* 28
D00 4 IDSEL* 29
D01 5 DMAReq0* 30
D02 6 MEMSEL* 31
D03 7 DMAReq1* 32
D04 8 IntSel* 33
D05 9 DMAck0* 34
D06 10 IOSEL* 35
D07 11 RESERVED 36
D08 12 A1 37
D09 13 DMAEnd* 38
D10 14 A2 39
D11 15 ERROR* 40
D12 16 A3 41
D13 17 INTReq0* 42
D14 18 A4 43
D15 19 INTReq1* 44
BS0* 20 A5 45
BS1* 21 STROBE* 46
-12V 22 A6 47
+12V 23 ACK* 48
+5V 24 RESERVED 49
GND 25 GND 50
Asterisk (*) is used to indicate an active-low signal.
BOLD ITALIC Logic Lines are NOT USED by the carrier board.
CompactPCI Bus Connections for J1
Table 2.2 indicates the pin assignments for the CompactPCI
bus signals at the J1 connector. The J1 connector is the lower rear
connector on the ACPC8625 board, as viewed from the front. The
connector consists of 25 rows of six pins labeled A, B, C, D, E and
F. Pin A1 is located at the lower right hand corner of the connector
if the board is viewed from the front component side.
Refer to the CompactPCI bus specification for additional
information on the CompactPCI bus signals.
TABLE 2.2: CompactPCI bus J1 CONNECTIONS
Pin Row A Row B Row C Row D Row E Row F
1 +5V -12v TRST# +12V +5V GND
2TCK +5V TMS TDO TDI GND
3INTA#INTB# INTC# +5V INTD# GND
4BR*A4 GND V(I/0) INTP INTS GND
5BR*A5 BR*B5 RST# GND GNT# GND
6REQ# GND +3.3V CLK AD[31] GND
7 AD[30] AD[29] AD[28] GND AD[27] GND
8 AD[26] GND V(I/O) AD[25] AD[24] GND
9 C/BE[3]# IDSEL AD[23] GND AD[22] GND
10 AD[21] GND +3.3V AD[20] AD[19] GND
11 AD[18] AD[17] AD[16] GND C/BE[2]# GND
12 GND
13 KEY AREA GND
14 GND
15 +3.3V FRAME# IRDY# GND TRDY# GND
16 DEVSEL# GND V(I/O) STOP# LOCK# GND
17 +3.3V SDONE SBO# GND PERR# GND
18 SERR# GND +3.3V PAR C/BE[1]# GND
19 +3.3V AD[15] AD[14] GND AD[13] GND
20 AD[12] GND V(I/O) AD[11] AD[10] GND
21 +3.3V AD[9] AD[8] M66EN C/BE[0]# GND
22 AD[7] GND +3.3V AD[6] AD[5] GND
23 +3.3V AD[4] AD[3] +5V AD[2] GND
24 AD[1] +5V V(I/O) AD[0] ACK64# GND
25 +5V REQ64# ENUM# +3.3V +5V GND
Pound (#) is used to indicate an active-low signal.
BOLD ITALIC Logic Lines are NOT USED by the carrier board.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 6 -
CompactPCI I/O Signals Connections for J4
Table 2.3 indicates the pin assignments for the CompactPCI I/O
signal mapping at the J4 connector. The J4 connector is the second
connector from the upper rear corner on the ACPC8625 board, as
viewed from the front. The connector consists of 25 rows of six pins
labeled A, B, C, D, E and F. Pin A1 is located near the center of the
board, viewed from the front component side. J4 is used to route IP
Modules A & B field signals from the carrier to the backplane.
TABLE 2.3: CompactPCI I/O Signals J4 CONNECTIONS
Pin Row A Row B Row C Row D Row E Row F
1+3.3V +3.3V +3.3V +5V +5V GND
2 A46 A47 A48 A49 A50 GND
3 A41 A42 A43 A44 A45 GND
4 A36 A37 A38 A39 A40 GND
5 A31 A32 A33 A34 A35 GND
6 A26 A27 A28 A29 A30 GND
7 A21 A22 A23 A24 A25 GND
8 A16 A17 A18 A19 A20 GND
9 A11 A12 A13 A14 A15 GND
10 A6 A7 A8 A9 A10 GND
11 A1 A2 A3 A4 A5 GND
12 GND
13 KEY AREA GND
14 GND
15 +3.3V +3.3V +3.3V +5V +5V GND
16 B46 B47 B48 B49 B50 GND
17 B41 B42 B43 B44 B45 GND
18 B36 B37 B38 B39 B40 GND
19 B31 B32 B33 B34 B35 GND
20 B26 B27 B28 B29 B30 GND
21 B21 B22 B23 B24 B25 GND
22 B16 B17 B18 B19 B20 GND
23 B11 B12 B13 B14 B15 GND
24 B6 B7 B8 B9 B10 GND
25 B1 B2 B3 B4 B5 GND
Note: The letter in front of the number indentifies the IP Module
Slot. The number indentifies the I/O pin number of that IP
Module.
Example: A46 A = IP Module in Slot “A”
46 = I/O Pin number “46”
(This pin on the IP Module connects to J4, Pin 2, Row A.)
BOLD ITALIC Power Lines are NOT USED by the carrier board.
The I/O signals for the J4 connector are mapped per the IP
Module I/O to CompactPCI Specification (PICMG 2.4, R1.0).
CompactPCI I/O Signals Connections for J5
Table 2.4 indicates the pin assignments for the CompactPCI I/O
signal mapping at the J5 connector. The J5 connector is the first
connector from the upper rear corner on the ACPC8625 board, as
viewed from the front. The connector consists of 22 rows of six pins
labeled A, B, C, D, E and F. Pin A22 is located at the upper left
hand corner of the connector if the board is viewed from the front
component side. J5 is used to route IP Modules C & D field signals
from the carrier to the backplane.
