AR-B6050 Quick Manual
1 P/N:220010402-G
AR-B6050 Quick Manual V1.0
1. Main board illustration (Top Side)
JP1 COM1 VGA1
ATX1 COM2 J1
BAT1 SATA2 USB3
SYSFAN1 SATA1 USB1
CN2 CN4 USB2
CN3 JP3 LED1
JP2 LAN1 LVDS1
J7 LAN2 CN1
GPIO1 J6
AR-B6050 Quick Manual
2 P/N:220010402-G
Main board illustration (Bottom Side)
SODIMM1
CF

AR-B6050 Quick Manual
3 P/N:220010402-G
2. Connectors and Jumper Settings
1. JP1: LCD panel driving
voltage selection. 2. ATX1: AT power input
connector. 3. BAT1: CMOS battery holder.
STATUS SETTING
1-2 +3.3V
(Default).
2-3 +5V
PIN SETTING
1 GND
2 GND
3 +12V
4 +12V
CMOS battery holder.
4. SYSFAN1: System DC
Fan connector. 5. CN2: PCI-104 connector. 6. CN3: MINI PCI-E connector.
PIN SETTING
1 GND
2 +12V
3 Fan speed data
PCI-104 connector. MINI PCI-E connector.
7. JP2: Signal SERIRQ
connects to PCI-104 pin
#B1 selection.
8. J7: COM1/2 SELECT RI OR
+12V 9. GPIO1: GPIO connector.
STATUS SETTING
Open Disconnected.
(Default)
Short Connected.
PIN SIGNAL PIN SIGNAL
1 RI#1 2 RI#1_12V
3 +12V 4 RI#1_12V
5 RI#2 6 RI#2_12V
7 +12V 8 RI#2_12V
PIN SETTING PIN SETTING
1 GPIO0 2 +5V
3 GPIO1 4 GPIO7
5 GPIO2 6 GPIO6
7 GPIO3 8 GPIO5
9 GND 10 GPIO4
AR-B6050 Quick Manual
4 P/N:220010402-G
10. COM1: RS232 signal
connector for port #1. 11. COM2: RS232 signal connector for port #2. 12. SATA1: SATA device connector #1.
PIN SETTING PIN SETTING
1 DCD #1 2 DSR #1
3 RX #1 4 RTS #1
5 TX #1 6 CTS #1
7 DTR #1 8 RI #1
9 GND 10 GND
PIN SETTING PIN SETTING
1 DCD #2 2 DSR #2
3 RX #2 4 RTS #2
5 TX #2 6 CTS #2
7 DTR #2 8 RI #2
9 GND 10 GND
SATAdevice connector
#1.
13. SATA2: SATA device
connector #2. 14. CN4: Audio signal connector. 15. JP3:CF MASTER SELECT
SATAdevice connector #2. Audio line out
SET SIGNAL
SHORT MASTER
OPEN SLAVE
16. LAN1: RJ45 connector for
Gigabit Ethernet port #1. 17. LAN2: RJ45 connector for Gigabit Ethernet port #2. 18. J6: Front panel connector.
RJ45 connector for Gigabit
Ethernet port #1.
RJ45 connector for
Gigabit Ethernet port #2.
STATUS SETTING
1-2 Hardware reset
3-4 AT Mode - Short
ATX Mode - Open
5-6 Power Button

AR-B6050 Quick Manual
5 P/N:220010402-G
19. VGA1: D-SUB-15 female
connector for VGA output.
20. J1: CMOS data clear 21. USB3: Internal USB2.0
connector
D-SUB-15 female
connector for VGA
output. SHORT CMOS data clear
PIN SETTING PIN SETTING
1+5V 2 +5V
3USB5- 4 USB6-
5USB5+ 6 USB6+
7GND 8 GND
9GND 10 GND
22. USB1: USB connector 23. USB2: USB connector 24. LED1: System power and
HDD access indicators.
Upper: Port #2.
Lower: Port #1.
Upper: Port #4.
Lower: Port #3.
Green: System power
indicator.
Yellow: HDD access
indicator.
25. LVDS1: LCD panel inverter
power connector. 26. CN1: LCD panel inverter power connector.
PIN SETTING PIN SETTING
1 LCD VDD 2 GND
3 NC 4 NC
5 GND 6 NC
7 NC 8 GND
9 NC 10 NC
11 NC 12 NC
13 NC 14 NC
15 GND 16 O CLK+
17 CLK- 18 GND
19 Data2+ 20 Data2-
21 I2C CLK 22 Data1+
23 Data1- 24 I2C Data
25 Data0+ 26 Data0-
27 NC 28 NC
29 LCD VDD 30 LCD VDD
PIN SETTING
1 +12V
2 +12V
3 GND
4 BKL ON
5 GND
6 Reserved.
AR-B6050 Quick Manual
6 P/N:220010402-G
27. DIMM1: DDR-II SODIMM
Socket. 28. CF1: Type-II compact flash card socket.
DDR-II SODIMM
Socket.
+3.3V CF card only and
UDMA mode supported.