TABLE 2.4: CompactPCI I/O Signals J5 CONNECTIONS
Pin Row A Row B Row C Row D Row E Row F
1+3.3V +3.3V +3.3V +5V +5V GND
2 C46 C47 C48 C49 C50 GND
3 C41 C42 C43 C44 C45 GND
4 C36 C37 C38 C39 C40 GND
5 C31 C32 C33 C34 C35 GND
6 C26 C27 C28 C29 C30 GND
7 C21 C22 C23 C24 C25 GND
8 C16 C17 C18 C19 C20 GND
9 C11 C12 C13 C14 C15 GND
10 C6 C7 C8 C9 C10 GND
11 C1 C2 C3 C4 C5 GND
12 +3.3V +3.3V +3.3V +5V +5V GND
13 D46 D47 D48 D49 D50 GND
14 D41 D42 D43 D44 D45 GND
15 D36 D37 D38 D39 D40 GND
16 D31 D32 D33 D34 D35 GND
17 D26 D27 D28 D29 D30 GND
18 D21 D22 D23 D24 D25 GND
19 D16 D17 D18 D19 D20 GND
20 D11 D12 D13 D14 D15 GND
21 D6 D7 D8 D9 D10 GND
22 D1 D2 D3 D4 D5 GND
Note: The letter in front of the number indentifies the IP Module
Slot. The number indentifies the I/O pin number of that IP
Module.
Example: C46 C = IP Module in Slot “C”
46 = I/O Pin number “46”
(This pin on the IP Module connects to J5, Pin 2, Row A.)
BOLD ITALIC Power Lines are NOT USED by the carrier board.
The I/O signals for the J5 connector are mapped per the IP
Module I/O to CompactPCI Specification (PICMG 2.4, R1.0).
DATA TRANSFER TIMING
All CompactPCI bus read or write cycles to the ACPC8625 are
typically implemented within 150n seconds (FRAME# active to
TRDY# active). After 150n seconds the CompactPCI bus is
available to the system for other CompactPCI bus activity. As the
CompactPCI bus is released, the ACPC8625 completes the read or
write cycle to the targeted IP module or carrier register within the
access times given in Table 2.5.
TABLE 2.5: ACPC8625 Write and Read Complete Time
Register Data Transfer Time
Carrier Registers Write 650nS, Typical1
8 and 16-bit IP Write 750nS, Typical1,2
32-bit IP Write 1250nS, Typical1,3
Carrier Register Read 500nS, Typical1
8 and 16-bit IP Read 650nS, Typical1,2
32-bit IP Read 1100nS, Typical1,3
Notes (Table 2.5):
1. The data transfer times given in table 2.5 are measured from the
falling edge of FRAME# to the falling edge of LRDYi#. The
CompactPCI bus starts a data transfer cycle by driving
FRAME# low. The ACPC8625 signals the completion of a read
or write cycle bydriving LRDYi# low.
2. This access time assumes zero IP module wait states. For each
IP module wait state 125n seconds must be added to this value.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 7 -
3. This access time assumes zero IP module wait states. For each
IP module wait state 250n seconds must be added to this value.
FIELD GROUNDING CONSIDERATIONS
Carrier boards are designed with passive filters on each supply
line to each IP module. This provides maximum filtering and signal
decoupling between the IP modules and the carrier board. However,
the boards are considered non-isolated, since there is electrical
continuity between the CompactPCI bus and the IP grounds.
Therefore, unless isolation is provided on the IP module itself, the
field I/O connections are not isolated from the CompactPCI bus.
Care should be taken in designing installations without isolation to
avoid ground loops and noise pickup. This is particularly important
for analog I/O applications when a high level of accuracy/resolution
is needed (12-bits or more). Contact your Acromag representative
for information on our many isolated signal conditioning products
that could be used to interface to the IP input/output modules.
3.0 PROGRAMMING INFORMATION
This Section provides the specific information necessary to
program and operate the ACPC8625 non-intelligent carrier board.
This Acromag ACPC8625 complies with PCI Specification
Version 2.1 and CompactPCI Specification PICMG 2.0 R2.1. It is a
CompactPCI bus slave carrier board for Industrial I/O Pack
mezzanine (IP) modules. The carrier connects a CompactPCI host
bus to the IP module’s 16-bit data bus per the Industrial I/O Pack
logic interface specification on the mezzanine (IP) modules which
are installed on the carrier.
The CompactPCI bus is defined to address three distinct
address spaces: I/O, memory, and configuration space. The IP
modules can be accessed via the CompactPCI bus memory
space only.
The CompactPCI card’s configuration registers are initialized by
system software at power-up to configure the card. The
CompactPCI carrier is a Plug-and-Play card. As a Plug-and-Play
card the board’s base address and system interrupt request line are
not selected via jumpers but are assigned bysystem software upon
power-up via the configuration registers. A CompactPCI bus
configuration access is used to access a CompactPCI card’s
configuration registers.
CompactPCI Configuration Address Space
When the computer is first powered-up, the computer’s system
configuration software scans the CompactPCI bus to determine
what CompactPCI devices are present. The software also
determines the configuration requirements of the CompactPCI card.
The system software accesses the configuration registers to
determine how many blocks of memory space the carrier requires. It
then programs the carrier’s configuration registers with the unique
memory address range assigned.
The configuration registers are also used to indicate that the
CompactPCI carrier requires an interrupt request line. The system
software then programs the configuration registers with the interrupt
request line assigned to the CompactPCI carrier.
Since this CompactPCI carrier is relocatable and not hardwired
in address space, this carrier’s mapping and IRQ information is
stored in the carrier’s Configuration Space registers.
Configuration Transactions
The CompactPCI bus is designed to recognize certain I/O
accesses initiated bythe host processor as a configuration access.
Configuration uses two 32-bit I/O ports located at addresses 0CF8
and 0CFC hex. These two ports are:
•32-bit configuration address port, occupying I/O addresses
0CF8 through 0CFB hex.
•32-bit configuration data port, occupying I/O addresses 0CFC
through 0CFF hex.
Configuration space is accessed by writing a 32-bit long-word
into the configuration address port that specifies the CompactPCI
bus, the carrier board on the bus, and the configuration register on
the carrier being accessed. A read or write to the configuration data
port will then cause the configuration address value to be translated
to the requested configuration cycle on the CompactPCI bus.
Accesses to the configuration data port determine the size of the
access to the configuration register addressed and can be an 8, 16,
or 32-bit operation.
Any access to the Configuration address port that is not a 32-bit
access is treated like a normal computer I/O access. Thus,
computer I/O devices using 8 or 16-bit registers are not affected
because theywill be accessed as expected.
Table 3.1: Configuration Address Port
BIT FUNCTION
31 Enables accesses to Configuration Data to be
translated to configuration cycles on the CompactPCI
bus.
30-24 Reserved, Return 0 when read.
23-16 Bus Number
Choose a specific CompactPCI bus in the
system.
15-11 Device Number
Choose a specific device/CompactPCI board on
the bus.
10-8 Function Number
Choose a specific function in a device. Function
number is zero for the ACPC8625.
7-2 Register Number
Used to indicate which CompactPCI
Configuration Register to access. The
Configuration Registers and their corresponding
register numbers are given in Table 3.2.
1-0 Read Only bits that return 0.
Configuration Registers
The CompactPCI specification requires software driven
initialization and configuration via the Configuration Address space.
This CompactPCI carrier provides 256 bytes of configuration
registers for this purpose as shown in Table 3.2, to facilitate Plug-
and-Play compatibility.
The Configuration Registers are accessed via the Configuration
Address and Data Ports. The most important Configuration
Registers are the Base Address Registers and the Interrupt Line
Register which must be read to determine the base address
assigned to the carrier and the interrupt request line that goes active
on a carrier interrupt request.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 8 -
Table 3.2 Configuration Registers
Reg.
Num. D31 D24 D23 D16 D15 D8 D7 D0
0Device ID=1024 Vendor ID= 10B5
1Status Command
2Class Code Rev ID
3BIST Header Latency Cache
4Base Addr. Memory Mapped Configuration Registers
5Base Address for I/O Mapped Configuration Registers
632-bit Memory Base Address for ACPC8625
7 : 10 Not Used
11 Subsystem ID Subsystem Vendor ID
12 Not Used
13 Reserved
14 Reserved
15 Max_Lat Min_Gnt Inter. Pin Inter. Line
MEMORY MAP
The 1K byte of memory consumed by the board is composed of
blocks of memory for the ID, I/O and INT spaces corresponding to
four IP modules. In addition, a small portion of the 1K byte address
space contains registers specific to the function of the carrier board.
The carrier is configured to map this 1K byte block of memory
into 32-bit memory space. The system configuration software will
allocate space by writing the assigned address into the
corresponding Base Address register of the Configuration Registers.
The memory map for ACPC8625 is shown in Tables 3.3.
Table 3.3: ACPC8625 Carrier Bd Memory Map
Base
Address +
(Hex) High Byte D15 D08 Low Byte D07 D00
Base
Address +
(Hex)
0001 Bit-8 Software
Reset Carrier Board Status/Control 0000
0003 IP Interrupt Pending Register 0002
0005 IP A Interrupt 0 Select Space 0004
0007 IP A Interrupt 1 Select Space 0006
0009 IP B Interrupt 0 Select Space 0008
000B IP B Interrupt 1 Select Space 000A
000D IP C Interrupt 0 Select Space 000C
000F IP C Interrupt 1 Select Space 000E
0011 IP D Interrupt 0 Select Space 0010
0013 IP D Interrupt 1 Select Space 0012
0015 Not Used 0014
0017 Not Used 0016
0019
↓
↓↓
↓
003F Not Used Not Used 0018
↓
↓↓
↓
003E
0041
↓
↓↓
↓
007F
IP A
ID Space IP A ID Space 0040
↓
↓↓
↓
007E
0081
↓
↓↓
↓
00BF
IP B
ID Space IP B ID Space 0080
↓
↓↓
↓
00BE
00C1
↓
↓↓
↓
00FF
IP C
ID Space IP C ID Space 00C0
↓
↓↓
↓
00FE
0101
↓
↓↓
↓
013F
IP D
ID Space IP D ID Space 0100
↓
↓↓
↓
013E
Base
Address +
(Hex) High Byte D15 D08 Low Byte D07 D00
Base
Address +
(Hex)
0141
↓
↓↓
↓
017F Not Used Not Used 0140
↓
↓↓
↓
017E
0181
↓
↓↓
↓
01FF
IP A
I/O Space IP A I/O Space 0180
↓
↓↓
↓
01FE
0201
↓
↓↓
↓
027F
IP B
I/O Space IP B I/O Space 0200
↓
↓↓
↓
027E
0281
↓
↓↓
↓
02FF
IP C
I/O Space IP C I/O Space 0280
↓
↓↓
↓
02FE
0301
↓
↓↓
↓
037F
IP D
I/O Space IP D I/O Space 0300
↓
↓↓
↓
037E
0381
↓
↓↓
↓
03FF Not Used Not Used 0380
↓
↓↓
↓
03FE
The ACPC8625 base address is determined through the
CompactPCI Configuration Registers. The addresses given in
Table 3.3 are relative to the base address of the ACPC8625 carrier.
The addresses within each IP’s own space are specific to that IP
module. Refer tothe IP module’s User Manual for information
relating to the IP specific registers.
The Carrier registers, IP Identification (ID) spaces, IP
Input/Output (IO), and IP Interrupt spaces are accessible via the
CompactPCI bus space as given in Table 3.3. A 32-bit
CompactPCI bus access will result in two 16-bit accesses to the IP
module. A 16-bit or 8-bit CompactPCI bus access results in a
single 16-bit or 8-bit access to the IP module, respectively.
Carrier Status/Control Register - (Read/Write, Base + 00H)
The Carrier Board Status Register reflects and controls
functions globally on the carrier board.
BIT FUNCTION
15-09 Not Used
08
Write
Only
Software Reset
Writing a “1” to this bit causes a software reset.
Writing a “0” or reading this bit has no effect.
When set, the software reset pulse will have a
duration of 1u second.
07-06 Not Used
05
Read
and
Write
IP Module Access Time Out Interrupt Pending
This bit will be "1" when there is an IP Module
Access Time Out interrupt pending. This bit will
be "0" when there is no interrupt pending. Reset
condition: Set to "0". Writing a “1” to this bit will
release the pending interrupt.
04
Read
Only
IP Module Access Time Out Status
Status bit to indicate that the last IP module
access has timed out. This bit only reflects the
last IP module access.
“0” if last IP module access did not time out.
“1” if last IP module access did time out.
03
Read
and
Time Out Interrupt Enable
When set to “1”, this bit will enable the carrier
board to generate an interrupt upon time out of an
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 9 -
BIT FUNCTION
Write IP module access. The default setting or reset
condition is “0” (interrupt generation upon time
out disabled). The interrupt service routine, in
responding to the Time Out Access interrupt, will
need to set this bit to 0 to clear the pending
interrupt request.
02
Read
and
Write
IP Module Interrupt Enable
When set to “1”, this bit will enable the generation
of IP module interrupts. The default setting or
reset condition is “0” (IP module interrupt
generation disabled). Interrupts must also be
supported and configured at the IPs.
01
Read
Only
IP Module Interrupt Pending
This bit will be "1" when there is an interrupt
pending. This bit will be "0" when there is no
interrupt pending. Polling this bit will reflect the
IP Module’s pending interrupt status, even if the
IP Module Interrupt Enable bit is set to "0".
Reset condition: Set to "0".
00
Read
Only
IP Module Error
This bit will be "1" when there is an active IP
Module Error signal. This bit will be "0" when all
IP module Error signals are inactive. This bit
allows the user to monitor the Error signals of IP
modules A through D. The Industrial I/O Pack
specification states that the error signals indicate
a non-recoverable error from the IP (such as a
component failure or hard-wired configuration
error). Refer to your IP specific documentation to
see if the error signal is supported and what it
indicates. Reset condition: Set to "0".
IP Interrupt Pending Register - (Read, Base + 02H)
The IP Interrupt Pending Register is used to individually identify
pending IP interrupts or a pending carrier generated interrupt as a
result of IP module time out access. If multiple IP interrupts are
pending, software must determine the order in which they are
serviced.
MSB
D7 D6 D5 D4 D3 D2 D1 LSB D0
IP D
Int1
Pend
IP D
Int0
Pend
IP C
Int1
Pend
IP C
Int0
Pend
IP B
Int1
Pend
IP B
Int0
Pend
IP A
Int1
Pend
IP A
Int0
Pend
MSB
D15 D14 D13 D12 D11 D10 D9 LSB D8
Not
Used Time Out Interrupt
Pend
Not
Used Not Used
Where:
All Bits
IP Interrupt Pending
(Read)
A bit will be a “1” when the corresponding
interrupt is pending. A bit will be a “0” when
its corresponding interrupt is not pending.
Polling this bit will reflect the IP module’s
pending interrupt status, even if the IP
interrupt enable bit is set to “0”.
Reset Condition: Set to "0". An IP module
pending interrupt bit will be cleared if its
corresponding interrupt request signal is
inactive.
IP Module Interrupt Space - (Read Only)
The Interrupt space for each IP module is fixed at two 16-bit
words. Interrupt 0 select space is read, typically by an interrupt
service routine, to respond to an interrupt request via the IP
Module’s INTREQ0* signal. Likewise interrupt 1 select space is
read to respond to an interrupt request via the IP Module’s
INTREQ1* signal. An access to an interrupt select space results in
the IP module serving up an interrupt vector. In addition, access to
the interrupt space will cause some IP modules to release their
interrupt request. See each IP module’s User Manual for details.
IP Module ID Space - (Read Only)
Each IP contains identification (ID) information that resides in
the ID space per the IP specification. This area of memory contains
either 32 bytes (Format I ID) or 64 bytes (Format II ID) of
information, at most. Format I requires read of only the least
significant byte. Format II requires read of a 16-bit value. The
carrier will implement 16-bit reads to the ID space to allow support
for either Format I or Format II. Both fixed and variable information
may be present within the ID ROM. Variable information may
include unique information required for the module. The
identification Section for each IP module is located in the carrier
board memory map per Table 3.3. Refer to the documentation of
your IP module for specific information about each IP module’s ID
Space contents.
IP Module I/O Space - (Read/Write Only, 256-Byte Addresses)
The I/O space on each IP module is fixed at 128, 16-bit words
(256 bytes). The four IP module I/O spaces are accessible at fixed
offsets for the ACPC8625’s Base Address. IP modules may not
fully decode their I/O space and may use byte or word only
accesses. See each IP module’s User Manual for details.
GENERATING INTERRUPTS
Interrupt requests originate from the carrier board in the case of
an access time out and from the IP modules. Each IP may support
0, 1, or 2 interrupt requests. Upon an IP module interrupt request
the carrier passes the interrupt request on to the host, provided that
the carrier board is enabled for interrupts within the Carrier Board
Status Register.
Sequence of Events For an Interrupt
1. Clear the interrupt enable bits in the Carrier Board Status
Register by writing a "0" to bit 2/bit 3.
2. Write interrupt vector to the location specified on the IP and
perform any other IP specific configuration required - do for
each supported IP interrupt request.
3. Determine the IRQ line assigned to the carrier during system
configuration (within the configuration register).
4. Set up the CPU’s interrupt vector for the appropriate interrupt.
5. Unmask the IRQ on the CPU’s 8259 (or equivalent) interrupt
controller.
6. The IP asserts an interrupt request to the carrier board (asserts
interrupt request line IntReq0* or IntReq1*).
7. The carrier drives PCI bus interrupt request signal INTA#
active.
8. CPU drives the IRQ line assigned to the active carrier.
9. The interrupt service routine pointed to by the vector set up in
step 4 starts.
10. Interrupt service routine determines which IP module caused
the interrupt by reading the carrier interrupt pending register. If
multiple interrupts are pending the interrupt service routine
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 10 -
software determines which IP module to service first. In a
CompactPCI System interrupts are shared and can be from
any slot on the backplane. The routine must first check that
the interrupt came from the CompactPCI carrier by reading the
carrier interrupt pending register.
11. The interrupt service routine accesses the interrupt space of
the IP module selected to be serviced. Note that the interrupt
space accessed must correspond to the interrupt request
signal driven by the IP module.
12. The carrier board will assert the INTSEL* signal to the
appropriate IP together with (carrier board generated) address
bit A1 to select which interrupt request is being processed (A1
low corresponds to INTREQ0*; A1 high corresponds to
INTREQ1*).
13. The IP module receives an active INTSEL* signal from the
carrier and supplies its interrupt vector to thehost system
during this interrupt acknowledge cycle. An IP module
designed to release its interrupt request on acknowledge will
release its request upon receiving an active INTSEL* signal
from the carrier. If the IP module is designed to release its
interrupt request on register access theinterrupt service
routine must access the required register to clear the interrupt
request.
14. Write “End-Of-Interrupt” command to CPU’s 8259 (or
equivalent).
15. If the IP interrupt stimulus has been removed and no other IP
modules have interrupts pending, the interrupt cycle is
completed (i.e. the carrier board negates its interrupt request
INTA#).
4.0 THEORY OF OPERATION
This section describes the basic functionalityof thecircuitry
used on the carrier board. Refer to the Block Diagram shown in the
Drawing 4501-790 as you review this material.
CARRIER BOARD OVERVIEW
The carrier board is a CompactPCI bus slave/target board
providing up to four industry standard IP module interfaces. The
carrier board’s CompactPCI bus interface allows an intelligent single
board computer (CompactPCI bus Master) to control and
communicate with IP modules that are present on the CompactPCI
bus carrier. IP module field I/O connections link to the field I/O
connections of the carrier which in turn are used to connect field
electronic hardware to the carrier board via SCSI-2 cable and
TRANS-C200 transition module.
The CompactPCI bus and IP module logic commons have a
direct electrical connection (i.e., they are not electrically isolated).
However, the field I/O connections can be isolated from the PCI bus
if an IP module that provides this isolation (between the logic and
field side) is utilized. A wide variety of IP modules are currently
available (from Acromag and other vendors) that allow interface to
many external devices for digital I/O, analog I/O, and communication
applications.
CompactPCI Bus Interface
The carrier board’s CompactPCI bus interface is used to
program and monitor carrier board registers for configuration and
control of the board’s documented modes of operation (see section
3). In addition, the CompactPCI bus interface is also used to
communicate with and control external devices that are connected to
an IP module’s field I/O signals (assuming an IP module is present
on the carrier board).
The CompactPCI bus interface is implemented in the logic of
the carrier board’s CompactPCI bus target interface chip. The
CompactPCI bus interface chip implements PCI Specification
Version 2.1 and CompactPCI Specifications PICMG 2.0 R2.1 as an
interrupting slave including 8-bit and 16-bit data transfers to the IP
modules.
The carrier board’s CompactPCI bus data transfer rates are
shown in Table 2.5.
Carrier Board Registers
The carrier board registers (presented in section 3) are
implemented in the logic of the carrier board’s Field Programmable
Gate Array (FPGA). An outline of the functions provided by the
carrier board registers includes:
•Monitoring the error signal received from each IP module is
possible via the IP Error Bit.
•Enabling of CompactPCI bus interrupt requests from each IP
module is possible via the IP Module Interrupt Enable Bit.
•Enabling of interrupt generation upon an IP module access
time out is implemented via the Time Out Interrupt Enable
Bit.
•Monitoring an IP module access time out is possible via the IP
Module Access Time Out Status Bit.
•Identify pending interrupts via the carrier’s IP Module
Interrupt Pending Bit.
•Lastly, pending interrupts can be individually monitored via the
IP Module Interrupt Pending register.
IP Logic Interface
The IP logic interface is also implemented in the logic of the
carrier board’s FPGA. The carrier board implements ANSI/VITA 4
1995 Industrial I/O Pack logic interface specification and includes
four IP logic interfaces. The CompactPCI bus address and data
lines are linked to the address and data of the IP logic interface.
This link is implemented and controlled by the carrier board’s FPGA.
The CompactPCI bus to IP logic interface link allows a
CompactPCI bus master to:
•Access up to 64 ID Space bytes for IP module identification via
8-bit or 16-bit data transfers using CompactPCI bus.
•Access up to 128 I/O Space bytes of IP data via 8-bit or 16-bit
data transfers.
•Access IP module interrupt space via 8-bit or 16-bit
CompactPCI bus data transfers.
•Respond to two IP module interrupt requests per IP module.
Carrier Board Clock Circuitry
A 16MHz clock is divided down by a clock driver to obtain the IP
module 8MHz clock signals. Separate IP clocks are driven to each
IP module. All clock lines include series damping resistors to
reduce clock overshoot and undershoot.
When an IP module places data on the bus, for all data read
cycles, any undriven data lines are read by the CompactPCI bus as
high because of pull-up resisters on the carrier board’s data bus.
CompactPCI Interrupter
Interrupts are initiated from an interrupting IP module. However,
the carrier board will only pass an interrupt generated by an IP
module to the CompactPCI bus if the carrier board has been first
enabled for interrupts. Each IP module can initiate two interrupts
which can be individually monitored on the carrier board. After
interrupts are enabled on the carrier board via the Interrupt Enable
Bits (see section 3 for programming details), an IP generated
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 11 -
interrupt is recognized by the carrier board and is recorded in the
carrier board’s Interrupt Pending Register.
A carrier board pending interrupt will cause the board to pass
the interrupt to the CompactPCI bus provided the Interrupt Enable
bits of the carrier’s Status Register have been enabled (see section
3 for programming details). The PC interrupt request line assigned
by the system configuration software will then be asserted. The
CPU will respond to the asserted interrupt line byexecuting the
interrupt service routine corresponding to the interrupt line asserted.
The interrupt service routine is executed only if the IRQ on the
CPU’s 8259 interrupt controller has been previously unmasked (see
section 3 for programming details).
The interrupt service routine should respond to an interrupt by
accessing IP Interrupt Select (INTSEL*) space. The interrupt
service routine should also conclude the interrupt routine by writing
the “End-Of-Interrupt” command to the CPU’s 8259 interrupt
controller (see section 3 for more details).
Power Failure Monitor
The carrier board contains a 5 volt undervoltage monitoring circuit
which provides a reset to the IP modules when the 5 volt power
drops below 4.27 volts typical / 4.15 volts minimum. This circuitry is
implemented per the Industrial I/O Pack specification.
Power Supply Fuses
The +5V, supply lines to each of the IP modules are individually
fused with a current limit of 2 amp imposed by the fuses. In
addition, the +12, and -12 supply lines to each of the IP modules
are individually fused with a current limit of 1 amp imposed by the
fuses. A blown fuse can be identified by visible inspection or by use
of an ohm meter. The fuses are located under each IP slot near the
“logic connectors” (see figure 4501-788).
Power Supply Filters
Power line filters are dedicated to each IP module for filtering of
the +5, +12, and -12 volt supplies. The power line filters are a “T”
type filter circuit comprising ferrite bead inductors and a feed-
through capacitor. The filters provide improved noise performance
as is required on precision analog IP modules.
5.0 SERVICE AND REPAIR
SERVICE AND REPAIR ASSISTANCE
Surface-Mounted Technology (SMT) boards are generally
difficult to repair. It is highly recommended that a non-functioning
board be returned to Acromag for repair. The board can be
damaged unless special SMT repair and service tools are used.
Further, Acromag has automated test equipment that thoroughly
checks the performance of each board. When a board is first
produced and when any repair is made, it is tested, placed in a burn-
in room at elevated temperature, and retested before shipment.
Please refer to Acromag's Service Policy Bulletin or contact
Acromag for complete details on how to obtain parts and repair.
PRELIMINARY SERVICE PROCEDURE
Before beginning repair, be sure that all of the procedures in
Section 2, Preparation For Use, have been followed. Also, refer to
the documentation of your carrier board to verify that it is correctly
configured. Verify that there are no blown fuses. Replacement of
the carrier and/or IP with one that is known to work correctly is a
good technique to isolate a faulty board.
CAUTION: POWER MUST BE TURNED OFF BEFORE
REMOVING OR INSERTING BOARDS
Acromag’s Applications Engineers can provide further technical
assistance if required. When needed, complete repair services are
also available from Acromag.
6.0 SPECIFICATIONS
PHYSICAL
Physical Configuration..................CompactPCI 5 V Board
Length..........................................9.187 inches (233.3 mm)
Width........................................... 6.299 inches (160.0 mm)
Board Thickness....................….. 0.062 inches (1.59 mm)
Max Component Height............... 0.550 inches (13.97 mm)
Max Component
Height Under IP Modules.............0.180 inches (4.57 mm)
Recommended Card Spacing.......0.800 inches (20.32 mm)
Connectors:
J1 (CompactPCI Bus)..................PCI Specification Version 2.1
& CompactPCI Specification
PICMG 2.0 R2.1 5 V Board.
Type “A” right-angle female
connector, 110 contacts with
upper shield.
Note: A 5 volt coding key is inserted into J1 connector to
allow this card to be plugged into a 5 volt backplane
system only. (Key Color: Brilliant Blue)
J4, J5 (CompactPCI Field I/O).....CompactPCI Specification
PICMG 2.4 R1.0. IP field
I/O mapping to CompactPCI
field I/O. Type “B” right-angle
female connector, 110
contacts with upper shield.
Note: J4 and J5 are not compliant with Computer
Telephony Specification.
(H.110 and Telephony I/O)
P1,3,5, 7 (IP Field I/O)..................50-pin maleplug header
(AMP 173280-3 or equivalent).
P2,4,6, 8 (IP Logic).......................50-pin male plug header
(AMP 173280-3 or equivalent).
Power:
Board power requirements are a function of the installed IP
modules. This specification lists currents for the carrier board
only. The carrier board provides +5V, +12V and -12V power to
each IP from the CompactPCI bus. Each IP module supplyline
is individually filtered and fused.
Fuses: +5 volts, 2 amp per slot
±12 volts, 1 amp per slot
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 12 -
The power failure monitor circuit provides a reset to IP modules
when the 5 volt power drops below 4.27 volts typically / 4.15
volts minimum.
Currents specified are for the carrier board only, add the IP
module currents for the total current required from each supply.
+5 Volts (±5%)...................…...... 180mA, Typical
250mA, Maximum.
+12 Volts (±5%)...........…............ 0mA (Not Used)
-12 Volts (±5%)............................0mA (Not Used)
CompactPCI BUS COMPLIANCE
Specification................................ This device meets or exceeds
all written PCI Specification
Version 2.1 & CompactPCI
Specification PICMG 2.0 R2.1.
DataTransfer Bus........................Slave with 32-bit, 16-bit, and
8-bit data transfer operation.
32-bit read or write accesses
are implemented as two 16
bit transfers to the IP modules.
CompactPCI bus Write
Cycle Time...................................150nS typical measured from
falling edge of FRAME# to the
falling edge of TRDY#.
CompactPCI bus Read
Cycle Time...................................150nS typical; The carrier issues
a RETRY which frees the
CompactPCI bus while the read
request is completed. The
CompactPCI bus will repeat the
same read request until it
completes with the requested data.
ACPC8625 Write
Complete Time............................ Time from FRAME# active until
LRDYi# active. 650nS typical
carrier register; 750nS typical 8-bit
and 16-bit IP module write
assuming 0 IP module wait
states). 1250nS typical 32-bit IP
module write (assuming 0 IP
module wait states).
ACPC8625 Read
Complete Time.............................Time from FRAME# active until
LRDYi# active. 500nS typical
carrier register; 650nS typical 8-bit
and 16-bit IP module read
(assuming 0 IP module wait
states). 1100nS typical 32-bit IP
module read (assuming 0 IP
module wait states).
Interrupts.............................….....CompactPCIbus INTA# interrupt
signal. Up to two requests
sourced from each IP mapped to
INTA#. Interrupt vectors come
from IP modules via access to IP
module INT space.
32-bit Memory Space...................Upon power-up thesystem auto-
configuration process (plug &
play) maps the carrier’s base
address (for a 1K byte block of
memory) into the PCI bus 32-bit
Memory Space.
INDUSTRIAL I/O PACK COMPLIANCE
Specification................................This device meets or exceeds all
written Industrial I/O Pack
specifications per ANSI/VITA 4
1995 (For 8MHz operation only)
and IP I/O Mapping to
CompactPCI (PICMG 2.4 R1.0).
Electrical/Mechanical Interface....Carrier supports four single-size
IP modules (A-D), or two double-
size IP module. 32-bit IP modules
are not supported.
I/O Space.....................................16-bit and 8-bit: Supports 128
byte values per IP module.
ID Space..................................... A16/D08(O); supports 32 bytes
per IP (consecutive odd-byte
addresses) ID Data Format I. D16
is also supported with pull-ups on
the carrier board holding the upper
8-bits high.
Memory Space.............................Not Supported.
Interrupts..................................…Supports two interrupt requests
per IP and interrupt acknowledge
cycles via access to IP INT space.
Access LED
(Illuminate duration).................... 0.125 second, typical
ENVIRONMENTAL
Operating Temperature................0 to +70°C;
-40 to +85°C (E Versions)
Note that visual LED performance
may be degraded below -20oC.
Relative Humidity......................... 5-95% non-condensing
Storage Temperature...................-55 to +100°C.
Non-Isolated.................................CompactPCI bus and IP module
logic commons have a direct
electrical connection. As such,
unless the IP module provides
isolation between the logic and
field side, the field I/O connections
are not isolated from the
CompactPCI bus.
Radiated Field Immunity(RFI)..... Designed to comply with
IEC1000-4-3 Level 3 (10V/m at
frequencies 27MHz to 500MHz)
and European Norm EN50082-1.
Electromagnetic Interference
Immunity (EMI)............................ No digital upset under the
influence of EMI from switching
solenoids, commutator motors,
and drill motors.
Electrostatic Discharge
Immunity (ESD)........................... Complies with IEC1000-4-2
Level 1 (2KV direct contact
discharge) at field input/output
terminals and European Norm
EN50082-1.
Electric Fast Transient
Immunity EFT.............................. Complies with IEC1000-4-4
Level 2 (0.5KV at field input and
output terminals) and European
Norm EN50082-1.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 13 -
Radiated Emissions.....................Meets or exceeds European
Norm EN50081-1 for class A
equipment.
APPENDIX
CABLE: MODEL 5028-187 (SCSI-2 to Flat Ribbon, Shielded)
Type: Round shielded cable, 50-wires (SCSI-2 male connector at
one end and a flat female ribbon connector at the other end).
The cable length is 2 meters (6.56 feet). This shielded cable is
recommended for all I/O applications (both digital I/O and
precision analog I/O).
Application: Used to connect Model 5025-552 termination panel to
the TRANS-C200 Transition Module. The transition module
then connects to all four IP module slots to the rear of the
ACPC8625 (Slots A-D).
Length: Standard lenght is 2 meters (6.56 feet). Consult factory for
other length. It is recommended that this length be kept to a
minimum to reduce noise and power loss.
Cable: 50 conductors, 28 AWG on 0.050 inch centers (permits
mass termination for IDC connectors), foil/braided shield inside
a PVC jacket.
Connectors: (One End): SCSI-2, 50-pin male connector with
backshell and spring latch hardware. (Other End): IDC, 50-pin
female connector with strain relief.
Keying: The SCSI-2 connector has a “D Shell” and the IDC
connector has a polarizing key to prevent improper installation.
Schematic and Physical Attributes: See Drawing 4501-758.
Electrical Specifications: 30 VAC per UL and CSA (SCSI-2
connector spec.’s). 1 Amp maximum at 50% energized
(SCSI-2 connector spec.’s).
Operating Temperature: -20°C to +80°C.
Storage Temperature: -40°C to +85°C.
Shipping Weight: 1.0 pound (0.5Kg), packed.
TERMINATION PANEL: MODEL 5025-552
Type: Termination Panel For Carrier Boards
Application: To connect field I/O signals to the Industrial I/O Pack
(IP). Termination Panel: Acromag Part 4001-040 (Phoenix
Contact Type FLKM 50). The 5025-552 termination panel
facilitates the connection of up to 50 field I/O signals and
connects to the TRANS-C200 transition module via a cable
(Model 5028-187). Field signals are accessed via screw terminal
strips. The terminal strip markings on the termination panel (1-
50) correspond to P2 (pins 1-50) on the Industrial I/O Pack (IP).
Each Industrial I/O Pack (IP) has its own unique P2 pin
assignments. Refer to the IP module manual for correct wiring
connections to the termination panel.
Schematic and Physical Attributes: See Drawing 4501-464.
Field Wiring: 50-position terminal blocks with screw clamps. Wire
range 12 to 26 AWG.
Connections to TRANS-C200 Transition Module: P1, 50-pin male
header with strain relief ejectors. Use Acromag 5028-187 cable
to connect panel to TRANS-C200 transition module. Keep
cable as short as possible to reduce noise and power loss.
Mounting: Termination panel is snapped on the DIN mounting rail.
Printed Circuit Board: Military grade FR-4 epoxy glass circuit board,
0.063 inches thick.
Operating Temperature: -40°C to +100°C.
Storage Temperature: -40°C to +100°C.
Shipping Weight: 1.25 pounds (0.6kg) packed.
CompactPCI TRANSITION MODULE: MODEL TRANS-C200
Type: Transition module for ACPC8625 board.
Application: To repeat field I/O signals of IP modules A through D
for rear exit from CompactPCI card cages. This module is
available for use in card cages which provide rear exit for I/O
connections via 80 mm wide transition modules (transition
modules can only be used in card cages specifically designed
for them). It is a double-height (6U), single-slot modulewith front
panel hardware adhering to the CompactPCI bus mechanical
dimensions and IEEE Standard (1101.11-1998), for 80 mm
depth. Connects to Acromag termination panel 5025-552 from
the rear of the card cage, and to ACPC8625 boards within card
cage, via connectors P4 and P5.
Schematic and Physical Attributes: See Drawing 4501-791.
Electrical Specifications: 30 VAC per UL and CSA (SCSI-2
connector spec.’s). 1 Amp maximum at 50% energized
(SCSI-2 connector spec.’s).
Field Wiring: Four SCSI-2, 50-pin female connectors (AMP
787082-5 or equivalent) employing latch blocks and 30 micron
gold in the mating area (per MIL-G-45204, Type II, Grade C).
Connects to Acromag termination panel 5025-552 from the rear
of the card cage via round shielded cable (Model 5028-187).
Connections to ACPC8625: Connections are made though the PC
board connectors P4 and P5 (right-angle female connector, 110
contacts with upper shield. The transition module plugs directly
behind the ACPC8625 board into the CompactPCI bus
backplane within the card cage system.
Mounting: Transition module is inserted into a 6U-size, 80 mm
width slot at therear of the CompactPCI bus card cage.
(Directly behind ACPC8625 board)
Printed Circuit Board: Eight-layer, military-grade FR-4 epoxy glass
circuit board, 0.063 inches thick.
Operating Temperature: -40°C to +85°C.
Storage Temperature: -40°C to +85°C.
Shipping Weight: 1.25 pounds (0.6Kg) packed.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 14 -
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 15 -
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

INDUSTRIAL I/O PACK SERIES ACPC8625 CompactPCI BUS CARRIER BOARD
___________________________________________________________________________________________
- 16 -
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

______________________________________________________________________
TRANSITION MODULE: MODEL TRANS-C200
______________________________________________________________________
Type: Transition Module For ACPC8625 Boards
The TRANS-C200 transition module plugs into the rear backplane directly behind the carrier board. The field I/O
connections are made through the backplane to J4 and J5 connectors of the carrier board and then routed to four
SCSI-2 connectors on the transition module (marked IP module slots “A through D”) for rear exit from the card
cage. It is available for use in CompactPCI bus card cages which provide rear exit for I/O connections via
transition modules (transition modules can only be used in card cages specifically designed for them). It is a
double-height (6U), single-slot module with front panel hardware adhering to the CompactPCI mechanical
dimensions and IEEE Standard (1101.11-1998), with a printed circuit board depth of 80mm, which is a standard
transition module depth. The transition module connects to Acromag Termination Panel (Model 5025-552) using
SCSI-2 to Flat Ribbon Cable, Shielded (Model 5028-187) to the rear of the card cage, and to ACPC8625 boards
within the card cage.
Application........................................................... To repeat field I/O signals of IP modules A through D for rear
exit from CompactPCI card cages.
Schematic and Physical Attributes...................... See Drawing 4501-791 (Over).
Electrical Specifications....................................... 30 VAC per UL and CSA (SCSI-2 connector spec.’s).
1 Amp maximum at 50% energized (SCSI-2 connector spec.’s).
Field Wiring.......................................................... Four SCSI-2, 50-pin female connectors (AMP 787082-5 or
equivalent) employing latch blocks and 30 micron gold in the
mating area (per MIL-G-45204, Type II, Grade C). Connects to
Acromag termination panel 5025-552 from the rear of the card
cage via round shielded cable (Model 5028-187).
Connections to ACPC8625...................................Connections are made though the PC board connectors J4
(110 signals, female right angle with upper ground shield-keyed)
and J5 (110 signals, female right angle with upper ground shield).
The transition module plugs directly behind the ACPC8625 board
into the CompactPCI bus backplane within the card cage system.
Mounting.............................................................. Transition module is inserted into a 6U-size, 80 mm width slot at
the rear of the CompactPCI bus card cage.
(Directly behind ACPC8625 board)
Printed Circuit Board........................................... Eight-layer, military-grade FR-4 epoxy glass circuit board, 0.063
inches thick.
Operating Temperature....................................... -40°C to +85°C.
Storage Temperature.......................................... -40°C to +85°C.
Shipping Weight.................................................. 1.25 pounds (0.6Kg) packed.
ACROMAG INCORPORATED
30765 South Wixom Road
P.O. BOX 437
Wixom, MI 48393-7037 U.S.A.
Tel: [phone]
Fax: [phone]
Copyright 1999 Acromag, Inc., Printed in USA
Data and specifications subject to change without notice
8500-623-B00D012
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
4501-791B
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group is your source for quality
new and certied-used/pre-owned equipment
• FAST SHIPPING AND
DELIVERY
• TENS OF THOUSANDS OF
IN-STOCK ITEMS
• EQUIPMENT DEMOS
• HUNDREDS OF
MANUFACTURERS
SUPPORTED
• LEASING/MONTHLY
RENTALS
• ITAR CERTIFIED
SECURE ASSET SOLUTIONS
SERVICE CENTER REPAIRS
Experienced engineers and technicians on staff
at our full-service, in-house repair center
WE BUY USED EQUIPMENT
Sell your excess, underutilized, and idle used equipment
We also offer credit for buy-backs and trade-ins
www.artisantg.com/WeBuyEquipment
REMOTE INSPECTION
Remotely inspect equipment before purchasing with
our interactive website at www.instraview.com
LOOKING FOR MORE INFORMATION?
Visit us on the web at www.artisantg.com for more
information on price quotations, drivers, technical
specications, manuals, and documentation
Contact us: (888) 88-SOURCE | [e-mail] | www.artisantg.com
SM
View
Instra
